- Page 1 Type IOP 20674-94 X Instruction Manual 2...
-
Page 2: Dear Customer
DEAR CUSTOMER, The oven is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the oven will be easy. Before being packaged and leaving the manufacturer, the oven was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully. -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ....................4 Description of the appliance ...................8 Installation ......................10 Operation ......................12 Baking in the oven – practical hints ..............22 Test dishes.........................25 Cleaning and maintenance ...................27 Troubleshooting ....................31 Technical data.......................32... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning... - Page 5 SAFETY INSTRUCTIONS During the pyrolytic oven cleaning process the oven chamber can reach a very high temperature. Consequently, the appliance outer surfaces can heat up more than usual, so keep children away at all times. Danger of burns! Hot steam may escape when you open the oven door.
-
Page 6: How To Save Energy
HOW TO SAVE ENERGY Using energy in a respon- sible way not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: ● Do not uncover the pan too often (a watched pot never boils!). - Page 7 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...
-
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 1 Control Panel 2 On / off switch... -
Page 9: Specifications Of The Appliance
SPECIFICATIONS OF THE APPLIANCE Oven fittings: Grill grate (drying rack) Roasting tray Baking tray Side racks... -
Page 10: Installation
INSTALLATION Electrical connection Installing the oven The oven is manufactured to work with The kitchen area should be dry and aired a one-phase alternating current (230V and equipped with efficient ventillation. 1N~50 Hz) and is equipped with a 3 x 1,5 When installing the oven, easy access to connection lead of 1.5 mm length all control elements should be ensured. - Page 11 INSTALLATION Mounting scheme with dimensions 5 5 0 4 2 9 m a x 5 7 0 5 9 5 5 9 5 1 0 3 4 5 6 0 6 0 0 5 6 0 5 6 0...
-
Page 12: Operation
OPERATION Before first use Control Panel On/off switch is on the right side of the dis- • Remove all packaging elements, par- play. To activate the On/off switch, touch the ticularly those protecting the interior of glass in the place indicated by a pictogram. the oven chamber during transport. -
Page 13: Control Panel
OPERATION Control Panel The Electronic programmer is equipped with an LED display and 8 touch sensors (the sen- sors are not illuminated): Sensors Description Sensors Description On / off switch (Standby mode) Clock setting Oven functions Plus / up [+] Pre-set programmes minus / down [–] Temperature of the setting... - Page 14 OPERATION Active functions* door is locked for any other reason), the oven will start the cooling and door opening proce- dure before you can set the time. Meat probe connected Set the current time Lighting on When you connect the appliance to the AutoDoor Open power supply, the hour flash on the dis-...
- Page 15 OPERATION any function is activated. The cooling fan Oven functions operates as long as the oven cavity tem- perature exceeds 80°C. Below this tem- When the appliance is on, touch to access perature, the cooling fan turns off. the oven functions menu – the oven function marked “1”...
- Page 16 OPERATION Pizza √ √ √ √ Roasting √ √ Defrosting √ √ Steam Cleaning* √ Pyrolytic cleaning* √ * depending on model Note: When use do not use any sensors in oven function menu for 10 seconds, the appliance will exit the menu and any unconfirmed settings will be lost. Child Lock When and oven function is active.
- Page 17 OPERATION any sensor to mute the beeping. the display. Touch the sensor again, the display will show the symbol. Now you can: Preview and modify settings during oven operation to set the duration and touch confirm. Touch once to check the temperature inside to adjust the time settings.
- Page 18 OPERATION will hear beeping. Touch any sensor to mute most suitable for a given dish. When the ap- the beeping. When the beeping is muted the pliance is on, touch to access the pre-set appliance enters the operation mode. programmes menu – the pre-set programme “P01”...
- Page 19 OPERATION All pre-set programmes can be freely modi- the active settings are unaffected. For safety fied – you can adjust temperature or duration. reasons, after this time, the oven enters the To do this, follow the relevant instructions standby mode (all settings are cleared). (“Preview and modify settings during oven operation”...
- Page 20 OPERATION the handle for at least 0.5 second. The sen- • Before using this function, read the sitivity of the handle allows you to open the chapter on cleaning, in particular the door with your hand or a covered part of the basic information on the pyrolytic body, e.g.
-
Page 21: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking ● we recommend using the baking trays which were provided with your cooker; ● it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;... - Page 22 BAKING IN THE OVEN – PRACTICAL HINTS ECO Heating ECO Heating an optimised heating function designed to save energy when preparing food. You cannot reduce the cooking time by setting a higher temperature; preheating the oven is not recommended. Do not change the temperature setting and do not open the oven door during ...
- Page 23 BAKING IN THE OVEN – PRACTICAL HINTS Type of Type Temperature Level Time dish of heating °C) (min.) Sponge cake 160 - 200 2 - 3 30 - 50 Yeast cake/ 160 - 170 25 - 40 Pound cake Yeast cake/ 155 - 170 25 - 40 Pound cake...
-
Page 24: Test Dishes
TEST DISHES. According to standard EN 60350-1. Baking Type of dish Accessory Level Type Temperature Baking of heating time (min.) Baking tray 28 - 32 Baking tray 23 - 26 Baking tray 26 - 30 Small cakes 2 + 4 Baking tray 2 - baking tray 27 - 30... - Page 25 TEST DISHES. According to standard EN 60350-1. Grilling Type of dish Accessory Level Type Temperature Time of heating (min.) Wire rack 1,5 - 2,5 White bread toast Wire rack 2 - 3 Wire rack + 4 - wire rack roasting tray 1st side 10 - 15 Beef burgers 3 - roasting...
-
Page 26: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and mainte- Wire shelf supports nance of your oven you can have a significant influence on the continuing fault-free opera- Oven is equipped with easily removable wire tion of your appliance. shelf supports. To remove them for cleaning use size 3 Allen key to undo the fixing screws Before you start cleaning, the oven must from shelf support holders Once cleaned,... - Page 27 CLEANING AND MAINTENANCE Important! Pyrolytic cleaning During pyrolytic cleaning, the oven chamber can reach a very high temperature. Oven pyrolytic self-cleaning. The oven heats Consequently, the outer oven surfaces can up to a temperature of about 480°C. Grilling heat up more than usual, so keep children or baking residue is burnt into an easy to away at all times.
- Page 28 CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Using a cross-head screwdriver undo the screws in the upper door slat (fig. B). In order to obtain easier access to the oven 2. Using a flat screwdriver remove the chamber for cleaning, it is possible to remove upper door slat, prying it gently on the the door.
- Page 29 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat Replacing the halogen bulb in the oven (in the lower section of the door). Important! Risk of damage to glass Before replacing the halogen bulb, make panel mounting. Do not lift the glass sure the appliance is disconnected from panel up but pull it out.
-
Page 30: Troubleshooting
TROUBLESHOOTING In the event of any fault: • turn off the appliance, • disconnect the power supply, • based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer service. -
Page 31: Technical Data
TECHNICAL DATA Voltage rating 230V~50 Hz Power rating max. 3,6 kW Cooker dimensions H/W/D 59,5 / 59,5 / 57,0 cm The product meets the requirements of European standards EN 60335- 1; EN60335-2-6. The data on the energy labels of electric ovens is given according to standard EN 60350-1 / IEC 60350-1. - Page 32 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S Gejlhavegård 2B DK-6000 Kolding +45 73 20 10 00 www.gram.dk IO-CBI-1277 / 8506313 (11.2022 V6)
