Stratus SAE-PS6 Safety, Installation, Operation, Maintenance

Electrical safety lock release scissor parking lift 110v
Hide thumbs

Advertisement

Quick Links

Download this manual
1
5881 Imperial Loop Dr.
College Station, Tx USA
Telephone:(512) 640-9896
stratusautoequip.com
Safety - Installation - Operation - Maintenance
Stratus Electrical Safety Lock Release Scissor Parking Lift PS6
IMPORTANT NOTE:
1.
Save these instructions!
2.
This equipment should not be installed, operated or repaired without first reading the instructions.
Failure to follow the instructions and safety can result in serious injury or death.
3.
Electricity should be hooked up by a certified electrician.
4.
Do NOT use equipment beyond its rated capacity.
5.
Keep manual near lift for reference
6.
By proceeding with installation and operation, you agree that you fully understand the contents of
this manual and assume full responsibility for product use.
7.
Only Operate this lift if it can be done so safely.
Stratus 2 Post Base Plate Lift Installation & Operation & Maintenance Instructions
110V SAE-PS6
Model: SAE-PS6
Manual SAE-PS6— Oct 2024
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAE-PS6 and is the answer not in the manual?

Questions and answers

Related Manuals for Stratus SAE-PS6

Summary of Contents for Stratus SAE-PS6

  • Page 1 5881 Imperial Loop Dr. College Station, Tx USA Stratus 2 Post Base Plate Lift Installation & Operation & Maintenance Instructions Telephone:(512) 640-9896 stratusautoequip.com Safety - Installation - Operation - Maintenance Stratus Electrical Safety Lock Release Scissor Parking Lift PS6 110V SAE-PS6 Model: SAE-PS6 Manual SAE-PS6—...
  • Page 2 Introduction This manual is designed to help customers use Stratus SAE-PS6, scissor parking lift. This is a scissor parking lift with an open center that provides full under vehicle access. This lift comes with a capacity of 6,000 LBS. Stratus recommends keeping this manual within reach of the lift for anyone who is to use or service the machine.
  • Page 3 Liability Stratus Auto Equipment assumes no liability for damages resulting from: •Use of the product for purposes other than those described in this manual. •Modifications to the equipment without prior, written permission from Stratus Auto Equipment •Injury or death caused by modifying, disabling, overriding, or removing safety features.
  • Page 4 Stratus Auto Equipment's website. Not all of Stratus Auto Equipment lift models meet the standards as prescribed by ANSI/ALI ALCTV-(current edition) or ANSI/UL 201. Consult www.autolift.org...

  • Page 5: Unit Information

    Unit Information Be sure to document the Model Number, Serial Number, and Date of Manufacture from the label on your unit below. This information is required for part or warranty issues.

  • Page 6: Table Of Contents

    Index ………………………………………………………………………………………………7 Product Overview ………………………………………………………………………………………………8 Technical Specifications ……………………………………………………………………………………………………………9-13 Install Instructions ………………………………………………………………………………………………14 Testing ……………………………………………………………………………………………14 Description of Operations ……………………………………………………………………………………………15 Oil Filling and Leveling Operation ………………………………………………………………………………………………………15 Maintenance ……………………………………………………………………………………………………15-17 Problem symptoms and solutions ……………………………………………………………………………………18 Hydraulic Schematic Diagram …………………………………………………………………………………………19-20 Electrical Schematic Diagram …………………………………………………………………………………………21 Special Notes Important Safety Instructions ……………………………………………………………………………………………………………22-27 &...

  • Page 7: Product Overview

    Product overview Product description The scissor parking lift SAE-PS6 has a scissor-type structure. The equipment is suitable for parking 2 vehicles. The transmission system adopts a hydraulic transmission method. The hydraulic pump outputs high- pressure oil to push the hydraulic cylinder and drive the vehicle-carrying plate to rise or fall to achieve the purpose of accessing the vehicles.

  • Page 8: Technical Specifications

    Technical Specifications: Model SAE-PS6 Lift Capacity 6,000 LBS Overall Height 72 13/16" (1850 mm) Overall Width 103 5/32" (2620 mm) Overall Length 161 7/16"(4100mm) Minimum Height 9 13/16" (2108 mm) Platform Width 83" (2108 mm) Platform Length 125" (3175 mm) Lifting time About 60 Sec.

  • Page 9: Installation Instructions

    But if you do not contact us and proceed with installation after knowing lack of parts, Stratus as well as our dealers will not bear any responsibility for this and will charge for any parts subsequently demanded by the buyer.

  • Page 10: Precautions During Installation

    3.2 Precautions during Installation • Joints of oil hose and electric wire must be firmly connected in order to avoid leakage and wire loosing • All bolts should be firmly screwed up. • Do not place any vehicle on the lift in the case of trial running. 3.3 Installation steps Step1:Remove Lift from packaging and ensure all parts are present.
  • Page 11 Step 3: Connect all electrical and hydraulic connections to the power unit ensuring the hydraulic fittings are properly tightened to prevent leakage. Teflon/Plumbers tape should NOT be used for the connections as this may introduce contaminants into the system. Step 3A: Tubing Connection (this step is very important to understand the tubing connection diagram and the following instructions before operation).
  • Page 12 Step 3B: Electrical connection Connect to the external power supply plug according to the electrical schematic diagram, the black line is the phase line, the blue line is the zero line, and the yellow and green line is the ground line. Step 4: Fill it up with the hydraulic oil Fill the hydraulic reservoir with 13 liters (~ 3 Gal) of AW32/46 hydraulic oil from the top of the barrel between 10mm and 40mm (measured with a gauge on the barrel cover)
  • Page 13 Step 6: Connect the limit switch 1. Raise the vehicle board to 1980mm (78 in), adjust the limit switch action, pay attention to the highest limit, and park the insurance safety lock 5~10mm (0.25-0.5 in) in front of the final tooth of the locking tooth, or adjust to the required height according to the user's requirements.

  • Page 14: Testing

    4.2 Test A. No-load test: Turn on the power switch and press the "rise" button to observe whether the vehicle plate rising is stable and the two cylinders are synchronized; rise to the highest point to observe whether the upper limit of the device is accurate and reliable; press the "drop lock" button to observe whether the safe block is accurately.

  • Page 15: Oil Filling And Leveling Operation

    3. Oil Filling and Leveling Operation (Normal Service Period): Raise the vehicle loading plate to about 500 mm. Open the oil filling stop valve, press either the "up" or "down" button, and then close the oil filling stop valve once the desired level is reached. This completes the oil filling adjustment procedure.
  • Page 16 Fault phenomenon Cause The exclusion method The power supply is not normal Check and remove and connect the wires 2) The AC contactor of the main If the motor is pressed with the insulation rod, check circuit of the pump motor does not the control loop, and if the voltage at the contactor engage coil end is normal, replace the contactor...
  • Page 17 Replace the hydraulic oil or take thermal 1) Hydraulic oil viscosity is too large insulation measures according to the or frozen or deteriorated (in winter) instructions The drop speed of the equipment is slow during Remove or close the power supply of the the normal load 2) The "explosion-proof valve"...

  • Page 18: Hydraulic Schematic Diagram

    Attachment 1 Hydraulic Schematic Diagram 1. Main hydraulic cylinder 2. Auxiliary hydraulic cylinder 3. Explosion-proof valve 4. Working solenoid valve 5. Stop valve 6. Check valve 7. Relief valve 8. Descending solenoid valve 9. Throttle valve 10. Gear pump 11. Pump motor 12.

  • Page 19: Electrical Schematic Diagram

    Annex II Electrical Schematic Diagram...

  • Page 21: Special Notes

    Special Notes Environmental damage : Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling: To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected.

  • Page 22: Important Safety Instructions

    Important Safety Instructions 1.1 Important Notices Make sure to pay careful attention to the label of the lifting capacity attached on the lift and never try to lift cars above the lifting capacity labeled. Read this manual carefully before operating the machine so as to avoid personnel injury Users are not permitted to make any modification to the control or mechanical unit 1.2 Qualified Personnel...

  • Page 23: Safety Instructions

    1.4 Safety Instructions Make sure that you have read the User’s Manual completely, including relevant instructions on installation, operation, and safety before operating the lift. This lift is designed for lifting vehicles 6,000 LBS and under. Any other use may result in damage of the lift or injury to personnel.
  • Page 24 Keep areas well lit. Keep loads balanced on the lift platforms. Clear the area immediately if a vehicle is in danger of falling off the lift. DO NOT ATTEMPT TO CATCH A FALLING VEHICLE! Make sure there are no obstacles under the vehicle before lowering it If the lift will be left unused for a long period of time, it is recommended that the user disconnects power, empties the oil tank, and lubricates any moving parts with hydraulic Attention: For environment protection, please dispose of the used oil in a proper way.
  • Page 25 CAUTION Only trained personnel is allowed to use the lift. Read the entire manual before operating Never try to raize the vehicle exceding lift capacity Make sure you meet all safety requirements before you start working under the vehicle Surrounding of lift will remain clear when raising or lowering The manufacturer and distributor will not take any responsibility if user does not follow the...
  • Page 26 *Warning label pictographs used with permission of the Automotive Lift Institute.

  • Page 27: Sound Level

    1.6 Sound Level The sound emitted from the lift should not exceed 75 DB. 1.7 Special Reminder The newly installed lift can NOT directly lift vehicle, and should be raised to the highest point then lowered to the lowest point 2-3 times repeatedly without any load to bleed the air out from the hydraulic hose and cylinders to ensure the lift runs smoothly 1st time use of the lift with a load after bleeding air out of the the hydraulic hose and cylinders should follow the steps below...
