ALI Washtech M2C Series Installation

M2C SERIES-5 CUSTOMISATION
GENERAL WARNINGS
This document is to be read in conjunction with the supplied Operator Manual and is for the use
of suitably qualified Service Technicians only. Do not attempt these modifications if you are not
qualified to do so, and contact Washtech if additional information or assistance if required.
Non-compliance with warnings or failure to follow the instructions in this manual can result in
loss of life, severe personal injury and / or serious damage to property.
Before installation, commissioning and / or repair of the machine you must carefully read the
safety instructions and warnings and all warning labels attached to the machine.
Hazards can include high surface temperatures, hot water, caustic detergent, sharp edges
including broken glass and knives left in the wash chamber, and dangerous electrical voltages.
All service work must be carried out by qualified personnel only who ensure compliance with all
local codes and standards including AS/NZS 3500.1.
The electrical supply must be turned off at the wall before accessing the machine for servicing.
All electrical terminals must be covered at all times to prevent access to the terminal.
Appropriate electrical tests must be carried out after any and all service repairs.
MODEL CUSTOMISATION
The new M2 Series-5 features our versatile touchscreen display that can be installed as a Heads-Up
Display on either side of the upper rear of the machine, or can be mounted underbench to the side of
the cabinet if preferred.
This enables corner installations in either direction, and positioning of the controls either to provide the
operator with the best display of the operation of the machine, or out of the way in tight locations
where space is at an absolute premium.
Multiple power connection options are available for
this model as well.
