- Page 1 Instruction Manual Poweroyal Triplex X Reciprocating Pump- Low and Medium Pressure Liquid End MR.ENG.PTX.LP.08/2014...
- Page 2 Preface Welcome to become one of the users of Milton Roy Industrial (Shanghai) Co., Ltd ( Hereinafter referred to as MRIS) and thank you for your choice of Milton Roy products. MRIS aims to provide metering pumps, high-pressure reciprocating plunger pumps, mixers and other equipment with reliable performance, high technique and complete series for customers.
-
Page 3: Safety Warning
Safety Regulations Safety Warning MRIS carries out the design, manufacture, inspection and assembly of reciprocating plunger pumps in strict accordance with the International Quality Management System Standard (ISO9001-2000) approved and audited by UK BSI certification authority. All parts are manufactured by professional companies approved by MRIS and inspected, assembled and tested strictly at MRIS to ensure the quality and performance of pumps. -
Page 4: Table Of Contents
Table of Contents Chapter 1 Instruction …………………………………………………………………………………………… 1 Unpacking and storage ……………………………………………………………………………………………… 1 General ………………………………………………………………………………………………………………… 1 Operation principle of drive end ……………………………………………………………………………………… 2 Operation principle of hydraulic end ………………………………………………………………………………… 4 Operation safety guidance …………………………………………………………………………………………… 4 Chapter 2 Installation …………………………………………………………………………………………… 5 Equipment base requirement …………………………………………………………………………………………... -
Page 5: Chapter 1 Instruction
Chapter 1 Instruction 1.1 Unpacking and storage Unpacking During receipt of products, the package must be checked carefully to ensure no package damage. At the same time, check the number of the nameplate according to the packing list and the purchase order to ensure that the pump is supplied correctly. -
Page 6: Operation Principle Of Drive End
please read this Operation Manual carefully before installation and commissioning of the pump. If anything herein cause any doubt or if further information is expected, please contact MRIS After-Sales Department or your local authorized dealer. PTA series high-pressure reciprocating pump is designed according to continuous operating mode of in- dustry. - Page 7 Figure 1: Drive End Cutaway Chart...
-
Page 8: Operation Principle Of Hydraulic End
1.4 Operation principle of hydraulic end The crosshead of the pump connects the plunger and drive end together, so the pump has a consistent reciprocating linear stroke. During the suction stroke, the drawing action of the plunger generates certain space of vacuum, which absorbs corresponding volume of liquid into the pump cavity through the suction valve unit;... -
Page 9: Chapter 2 Installation
Chapter 2 Installation 2.1 Equipment base requirement Due to periodical imbalanced inertial force and inertia moment of the equipment that will load on the base, the base shall employ firm support and the concrete that can absorb the normal strain or vibration. ●... -
Page 10: Suction Pipeline
● When installing suction and discharge pipelines, a section of detachable pipe shall be kept for conve- nience of easy maintenance. Suction pipeline Install a filter with a mesh no less than 50. The more sophisticated filter may be required in specific ap- plication. -
Page 11: Leakage Collection
centerline (E. g. the pressure generated by the difference in height between the liquid surface of container and the pump centerline). Any system without a high enough allowable NPSHa value will result in pump cavitation. The common manifestation of cavitation involves noise, metal surface erosion and system vibration. Cavitation occurs when pump suction pressure lowers and approximates to the saturated vapor pressure of the medium that varies along with the changes of temperature. -
Page 12: Chapter 3 Starting
Chapter 3 Starting 3.1 Preliminary preparation before starting During operation, special attention must be paid to the impact of certain transferred chemicals (acid, al- kaline, oxidizing, reducing solution, and so on) on the environment. ● Check whether electric connection is completed as required. ●... - Page 13 3.3 Inspection and maintenance of operation record sheet ● Inspection record is dependent on service condition of the equipment. Therefore, the following inspec- tion cycles only serve as reference for daily operation and maintenance of users. ● Individual customers shall arrange the record for each phase based on their own service. Time Inspection Maintenance...
-
Page 14: Inspection And Maintenance Of Operation Record Sheet
Maintenance Record Pump Model: Contract No: Transferred Liquid: Solution Date Operation Period Remarks Sample Sheet of Maintenance Records... -
Page 15: Chapter 4 Routine Maintenance
Chapter 4 Routine Maintenance 4.1 Oil Change Protective gloves must be prepared to avoid the burn risk of hot oil. ● After the initial 300h run, replace oil for the first time. After that, replace oil per 4000h or once every six months. -
Page 16: Packing Change
4.2 Packing change V-ring packing of special material is very durable, usually serving for more than one year in case of con- veying clean medium. However, as for preventative maintenance, it is recommended to replace the packing and suction and outlet valves every year. During packing changing, there is no need to disassemble the pump head or pipeline but to take down the stuffing box from the middle section of the drive box body. - Page 17 ed(such as the sharp rise in temperature, etc.), shut down the equipment for examination. ● Regularly check the pump flow. Check whether its is in line with the requirement and whether it con- forms to the number of the nameplate.
-
Page 18: Chapter 5 Failure Analysis
Chapter 5 Failure Analysis Failure Type Failure Course Solution Power Problem Check the power supply situation Thermal relay fails Repair the thermal relay Motor does not work Motor has defects Replace the motor Wiring has defects Re-wiring One phase of the motor is not properly Re-wiring connected Power supply and the motor does not... - Page 19 Failure Type Failure Course Solution Ensure the oil level in the fuel Incorrect amount of lubricating oil tank meets the requirements High temperature of the housing at drive end Ensure the oil brand/grade in the Incorrect brand/grade of lubricating oil fuel tank meets the requirements Worn bearing Replace the worn bearing...
- Page 20 Failure Type Failure Course Solution Make sure the pump is used in Suction valve opening is small the correct operating conditions Make sure the pump is used in Liquid viscosity is too high the correct operating conditions Fully exhaust the residual gas in Pump cavity has residual gas the pump cavity Packing has leakage...
-
Page 21: Chapter 6 Periodical Maintenance
Chapter 6 Periodical Maintenance 6.1 On normal conditions Periodically examine and replace the quick-wear components in the accessory bag. Please refer to Chapter 8 and 9 for specific operations: Maintenance of Drive End & Maintenance of Hy- draulic End 6.2 Maintenance cycle ●... - Page 22 ● Information about spare parts: part number, part name and quantity. All parts information can be found in the List of Goods enclosed in the goods package. Standard Nameplate...
-
Page 23: Chapter 7 Shutdown
Chapter 7 Shutdown Cut off the electrical power supply, the pump will stop running. ● After shutdown, first close the inlet line valve and then close the discharge line valve. ● Long-term shutdown (more than three months). If the pump needs stop running more than three months, following operations shall be carried out after the shutdown: -Exhaust fully the lubricating oil, if necessary, anti-rust oil may be used for rust protection;... -
Page 24: Chapter 8 Maintenance Of Drive End
Chapter 8 Maintenance of Drive End Note: ● In order to have a concise description, the following sections shall not have such descriptions as plac- ing the gasket on the fasteners (such as bolts and nuts). Please do not forget these parts. ●... -
Page 25: Disassembly/Assembly Of Cover Plate
8.1 Disassembly/Assembly of Cover Plate Assembly Drawing of PTX Cover Plate Version:00 Disassembly Assembly Location Torque 1. Unscrew the screws[01] [09] [11]. Place the gasket [05] [06]into the housing after lu- 2. Remove the cover plate[04] [07] [10]. bricating grease has been applied to it. 3. -
Page 27: Disassembly/Assembly Of Crankshaft
8.2 Disassembly/Assembly of Crankshaft PTX Crankshaft/low speed gear assembly drawing Version:00 Disassembly Assembly Location Torque 30 N · m [04] 30 N · m [01] 1. Unscrew the screw[01]. Place the crankshaft with hot jacket, gear assem- 2. Remove the end cap [02] of the crankshaft bly [08] into the housing. -
Page 29: Disassembly/Assembly Of High-Speed Shaft / Rod Cap
8.3 Disassembly/Assembly of High-Speed Shaft / Rod Cap PTX high speed shaft / rod cap assembly drawing Version:00 Disassembly Assembly Location Torque 90 N · m [01] 30 N · m [13] 1. Remove the screw [01], washer [02]. Mount the bearing bush [04] in the connecting 2. -
Page 31: Disassembly/Assembly Of Connecting Rod / Crosshead
8.4 Disassembly/Assembly of Connecting Rod / Crosshead PTX Connecting Rod / Crosshead Assembly Drawing Version:00 Disassembly Assembly Location Torque 1. After completion of the disassembly of Mount the bearing bush [01] and the small head above mentioned cover plate, crankshaft, copper bush [03] to the rod body [02]. -
Page 33: Disassembly/Assembly Of Crosshead Seal And Plunger Rod
8.5 Disassembly/Assembly of Crosshead Seal and Plunger Rod PTX Crosshead Seal and Plunger Rod Assembly Drawing Version:00 Disassembly Assembly Location Torque 200 N · m [10] 1. Unscrew the plunger’ s fastening nut [10], Mount the crosshead sealing ring [02] [05], the and push toward the head direction, then crosshead sealing check ring[01] [06] and the plunger[11] and crosshead can be separat-... -
Page 35: Chapter 9 Maintenance Of Hydraulic End
Chapter 9 Maintenance of Hydraulic End 9.1 General Note: ● For simplicity, the following sections will have no such description as placing gasket on the fasteners (such as bolts and nuts). Do not forget these parts ● Replace the seal rings every time of maintenance. Tips: Special attention must be paid to the transferred chemicals (acidic, alkaline, oxidizing, reducing solu- tion, etc. -
Page 36: Disassembly/Assembly Of Pump Head And Packing Box Components
9.1 Disassembly/Assembly of Pump Head and Packing Box Components PTX Pump Head and Packing Box Components Assembly Drawing Version:00 Disassembly Assembly Location Torque 95 N · m [03] 195 N · m [26] Replace the disassembly sequence of packing Install RSK or WQ packing rings [06] to the pack- ing gland [08] in sequence. -
Page 38: Disassembly/Assembly Of Connecting Flange
9.2 Disassembly/Assembly of Connecting Flange PTX Connecting Flange Assembly Drawing Version:00 Disassembly Assembly Location Torque 90 N · m [01] 160 N · m [08] 1. Unscrew the hexagon nuts[01]. Place O-Ring[13], seal ring’ s check rings[12] to 2. Remove the inlet blank flange and the inlet flange assembly[11] and outlet blind side flange flange assembly as illustrated in the Figure. -
Page 40: Disassembly/Assembly Ofinlet/Outlet Valve
9.3 Disassembly/Assembly of inlet/Outlet Valve PTXPump Head and Packing Box Components Assembly Drawing Version:00 Disassembly Assembly Location Torque 105 N · m [01] 1. crew the hexagon nuts [01]. The valve spring [09] [15] and valve[10] [16], that 2. Remove the valve’ s pressing plate [04]。 respectively according to the discharge valve 3. - Page 42 Milton Roy IndustrialShanghaiCo.,Ltd. Building1,No.879 Shen Fu Road,Shanghai China201108 Tel86 21 61211600Fax86 21 61215265/66 www.miltonroy.com.cn...
