- Page 1 UPER ® SC113 Chassis Series SC113TQ-R650UB SC113TQ-700CB SC113TQ-700UB SC113TQ-R650CB SC113TQ-560UB USER’S MANUAL 1.0a...
- Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.
- Page 3 About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC113 1U chassis. Installa- tion and maintenance should be performed by experienced technicians only. Supermicro’s SC113 1U chassis features a unique and highly-optimized design.
-
Page 4: Manual Organization
Manual Organization Chapter 1 Introduction The first chapter provides a checklist of the main components included with this chassis and describes the main features of the SC113 chassis. This chapter also includes contact information. Chapter 2 System Safety This chapter lists warnings, precautions, and system safety. You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed before installing and servicing this chassis. -
Page 5: Table Of Contents
Chassis Features .................... 1-2 CPU ......................... 1-2 Hard Drives ..................... 1-2 I/O Expansion Slots ..................1-2 Peripheral Drives ..................... 1-2 Contacting Supermicro ..................1-3 Returning Merchandise for Service ..............1-4 Chapter 2 System Safety Overview ......................2-1 Warnings and Precautions ................2-1 Preparing for Setup .................. - Page 6 Reliable Ground ..................6-3 Rack Mounting Instructions ................6-4 Identifying the Sections of the Rack Rails ............6-4 Inner Rail Extension ..................6-5 Outer Rails ...................... 6-6 Installing the Chassis into a Telco rack ............6-9 Appendix A SC113 Chassis Cables...
- Page 7 Preface Appendix B SC113 Power Supply Specifications Appendix C BPN-SAS-113TQ Backplane...
- Page 8 SC113 Chassis Manual Notes viii...
-
Page 9: Chapter 1 Introduction
Chapter 1 Introduction Overview Supermicro’s SC113 1U chassis features a unique and highly-optimized design. The chassis is equipped with high efficiency power supply. High performance fans pro- vide ample optimized cooling for the dual processor modules and 8 hot-swap drive bays offer maximum storage capacity in a 1U form factor. -
Page 10: Chassis Features
I/O Expansion Slots The SC113 Chassis includes either one full I/O expansion slot or two full I/O expan- sion slots and one low profile I/O slot. See the chart on the previous page for your specific chassis model. -
Page 11: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 12: Returning Merchandise For Service
For faster service, RMA authorizations may be requested online (http://www. supermicro.com/support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping. -
Page 13: Chapter 2 System Safety
fields are generated. You will also need it placed near at least one grounded power outlet. When con- figured, the SC113 chassis includes one power supply. "R" models (i.e. SC113TQ- R650UB chassis) includes a redundant power supply and require two grounded outlets. -
Page 14: Electrical Safety Precautions
SC113 Chassis Manual Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SC113 from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room’s emergency power-off switch, disconnection switch or electrical outlet. -
Page 15: General Safety Precautions
Chapter 2 System Safety radiation exposure, do not open the enclosure or use the unit in any uncon- ventional way. General Safety Precautions • Keep the area around the chassis clean and free of clutter. • Place the chassis top cover and any system components that have been re- moved away from the system or on a table so that they won’t accidentally be stepped on. - Page 16 SC113 Chassis Manual • Do not let components or PCBs come into contact with your clothing, which may retain a charge even if you are wearing a wrist strap. • Handle a board by its edges only; do not touch its components, peripheral chips, memory modules or contacts.
-
Page 17: Chapter 3 Chassis Components
System fans for the SC113 chassis are powered from the serverboard. These fans are 1U high and are powered by 4-pin connectors. Mounting Rails The SC113 can be placed in a rack for secure storage and use. To setup your rack, follow the step-by-step instructions included in this manual. -
Page 18: Power Supply
SC113 Chassis Manual Power Supply Each SC113 chassis model includes one or two high-efficiency power supplies rated at 560, 650 or 700 Watts. "R" models include a second redundant, hot-swappable power supply. In the unlikely event your power supply fails, replacement is simple and can be done without tools. -
Page 19: Chapter 4 System Interface
Chapter 4 System Interface Chapter 4 System Interface Overview There are several LEDs on the control panel and on the drive carriers that provide system and component status. This chapter explains the meanings of all LED indi- cators and the appropriate responses that need to be taken. Figure 4-1. -
Page 20: Control Panel Buttons
SC815 Chassis Manual Control Panel Buttons The SC815 chassis includes two or three push-buttons located on the front panel: a reset button, a power on/off button, and a UID button • Reset: The reset button is used to reboot the system. •... -
Page 21: Control Panel Leds
Chapter 4 System Interface Control Panel LEDs The control panel located on the front of the SC815 chassis has up to five LEDs. These LEDs provide critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any action that may be required. -
Page 22: Drive Carrier Leds
Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs The SC113 chassis uses SAS/SATA drives. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. -
Page 23: Power Supply Leds
Chapter 4 System Interface nection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. • Red: The red LED to indicate an SAS/SATA drive failure. If one of the SAS/SATA drives fail, you should be notified by your system management software. -
Page 24: All Other Power Supplies
SC815 Chassis Manual All Other Power Supplies • Solid Green: When illuminated, this green LED indicates that the power supply is on. • Solid Amber: When illuminated, the amber LED indicates the power supply is plugged in and turned off, or the system is off but in an abnormal state. -
Page 25: Chapter 5 Chassis Setup And Maintenance
Chapter 5 Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform mainte- nance on the chassis. The only tool you will need to install components and perform maintenance is a Phillips screwdriver. -
Page 26: Removing The Chassis Cover And Front Bezel
SC113 Chassis Manual Removing the Chassis Cover and Front Bezel Removing the Chassis Cover: Remove the screws securing the top cover to the chssis. Slide the cover toward the rear of the chassis. Lift the cover off the chassis. -
Page 27: Installing Hard Drives
Chapter 5 Chassis Setup and Maintenance Installing Hard Drives The SC113 chassis excepts 8 hot-swappable hard drives. Only SAS or enterprise SATA HDD are recommended. Removing Hard Drive Trays from the Chassis 1. Press the release button on the drive tray. This extends the drive bay handle. - Page 28 SC113 Chassis Manual Figure 5-3: Hard Drive Carrier Installing a Hard Drive into a Drive Carrier Remove the dummy drive, which comes pre-installed in the drive carrier, by removing the screws securing the dummy drive to the carrier. Note that these screws cannot be reused on the actual 2.5"...
-
Page 29: Dvd-Rom Drive Installation
Chapter 5 Chassis Setup and Maintenance DVD-ROM Drive Installation The SC113 chassis models include a DVD-ROM, which is usually pre-installed. Installing or Replacing a DVD-ROM Drive Power down the system and if necessary, remove the server from the rack and the front bezel from the chassis. - Page 30 SC113 Chassis Manual Reconnect the data and power cables. Replace the chassis cover (replace the server in the rack, if necessary) and power up the system.
-
Page 31: Installing The Motherboard
Permanent and Optional Standoffs Standoffs prevent short circuits by creating space between the motherboard and the chassis surface. The SC113 chassis includes permanent standoffs in locations used by most motherboards. These standoffs accept the rounded Phillips head screws included in the SC113 accessories packaging. - Page 32 SC113 Chassis Manual Installing the Motherboard Review the documentation that came with your motherboard. Become familiar with component placement, requirements, and precautions. Disconnect the power supply and lay the chassis on a flat surface. Open the chassis cover. If necessary, remove the riser card. To do this, remove the two screws hold- ing the card in place and lift the card from the chassis.
-
Page 33: Expansion Card Setup
(like SC113TQ-700CB) include one full height slot. "U" model chassis include two full-height expansion slots and one low-profile expansion slot. Note: You must use a riser card to install expansion cards into any SC113 chassis. Riser cards are sold separately. - Page 34 SC113 Chassis Manual Riser Card Riser Card Bracket Screws Figure 5-8: Chassis with a Riser Card Installing an Expansion Card Confirm that you have the correct riser card for your chassis model and the add-on card includes a standard bracket.
-
Page 35: Installing The Air Shroud
Chapter 5 Chassis Setup and Maintenance Installing the Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. The SC113 chassis air shroud does not require screws to set up. Figure 5-9: Air Shroud Installation Air Shroud Installation If your motherboard uses 8 DIMMS, skip this step. If your motherboard uses between 9 and 16 DIMMS, you must install the optional air shroud flap. -
Page 36: Checking The Air Flow
SC113 Chassis Manual Checking the Air Flow Check the Airflow Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically. -
Page 37: System Fans
Four heavy duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis' internal temperature. The SC113 chassis contains counter-rotating fans. Each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions. This counter-ro- tating action generates exceptional airflow and works to dampen vibration levels. - Page 38 SC113 Chassis Manual Figure 5-11: Chassis Fans The SC113 Chassis includes four pre-installed fans. Two additional open slots are available so that. up to two more fans may be added. Replacing a System Fan If necessary, open the chassis while the power is running to determine which fan has failed.
-
Page 39: Power Supply
If the power supply unit fails, the system will shut down and you will need to replace the unit. Replacement units can be ordered directly from Supermicro (see contact information in the Preface). As there is only one power supply unit in the SC113 Chassis, power must be completely removed from the server before removing and replacing the power supply unit for whatever reason. - Page 40 SC113 Chassis Manual Release Tab Figure 5-12: Removing the Power Supply Replacing the Power Supply Power down the server and unplug the power cord. If your chassis includes a redundant power supply (at least two power modules), you can leave the server running and remove only one power supply.
-
Page 41: Chapter 6 Rack Installation
Chapter 6 Rack Installation Chapter 6 Rack Installation Overview This chapter provides a quick setup checklist to get your chassis up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way. -
Page 42: Rack Precautions
SC113 Chassis Manual Warnings and Precautions! Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installation, stabilizers should be attached to the rack. -
Page 43: Rack Mounting Considerations
Chapter 6 Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra). -
Page 44: Rack Mounting Instructions
SC113 Chassis Manual Rack Mounting Instructions This section provides information on installing the SC113 chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using. - Page 45 Chapter 6 Rack Installation Figure 6-2. Identifying the Sections of the Rack Rails (right side rail shown) Installing the Inner Rails Place the inner rack extensions on the side of the chassis aligning the hooks of the chassis with the rail extension holes. Make sure the extension faces "outward"...
-
Page 46: Outer Rails
SC113 Chassis Manual Secure to the Front of the Rack Secure to the Rear of the Rack Attach Outer Racks together Figure 6-3. Assembling the Outer Rails Outer Rails Installing the Outer Rails to the Rack Attach the short bracket to the outside of the long bracket. You must align the pins with the slides. - Page 47 Chapter 6 Rack Installation SCALE 0.380 Figure 6-4. Installing the Outer Rails to the Server Rack...
- Page 48 SC113 Chassis Manual Figure 6-5. Installing the Rack Rails Installing the Chassis into a Rack Confirm that chassis includes the inner rails and rail extensions . Also, confirm that the outer rails are installed on the rack. Line chassis rails with the front of the rack rails.
-
Page 49: Installing The Chassis Into A Telco Rack
Chapter 6 Rack Installation Installing the Chassis into a Telco rack To install the chassis into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack. - Page 50 SC113 Chassis Manual Notes 6-10...
-
Page 51: Appendix A Sc113 Chassis Cables
This appendix lists supported cables for your chassis system. It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www.supermicro.com. Cables Included with SC111 Chassis (SAS/SATA) - Page 52 SC111 Chassis Manual Compatible Cables These cables are compatible with the SC111 Chassis. This section lists cables included with the SC111 Chassis packages. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.
-
Page 53: Extending Power Cables
Appendix A Chassis Cables Extending Power Cables Although Super Micro chassis are designed with to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards. - Page 54 SC111 Chassis Manual Notes...
- Page 55 Appendix B Power Supply Specifications Appendix B SC111 Power Supply Specifications This appendix lists power supply specifications for your chassis system. SC111-560CB, SC111-560UB 560W MFR Part # PWS-562-1H20 100-240V Rated AC 60-50Hz Voltage 6.5 - 2.6 Amp +5V standby 2 Amp +12V 46.5 Amp +5V 15 Amp +3.3V 15 Amp...
- Page 56 SC111 Chassis Manual Notes...
- Page 57 Appendix C BPN-SAS-113TQ Backplane Specifications Appendix C BPN-SAS-113TQ Backplane To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electric Static Discharge (ESD) can damage electronic components. To prevent dam- age to your system, it is important to handle it very carefully.
- Page 58 SC113 Chassis • Make sure that the SAS-113TQ backplane is securely and properly installed on the motherboard to prevent damage to the system due to power shortage. C-3 An Important Note to Users • All images and layouts shown in this user's guide are based upon the latest PCB revision available at the time of publishing.
- Page 59 Appendix C BPN-SAS-113TQ Backplane Specifications Jumper Settings and Pin Definitions C-4 Front Connectors and Jumpers +12V +12V 9072 RST UPGRADE JP46 SB#2 JP52 SB#1 JP33:MODE SEL JP29 1-2:SGPIO JP13 2-3:I2C I2C#2 JP45 JP33 BUZZER RST C137 REV 1.02 I2C#1 Figure 1-1: Front Jumpers and Connectors Front Connectors and Jumpers Power Connectors (4-pin) JP10, JP13 Connector #6 J14...
- Page 60 SC113 Chassis C-5 Front Connector and Pin Definitions #1. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JP10 provide 4-Pin Connector (JP10) power to the backplane. See the table on the Pin# Definition right for pin definitions.
- Page 61 Appendix C BPN-SAS-113TQ Backplane Specifications #6 and #7. I C Connectors C Connector Pin Definitions The I C Connectors, designated JP44 and (JP44 and JP45) JP45, are used to monitor HDD activity and Pin# Definition status. See the table on the right for pin Data definitions.
-
Page 62: Explanation Of Jumpers
SC113 Chassis C-6 Front Jumper Locations and Pin Definitions +12V +12V 9072 RST UPGRADE JP46 SB#2 JP52 SB#1 JP33:MODE SEL JP29 1-2:SGPIO JP13 2-3:I2C I2C#2 JP45 JP33 BUZZER RST C137 REV 1.02 I2C#1 Explanation of Jumpers Connector Pins To modify the operation of the backplane, jumpers can be used to choose between optional settings. -
Page 63: Front Led Indicators
Appendix C BPN-SAS-113TQ Backplane Specifications C and SGPIO Modes and Jumper Settings This backplane can utilize I C or SGPIO. SGPIO is the default mode and can be used without making changes to your jumpers. The following information details which jumpers must be configured to use I C mode or restore your backplane to SGPIO mode. - Page 64 SC113 Chassis C-7 Rear Connectors and LED Indicators SAS #5 SAS #1 SAS #3 SAS #6 SAS #4 SAS #2 SAS #7 SAS #0 Rear SAS/SATA Connectors Rear Connector SAS Drive Connector Number Number SAS #0 SAS/SATA HDD #0 SAS #1...
- Page 65 Appendix C BPN-SAS-113TQ Backplane Specifications Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic...
- Page 66 SC113 Chassis Notes C-10...
