Page 1: Table Of Contents
Audi MMI 2G HIGH Quick User Guide Model No : P2000-2G26ML A6/C7 A8/D3 Q7/4L Model No : P2000-2G20ML A4/B8 A5/8T 1 - All you need to know before Installation 2 - Product Features 3 - Main Feature Operations 4 - Car Settings 5 - USB Supported Formats &... -
Page 2: All You Need To Know Before Installation
1 - All you need to know before Installation Mr12volt interface emulates CD changer function of a Audi MMI radio and is connected through MOST bus of its function. once successfully installed, Mr12volt appears in CD7. ( Picture illustrated above) ... -
Page 3: Product Features
2 - Product Features CarPlay Android Auto Mirroring Music & Video Playback ( Through USB Flash ) Bluetooth HF & Music Streaming Reverse Camera Input ( Support up to AHD720P ) Front Camera Input ... -
Page 4: Main Feature Operations
3 - Main Feature Operations CarPlay/Android Auto Support both Wired and Wireless CarPlay Connection To connect to CarPlay Wirelessly, both Bluetooth and Wi-Fi connection are required For Wired CarPlay & Android Auto : Use Genuine cable to connect through the USB connector. -
Page 5: Android Phone
2. Enter Mirroring menu on Car display and Choose “Android” 3. Network name & Password on phone must be set same as shown on Mr12volt “Mirroring” menu 4. Open MLink app-->turn on Bluetooth and Hotspot 5. When both Bluetooth and Hotspot are successfully connected, Phone display will appear on Car Display ... - Page 6 Mr12volt Does not support the integration of OEM microphone even with the installation of a Y-cable. if you need to use Mr12volt HF or Voice Command such as SIRI, the 3.5mm jack microphone supplied in the package must be installed.
-
Page 7: Car Settings
4 - Car Settings Car Setting “Reverse Camera” settings OE Camera (Default) - Select this when car is fitted with factory camera AfterMarket 360 - Select this when car is installed with a aftermarket camera ( support up to AHD720 only) “Reverse condition”... - Page 8 When do i select “Reverse State” ? Mr12volt detects Car CAN bus with most of the car models in the market, however in some cases particularly in older generation cars, when a CAN bus can’t be detected, it is necessary to manually detect camera through car reverse light signal.
-
Page 9: Usb Supported Formats & Other Specs
“Reverse track” - Option to turn ON or OFF of a Parking Grid (For AfterMarket camera only) “Reverse radar” - Option to turn ON or OFF of a Reverse Sensor (For AfterMarket Reverse sensor only) 5 - USB Supported Formats & Other Specs Music and Video Playback File Format ... -
Page 10: Faq
Mr12volt instead of the microphone in the package. ? A: NO, Mr12volt Does Not support the integration of OEM microphone even with the installation of a Y-cable. if you need to use Mr12volt HF or Voice Command such as Siri, the 3.5mm jack microphone supplied in the...
