7-INCH "S" SERIES SYSTEM
Part # SM07S
Please read this manual completely before operating the SYSTEM
A division of
Component Solution Services, LLC.
56600 Twin Branch Dr.,
Mishawaka, IN 46545
www.VeritySafe.com
Verity ©
All rights reserved 2021-Current

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM07S and is the answer not in the manual?

Questions and answers

Summary of Contents for Verity Audio SM07S

  • Page 1 7-INCH “S” SERIES SYSTEM Part # SM07S Please read this manual completely before operating the SYSTEM A division of Component Solution Services, LLC. 56600 Twin Branch Dr., Mishawaka, IN 46545 www.VeritySafe.com Verity © All rights reserved 2021-Current...
  • Page 2: Table Of Contents

    TABLE of CONTENTS Contents ABOUT US .................. 3 THINK SAFETY ................4 SYSTEM FEATURES ..............6 SYSTEM COMPONENTS ............7 MOUNTING ................. 8 CABLE CONNECTIONS ............. 9 MONITOR OPERATIONS ............10 MENU OPERATIONS ............... 11 SYSTEM DIMENSIONS ............14 ® VERITY WARRANTY ..............
  • Page 3: About Us

    ABOUT US Component Solution Services LLC engineers the ® Verity products to meet any requirement and price point within the commercial and fire rescue industries. Designed for professional drivers, Verity develops and markets products and applications to transmit video, ® ®...
  • Page 4: Think Safety

    Most likely, your system came pre-installed so the installation section will be for reference. Thank you for your purchase of our Verity SM07S. When installed and used properly, your SM07S is designed to deliver you years of trouble-free operation. This manual contains important information required to properly install and operate the unit.
  • Page 5 WARNING  Do not place heavy objects on cables or cover them with carpet or mats.  Do not place cables where they can be crushed in any manner.  Our systems are designed as a driving aid. Watching videos, broadcasts, DVDs and/or any images other than intended driving assistance cameras is prohibited.
  • Page 6: System Features

    SYSTEM FEATURES MONITOR SPECIFICATIONS (Monitor part #MK07S) • Screen size: 7-inch digital screen (16:9) • High Resolution: 1024 × 600 Pixel (RGB) • System: PAL/NTSC Auto select • Contrast: 400:1 • Brightness: 300 cd/m2 • Power supply: DC 12V~24V with reverse polarity protection •...
  • Page 7: System Components

    SYSTEM COMPONENTS 7-Inch digital Manual LCD monitor 20-Meter Camera Cable Weatherproof Camera with night vision 13-pin to 4-pin Monitor Fan Style Mount Harness...
  • Page 8: Mounting

    MOUNTING This monitor can be mounted on the dash and on horizontal and vertical surfaces. Make sure the view is suitable for the driver to observe the images. Take care not to block any necessary viewing area when mounting. Before mounting the system, permanently hook up all connections to ensure proper operation.
  • Page 9: Cable Connections

    CABLE CONNECTIONS Fuse Chassis Ground CAM 1 Camera one trigger wire CAM 2 Camera two trigger wire CAM 3 Camera three trigger wire Wire Connection Key:  wire to ignition hot (+) 10-26 volts  BLACK wire to ground (-) (please use a chassis ground post) ...
  • Page 10: Monitor Operations

    MONITOR OPERATIONS Buttons from left to right 1. (VOL+) Volume Increase Up Arrow 2. Menu Control Button 3. (VOL-) Volume Decrease Down Arrow 4. Power Off/On button - Red color is stand-by- Blue is powered 5. Channel / Camera 1 6.
  • Page 11: Menu Operations

    MENU OPERATIONS The menu button operates the menu options: The following shows how the menu options work. The down and up arrow buttons control decreases and increases the options. Menu Press 1 time PICTURE: Brightness, displays on-screen. BRIGHTNESS Menu Press 2 times CONTRAST: Contrast, displays on screen.
  • Page 12 Menu Press 6 times ZOOM Toggles between 16:9 / 4:3 image sizes Menu Press 7 times “FLIP” Image Orientation: This selection flips each camera image individually both horizontally and vertically. This allows for a correct image of interior/forward- facing cameras. Menu Press 8 times LANG (LANGUAGE): “Show English as the primary language.”...
  • Page 13 Menu Press 11 times Parking line functions Displays on the screen. PARK When the parking line function is on the backup lines can be adjusted. (See section below) Menu Press 12 times - Resets the monitor back to factory defaults Displays on the screen.
  • Page 14: System Dimensions

    SYSTEM DIMENSIONS...
  • Page 15: Limited One (1) Year Warranty

    ® Verity A division of COMPONENT SOLUTION SERVICES, LLC (CSS) LIMITED One (1) YEAR WARRANTY 1. CSS products’ warranties are not transferable. They apply to the consumer for one (1) year and cover defects in material and workmanship. We do not warranty our cables, which are QC tested at three different stations before shipping.
  • Page 16: Technical Support

    Technical Support A service ticket can be filled out online to supply the quickest service. The service ticket can be easily found on our website, www.VeritySafe.com, or use the code to the right. Please have the system's serial number, which is found on the back of the monitor, when contacting the service department.
