Page 1: Repair Parts
DRYER Repair Parts List MODEL NUMBER MDG9206AWW When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: CONTROL PANEL Model: MDG9206AWW LD11-99...
-
Page 3: Control Panel
Section: CONTROL PANEL Part No. Description Series Qty 33001918 PANEL, CONTROL (WHT) 22002339 SCREW Note: SCREW, CONTROL PANEL 33001621 SKIRT, TIMER DIAL (WHT) 22001659 TIMER KNOB - GREY 22001664 TIMER KNOB INSERT/CAP (WHT) 33001619 BUTTON, PUSH TO START (WHT) 33001690 SCREW, TIMER 33001624 TIMER... - Page 4 Section: CABINET-FRONT Model: MDG9206AWW LD12-57...
-
Page 5: Cabinet-Front
Section: CABINET-FRONT Part No. Description Series Qty 33001896 COVER, TOP (WHT) 2 N 33001897 CABINET (WHT) 22002049 CLIP Note: CLIP, FRONT PANEL 213280 FRONT PANEL BRACKET/FASTENER Note: RETAINER, FRONT PANEL 22001995 SCREW Note: SCREW, FRONT PANEL 310376 CLIP, WIRE HARNESS 213007 SCREW, CABINET 310376... - Page 6 Section: DOOR Model: MDG9206AWW LD17-26...
- Page 7 Section: DOOR Part No. Description Series Qty 33001767 SEAL, SHROUD 22002247 HOOK, SECURITY 33001900 SHROUD (WHT) 22001995 SCREW Note: SCREW, TUMBLER FRONT & SHROUD 33001768 SCREW, SHROUD Note: SCREW, SHROUD & OUTLET DUCT 33001509 SWITCH, DOOR 33001760 BRACKET, HINGE 8 N 33001174 PLUG, DOOR CATCH 33001791 CATCH, DOOR (W/PLUG)
- Page 8 Section: CABINET-REAR Model: MDG9206AWW LD12-61...
-
Page 9: Cabinet-Rear
Section: CABINET-REAR Part No. Description Series Qty 1 N 33001897 CABINET (WHT) 2 N 33001827 BRACKET, CABINET HINGE 33001795 COVER, TERMINAL BLOCK 22001995 SCREW Note: SCREW, TERMINAL BLOCK COVER 211881 GROMMET, CORD 33001246 CORD, POWER 22001995 SCREW Note: SCREW, CABINET *Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available... - Page 10 Section: MOTOR DRIVE Model: MDG9206AWW CD17-12...
-
Page 11: Motor Drive
Section: MOTOR DRIVE Part No. Description Series Qty 33001789 HOUSING, BLOWER 33001800 DUCT ASSY., EXHAUST 22001995 SCREW Note: SCREW, EXHAUST DUCT ASSEMBLY 410233 RING, RETAINING 33001790 WHEEL, BLOWER 312967 CLAMP, BLOWER HOUSING 33001855 SCREW (HEX HEAD) Note: SCREW, HOUSING COVER 7 N 313561 SCREW----NA Note: SCREW, HOUSING COVER 307250... - Page 12 Section: GAS VALVE Model: MDG9206AWW CD14-5...
-
Page 13: Gas Valve
Section: GAS VALVE Part No. Description Series Qty 306195 CONVERSION KIT (NATURAL TO LP) Note: CONVERSION KIT (NAT. TO LP) 306204 CONVERSION KIT (LP TO NATURAL) Note: CONVERSION KIT (LP TO NAT.) 304971 SCREW Note: SCREW, IGNITER 304970 IGNITER ASSY, GAS VALVE 33001247 BURNER ASSY. - Page 14 Section: WIRING INFORMATION Model: MDG9206AWW 15002304...
- Page 15 Section: TUMBLER Model: MDG9206AWW LD13-43...
- Page 16 Section: TUMBLER Part No. Description Series Qty 33001799 OUTLET DUCT ASSEMBLY Note: OUTLET DUCT ASSEMBLY 33001808 FILTER, LINT 33001758 SEAL, BLOWER 33002190 SCREW (#10-3/8") 310376 CLIP, WIRE HARNESS 33001802 FRONT, TUMBLER (W/SEAL) 306508 TUMBLER BEARING KIT 210720 RIVET Note: RIVET, TUMBLER 22001996 SCREW Note: SCREW, INLET DUCT 210932...
