  • Page 1 Manual Reactor R5...

  • Page 2: Table Of Contents

    Table of contents Safety instructions ..........................3 1.1. For safe and efficient operation ....................3 Designated use ..........................4 2.1. Overhead installation ....................... 5 Introduction ............................7 3.1. Product overview ........................7 Connections ............................. 8 4.1. Electrical connections ......................8 4.2.

  • Page 3: Safety Instructions

    1. Safety instructions • This device is suitable for indoor use (not outdoors) only device is suitable for indoor use (not outdoors) only. • All modifications to the device will void the warranty. All modifications to the device will void the warranty. •...

  • Page 4: Designated Use

    2. Designated use This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use. Regular breaks during operation increase the lifetime of your device. Avoid convulsions or any form of forceful impact during the installation or the start-up of the device.

  • Page 5: Overhead Installation

    2.1. Overhead installation Overhead installation Danger of life! Danger of life! You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and EN60598-2-17 17 Installations are to carry out by skilled personnel only.
  • Page 6 The maximum drop exceed must not exceed 20cm. A safety rope once exposed to failing load or damaged may not be used furthermore. Adjust the desired inclination angle via the mounting bracket and tighten the screw. 6 / 18...

  • Page 7: Introduction

    3. Introduction Thank you for buying the Reactor R5. It is a powerful device. For a successful installation and operation, please read this manual carefully. 3.1. Product overview 7 / 18...

  • Page 8: Connections

    4. Connections 4.1. Electrical connections If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected. Cable (EU) Cable (US) International Brown Black...

  • Page 9: Control

    5. Control To get to the main menu, press MENU. You are now in the main menu. You can select the menu items by using the UP / DOWN keys. When the function appears, you want to change, press the ENTER button.
  • Page 10 Total time The total time of the device is shown. Current The time in the current mode is shown. System Info Mode Software The current software version is shown. version 000-255 Tilt 000-255 X Shaking 000-255 Y Shaking 000-255 Colour 000-255 Gobo 000-255...

  • Page 11: Dmx Chart

    6. DMX chart 6.1. Modus 1 (channels) Channel Value from Value to Function Pan Shaking slow-fast Tilt Tilt Shaking slow-fast Colours White White / Colour 1 Colour 1 Colour 1 / Colour 2 Colour 2 Colour 2 / Colour 3 Colour 3 Colour 3 / Colour 4 Colour 4...
  • Page 12 Gobo 2 Gobo 3 Gobo 4 Gobo 5 Gobo 6 Gobo 7 Gobo 8 Gobo 9 Gobo 10 Gobo 11 Gobo 12 Gobo 13 Gobo 14 Gobo 15 Gobo 16 Gobo 17 Clockwise Gobo rotation fast-slow Counter clockwise gobo rotation slow-fast Pattern Macros No function...

  • Page 13: Mode 2 (21 Channels)

    Beam Rotation 0-360° Beam Shaking Clockwise beam rotation fast-slow Stop Counter-clockwise beam rotation slow-fast No function Prism No function Clockwise prism rotation fast-slow Stop Counter clockwise prism rotation slow-fast Focus No function Strobe slow-fast No function Dimmer 0-100% Functions No function Lamp on (6s) Lamp off (6s) No function...
  • Page 14 Colour 4 / Colour 5 Colour 5 Colour 5 / Colour 6 Colour 6 Colour 6 / Colour 7 Colour 7 Colour 7 / Colour 8 Colour 8 Colour 8 / Colour 9 Colour 9 Colour 9 / Colour 10 Colour 10 Colour 10 / Colour 11 Colour 11...
  • Page 15 slow-fast Pattern Macros No function Pattern macro 1 Pattern macro 2 Pattern macro 3 Pattern macro 4 Pattern macro 5 Pattern macro 6 Pattern macro 7 Pattern macro 8 Pattern macro 9 Pattern macro 10 No function Clockwise pattern rotation fast-slow No function Counter clockwise pattern rotation...
  • Page 16 Dimmer 0-100% Functions No function Lamp on (6s) Lamp off (6s) No function Reset (6s) No function Pan movement range wide-narrow Tilt movement range wide-narrow 16 / 18...

  • Page 17: Technical Data

    7. Technical data Power supply Voltage 100-230 V / 50-60 Hz Power consumption max. 350 W Light source LM type Philips R5 Optics Effect Beam scanner laser simulation Connections Current in P-Con Current out P-Con XLR in/out XLR 3pol Functions Colours Colour wheel (14 Colour) Gobo wheel...
  • Page 18 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 18 / 18...
