INTELLIVIBE™ NANO
LED LIGHT
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
Digital copies of all IntelliVibe Nano manuals can be found
at www.pentair.com, or by scanning the provided QR code.
Se pueden encontrar copias digitales de todos los manuales
de IntelliVibe Nano en www.pentair.com, o escaneando el
código QR proporcionado.
Des copies numériques de tous les manuels IntelliVibe
Nano peuvent être trouvées sur www.pentair.com, ou en
scannant le code QR fourni.
SAVE THESE INSTRUCTIONS
INSTALLATION
USER'S GUIDE
AND
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair Pool Products INTELLIVIBE NANO
Summary of Contents for Pentair Pool Products INTELLIVIBE NANO
- Page 1 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS Digital copies of all IntelliVibe Nano manuals can be found at www.pentair.com, or by scanning the provided QR code. Se pueden encontrar copias digitales de todos los manuales de IntelliVibe Nano en www.pentair.com, o escaneando el código QR proporcionado.
-
Page 2: Table Of Contents
Replacing the Light Assembly (In an Existing Pool or Spa) ......TROUBLESHOOTING ................... REPLACEMENT PARTS ................IntelliVibe Nano Models ................IntelliVibe Nano Replacement Parts ............. Available Niche Kits ..................READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL INTELLIVIBE™ NANO LED Light Installation and User’s Guide... -
Page 3: Important Warning And Safety Instructions
IMPORTANT WARNING AND SAFETY INSTRUCTIONS SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS LIGHT IS NOT INSTALLED AND USED CORRECTLY. INSTALLERS, POOL OPERATORS AND POOL OWNERS MUST READ THESE WARNINGS AND ALL INSTRUCTIONS BEFORE USING THE POOL AND/OR SPA LIGHT. Most states and local codes regulate the construction, installation, and operation of public pools and spas, and the construction of residential pools and spas. - Page 4 FOR LIGHT OPERATION, ONLY USE A SAFETY ISOLATION TRANSFORMER. FIXED POOL AND SPA CONTROLLER SPECIFICATION: 14 VAC 50/60 Hz. IntelliVibe Nano Lights are approved to be installed in a vertical position (facing up). Vertical light installations are recommended only in non-occupant areas of the pool (e.g.
-
Page 5: Installation
INSTALLATION LIGHT OVERVIEW The IntelliVibe Nano is rated for both underwater and air operation. OUTPUT LIGHTING TABLE • IntelliVibe Controller Maximum: 200 W • Individual Output Maximum: 100 W • IntelliVibe Nano Output: 2 W IF USING PS300 300 VOLT-AMP TRANSFORMER... -
Page 6: Light Installation In Nano Niche Or 1.5" Wall Fitting (Usa)
The following describes how to install the light in a 1-1/2″ wall fitting. Note: IntelliVibe Nano lights are approved for horizontal and vertical installation. For Intellivibe Nano installation in anything OTHER than a standard wet conduit 1.5" NPT return fitting, the light requires a custom niche for installation. Refer to the IntelliVibe Nano Niche Installation Manual (P/N 619148) for custom niche installation. -
Page 7: Light Installation In Nano Niche Or 1.5" Wall Fitting (Canada)
LIGHT INSTALLATION IN NANO NICHE OR 1.5″ WALL FITTING (CANADA) Be sure the electrical system of your pool conforms with the following requirements of the Canadian Electrical Code (CE), and all local codes and ordinances. A licensed or certified electrician must install the electrical system to meet or exceed those requirements before the light and (fixture- housing) is installed. -
Page 8: Dry/Sealed Conduit Installation (Use Provided Kit)
DRY/SEALED CONDUIT INSTALLATION (USE PROVIDED KIT) Dry/sealed conduit installation requires one of the niche fitting kits shown below. Refer to the Nano Niche Installation Manual (P/N 619148) for fitting installation instructions. The pool water level must be below the light wall fitting. Route the light power cord through the 1.5″... -
Page 9: Wet Conduit Installation
Note: The Threaded Adapter (P/N 602274) for IntelliVibe Nano’s 1-1/2″ standard fitting is not included with the light and must be purchased. Note: The IntelliVibe Nano is a low-power (2 W) LED luminaire that produces significantly less light than a 12 W luminaire (such as a MicroBrite or IntelliVibe Micro). - Page 10 WET CONDUIT INSTALLATION (continued) Ensure the inside of the wall fitting and threaded adapter are free of debris, then thread the light clockwise into the wall fitting until hand-tight. HAND-TIGHTEN ONLY. OVER-TIGHTENING CAN PERMANENTLY DAMAGE THE LIGHT. Turn light clockwise. Cord will un-twist as light is threaded into wall fitting.
-
Page 11: Fiber Optic Retrofit Applications
FIBER OPTIC RETROFIT APPLICATIONS The IntelliVibe Nano LED Light may be suitable for many fiber optic retrofit applications. IMPORTANT: Before proceeding with the fiber optic retrofit installation, verify that the light fits properly before removing the fiber optic system. Refer to Light Dimensions on page 1. -
Page 12: Wiring Diagram
WIRING DIAGRAM BLACK WHITE WHITE GREEN BLACK INTELLIVIBE™ NANO LED Light Installation and User’s Guide... -
Page 13: Maintenance
MAINTENANCE REPLACING THE LIGHT ASSEMBLY (IN AN EXISTING POOL OR SPA) This underwater light must be installed by a licensed or certified electrician or a qualified pool professional in accordance with the current National Electrical Code (NEC), NFPA 70 or the Canadian Electrical Code (CEC), CSA C22.1 and all applicable local codes and ordinances. -
Page 14: Troubleshooting
TROUBLESHOOTING If lights are not turning on: Ensure power is being supplied to the IntelliVibe controller. Refer to the IntelliVibe Controller Manual (P/N 619140). Ensure lights are wired to IntelliVibe controller correctly. Refer to the IntelliVibe Controller Manual (P/N 619140). Ensure IntelliVibe controller is installed properly and provisioned to the Pentair Home App. -
Page 15: Replacement Parts
PART NUMBER DESCRIPTION 602268 Light Assembly, 50 foot cord 602269 Light Assembly, 100 foot cord 602270 Light Assembly, 150 foot cord INTELLIVIBE NANO REPLACEMENT PARTS PART NUMBER DESCRIPTION 602271* Niche Kit, Gunite 602272* Niche Kit, Vinyl 602273* Niche Kit, Fiberglass 602274 1.5-inch Fitting Adapter... -
Page 16: Available Niche Kits
AVAILABLE NICHE KITS 1/2″ Conduit Gunite Kit (P/N 602271) Gunite Cover Gunite Niche Wall Panel Liner 1/2″ Conduit Vinyl Kit Sealing Cover (P/N 602272) Gasket multiple colors available Cover Install Tool Liner Sealing Gasket Vinyl Liner Niche 1/2″ Conduit Fiberglass Kit Sealing Gasket (P/N 602273) Fiberglass Niche... - Page 17 NOTES INTELLIVIBE™ NANO LED Light Installation and User’s Guide...
- Page 18 NOTES INTELLIVIBE™ NANO LED Light Installation and User’s Guide...
- Page 19 NOTES INTELLIVIBE™ NANO LED Light Installation and User’s Guide...
- Page 20 1620 HAWKINS AVE., SANFORD, NC 27330 • (919) 566-8000 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • (805) 553-5000 All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners. ©...
