Blue Torrent MyBot Instructions Manual page 6

GENERAL OPERATING INSTRUCTIONS
Take a moment to get familiar with the CLEANER using the figure on page 9.
Throughout this manual reference to this figure is made when referring to different
components of the CLEANER.
Remove the CLEANER by placing the carton down and removing
it from the box.
1. The control box must be fixed at a minimum distance of 11 ft. from the edge of the
swimming pool and minimum 8 ft. overtop of top edge of pool (outside Zone 1 defined
in IEC 60364-7-702). Never operate the unit without fixing the control box first. The length
of the standard CLEANER cable is 60 feet.
2. Connect the floating cable to the power supply control box. Use only the original Power
Supply manufactured by Blue Torrent. Connect the floating cable to the control box.
Make sure they are connected correctly. (The fitting on the cleaner floating cable should
be connected with the control box by turning it the clockwise direction).
3. Place the CLEANER in the pool. It will slowly sink to the bottom of the pool as the air
inside is released. (Do not use cable to lower into pool)
4. Connect the power supply to the GFCI protected outlet and switch it on. The CLEANER
will run according to the procedures set to do the cleaning cycle. CAUTION - DO NOT
switch on CLEANER when the CLEANER is out of water. This may result in damage to
the pump and drive motor seals, which will VOID the warranty.
6
Minimum 11 Feet
1
Power Supply
Connector
Floating Cable
2
