ASSEMBLY INSTRUCTIONS
14
B.
If not visible, the electrode wires (BE) can be found behind the control panel.
Tip: Firmly grasp the wires between your thumb and index finger. Insert the wire into
the appropriate terminal until a positive connection is made.
BE
Small x 2
DG
BE
DG
Large x 2
DQ
30
Electrode Set, Main Burner |
Small Wire
Electrode Set, Side Stove | Small Wire
Ignition Wire | Large Wire
DQ
