- Page 1 THE STINGER ROBOTIC POOL CLEANER FOR ABOVEGROUND POOLS Congratulations on purchasing a Stinger Robotic Pool Cleaner. You have made an excellent choice. 10144...
- Page 2 READ THESE IMPORTANT OPERATING TIPS BEFORE USING YOUR UNIT Thank you for choosing a robotic pool cleaner. In order to achieve optimal performance, please read and follow these steps: 1. Cleaner filter bags should be thoroughly cleaned after each use or as often as needed to ensure cleaner’s optimal performance.
-
Page 3: Important Safety Precautions
CAUTION 1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Risk of electrical shock or electrocution DANGER The electrical supply to this product must be installed in accordance with all applicable local codes and ordinances. Improper installation will create an electrical hazard which could result in death or serious injury to pool users or others due to electrical shock, and may also cause damage to property. -
Page 5: General Information
GENERAL INFORMATION Congratulations! You have got the most advanced automatic swimming pool cleaner. The Stinger is easy to use, and will help you clean your swimming pool. Operated according to this manual, your robot will clean your pool quickly and effectively. - Page 6 3. Connect the floating cable to the power supply control box. Use only the original Power Supply manufactured by Blue Torrent. Connect the floating cable to the control box as follow photo. Make sure they are connected correctly. (The fitting on the...
- Page 7 a. To turn the power supply ON, press and release the power button once. Then select the cycle mode you need, after 5 seconds, press START again. b. To turn the power supply OFF, press and release the power button. Light will turn OFF. c.
- Page 8 THE STINGER ROBOTIC POOL CLEANER PARTS...
- Page 9 THE STINGER ROBOTIC POOL CLEANER PARTS PART # MODEL # DESCRIPTION AC 20362 Stinger Cover Assembly AC 20362 Stinger Cover Assembly AC 20362 Stinger Cover Assembly AC 20362 Stinger Cover Assembly AC 20362 Stinger Cover Assembly AC 20362 Stinger Cover Assembly...
-
Page 10: Maintenance
DIRECTIONAL ANGLE ADJUSTMENT • The cleaner has two outlets and the direction angle of each outlet is adjustable during running. If the Directional Angle adjustment angle is not satisfying, stop the cleaner, unscrew the screw as shown in the figure, manually adjust to a proper position (angle dimension: 0 <... - Page 11 • Remove filter basket from inside cleaner • Use a garden hose to clean filter bag • Filter cleaning solution can be used to remove excessive dirt and/or sand. • Remember: The cleaner your filter is, the more efficient the CLEANER will perform. •...
-
Page 12: Cable Care
STORAGE • When out of the water, store the CLEANER in a dry, shady location at temperatures between 40ºF — 80ºF. CABLE CARE • With continued use, the cable may become coiled (like a telephone cord). To correct this, periodically stretching the cord out in the sun should remove any cord twists. IMPORTANT: The cable should be checked periodically for any external damage. -
Page 13: Troubleshooting
TROUBLESHOOTING If CLEANER fails to pick up fine or heavy debris: • Clean the filter bags. It may be clogged. A filter cleaning solution can be used to remove excessive dirt and/or sand. If CLEANER starts working momentarily but then stops working: •... -
Page 14: Preventative Maintenance
SAVE THESE INSTRUCTIONS 1. ALWAYS PUT THE CLEANER INTO THE WATER BEFORE CONNECTING IT TO THE ELECTRICAL OUTLET. 2. IT IS IMPORTANT FOR SWIMMERS’ SAFETY TO REMOVE THE UNIT IMMEDIATELY FOLLOWING USE. THIS CAN ALSO IMPROVE THE OPERATING LIFE OF YOUR CLEANER. 3. -
Page 15: Year Limited Warranty
• Customer must retain the original sales invoice as proof of purchase along • Commercial facilities are not covered by warranty Please return any and all defective items to your local authorized Blue Torrent dealer for inspection. The customer is responsible for all shipping charges to and from the nearest Factory Warranty Center.
