Ubisys 2 Series Quick Start Manual

Control Unit C4 (Series 2)
Zigbee and Bluetooth
Router R0
90 - 270 V~, 50/60 Hz
Item No.: 1120 (12 - 400 V=)
Specifications
The C4 is a wireless control unit with four universal inputs for controlling
other smart home components. In the current in-wall version, it is compatible
to every standard in-wall mounted housing. It is not only suitable for new buil-
dings but also for renovations – for due to the use of radio technology, retro-
fitting with ubisys components has no special requirements for the electrical
installation. The Control Unit C4 offers full functionality when combined with
other components of the ubisys Smart Home product line or other Zigbee
systems and allows for example:
•
Freely configurable assignments between control elements and
electrical consumers
•
Zigbee router integrated
•
Integration in scenes and group controlling
•
Interoperable with many Smart Home systems of other manufacturers
•
Can be connected to switches and motion sensors
Note:
The Control Unit C4 is to be considered as an additional option, which provi-
des additional inputs. The components D1(-R), S1-R, S2(-R), J1(-R) already
have two inputs.
Dimensions
17 mm 47 mm
Installation
The Control Unit C4 is designed for installation in flush mounted sockets
according to DIN 49073. For installation behind a switch, the use of deep
sockets is recommended.
Router R0
Funkvernetzt
AC 230 V ~ / 50 Hz
When connecting the Router R0 the included push-wire terminals can be
used.
Zigbee Initial Commissioning via Gateway or Hub
1.
2.
3.
4.
Zigbee Direct (Bluetooth) Initial Commissioning – without Gateway or
Hub
Zigbee Direct allows for integration and control of Zigbee devices directly
via Bluetooth. With Zigbee Direct, users can seamlessly interact with their
Zigbee networks via smartphone, tablet or other Bluetooth-enabled devices:
12 mm
47 mm
1.
2.
3.
4.
5.
2
1
Note:
Zigbee Direct supports many commissioning options and is an open stan-
dard. Zigbee Direct also allows further settings, such as the configuration of
inputs, links, groups and scenes, in third-party systems that do not provide
these functions themselves. It is also possible to update the firmware this
way. Just one Zigbee Direct device in the network is sufficient to set up and
control all the other Zigbee devices.
47 mm 12 mm
Factory Reset
Via Power-Cycle Sequencing: To reset the device to factory settings without
directly accessing the device itself (only the power supply), follow this on/off
sequence:
1.
2.
3.
4.
2
4 3 2 1
5.
Bedieneinheit C4
Funkvernetzt
Leads: AC 230 V ~ / 50 Hz
4 3
Connect the unit to a power source (according to the leads).
Open a Zigbee network: when using the ubisys gateway, tap Confi-
guration -> Basic Configuration -> Open for new devices in the
ubisys app (if you are using third-party gateways or apps, follow the
corresponding procedure).
The Zigbee network is open and the device joins.
The device appears in the component list: Configuration -> Basic
Configuration -> Components.
12 mm
Connect the unit to a power source (according to the leads).
When using the ubisys iOS app, tap on Settings -> Facilities -> Pen
top right -> New Facility -> Create via Bluetooth.
Select the R0 from the list of available components.
Note: The last four digits of the serial number are displayed.
Confirm the creation of a new system with this device.
Under Configuration -> Basic configuration -> Components the
2 virtual gateway will be displayed together with the R0.
1
47 mm
Power on for at least 15 seconds.
Power off for at least 15 seconds.
Power on for at least 0.5 seconds but no more than 2 seconds.
Repeat steps 2.-3. three more times (four times in total). The final
2
power-on must last at least 30 seconds until the device resets and
restarts (see step 5.).
The device will automatically reboot to the original factory settings.
2 1
47 mm 12 mm
2 1
12 mm 47 mm
Router R0
90 - 270 V~ , 50/60 Hz
(12 - 400 V=)
2
Page 1/2 As per 02/2025
4
4 3
12 mm
