How to Connect
CONNECTING TURNTABLE TO PHONO 1 AND 2
Connect the cable from the "left" channel of the
turntable into the L PHONO 1 INPUT jack. Connect
the "right" channel into the R PHONO 1 INPUT jack.
Connect a second turntable in the same manner
to the PHONO 2 INPUT jacks. Shorting plugs are
shipped in the PHONO 2 INPUT jacks to eliminate
noise if a second turntable is not used. Remove
these shorting plugs when connecting the second
turntable. Keep them for possible future use. DO
NOT plug the shorting plugs into an output jack as
this may prevent operation of the MA 6200.
GROUND CONNECTION
A single ground post is provided. Grounds for turn-
tables, record changers, tape decks, etc. are to be
connected to this post. The left and right program
cables and the ground wire from that source should
be wound or twisted together. To avoid hum make
sure the ground wire does not make any connec-
tions to the shields of the left and right program
cables between the program source and the MA
6200.
CONNECTING A STEREO TUNER AND AUX 1 AND 2
Connect the cable from the "left" channel tuner
output to the L TUNER INPUT jack.
Connect the cable from the "right" channel tuner
output to the R TUNER INPUT jack
AUX—Any high level program source such as a
tuner, a TV set or a tape recorder can be connected
to the AUX 1 and 2 INPUT jacks. The connecting pro-
cedure is the same as for the tuner input.
CONNECTING TAPE RECORDERS
To Record:
Connect a cable from the L TAPE 1 OUTPUT jack
to the left high level input of the tape recorder. Con-
nect a cable from the R TAPE 1 OUTPUT jack to the
right high level input of the tape recorder.
Connect a second recorder in the same manner to
the TAPE 2 OUTPUT jacks.
To Playback/Monitor:
Connect a cable from the left channel output of a
tape recorder to the L TAPE 1 INPUT jack. Connect a
cable from the right channel output of a tape
recorder to the R TAPE 1 INPUT jack.
Connect a second recorder in the same manner to
the TAPE 2 INPUT jacks.
CONNECTING AC POWER
The MA 6200 AC power cord is to be plugged into
a 120 volt 50/60 Hz wall outlet.
There are two types of AC power outlets on the
back panel of the MA 6200; three black, and two
green.
The green AC power outlets are on at all times.
Plug the AC power cables from the turntable into the
green TURNTABLE power outlets on the rear panel.
The three black outlets are switched on and off
when the amplifier is turned on or off. These are in-
tended for equalizers and other accessories.
The POWER ON pushbutton shares AC power
control, with the AC power switch on a turntable,
through a current detecting switch circuit. On the
rear panel the TURNTABLE AUTO/MANUAL switch
selects the mode of operation.
When the switch is in the AUTO position and a
turntable plugged into one of the green AC power
outlets, the AC power to the receiver and to the
black AC power outlets can be controlled by the
4
