Stratus Commercial Grade On-Ground or In-Ground Mount
Low Profile Full Rise Scissor Car Lift SAE-UT9000
IMPORTANT NOTE:
1.
Save these instructions!
2.
This equipment should not be installed, operated or repaired without first reading the instructions.
Failure to follow the instructions and safety can result in serious injury or death.
3.
Electricity should be hooked up by a certified electrician.
4.
Do NOT use equipment beyond its rated capacity.
5.
Keep manual near lift for reference
6.
By proceeding with installation and operation, you agree that you fully understand the contents of
this manual and assume full responsibility for product use.
7.
Only Operate this lift if it can be done so safely.
Model: UT9000
Manual SAE-UT9000— Revision A1 — June 2024
1
Advertisement
Related Manuals for Stratus UT9000
Summary of Contents for Stratus UT9000
- Page 1 College Station, TX USA Telephone:(512) 640-9896 stratusautoequip.com Safety - Installation - Operation - Maintenance Stratus Commercial Grade On-Ground or In-Ground Mount Low Profile Full Rise Scissor Car Lift SAE-UT9000 Model: UT9000 Manual SAE-UT9000— Revision A1 — June 2024 IMPORTANT NOTE: Save these instructions! This equipment should not be installed, operated or repaired without first reading the instructions.
- Page 2 Introduction This manual is designed to help customers use Stratus UT9000 scissor lift. This is a mid rise, with an open center that provides full under vehicle access. This lift comes with a capacity of 9,000 LBS. Stratus recommends keeping this manual within reach of the lift for anyone who is to use or service the machine.
- Page 3 Liability Stratus Auto Equipment assumes no liability for damages resulting from: •Use of the product for purposes other than those described in this manual. •Modifications to the equipment without prior, written permission from Stratus Auto Equipment •Injury or death caused by modifying, disabling, overriding, or removing safety features.
- Page 4 Manual - UT9000 - On-Ground or In-Ground Mount Low Profile Full Rise Scissor Car Lift - Safety - Installation - Operation - Maintenance Copyright - Copyright © 2023 by Stratus Metals, Inc. dba Stratus Auto Equipment reserves all rights. Copies may be made of this document if you agree full attribution to Stratus Metals Inc. Changes and Copies for commercial purposes to this document are prohibited.
-
Page 5: Unit Information
Unit Information Be sure to document the Model Number, Serial Number, and Date of Manufacture from the label on your unit below. This information is required for part or warranty issues. - Page 6 Index Important Safety Instructions ............7~11 1.1 Important Notices 1.2 Qualified Personnel 1.3 Warning Signs 1.4 Safety Instructions 1.5 Labels 1.6 Sound Level 1.7 Training 1.8 Special Reminder 2. Overview of the Lift...................12 2.1 General Description 2.2 Measurements 3. Installation Instructions..............13~15 3.1 Precautions for Installation 3.3 Installation 4.
-
Page 7: Important Safety Instructions
Important Safety Instructions 1.1 Important Notices Make sure to pay careful attention to the label of the lifting capacity attached on the lift and never try to lift cars above the lifting capacity labeled. Read this manual carefully before operating the machine so as to avoid personnel injury Users are not permitted to make any modification to the control or mechanical unit 1.2 Qualified Personnel... - Page 8 1.4 Safety Instructions Make sure that you have read the User’s Manual completely, including relevant instructions on installation, operation, and safety before operating the lift. This lift is designed for lifting vehicles 9,000 LBS and under. Any other use may result in damage of the lift or injury to personnel.
- Page 9 Keep areas well lit. Keep loads balanced on the lift platforms. Clear the area immediately if a vehicle is in danger of falling off the lift. DO NOT ATTEMPT TO CATCH A FALLING VEHICLE! Make sure there are no obstacles under the vehicle before lowering it If the lift will be left unused for a long period of time, it is recommended that the user disconnects power, empties the oil tank, and lubricates any moving parts with hydraulic Attention: For environment protection, please dispose of the used oil in a proper way.
- Page 10 CAUTION Only trained personnel is allowed to use the lift. Read the entire manual before operating Never try to raize the vehicle exceding lift capacity Make sure you meet all safety requirements before you start working under the vehicle Surrounding of lift will remain clear when raising or lowering The manufacturer and distributor will not take any responsibility if user does not follow the...
- Page 11 1.7 Special Reminder The newly installed lift can NOT directly lift vehicle, and should be raised to the highest point then lowered to the lowest point 2-3 times repeatedly without any load to bleed the air out from the hydraulic hose and cylinders to ensure the lift runs smoothly 1st time use of the lift with a load after bleeding air out of the the hydraulic hose and cylinders should follow the steps below Loosen the screw cap of the hydraulic oil flow valve and tighten the middle hexagonal...
- Page 12 Overview of the Lift 2.1 Technical data Lifting Lifting Lifting Power Model Air Supply Capacity Time Height Supply SAE- 73-87 PSI 9,000 LBS ~60 Sec 77 9/16" 220V 1ph UT9000 (5-6 BAR) 2.2 Measurements...
-
Page 13: Installation Instructions
Installation Instructions 3.1 Precautions for Installation The joints of the oil hose must be firmly connected in order to avoid leakage All bolts should be firmly screwed up Do not place any vehicle on the lift during trial running 3.2 Installation Remove the accessory packages, and take the parts out of their packaging. - Page 14 After all wiring and hose connections have been completed, connect the rollers onto the ends of the platforms by removing the rods, placing the roller in place, and sliding the rods back through the slots. This step is easiest with the lift raised Note: These roller pieces, can be placed parallel to the platform, or can be moved, so they are at an angle Installing the extension ramps (Optional)
- Page 15 If the lift is used while the vehicle’s center of gravity is not positioned midway between the rising platforms, Stratus, as well as our dealers will not bear any responsibility for any consequence resulted thereby.
- Page 16 4.3 Emergency lowering The safety lock is not engaged: Tie up the safety teeth on both sides with rope; pull upward on the rope to make sure the safety teeth are unlocked. Once the safety teeth are unlocked, manually loosen the core of the electro-magnetic valve on the pump assembly.
-
Page 17: Frequently Asked Questions
Frequently Asked Questions What kind of oil do I use? AW32 or AW46 hydraulic oil Does this lift come with a plug? The lift does not come with a plug, you will need to get a 110V, or 220V connection with plug How do I hook up the electrical? Yellow Green Wire: ground Wire Blue and Brown Wire:... -
Page 18: Maintenance
Maintenance Daily Pre-operation Check oil hoses for leaks Check the electrical system Check that the plug bolts are firmly screwed Check that the safety teeth and safety block match Weekly Check the flexibility of moving parts Check the working conditions of safety parts Check the amount of oil in the oil tank Every 1 Month Check the tightness of the hydraulic system and screw firm the joints... -
Page 19: Warranty
Warranty 5 years lifting structure Post, Cross Bar, Carriage, Arms, Safety Locks, Safety Lock Pins, Arm Pin, Runway 3 years hydraulic Power Unit/Station, Cylinder 2 years electrical Electrical, Buttons, Solenoid, Limit Switch 1 Year Balance Cable, Safety Lock Release Cable, Safety Covers, Support Bar, Ramps, Hydraulic Hose, Fittings No Warranty Door Guard, Rubber Pads, Truck Adaptors **Parts only!! Labor costs for someone to install replacement parts are NOT covered. - Page 20 Parameters Model UT9000 Rated Lifting Capacity 9,000 LBS Minimum Height 4 5/16" Lifting Height 77 9/16" Platform Width 25 9/16" Motor Parameters 220V Hydraulic Oil AW32 or AW46 Air Supply 73-87 PSI (5-6 BAR) Features Commercial grade open center design Low profile, minimum height is 4 5/16"...
-
Page 21: Exploded View
Exploded View Pump: Description Description Motor Oil Hose Tie-In Hydraulic Block Electrical Unloading Valve Overflow Valve Single Way Valve Fitting Gear Pump Cushion Valve Oil Tank Absorbing Oil Pipe Oil Tank Cover Oil Filer Oil Back Pipe Throttle Valve... - Page 22 Automotive Lift Institute Store You probably checked the ALI’s Directory of Certified Lifts(www.autolift.org/ali-directory-of- certified-lifts/) before making your most recent Lift purchase, but did you know the ALI Store (www.autolift.org/ali-store/) offers a wide variety of professional, easy-to-use, and reasonably priced training and safety materialsthat will make your garage a safer place to work? The ALI Store is your trusted source for workplace safety! Visit today and get the training and materials you need to worksafely:...
- Page 23 Special Notes Environmental damage : Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling: To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected.
