Pool Water Heating Option – Bonding
Pool Equipment Bonding
The dehumidifier shall be bonded to the pool bonding
and grounding system through the wiring lug installed
for this purpose (example shown in the picture below).
One side of the lug is connected internally to the pool
water heat exchanger. This allows the dehumidifier to
be part of the pool equipotential bonding system and
prevents pool water heater corrosion.
WARNING!
Pool equipment bonding.
exchanger may cause failure which will not be covered under warranty.
Air Conditioning Options – Outdoor Air Fluid Coolers (OAFC).
Basic views of standard air conditioning options are shown on Pic.C.4 (below). Note, that depending on number of
factors, dehumidifier may have different fluid cooler provided with it - refer to the dehumidifier's submittal
documentation for more details.
Standard fluid coolers used with current series of dehumidifier is NG-V series, composed of number of "two-coils-
two-fans" blocks, based on required capacity of the cooler:
Fluid cooler NG-V-12 (Pic.C.4, Fig.1) is composed of one such block; NG-V-22 (Fig.2) composed of two such
•
blocks etc. largest single fluid cooler, NG-V-62 (Fig.3) composed of six of them.
As an option, each block of fluid cooler could be equipped with the pump package (as shown on Fig.1 for NG-V-12).
Proper clearances should be maintained for adequate airflow and heat rejection! Generally, up to 36" side and
96" top clearances are required. For more information on clearances as well as equipment dimensions and other
details, refer to the submittal documentation.
December 2024
Failure to properly bond the dehumidifier's pool water heat
Attention! Equipment Clearances!
