Maytag Atlantis Neptune MDG9800 Service Manual
  1. Manuals
  2. Brands
  3. Maytag Manuals
  4. Dryer
  5. Atlantis Neptune MDG9800
  6. Service manual
Maytag Atlantis Neptune MDG9800 Service Manual

Maytag Atlantis Neptune MDG9800 Service Manual

Sloped-front electric and gas dryer
Hide thumbs

Advertisement

Quick Links

Download this manual
Appliance 911
Atlantis_Neptune_Electric_and_Gas_Dryer_Service_Manual
16023110

Advertisement

loading
Need help?

Need help?

Do you have a question about the Atlantis Neptune MDG9800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maytag Atlantis Neptune MDG9800

Summary of Contents for Maytag Atlantis Neptune MDG9800

  • Page 1 Appliance 911 Atlantis_Neptune_Electric_and_Gas_Dryer_Service_Manual 16023110...
  • Page 2 16023110...
  • Page 3 MDG9800 MDE9800 MDE6800 MDG6800 MDE7000 MDE7600 MDG7600 MDE8600 MDG8600 16023110...
  • Page 4 16023110...
  • Page 5 16023110...
  • Page 6 16023110...
  • Page 7 MDE7500 (Canada) ......................10-16 MDG7500 ..........................10-17 MDG6200 ..........................10-18 MDE7600 ..........................10-19 MDG7600 ..........................10-20 MDE7600 (Canada) ......................10-21 MDE8600 ..........................10-22 MDE8600 (Canada) ......................10-23 MDG8600 ..........................10-24 MDE6200 ..........................10-25 16023110 Contents ©2000 Maytag Appliances Sales Company...
  • Page 8 MDE6200 (Canada) ......................10-26 MDE6800 ..........................10-27 MDG6800 ..........................10-28 MDE9800 ..........................10-29 MDG9800 ..........................10-30 16023110 Contents ©2000 Maytag Appliances Sales Company...
  • Page 9 16023110...
  • Page 10 16023110...
  • Page 11 16023110...
  • Page 12 16023110...
  • Page 13 16023110...
  • Page 14 16023110...

  • Page 15: Product Specifications

    MDE/DG5500 Facia (LED Screen) MDE/DG7500 Facia (LCD Screen) PRODUCT SPECIFICATIONS Same specifications as outlined in service manual part number 16009968. 16023110 Section 1. General Information © 2000 Maytag Appliances Sales Company...
  • Page 16 16023110...
  • Page 17 16023110...
  • Page 18 16023110...
  • Page 19 16023110...
  • Page 20 16023110...
  • Page 21 16023110...
  • Page 22 16023110...
  • Page 23 BB2(3) 120VAC closed. Door must be Door Sense BB2(3) BB1(1) 120VAC closed. Thermistor J4(1) J4(2) 5VDC F=10K ohms F=1754 ohms Sensor Bar J4(3) J4(4) 24VDC 16023110 16010279 Section 2. Electrical Components & Testing (16009968-01) © 2000 Maytag Appliances Sales Company...
  • Page 24 J7(11) J7(15) press care J7(9) J7(15) air fluff J710) J7(15) start/pause J7(11) J716) signal (-) J7(12) J7(15) J7(9) J7(16) signal (+ ) J7(12) J7(16) 16023110 16010279 Section 2. Electrical Components & Testing (16009968-01) © 2000 Maytag Appliances Sales Company...
  • Page 25 16023110...
  • Page 26 16023110...
  • Page 27 16023110...
  • Page 29 16023110...
  • Page 30 16023110...

  • Page 31: Console Removal

    Note the hooked tabs on bottom of the console, which engage the slots in the top cover. Figure 4-11 Figure 4-9 16023110 16010279 Section 4. Console Assembly (16009968-01) © 2000 Maytag Appliances Sales Company...
  • Page 32 16023110...
  • Page 33 16023110...
  • Page 34 16023110...
  • Page 35 16023110...
  • Page 36 16023110...
  • Page 37 16023110...
  • Page 38 16023110...
  • Page 39 16023110...
  • Page 40 16023110...
  • Page 41 16023110...
  • Page 42 16023110...
  • Page 43 16023110...
  • Page 44 16023110...
  • Page 45 16023110...
  • Page 46 16023110...
  • Page 47 16023110...
  • Page 48 16023110...
  • Page 49 16023110...
  • Page 50 16023110...
  • Page 51 16023110...
  • Page 52 16023110...
  • Page 53 16023110...
  • Page 54 16023110...
  • Page 55 16023110...
  • Page 56 16023110...
  • Page 57 16023110...

  • Page 58: Special Features

    Advertising diagnostic/help code information displayed mode. No functions will be run except provides information about the machine. illumination of the touch screen panel. 16023110 Section 9. Dryer Controls Overview © 2000 Maytag Appliances Sales Company...

  • Page 59: Special Tests

    (^) & (v) keys. SPECIAL TESTS The following table lists the various tests available while in the Service Mode, which can be accessed by pressing the following keys: 16023110 Section 9. Dryer Controls Overview © 2000 Maytag Appliances Sales Company...
  • Page 60 LED. To exit the test at any point, press the damp dry (>) & sensor dry keys again for 5 seconds or press the off key to exit diagnostic mode. 16023110 Section 9. Dryer Controls Overview © 2000 Maytag Appliances Sales Company...
  • Page 61 Service Mode until 5 minutes of The screen displays the status of the touch inactivity has occurred at the end of this screen test that was just performed. The cycle. 16023110 Section 9. Dryer Controls Overview © 2000 Maytag Appliances Sales Company...
  • Page 62 16023110...
  • Page 63 16023110...
  • Page 64 2 seconds or press the OFF key to exit Time (-) - 15 Key Service Mode. View current Sensor Dry Level (^) - 13 cycle temperature in Celsius Very Dry (<) - 15 Key 16023110 Section 9. Dryer Controls Overview 9-12 16023110 © 2000 Maytag Appliances Sales Company...
  • Page 65 Action Taken Dryer Thermistor Check for: Short Sensed thermistor Clogged lint resistance is screen. very low, Restricted with a vent system. temperature Failed thermistor. > 175 degrees. 16023110 Section 9. Dryer Controls Overview 9-13 16023110 © 2000 Maytag Appliances Sales Company...
  • Page 66 BB2(3) BB1(1) 120VAC Door must be open Thermistor J4(1) J4(2) 5VDC 70 F = 10K ohms 150 F = 1754 ohms Sensor Bar J4(3) J4(4) 24VDC 16023110 Section 9. Dryer Controls Overview 9-14 16023110 © 2000 Maytag Appliances Sales Company...

  • Page 67: Sensor Dry

    Service Mode, the machine will exit Service Mode and return to the state just prior to where the user first entered Service Mode. create a edit a delete a favorite favorite favorite 16023110 Section 9. Dryer Controls Overview 9-15 16023110 © 2000 Maytag Appliances Sales Company...
  • Page 68 On/Off. The screen will also display the current status of the component inputs to the control board. toggle motor toggle heater (if motor is running) toggle sensor exit system circuit check 16023110 Section 9. Dryer Controls Overview 9-16 16023110 © 2000 Maytag Appliances Sales Company...

  • Page 69: Diagnostic Codes

    If relay does not function, replace machine control board. Not Used Non Volatile Problem Disregard Memory Detected with integrity parameters stored in EEPROM memory. 16023110 Section 9. Dryer Controls Overview 9-17 16023110 © 2000 Maytag Appliances Sales Company...
  • Page 70 BB2(3) BB1(1) 120VAC Door must be open Thermistor J4(1) J4(2) 5VDC 70 F = 10K ohms 150 F = 1754 ohms Sensor Bar J4(3) J4(4) 24VDC 16023110 Section 9. Dryer Controls Overview 9-18 16023110 © 2000 Maytag Appliances Sales Company...
  • Page 71 16023110 9-19...
  • Page 72 16023110...
  • Page 73 16023110...
  • Page 74 16023110...
  • Page 75 16023110...
  • Page 76 16023110...
  • Page 77 16023110...
  • Page 78 16023110...
  • Page 79 16023110...
  • Page 80 16023110...
  • Page 81 16023110...
  • Page 82 16023110...
  • Page 83 16023110...
  • Page 84 16023110...
  • Page 85 16023110...
  • Page 86 16023110...
  • Page 87 16023110...
  • Page 88 16023110...
  • Page 89 16023110...
  • Page 90 16023110...
  • Page 91 16023110...
  • Page 92 (Canada) 16023110...
  • Page 93 16023110...
  • Page 94 (Canada) 16023110...
  • Page 95 16023110...
  • Page 96 16023110...
  • Page 97 16023110...

  • Page 98: Section 10. Wiring Diagrams

    MDE6800 16023110 10-27 16010297 Section 10. Wiring Diagrams (16009968-02) © 2000 Maytag Appliances Sales Company...
  • Page 99 MDG6800 16023110 10-28 16010297 Section 10. Wiring Diagrams (16009968-02) © 2000 Maytag Appliances Sales Company...
  • Page 100 MDE9800 16023110 10-29 16010297 Section 10. Wiring Diagrams (16009968-02) © 2000 Maytag Appliances Sales Company...
  • Page 101 MDG9800 16023110 10-30 16010297 Section 10. Wiring Diagrams (16009968-02) © 2000 Maytag Appliances Sales Company...
