Summary of Contents for MAXTEK 71127
- Page 1 DAB & FM Radio MODEL NUMBER: 71127 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section 10-13. System • System Menu Options Information & Safety Instructions • Sleep • Alarm (See page 16) Contents & Features • EQ • Backlight Layout & Controls • Inactive Standby • Lang. Control Method • Reset • On/Off/Standby •... -
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality MAXTEK product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. -
Page 4: Information & Safety Instructions
Information & Safety Instructions This radio is powered by 4 x ‘AA’ size alkaline batteries (not included). Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. • Never throw batteries into a fire or expose to excessive heat sources. •... -
Page 5: Contents & Features
Contents & Features Contents 1 x DAB / FM Radio 1 x 5V Mains Adaptor Features • DAB receiver (174MHz - 240MHz) • FM receiver (87.5MHz - 108.00MHz) • Stores 10 FM presets • Stores 10 DAB presets • Powered by 4 x AA alkaline batteries (not included) •... -
Page 6: Layout & Controls
Layout & Controls On/Off Mode Scan Tune + Aerial Vol +/- Standby Select / Snooze Info/Menu Preset Alarm Tune - Display Battery Headphone DC In Port After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL:... -
Page 7: Control Method
Control Method On/Off/Standby Press the button to turn the radio on. Once on press it again to enter standby mode or hold it to turn the radio off. Using The Buttons All the button actions are just a quick press unless otherwise stated in the required action. -
Page 8: Dab Mode
DAB Mode Selecting A Station Use the tune +/- buttons to cycle through the available DAB stations on the display. Press the dial to tune the radio into the station that is shown on the display. Scan You can retune or refresh the amount of DAB stations available by pressing the ‘Scan’... -
Page 9: Drc
Manually Tune DAB To manually tune the radio select ‘Manual Tune’ in the menu options. Use the tune +/- buttons to tune the radio in then press the dial to keep the current tuning. Save as a preset if required (see page 14). This helps in poor signal areas to get a clearer signal. -
Page 10: Fm Mode
FM Mode Select FM Mode Press ‘Mode’ to change from DAB to the FM function. Auto Tune FM To auto tune to the next available radio station press and hold either ‘Tune +/-’ buttons for 3 seconds. This will start the FM auto scan. ‘+’... -
Page 11: Scan Settings
Scan Settings You can change the Auto Tune search ability between ‘all stations’ and ‘strong stations’. Select ‘Scan Settings’ from the menu options. Press the tune +/- buttons to cycle between either ‘Strong Stations’ or ‘All Stations’. Press the dial to select the required option. The asterisk in the top right corner indicates current selection. -
Page 12: System Menu Options
System Options System Menu Options Press and hold the ‘Info/Menu’ button until you see either ‘Scan Setting’ in FM mode or ‘Full Scan’ in DAB mode. Press the tune +/- button to cycle through the options until you get to ‘System’ then press the dial to select it. - Page 13 Time All the time and date functions and preferences can be altered here. Press the tune +/- buttons to cycle through the options and press the dial to select. The options here are: Time/Date > Auto Update > Set 12/24 > Date Format. Time/Date With this option you can manually set the time and date.
-
Page 14: Backlight
All the preferences can be altered by pressing the tune +/- buttons to cycle through the options and press the dial to select. Backlight You can change the brightness and light duration of the display. The options here are: Time Out > On Level > Dim Time Out This is to set the duration of time before the display dims. -
Page 15: Inactive Standby
Inactive Standby You can set the radio to turn it’s self to standby after a preselected period of time with this feature. Once selected from the system options you will have the following options: OFF > 2 > 4 > 5 > 6 (Hours) Cycle through the options with the tune +/- buttons and press the dial to select an option. -
Page 16: Dab/Fm Preset
DAB/FM Preset Storing a Preset Press and hold ‘Preset’ for 5 seconds, then use the ‘Tune +/-’ buttons to cycle through the available preset slots. Press the dial to save the station. You will see a saved message appear if successful. The radio has 10 preset slots for both DAB and FM selections. -
Page 17: Alarm
Alarm Setting the Alarm There are 2 alarms you are able to set on this radio. When the radio is on and not in standby Press ‘Alarm’ to set alarm 1 or press ‘Alarm’ twice to set alarm 2 and press the dial to select. The process is controlled by using tune +/- buttons to cycle through the available options and pressing the dial to select it. -
Page 18: Turning The Alarm On/Off
Alarm Turning The Alarm On/Off When the radio is in standby mode press the ‘Alarm’ button and use the tune +/- buttons to cycle through the options on the display and press the dial to select. The combination options with icons are: Alarm 1: Off >... -
Page 19: Specifications
Specifications Specifications • DAB receiver (174MHz - 240MHz) • FM receiver (87.5MHz - 108.00MHz) • Stores 10 FM presets • Stores 10 DAB presets • Powered by 4 x AA alkaline batteries (not included) • 5v mains adapter (included) • Auto adjusting clock •... - Page 20 Intentionally Left Blank...
- Page 21 Intentionally Left Blank...
-
Page 22: Warranty Certificate
Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 23: Warranty Card
Warranty Card DAB & FM Radio Model Number: 71127 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
