- Page 1 7” MIRROR MONITOR SYSTEM Part # SMM07 Please read this manual completely before operating the SYSTEM A division of Component Solution Services, LLC. 56600 Twin Branch Dr., Mishawaka, IN 46545 www.VeritySafe.com Verity © All rights reserved 2021-Current...
- Page 2 Verity Rear Vision Systems Wire Connection Key 4-pin camera connectors & trigger wires Camera 2 for Rear Camera Red wire to key-on hot (+) 12-32v. DC (fused) Black wire to GND. (-) Green wire to positive back-up light BE SURE TO ALIGN MONITOR CABLE CONNECTION Waterproof Fuse Chassis Ground...
- Page 3 ABOUT US Component Solution Services LLC. engineers the ® Verity products to meet any requirements and price point within the commercial and fire rescue industries. Designed for professional drivers, Verity develops and markets products and applications to ® transmit video, audio, and data. Verity is also home ®...
- Page 4 Thank you for your purchase of our Verity Rear Vison System SMM07. When installed and used properly, your SMM07 is designed to deliver you years of trouble-free operation. This manual contains important information required to properly install and operate the unit.
- Page 5 WARNING Do not place heavy objects on cables or cover them with carpet or mats. Do not place cables where they can be crushed in any manner. Our systems are designed as a driving aid. Watching videos, broadcasts, DVDs and/or any images other than intended driving assistance cameras is prohibited.
-
Page 6: System Features
SYSTEM FEATURES MONITOR SPECIFICATIONS (Monitor part #MMK07) | 7-inch Clip-On Mirror Monitor • TFT-LCD (16:9) • Format: NTSC • New Higher Resolution: 800 (W) x 480(H) RGB • Power supply: DC 12V • Video: 2-channel video input, V1/V1 switching with •... - Page 7 SYSTEM MEASURMENTS...
-
Page 8: System Components
SYSTEM COMPONENTS 7” Clip-on / post Manual Mirror Monitor Windshield Bracket Monitor Harness w/ Post mount waterproof fuse Weatherproof Camera 20-Meter Camera with night vision Cable Remote Hardware... - Page 9 SYSTEM COMPONENTS This monitor can be mounted over any existing mirror. Take caution not to block any sensors on the current mirror. Camera Connection Do NOT make the cable tight from the back of camera going into the truck – form a drip loop with slack.
-
Page 10: Cable Connections
CABLE CONNECTIONS Verity Rear Vision Systems Wire Connection Key 4-pin camera connectors & trigger wires Camera 2 for Rear Camera Red wire to key-on hot (+) 12-32v. DC (fused) Black wire to GND. (-) Green wire to positive back-up light BE SURE TO ALIGN MONITOR CABLE CONNECTION Waterproof Fuse... -
Page 11: Monitor Operations
MONITOR OPERATIONS... - Page 12 Menu BRIGHTNESS BRIGHTNESS llllllllllllllllllll------------- Use DOWN / UP arrows to adjust the brightness CONTRAST CONTRAST llllllllllllllllllll------------- Use DOWN / UP arrows to adjust contrast COLOR COLOR llllllllllllllllllll------------- Use DOWN / UP arrows to adjust the color LANGUAGE There are 12 to choose from LANG ENGLISH Use DOWN / UP arrows to change the language...
- Page 13 ZOOM ZOOM 16:4 Use DOWN / UP arrows to adjust zoom 16:4 / 4:3 (zoom in) ROTATE ROTATE Use DOWN / UP arrows to Rotation / Flip RESET Restores all preset factory settings...
- Page 14 Possible safety additions ADD60S Rear Sensor System Increase your vehicle safety by adding a Verity ADD60S Sensor System. These sensors alert you of objects behind the truck while reversing the vehicle. They can show you how close you are to an object as the sound intensifies as you move closer.
-
Page 15: Limited One (1) Year Warranty
® Verity A division of COMPONENT SOLUTION SERVICES, LLC (CSS) LIMITED One (1) YEAR WARRANTY 1. CSS products’ warranties are not transferable. They apply to the consumer for one (1) year and cover defects in material and workmanship. We do not warranty our cables, which are QC tested at three different stations before shipping. - Page 16 Technical Support A service ticket can be filled out online to supply the quickest service. The service ticket can be easily found on our website, www.VeritySafe.com, or use the code to the right. Please have the system's serial number, which is found on the back of the monitor, when contacting the service department.
