Warehouse
8413 Calibration Ct.
College Station, Tx USA
Telephone:(512) 640-9896
stratusautoequip.com
Safety - Installation - Operation - Maintenance
Extra Wide Extra Tall Commercial Grade 9,000 LBS Capacity
Open Center Mobile Mid Rise Electric Safety Lock Release
IMPORTANT NOTE:
1.
Save these instructions!
2.
This equipment should not be installed, operated or repaired without first reading the instructions.
Failure to follow the instructions and safety can result in serious injury or death.
3.
Electricity should be hooked up by a certified electrician.
4.
Do NOT use equipment beyond its rated capacity.
5.
Keep manual near lift for reference
6.
By proceeding with installation and operation, you agree that you fully understand the contents of
this manual and assume full responsibility for product use.
7.
Only Operate this lift if it can be done so safely.
Sales
8413 Calibration Ct.
College Station, Tx USA
Telephone:(512) 640-9896
Scissor Car Lift: SAE-MS9000XT
Model: MS9000XT
Manual SAE-MS9000XT— Revision A1 — May 2024
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Stratus MS9000XT
Summary of Contents for Stratus MS9000XT
- Page 1 Open Center Mobile Mid Rise Electric Safety Lock Release Scissor Car Lift: SAE-MS9000XT Model: MS9000XT Manual SAE-MS9000XT— Revision A1 — May 2024 IMPORTANT NOTE: Save these instructions! This equipment should not be installed, operated or repaired without first reading the instructions.
- Page 2 Introduction This manual is designed to help customers use Stratus MS9000XT scissor lift. This is a mid rise, with an open center that provides full under vehicle access. This lift comes with a capacity of 9,000 LBS. Stratus recommends keeping this manual within reach of the lift for anyone who is to use or service the machine.
- Page 3 Liability Stratus Auto Equipment assumes no liability for damages resulting from: •Use of the product for purposes other than those described in this manual. •Modifications to the equipment without prior, written permission from Stratus Auto Equipment •Injury or death caused by modifying, disabling, overriding, or removing safety features.
- Page 4 Stratus Auto Equipment's website. Not all of Stratus Auto Equipment lift models meet the standards as prescribed by ANSI/ALI ALCTV-(current edition) or ANSI/UL 201. Consult www.autolift.org...
-
Page 5: Unit Information
Unit Information Be sure to document the Model Number, Serial Number, and Date of Manufacture from the label on your unit below. This information is required for part or warranty issues. - Page 6 Index Important Safety Instructions ............7~11 1.1 Important Notices 1.2 Qualified Personnel 1.3 Warning Signs 1.4 Safety Instructions 1.5 Labels 1.6 Sound Level 1.7 Training 1.8 Special Reminder 2. Overview of the Lift...................12 2.1 General Description 2.2 Measurements 3. Installation Instructions..............13~15 3.1 Precautions for Installation 3.3 Installation 4.
-
Page 7: Important Safety Instructions
Important Safety Instructions 1.1 Important Notices Make sure to pay careful attention to the label of the lifting capacity attached on the lift and never try to lift cars above the lifting capacity labeled. Read this manual carefully before operating the machine so as to avoid personnel injury Users are not permitted to make any modification to the control or mechanical unit 1.2 Qualified Personnel... - Page 8 1.4 Safety Instructions Make sure that you have read the User’s Manual completely, including relevant instructions on installation, operation, and safety before operating the lift. This lift is designed for lifting vehicles 9,000 LBS and under. Any other use may result in damage of the lift or injury to personnel.
- Page 9 Keep areas well lit. Keep loads balanced on the lift platforms. Clear the area immediately if a vehicle is in danger of falling off the lift. DO NOT ATTEMPT TO CATCH A FALLING VEHICLE! Make sure there are no obstacles under the vehicle before lowering it If the lift will be left unused for a long period of time, it is recommended that the user disconnects power, empties the oil tank, and lubricates any moving parts with hydraulic Attention: For environment protection, please dispose of the used oil in a proper way.
- Page 10 CAUTION Only trained personnel is allowed to use the lift. Read the entire manual before operating Never try to raize the vehicle exceding lift capacity Make sure you meet all safety requirements before you start working under the vehicle Surrounding of lift will remain clear when raising or lowering The manufacturer and distributor will not take any responsibility if user does not follow the...
- Page 11 1.7 Special Reminder The newly installed lift can NOT directly lift vehicle, and should be raised to the highest point then lowered to the lowest point 2-3 times repeatedly without any load to bleed the air out from the hydraulic hose and cylinders to ensure the lift runs smoothly 1st time use of the lift with a load after bleeding air out of the the hydraulic hose and cylinders should follow the steps below Loosen the screw cap of the hydraulic oil flow valve and tighten the middle hexagonal...
- Page 12 Overview of the Lift 2.1 Technical data Lifting Model Lifting Time Lifting Height Power Supply Capacity SAE- 110V/220V, 9,000 LBS ~50 sec 47 1/4" MS9000XT 2.2 Measurements...
-
Page 13: Installation Instructions
Installation Instructions 3.1 Precautions for Installation The joints of the oil hose must be firmly connected in order to avoid leakage All bolts should be firmly screwed up Do not place any vehicle on the lift during trial running 3.2 Installation Remove the accessory packages, and take the parts out of their packaging. - Page 14 Once your lift is in prime location, connect the hydraulic hose from the lift base to the pump With the hydraulic hose connected to the pump, fill the tank with hydraulic fluid. After filling the tank with hydraulic fluid, connect the cables, and proceed to wiring the power plug When wiring the power plug: Yellow Green Wire: ground Wire...
- Page 15 Note: The foam across the motor is only for shipping safety purposes. Remove the foam before continuing on. After all wiring and hose connections have been completed, connect the rollers onto the ends of the platforms by removing the rods, placing the roller in place, and sliding the rods back through the slots.
- Page 16 If the lift is used while the vehicle’s center of gravity is not positioned midway between the rising platforms, Stratus, as well as our dealers will not bear any responsibility for any consequence resulted thereby.
- Page 17 4.3 Emergency lowering The safety lock is not engaged: Tie up the safety teeth on both sides with rope; pull upward on the rope to make sure the safety teeth are unlocked. Once the safety teeth are unlocked, manually loosen the core of the electro-magnetic valve on the pump assembly.
-
Page 18: Frequently Asked Questions
Frequently Asked Questions What kind of oil do I use? AW32 or AW46 hydraulic oil Does this lift come with a plug? The lift does not come with a plug, you will need to get a 110V, or 220V connection with plug How do I hook up the electrical? Yellow Green Wire: ground Wire Blue and Brown Wire:... -
Page 19: Maintenance
Maintenance Daily Pre-operation Check oil hoses for leaks Check the electrical system Check that the plug bolts are firmly screwed Check that the safety teeth and safety block match Weekly Check the flexibility of moving parts Check the working conditions of safety parts Check the amount of oil in the oil tank Every 1 Month Check the tightness of the hydraulic system and screw firm the joints... -
Page 20: Warranty
Warranty 5 years lifting structure Post, Cross Bar, Carriage, Arms, Safety Locks, Safety Lock Pins, Arm Pin, Runway 3 years hydraulic Power Unit/Station, Cylinder 2 years electrical Electrical, Buttons, Solenoid, Limit Switch 1 Year Balance Cable, Safety Lock Release Cable, Safety Covers, Support Bar, Ramps, Hydraulic Hose, Fittings No Warranty Door Guard, Rubber Pads, Truck Adaptors **Parts only!! Labor costs for someone to install replacement parts are NOT covered. - Page 21 Parameters Model MS9000XT Rated Lifting Capacity 9,000 LBS Minimum Height 4 3/4" Lifting Height 47 1/4" Platform Length Without Ramps 62 5/8" Platform Length With Ramps 85 1/4" Platform Width 20 1/4" Motor Parameters 110V/220V Hydraulic Oil AW32 or AW46...
-
Page 22: Exploded View
Exploded View Pump: Description Description Motor Oil Hose Tie-In Hydraulic Block Electrical Unloading Valve Overflow Valve Single Way Valve Fitting Gear Pump Cushion Valve Oil Tank Absorbing Oil Pipe Oil Tank Cover Oil Filer Oil Back Pipe Throttle Valve... - Page 23 Exploded View Lift: Description Description Base Plate (right) Inner scissor arm Base plate(left) Slider for inner scissor arm(left) Outer scissor arm Slider for inner scissor arm(right)
- Page 24 Exploded View Description QTY No. Description Platform(left) Power arm idler pulley Platform(right) Power arm roller Slider for outer scissor arm Power arm roller shaft 10 Power arm oil-free shaft sleeve Power arm spacer washer Power arm shaft Non-metallic hexagon lock nut Locking shaft for inner scissor Scissor arm shaft Scissor arm shaft washer...
- Page 25 Automotive Lift Institute Store You probably checked the ALI’s Directory of Certified Lifts(www.autolift.org/ali-directory-of- certified-lifts/) before making your most recent Lift purchase, but did you know the ALI Store (www.autolift.org/ali-store/) offers a wide variety of professional, easy-to-use, and reasonably priced training and safety materialsthat will make your garage a safer place to work? The ALI Store is your trusted source for workplace safety! Visit today and get the training and materials you need to worksafely:...
- Page 26 Special Notes Environmental damage : Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling: To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected.
