Transmitter; Custom Codes; Data Format; Carrier - McIntosh IR REMOTE CONTROL DATA Manual

10/22/03

TRANSMITTER:

The following data refers to the NEC uPD6122G-001 IR Transmitter

CUSTOM CODES:

CODE C0 C1 C2
CA55H 0 1
CA95H 0 1
8050H 0 0
8A75H 0 1

DATA FORMAT:

CARRIER:

C3 C4 C5
0 1 0 0
0 1 0 0
0 0 0 0
0 1 0 0
McIntosh Laboratory
IR Remote Control Data
C6 C7 C'0 C'1
1 1 1 0
1 1 1 0
0 1 0 0
0 1 1 0
C'2 C'3 C'4 C'5
1 0 1 0
1 0 1 0
0 0 1 0
1 0 1 1
Page 3
C'6 C'7
1 0
0 1
1 0
1 0
