AMX NOVARA CP-3008 ControlPad Installation Manual

Overview
The Novara CP-3008 ControlPad (FG1302-08) (FIG. 1) with built-in Ethernet port
combines a controller with an easy to use 8-button keypad that mounts onto a
standard two gang US, UK, or EU back box. The ControlPads are configured using the
NOVARA DCS (Device Configuration Software) software application, available for
download from www.amx.com. Refer to the NOVARA 3000 Series ControlPads &
KeyPads Operation/Reference Guide (available at www.amx.com) for configuration
instructions. The CP-3008 ControlPad can be configured to control volume, input
selection and power for a wide range of A/V devices.
The ControlPad connects to AMX's Resource Management Suite® (RMS) which
enables web-based remote diagnostics and management through the built-in Ethernet
Port. The ControlPads are available in Black, White, and Brushed Aluminum finishes.
FIG. 1
Novara CP-3008-BA ControlPad
Product Specifications
NOVARA CP-3008 ControlPad Specifications
Power Requirements: • Min: 121mA@12 V
• Max: 320mA@12 V
• Using a non-PoE power supply operates on voltages
ranging from 9V to 16V continuously.
Button Layout: • 8 red, green, and blue backlit buttons with
programmable feedback
• Pressable volume knob
• Volume indicator
Colors: • Aluminum: FG1302-08-A
• Black: FG1302-08-B
• White: FG1302-08-W
Rear Panel • Power - 1 2-pin Phoenix connector accepting 12V
Connectors:
power
• Serial - 2 3-pin Phoenix connectors for RS-232
connections.
Input voltage: V
Output voltage: V
V < -5.0 V
OL
• IR - 2 2-pin Phoenix connectors for IR emitters.
Supports generating carriers up to 1.142 MHz. Output
only port.
Output voltage:
V
OH
V
OL
• I/O - 1 4-pin Phoenix connector for I/O connections.
Supports sensing contact closure.
Input voltage:
HIGH (no contact closure): V
LOW (contact closure): V
Output voltage:
V
OH
pull-up resistor)
V
OL
current)
• Relay - 1 4-pin Phoenix connector for relay connections
capable of switching 24 V
28V
AC
• LAN - 1 RJ-45 connector for LAN connectivity.
• Reset - 1 pinhole pushbutton for factory reset.
Supported Baud Up to 115200
Rates:
Dimensions (HWD): 4 11/16" x 6" x 1 3/4" (including knob)
(11.9cm x 15.2 cm x 4.5 cm)
Weight: 0.863 lbs (0.392 kg)
DC
DC
> +2.7 V , V < -2.7 V
IH DC IL DC
> +5.0 V @ 35 mA maximum,
OH DC
@ 35 mA maximum
DC
= +3.3 V +/- 0.3 V @ 13 mA maximum
DC DC
= 0 V +/- 0.3 V @ 13 mA maximum
DC DC
> 2.5 V
IH DC
< 0.8 V
IL DC
= +3.3 V +/- 0.3 V (internal 25k Ohm
DC DC
= 0 V +/- 0.3 V (200 mA maximum sink
DC DC
@ 1A maximum or
DC
@ 1A maximum
NOVARA CP-3008 ControlPad
NOVARA CP-3008 ControlPad Specifications (Cont.)
Operating
Environment:
Included Accessories:
Other AMX Equipment: • CP-RMS, RMS Gateway Module (FG1310-01)
Certifications:
Mounting Specifications
CP-3008 8-button keypads mount onto standard 2 gang US, UK, or EU back boxes.
FIG. 2 displays the dimensions for the CP-3008 ControlPad.
FIG. 2
CP-3008 dimensions
Wiring and Connections
Power
The CP-3008 features a 2-pin Phoenix connector accepting 12V
DC
Power Supply
FIG. 3
Power Supply wiring
Serial Connectors
The CP-3008 features two RS-232 connector ports so you can connect up to two
serial devices to the ControlPad. The serial connectors comply with EIA-232-F signal
levels.
RX
TX
GND
External Device
FIG. 4
Serial Connector wiring
IR Connectors
The CP-3008 features two IR connector ports so you can connect up to two
IR-controllable devices to the ControlPad. The IR/Serial connector wiring
specifications are listed in the following table:
IR Connector Wiring Specifications
IR connections
FIG. 5
IR port
WARNING: Do NOT connect a power connector to either IR port. Doing so may
damage the ControlPad.
Installation Guide
• Storage temperature range: 14° - 140° F (-10° - 60° C)
• Operating temperature range: 32° - 104° F (0° - 40° C)
• Relative humidity: 5% to 85%, non-condensing
• Power Supply, 90-240VACIN, 12VOUT, 500MA
(24-5791-SA)
• Pre-printed labels (40-0087)
• CC-NIRC, NetLinx IR Emitter (FG10-000-11)
FCC Class B, CE, UL, CB Scheme
ControlPad
ControlPad
Signal Function
1 GND (-) Signal GND
Signal 1 (+) IR data
2 GND (-) Signal GND
Signal 2 (+) IR data
power.
DC
+12V
DC
GND
TX
RX
GND
