Philips EasyKey 5000 Series User Manual
Smart rim lock
Hide thumbs
Also See for EasyKey 5000 Series:
- User manual (24 pages) ,
- User manual (22 pages) ,
- User manual (24 pages)
Related Manuals for Philips EasyKey 5000 Series
Summary of Contents for Philips EasyKey 5000 Series
- Page 1 5000 series Smart rim lock DDL506-18HS User manual www.philips.com/support Sign your product up and get support at www.philips.com/support...
-
Page 3: Table Of Contents
Contents 1. Important Information 5. Get to use your lock Safety Outdoor/ indoor unlock Caution Disposal of used products and batteries 6. Other features Default settings 2. Assembly Mute button Armed mode Packing list Exploded views Notice before assembling Assembly procedures 7. -
Page 4: Important Information
Philips. The use of such accessories and parts may ◆ Do not expose products to places that have void the warranty. water leakage or splashing. -
Page 5: Assembly
2 Assembly Packing list This packing list is for reference only. Please refer to the actual packing items. ① Exterior ② Interior ③ Strike plate ④ Mounting assembly with assembly with plate silicon pad silicon pad ⑤ Strike ⑥ Strike ⑦ Strike ⑧... -
Page 6: Exploded Views
Exploded views 1.Exterior assembly x1 4.Fixing screws for exterior assembly x4 2.Fixing screws for interior assembly x4 5.Interior assembly x1 3.Mounting plate x1 6.Battery cover x1... -
Page 7: Notice Before Assembling
Notice before assembling Step 1 | Door swing direction This product applies to doors with swing directions as follows: left-hand inswing, left-hand outswing, right-hand inswing, and right-hand outswing. Left-hand swing Right-hand swing Left-hand inswing Right-hand inswing Left-hand outswing Right-hand outswing Step 2 | Illustrations for doors Step 3 | Drill holes accordingly with different swing directions... -
Page 8: Assembly Procedures
Assembly procedures The following assembly instructions are for right-hand swing doors. For left-hand swing doors, please invert the interior assembly for installation. Use the appropriate installation method for the strike plate according to the actual door swing direction. ① Pass the front assembly cable through the ②... -
Page 9: Get To Know Your Lock
3 Get to know your lock Exterior assembly ① Keypad ② Card reader ③ Fingerprint sensor ④ Reboot and emergency charging port Interior assembly ① Battery cover ② Dead bolt ③ Mechanical keyhole ④ Fingerprint sensor... -
Page 10: Settings
4 Settings Instructions before setting ◆ The system mode is divided into general mode and dual-verification mode. General mode Any enrolled access method can unlock the door. Dual-verification mode Unlocked the door with both enrolled fingerprint and PIN code. ◆ User number You can delete individual users by their user numbers in the system without deleting all of them. -
Page 11: Master Mode
Master mode Add user information Add a User PIN Code Enter [#] followed by master PIN code and confirm with [#]. Press [2] to enter user settings, then press [1] to Master PIN Code add a user. Step1: Light up the keypad. Step2: Enter [#] twice before you enter any other numbers. - Page 12 Place the key tag near the recognition area until Add a user fingerprint you hear a "beep" sound. After hearing the voice prompt for successful setup, press [*] to return to the previous menu, and keep pressing [*] until you exit the setup mode. Attention Enter [#] followed by master PIN code and confirm with [#].
-
Page 13: System Settings
System settings for mute mode. After hearing a voice prompt indicating the setting was successful, press [*] to return to the previous menu until you exit Language settings the master mode. Remote control pairing Enter [#] followed by master PlN code and confirm with [#]. -
Page 14: Door Lock Linkage Settings
Door lock linkage settings 1.DDL506-18HS as master lock, DDL702-5HS as slave lock Step 1: Enter master mode on the DDL702-5HS by inputting “[*] twice + master PIN code + [#]”, then press [1], followed by [4] to enter pairing mode. Set button Step 2: Use a sharp object to double-click the setup button on the DDL506-18HS remote module. -
Page 15: Get To Use Your Lock
5 Get to use your lock Outdoor/ indoor unlock Outdoor unlock With a Fingerprint With a PlN Code Step1: Step1: Touch and light up the keypad, enter the Place the finger of which that has been registered PIN code and confirm with [#]. successfully registered on the fingerprint Step2: After hearing a voice prompt of... -
Page 16: Other Features
Indoor unlock Functional button Thumb turn Insert the mechanical key into the keyway hole Place the enrolled finger on fingerprint sensor and rotare to unlock after inserting firmly. to unlock. 6 Other features Default settings Function: To empty all user information and restore to default settings. -
Page 17: Mute Button
Mute button Function: Press the [Mute button] to enter one-time mute mode, this function applies to scenarios in which you don’t want to disturb your family. How to use: While the system is activated, press and hold the [#] button for 3 seconds to enter one-time mute mode. -
Page 18: Indicators
7 Indicators Low battery indicator Meanings of the indicator in different colors Red: When the lock system is awakened, it automatically detects the battery voltage. If the battery voltage is too low, the indicator light will turn on and flash in red, and the voice prompt will indicate low battery level, please replace the batteries in time. -
Page 19: System Locking Indicator
System-locking indicator The door lock will be locked Digit key “2” blinks Digit key “1” blinks for 100 seconds if there are 5 consecutive incorrect attempts of any enrolled access method (i.e. fingerprint, PIN code, and key tag) in 5 minutes. Attention The prompt will only appear when the touchscreen is lighting up or any of the... -
Page 20: Troubleshooting
8 Troubleshooting Alert types Armed mode alert Triggering: When the door lock is in the armed mode, opening the door lock from the inside will trigger an alert. Alert mode: Continuous and repeated alarm sound. Off: The alarm will be stopped when any of the enrolled access methods is successfully verified. Low battery alert Triggering: After the system wakes up, it will detect the battery voltage automatically. If the voltage is low, an alarm will sound to notify you to replace the battery promptly. -
Page 21: How To Apply External Power Supply
How to apply an external power supply Type-C port If the battery voltage is too low to open the lock from the outside, you can use a 5V power bank as an external power supply by connecting it to the lock through the Type-C port. - Page 23 Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license. This product has been manufactured by and is sold under the responsibility of Shenzhen Conex Intelligent Technology Co., Ltd., and Shenzhen Conex...
