Hoss Series
6 Burner Gas Grill/
6 Burner Gas Grill & Griddle
Important: Keep this Owner's Manual for
convenient reference and for part
replacement.
Read this Owner's manual carefully and be
sure your gas grill is properly assembled,
installed and maintained. Failure to follow
these instructions could result in serious
injury and/or property damage.
Please make sure the cylinder valve
connection device shall properly and
safely connected with the connection
device attached to the inlet of the
pressure regulator.
OWNER'S MANUAL
For Outdoor Use Only
Captivate Brands USA, Inc.
25541 Arctic Ocean Drive,
Lake Forest, CA.92630
If you have any questions or problems,
you can contact our customer service at
1-855-200-8445 ext 102 or
service@brandmangrill.com
from 9:00 AM - 5:00 PM Monday to Friday.
(Pacific). All emails and voice-mail calls
will be answered within 24 hours.
1
Model: BMHOS-GG/
BMHOS-GGD
Item:
BG2421A6/
BG2421B6
Advertisement
Table of Contents
Related Manuals for BRAND-MAN Hoss BMHOS-GG
Summary of Contents for BRAND-MAN Hoss BMHOS-GG
- Page 1 OWNER’S MANUAL Hoss Series 6 Burner Gas Grill/ 6 Burner Gas Grill & Griddle Model: BMHOS-GG/ BMHOS-GGD Item: BG2421A6/ BG2421B6 Important: Keep this Owner’s Manual for For Outdoor Use Only convenient reference and for part replacement. Captivate Brands USA, Inc. 25541 Arctic Ocean Drive, Read this Owner’s manual carefully and be Lake Forest, CA.92630...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE SAVE THESE INSTRUCTIONS WARNING DANGER Do not store or use gasoline or If you smell gas: other flammable liquids or Shut off gas to the appliance. vapors in the vicinity of this or Extinguish any open flame. - Page 3 pressure of 11” water column (W.C.) for connection SAFETY PRECAUTIONS to an LP gas cylinder. • Only use the regulator and the hose assembly The LP gas cylinder must be constructed and supplied with your gas grill. Replacement regulators marked in accordance with specifications of the and hose assemblies must be those specified in this U.S.
-
Page 4: Burner Flame Check
WARNING Burner Flame Check A strong gas smell, or the hissing sound of gas Flame Slight indicates a serious problem with your gas grill or Yellow the LP gas cylinder. Failure to immediately follow Slight the steps listed below could result in a fire or Blue explosion that could cause serious bodily injury, Burner... -
Page 5: Table Of Contents
TABLE OF CONTENTS Safety Precautions ----------------------------------2-4 Burner Flame Check----------------------------------- 4 Model Description------------------------------------- 6 Tools Required for Assembly------------------------ 6 Parts Diagram------------------------------------------- 7 Parts List------------------------------------------------7-8 Hardware ------------------------------------------------ 8 Assembly Steps -------------------------------------9-17 Connecting LP Gas cylinder to LP Grill --------- 18 Operating Instructions ------------------------- 18-20 Cleaning and Care ------------------------------- 21-23 Warranty ------------------------------------------------ 24 Customer Service------------------------------------- 24... -
Page 6: Model Description
6 Burners Grill Description 6 burners gas barbecue designed with: - BMHOS-GG/BG2421A6: 6 burners Grills; - BMHOS-GGD/BG2421B6: 3 burners Grills and 3 burners Griddles; 6 independently controlled stainless steel burners; The rated power of each main burner is 10,000 BTU with a total of 60,000BTU; Push and turn ignition system for firing up;... -
Page 7: Parts Diagram
Parts Diagram (3pcs for BMHOS-GGD BMHOS-GGD & 6pcs for BMHOS-GG) 18 (2pcs for & BMHOS-GG) 4pcs for 26 (For BMHOS-GGD ） 25 (For BMHOS-GGD) 24(1 for BMHOS-GGD & 2 for BMHOS-GG) Parts List BMHOS-GG / BG2421A6 Part# Description Part# Description Cylinder Hook Grill Assembly Grease Cup Holder... -
Page 8: Hardware
Parts List BMHOS-GGD / BG2421B6 Part# Description Part# Description Grease Cup Holder 2pcs Grill Assembly Left Leg Grease Cup 2pcs 2pcs Right Leg Lid Handle Side Shelf 2pcs Condiment Shelf Front Panel Cooking Grid 2pcs Gas Tank Blocker-Long Flame Tamer 3pcs Grease Tray 2pcs... -
Page 9: Assembly Steps
Assembly Steps • Attach and install Bottom Shelf (21) between Left Leg (2) and Right Leg (3) Step 1 with four Screws (A) as shown below. • Install on the two Castors with brake (10) on the Right Leg (3) as shown. Step 2 •... - Page 10 Assembly Steps • Secure two screws (B) onto each side of the Grill Assembly (1) with leaving Step 3 2.1 inches gap on each screw. • With the help of another person, put the Grill Assembly (1) on the cart assembly prepared in step 2 as shown below.
- Page 11 Assembly Steps • Install the Front Panel (5) onto the front of the cart with four screws (A) Step 5 as shown below. • Install the Magnet Assembly (8) on each side of the cart with two screws (G) each Step 6 as shown below.
- Page 12 Assembly Steps • Install the Condiment Shelf (4) at the front of the cart and on top of the Step 7 Front Panel with two screws (H) as shown. • Attach the two Wire for Condiment Shelf (22) onto the condiment shelf with Step 8 four screws (G) as shown below.
- Page 13 Assembly Steps • Install the Cylinder Hook (13) on the left side of cart with two screws (A). Step 9 • Ensure the screws are tightened. • Install the Side Shelf (17) with four screws (E) on each side. Step 10 figure 1 figure 2...
- Page 14 Assembly Steps • Unscrew the screws from the Lid Handles (16) and set aside. Step 11 heat pads and screws set aside previously as shown below. Step 12 • Open the lid. • as shown. NOTE: There are only 3 Flame Tamers for BMHOS-GGD/BG2421B6 (No Flame tamers under the Griddle).
- Page 15 Assembly Steps BMHOS-GG • Install two Warming Racks (24) for and one Warming Rack (24) Step 13 BMHOS-GGD as shown below accordingly. BMHOS-GG/ BG2421A6 BMHOS-GGD/ BG2421B6 • With the lid open, For BMHOS-GG/BG2421A6: put on 2 Cooking Grids (18)into each firebox. Step 14 For BMHOS-GGD/BG2421B6: put on 2 Cooking Grids (18) into left firebox and one Griddle(25)into the right firebox.
- Page 16 Assembly Steps • Attach Gas Tank Blocker-Long (6) with two Gas Tank Blocker-Short (7) on each Step 15 side of the cart and sercure with two screws (I) each as shown . • Unscrew the screws pre-assembled on the crossbeam, slide in the Grease Step 16 tray(20)as shown below, and then tighten the screws until the Grease tray are completely inserted.
- Page 17 Assembly Steps • Install the Grease Cup Holder (14) underneath the grease tray with Step 17 two wing screws (F) as shown. • Put on the Grease Cup (15) onto the installed grease cup holder. • Put on the gas cylinder onto the cylinder hook as shown. Step 18...
-
Page 18: Connecting Lp Gas Cylinder To Lp Grill
USING, CONNECTING & DISCONNECTING LP GAS TANK The installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code CSA B149.1, or Propane Storage and Handling Code, CSA B149.2, or the Standard for Recreational Vehicles, ANSI A119.2/NFPA 1192, and CSA 2240 RV Series, Recreational Vehicle Code 20 lb... - Page 19 OPERATING INSTRUCTIONS (CONTINUE) Checking for leaks 1. Make two to three oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are in the “OFF” position. 3. Spray some solution on the tank valve up to the regulator connection. 4.
- Page 20 OPERATING INSTRUCTIONS (CONTINUE) CAUTION: DO NOT obstruct the flow of combustion and ventilation air. Figure D 1. Check for obstructions of airflow to the burners. Spiders, insects and Flame Slight webs can clog the burner/venturi tube. A clogged burner tube can Yellow lead to a fire.
-
Page 21: Cleaning And Care
CLEANING AND CARE CAUTION: 1. All cleaning and maintenance should be done when Barbecue is cool and with the fuel supply disconnected. 2. DO NOT clean any barbecue part in self-cleaning oven. The extreme heat will damage the finish. 3. DO NOT enlarge valve orifices or burner ports when cleaning the valves or burners. Notices 1. - Page 22 CLEANING AND CARE Clean venturi of each burner with small bottle brush or compressed air. Remove all residue and dirt from burner surface. 10. Clean any clogged ports with a stiff wire (such as an opened paper clip). 11. Inspect burners for any damage (cracks or holes). If damage is found, replace with new burner(s) from manufacturer.
- Page 23 CLEANING AND CARE First Use Before cooking on your gas grill and griddle combo for the first time, you will want to “burn off” the grill to eliminate any odor or foreign matter. Just ignite the burners, lower the hoods, and operate grill on max setting for 3 to 5 mintes.
-
Page 24: Warranty
Warranty Two-Year Limited Warranty This warranty is non-transferable and does not cover failures due to misuse of improper installation or maintenance. This warranty is for replacement of defective parts only. We are not responsible for incidental or consequential damage. This warranty does not cover corrosion or discoloration after the grill is used, or lack of maintenance, hostile environment, accidents, alterations, abuse or neglect. -
Page 25: Troubleshooting
Troubleshooting Problem Possible Cause Prevention/Cure Make sure regulator is securely attached to the LP gas tank per LP gas tank valve is closed “Installing LP Gas Tank,” then turn LP gas tank valve to “OPEN” LP gas tank is low or empty Exchange, refill or replace LP gas tank Turn LP gas tank valve to “CLOSED”... - Page 26 Troubleshooting Problem Possible Cause Prevention/Cure High or gusting winds Do not use grill in high winds Low on LP Gas Exchange, refill or replace LP gas tank Flame goes out Overfilling prevention device may have been Refer to “Sudden drop in gas flow or reduced flame height” (see above) activated Grease buildup...
- Page 27 Captivate Brands USA, Inc. 25541 Arctic Ocean Drive, Lake Forest, CA.92630 If you have any questions or problems, you can contact our customer service at 1-855-200-8445 ext 102 or service@brandmangrill.com from 9:00 AM - 5:00 PM Monday to Friday. (Pacific). All emails and voice-mail calls will be answered within 24 hours.
