Category
Spreading Factor
6
7
8
9
10
11
12
1
Greater link budget is possible with higher gain antenna.
2
RFS_L500: RF sensitivity, Long-Range Mode, highest LNA gain, LNA boost, 500 kHz bandwidth using split Rx/Tx
path.
Indian Models (MTXDOT-EU1-IN1)
Category
Radio Frequency
ISM Bands
Certifications and Compliance
EMC
Radio
Safety
Transmission
Max Transmitter Power Output (TPO) 14 dBm
Maximum Receive Sensitivity
1
Link Budget
Max Effective Isotropic Radiated
Power (EiRP)
Deep Sleep Current
Category
Receive Sensitivity
®
xDot Developer Guide
Description
2
Australia
-111 dBm
-116 dBm
-119 dBm
-122 dBm
-125 dBm
-127 dBm
-129 dBm
Description
IN865-867 MHz
EN55022 Class B
EN55024
CISPR 22:2008
EN 300 220
IEC 60950-1 2nd ED AM1 & AM2
IEC 62368-1:2014
-137 dBm
147 dB Point-to-Point
151 dB Point-to-Multipoint
10 dBm
< 2 uA
Description
SPECIFICATIONS AND PIN INFORMATION
