Pyle PMP58U Quick Manual

DYNAMIC 50 WATT MEGAPHONE
W/ USB FUNCTION
Visit Our Website
Models: PMP58U
QUICK GUIDE
SCAN ME
PyleUSA.com
Megaphone for handheld or shoulder slung use (strap supplied).
Detachable anti-how/ microphone on coiled lead with on-off switch and
volume control. Metal and ABS construction.
Operating instructions
1. When carrying the megaphone on the shoulder, press the (1) press-
to-talk power on-off switch, on the left side of the microphone.
2. When holding the megaphone at the grip, fix the microphone
hanger inlet in the microphone fixing hanger, then press the (2)
press-to-talk power on-off switch back with your index finger.
3. Position the speaker opening mouth rowards the object, and
speak through the microphone mouthpiece. Bring the microphone
mouthpiece close to your lips and speak normally.
4. Turn the sound volume control, on the right hand side of the micro-
phone and adjust the sound level to max without causing howling.
USB FUNCTION INSTRUCTIONS
Plug in the USB device, switch the LOCK button on the left side of
microphone to the top. Now the USB drive is well connected, and the
megaphone will play the first file automatically. From there, you can
choose the one you like and adjust the volume according to the diagram
on the right. When you stop using the disk, please switch the lock
button to the bottom, and then unplug it.
NOTICE:
1. You can play the music on the disk and speak at the same time,
they will not affect each other.
2. If you don't need to speak when you play music, turn off the
volume control, this way it can turn down the noise and save the
battery.
3. Please don't touch the USB device while the indicator light is flashing.
4. The max capacity of the USB device is no more than 6GB, and it
will only identify MP3 format.
OPERATING INSTRUCTIONS OF THE PANEL
Selects the previous track
(Long press decreases the volume)
Pause/Play
(Long press to stop)
Selects the next track
(Long press increases the volume)
Notes
1. Make sure the batteries are inserted correctly, observing correct
polarity.
2. Remove the batteries when the megaphone is not in use for a
long period of time.
3. Drained batteries do not give sufficient volume. Replace the
batteries at regular intervals.
ENGLISH
Shoulder strap
Shoulder pad
adjuster
(2) Press-to-talk switch
Press this switch for
Grip
announcing, when
carrying the megaphone
at the grip.
(1) Press-to-talk switch
Press this switch forannouncing, when
carrying the megaphone on the shoulder.
TO REPLACE BATTERIES
1. Loosen the locking screw
of the battery compartment
cover on the back of the body.
The battery compartment
cover comes off.
2. Insert 8 x type-C (UM-2)
batteries in the battery
case observing correct
polarity.
3. Insert the battery case
with batteries into the
battery compartment of
the megaphone, paying
attention to polarity.
SPECIFICATIONS & FEATURES:
• Projection Range: Up to One Mile
• Modes: Talk And Siren
• For Indoor / Outdoor Use
• Variable Volume Control
• Ergonomic Grip w/ Lightweight Chassis
• USB Input to Play From Flash Drive up to 6GB
• Power: 50 Watts
• Powered by: 8 x C Batteries, Not Included
• Dimensions: Diameter 9" x Length 13 3/4" inches
(22.8 cm x 34.9 cm) (0.75 x 1.14 Ft)
• Weight: 4.38 lbs. (1.98 kg)
Battery compartment cover
Remove this cover to replace
batteries.
Mic fixing
hanger
DC-12V power
supply socket
Talk/Off/Siren
Sound
volume control
To increase volume,
turn counter clockwise.
