- Page 1 APPLICATION MODEL YXE-G01U(E) Thank you very much for purchasing this wired controller. Please read this use and installation instructions carefully before installing and using this appliance and keep this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions......................1 Introduction to Wired Controller ..................3 Function Setting........................4 Basic Functions........................4 Auxiliary Functions........................8 Drop-down Menu......................10 Installation of Wired Controller ..................13 Checking accessories ......................13 How to install........................13 Installer Settings .........................16 Fault and After-sales Service....................21... -
Page 3: Safety Precautions
Safety Precautions 1. Important Notice ● We pursue a policy of continuous improvement in design and performance of products. Company reserves the right to change the specifications without notice. ● We cannot anticipate every possible circumstance that might involve a potential hazard. ●... - Page 4 Safety Precautions ● Do not splash water on the appliance and do not touch it with wet hands. These products are equipped with electrical components, only an authorized personnel should perform the installation. ● Must not touch or regulate safety device in the appliance. Otherwise serious accident may occur. ●...
-
Page 5: Introduction To Wired Controller
Introduction to Wired Controller Introduction to wired controller Auxiliary functions on the right page Status bar Zone for basic functions Power on/off Return button button Homepage button Function and status Icon Icon Function Description Icon Function Description Self clean mode Temperature adjustment function Health mode Locale function... -
Page 6: Function Setting
Function Setting Basic Functions Homepage displays basic function icons. Mode setting This wired controller should be used with the air conditioner. it can be used for cooling, heating, dry and fan etc. For other functions and settings, please refer to the specific operation in this manual. Enter the mode selection function Select a mode &... -
Page 7: Timer Setting
Function Setting Timer setting The air conditioner operation and stop time can be set through the timer function. Enter the timer setting function Add a timer Set the start and end time of the timer (on/off) Confirm timing setting NOTE: The selection range for timed hours is 0~23. - Page 8 Function Setting Zone control setting & group control setting Zone control setting The zone control setting realizes the control of each outlet of the indoor unit separately. Enter the zone control setting function Turn on/off the outlet of each zone and the increase/decrease the air valve opening Zone renaming NOTE:...
-
Page 9: Group Control Setting
Function Setting Group control setting The group control function realizing grouping of the set zones and simultaneous on/off control of each zone within the group. Enter the “ZONE” function Add a group Select zones Enable/disable group control Group renaming Enter the group rename interface Select a name from the list Enter the group name selection interface... -
Page 10: Auxiliary Functions
Function Setting Auxiliary Functions In the on/off state, slide the screen to the left to open the right page and display the auxiliary functions. Effective functions are presented as dark icons, while ineffective functions are presented as light icons. Function selection Slide to the right page Select &... -
Page 11: Self Clean
Function Setting Step-by-step operation of some functions Self Clean Select & enable the “Self Clean” function Confirm During the process, you can choose to cancel... -
Page 12: Drop-Down Menu
Function Setting Drop-down Menu Implement shortcut operations for some functions in the drop-down menu. Function selection Enter the drop-down menu Select & enable the function(s) Introduction to functions of drop-down menu Functions Function describe To enter the Wi-Fi setting state. WiFi The screen lock protects your air conditioning from potential damage by children Locking... - Page 13 Function Setting Step-by step operation of some functions WiFi setting Select & enable the WiFi Start WLAN matching Successful matching Wait for matching NOTE: After setting successfully, the Wi-Fi indicator “ ” will be displayed. If the matching fails, return to the previous level to rematch. Notifications Tap on the “Notifications”...
- Page 14 Function Setting Settings Select the corresponding setting & enter Tap on the "Settings" the setting page Introduction to settings menu Menu Setting describe WLAN Setting To enter the Wi-Fi setting state. When the wired controller is connected to the network, under the "Date&Time" setting, Date &...
-
Page 15: Installation Of Wired Controller
Installation of Wired Controller Installation of Wired Controller Checking accessories ： Check the following accessories are included with the unit before installation Installation and Wood Connecting Screw operating manual Screw cable 2pcs 2pcs How to install 1.Selecting the Installation Location. Please select the installation location according to safety precautions. - Page 16 Installation of Wired Controller 3. Passing the wired controller cable out of the lower cover. There are four ways to pass the wired controller cord out, please select according to actual situation. Upper outlet left outlet right outlet lower outlet 4.
- Page 17 Installation of Wired Controller ② For Installation on the Switch Box Please fix lower cover with screws (2pcs) in accessories. Screws (Break through the reserved screw holes on the lower cover) 6. Well mount the upper cover Align the upper cover with the hasp of lower cover of the wired controller, and then press the upper cover onto the lower cover.
-
Page 18: Installer Settings
Installation of Wired Controller Installer Settings The installer settings introduced in this chapter should be operated by professionals, and the operation password can be found in the product technical service manual. First-use guide When Powering on and turning on the wired controller for the first time, follow the guide to make the following settings: When the wired controller is turned on, the WLAN matching guide page will be popped up automatically. - Page 19 Installation of Wired Controller Zone Settings (If no zone control damper is equipped, this step will be automatically skipped.) (1) Setting of number of zones The number of zones must be the same with the actual zones’ quantity at the site. If this is wrong ,the system may not work properly.
- Page 20 Installation of Wired Controller (2) Zone renaming (3) Setting of default spill zone Choose one spill zone unless there is a permanent open zone used as spill zone. Otherwise there will be no spill zone when all zones are closed and damage maybe caused by high pressure building up inside ducts if air conditioner is running.
- Page 21 Installation of Wired Controller (4) Set the number of outlets corresponding to each damper according to the actual situation. Different air outlet size represents different coefficient, 8 inch represents 0.6, 10 inch represents 1.0, 12 inch represent 1.4, below is the size & coefficient chart. We need to add each air outlet coefficient together and input the total air outlet coefficient into wired controller, we need to follow “half adjust”...
-
Page 22: Install Settings
Installation of Wired Controller Install settings Enter the "Settings" menu and then select the Select the setting item and enter the "Install Settings" corresponding setting interface EE Reading & Setting The EE reading & setting parameters is shown as follows: Parameter Value &... -
Page 23: Fault And After-Sales Service
Installation of Wired Controller Fault and After-sales Service When the system has a failure, an error prompt Tap on the "Notifications" to query the error code will pop up on the screen. Close the pop-up window. NOTE: When an error occurs, please contact local after-sales service personnel for handling; The error code table is detailed in the product technical service manual. - Page 24 VERSION NO. 2360671-A...
