Table of Contents Safety Instructions 9. Heat: The appliance should be situated away Introduction from heat sources such as radiators, heat CAUTION Safety Instructions ..............................1 RISK OF SHOCK registers, stoves, or other appliances (including CAUTION .................................. 2 CAUTION: ampli ers) that produce heat. To reduce the risk of electric Shock, Do not remove cover (or back).
Bluetooth networks from your mobile device. The mixer Please check the copyright laws in your country before will appear in the Bluetooth network list as 'PYLE SPEAKER' . recording from records, compact discs, radio,etc. 3. Connect and pair to 'PYLE SPEAKER' Recording of copyrighted material may infringe copyright laws.
Getting Connected Getting Connected Mic with Remote Key Control Ampli er, Mixer and External Sound System Connections Mic(s) connection Music and Vocals The unit's LINE OUT (RCA) jacks can be used to connect to a second power amplifier, an external sound system or mixing device.
Rear Panel Description 9. VIDEO OUTPUT (RCA) jacks: Connect RCA-ended video cables from these jacks to the VIDEO IN on a TV or display device. These are not independent outputs; they both output the same video signal simultaneously. 10. MIC OUTPUT jacks: These jacks output the two mic channels without any music. Connect a paired RCA-ended patch cable from these jacks to the appropriate INPUT jacks on a mixer or vocal effects unit.
Page 6
18. ECHO HI. control: This control increases/decreases the amount of HIGH frequency response applied Remote Control Description during the ECHO effect application. Turn clockwise to increase the HIGH frequency response, and counter-clockwise to decrease the HIGH frequency response. 1. MIC MASTER VOLUME control: Use this to control the 19.
Page 7
Using Digital Key Control Digital Key Control enables you to adjust the key of the source music (CD/DVD player) to t the vocal range of the person who is singing. The key can be adjusted by using the key control buttons on the unit's front panel, the remote control or from a Remote Key Control microphone.
PMXAKB2000 TROUBLESHOOTING 2000 Watt Bluetooth Stereo Mixer Karaoke Ampli er Microphone/RCA Audio/Video Inputs, Mic-Talkover, USB/SD Readers, Rack Mountable Amp PROBLEMS CAUSE SOLUTIONS System Features: Change Input Selector to the • Karaoke / PA Stereo Amplifier No sound coming from Input Selector is set incorrectly correct current playing source •...
