Pyle PMP53IN Quick Manual

MEGAPHONE/BULLHORN
Professional Compact Power Megaphone
QUICK GUIDE
Megaphone for handheld or shoulder·slung use (strap supplied).
Detachable anti-how/ microphone on coiled lead with on-off switch and
volume control. Metal and ABS construction.
Operating instructions
1. When carrying the megaphone on the shoulder, press the (1) press-
to-talk power on-off switch, on the left side of the microphone.
2. When holding the megaphone at the grip, fix the microphone
hanger inlet in the microphone fixing hanger, then press the (2)
press-to-talk power on-off switch back with your index finger.
3. Position the speaker opening mouth towards the object, and
speak through the microphone mouthpiece. Bring the micro-
phone mouthpiece close to your lips and speak normally.
4. Turn the sound volume control, on the right hand side of the micro-
phone and adjust the sound level to max without causing howling.
Adjust the
volume
Notes
1. Make sure the batteries are inserted correctly, observing correct
polarity.
2. Remove the batteries when the megaphone is not in use for a
long period of time.
3. Drained batteries do not give sufficient volume. Replace the
batteries at regular intervals.
SPECIFICATIONS & FEATURES:
• Projection Range: 1200 Yards
• Modes: Talk And Siren
• For Indoor/Outdoor Use
• Variable Volume Control
Model: PMP53IN
TO REPLACE BATTERIES
1. Loosen the locking
screw of the battery
compartment cover
on the back of the
body. The battery
compartment cover
comes off.
2. Insert 8 x type-C
(UM-2) batteries
in the battery case
observing correct
polarity.
3. Insert the battery
case with batteries
into the battery
compartment of the
megaphone, paying
attention to polarity.
• Ergonomic Grip w/ Lightweight Chassis
• Power: 50 Watts
• Powered by: 8 X C Batteries, Not Included
• Dimensions: Diameter 9'' X Length 13 3/4''
• Weight: 4.4 lbs.
