Congratulations on your new PC! Accessing the I/O panel and connecting your peripherals to the
MEK5080A9700XBT5/BLT5 is easy! Follow along this guide to learn how:
I/O Port
(Type-C x 1)
(USB 3.2 (Gen 2)
STEP 1
ONE-TOUCH RELEASE MECHANISM.
.
STEP 3
Unscrew the two thumb screws and lift
the top fan bracket latch to access the
I/O ports.
FRONT
BACK
Disconnect any fan cables as needed to
fully remove the top fan bracket.
MEK5080A9700XBT5,MEK5080A9700XBLT5
PERIPHERAL SETUP GUIDE
(Power light, Hdd light)
(HD Audio,mic)
(Rest button)
(Power button)
(USB 3.0 x 4)
STEP 2
Remove the back panel by pulling the
top notch for easier access to the I/O
ports.
STEP 4
Pass the cables through the designated
side cutouts.
All other peripherals
For technical support
1-877-599-6822
9:00am – 6:00pm PST
Mon – Fri.
For the PDF version please scan
this QR code
FRONT
BACK
Monitors and
other displays
Ver 2.0
