Summary of Contents for McIntosh CR7
- Page 2 IMPORTANT SAFETY INSTRUCTIONS THESE INSTRUCTIONS ARE TO PRO- TECT YOU AND THE MclNTOSH IN- STRUMENT. BE SURE TO FAMILIARIZE YOURSELF WITH THEM. 1. Read all instructions - Read the safety and oper- ating instructions before operating the instrument. 2. Retain Instructions - Retain the safety and oper- ating instructions for future reference.
- Page 3 15. Nonuse Periods - Unplug the power cord from the 19. CAUTION: TO PREVENT ELECTRICAL SHOCK DO AC power outlet when left unused for a long NOT USE THIS (POLARIZED) PLUG WITH AN EX- period of time. TENSION CORD, RECEPTACLE OR OTHER OUTLET 16.
-
Page 4: Table Of Contents
Contents Your CR 7 and CR 8 Remote Control will give you many years of satisfactory performance. If you have any questions, please contact, INTRODUCTION 3 FRONT PANEL 4 CUSTOMER SERVICE HAND HELD REMOTE 5 Mclntosh Laboratory Inc. CONNECTIONS 6, 7, 8, 9 2 Chambers Street Binghamton, New York 13903-9990 CONNECTIONS 10, 11, 12... -
Page 5: Introduction 3
2) you can select the listening sound source (tuner, compact disc, or preamplifier) for the local area while other areas can choose their listening source independently; 3) you can adjust the volume in the local area and not affect the volume in other areas; 4) when the tuner is the sound source, you can select the stations you wish to hear on either AM or FM and depending on the tuner, scan... -
Page 6: Front Panel
The touch-buttons on the black anodized aluminum remote control. A red LED above the MUTE button front pane! of the CR7 control AC power to the local will light, and the program will be silenced. To hear area, source selection, system mute and volume. In... -
Page 7: Hand Held Remote 5
TUNER Selects the Mclntosh tuner as the source of sound. 1 Thru 7. . Press one of the numbered buttons to recall from the electronic memory in the tuner the preset AM or FM station assigned to the numbered button, Press the FM button to switch to the FM circuits of the tuner. - Page 8 Two types of AC power outlets are provided on the the Mclntosh tuner to the CR7. Insert one end into back panel of the CR7. Two are black and one is red. the REMOTE CONTROL socket on the tuner and the The black outlets are switched on or off when the CR7 other into the TUNER CONTROL socket on the CR7.
-
Page 9: Connections 7
FIGURE 1 FIGURE 2 CONNECTIONS 7... - Page 10 Included with the CR8 is a cable with 25 pin com- puter connectors on each end. Connect one end of this cable to the TO AREA CONTROLLER socket on the CR7 and the other end to the AREA CONTROLLER INPUT socket on the CR8.
- Page 11 FIGURE 3 CONNECTING 9...
- Page 12 300' AREA CONTROLLER. Multiple sensors and the R 606 of RG-59/U between the R 606 and R 607 Remote Sensors. may be used with either the CR7 or CR8, When used 10 CONNECTING...
-
Page 13: Connections
AUDIO OUTPUT L. The tuner con- area independent of the tuner in the main area. The nected to the CR7 in the main area is controlled by 25 pin cable provided to interconnect the CR8 with and can be heard in only the main area, while the... - Page 14 FIGURE 6 Figure 6 illustrates the use of an existing video system, the video signals, the remote control data distribution system to interconnect the remote sen- and the DC voltages to operate the remote sensors sors with a remote control module. By inserting a can all be conducted on the existing RG-59/U video pair of Mclntosh R 615 VIDEO CABLE AND DC CON- distribution system without any interaction.
-
Page 15: Connections
TROLLER INPUT socket. Up to five remote areas can end of the cable with the 25 pin connectors is plug- be added to a CR7 main area each with independent source selection and volume adjustment. If wanted, ged into the 1st area remote CR8 socket labelled TO NEXT AREA CONTROLLER and the other end is additional tuners can be added as in Figure 5. -
Page 16: Accessories
R 617 CABLE TO ADD 2ND TUNER R 603 ADAPTER PANEL TO REMOTE SYSTEM Ihe CR7 or CR8 can be installed in a cabinet Five connectors terminate the R 617 cable. panel with the R 603 ADAPTER PANEL Us ap-... -
Page 17: Performance Limits 15
C R 7 FREQUENCY RESPONSE FREQUENCY RESPONSE + 0, -0.5 dB from 20 Hz to 20 KHz + 0, - 0.5 dB from 20 Hz to 20 KHz RATED OUTPUT VOLTAGE RATED OUTPUT VOLTAGE 2.5V 2.5V SENSITIVITY SENSITIVITY All input, 0.775V for 2.5V rated output AM input, 0.775V for 2.5V rated output TOTAL HARMONIC DISTORTION TOTAL HARMONIC DISTORTION... -
Page 18: Block Diagram
16 BLOCK DIAGRAM... - Page 19 BLOCK DIAGRAM 17...
