OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time of
publication. However, HYUNDAI reserves the right to make changes
at any time so that our policy of continual product improvement
may be carried out.
This manual applies to all models of this vehicle and includes
descriptions and explanations of optional as well as standard
equipment.
As a result, you may find material in this manual that does not apply
to your specific vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ioniq 9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai Ioniq 9

Summary of Contents for Hyundai Ioniq 9

  • Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the Department of Transportation and other government agencies in your country.

  • Page 3: Safety Message

    SAFETY MESSAGE Your safety, and the safety of others, are very important. This Owner's Manual provides you with many safety precautions and operating procedures. This information alerts you to potential hazards that may hurt you or others, and may damage your vehicle. Safety messages found on vehicle labels and in this manual describe these hazards and what to do to avoid or reduce the risks.
  • Page 4 Friday between 6:30 AM and 3:00 PM PST. HYUNDAI MOTOR AMERICA Copyright 2025 HYUNDAI Motor America. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any...

  • Page 5: Table Of Contents

    Warnings and Indicators .................. 110 Cluster Settings ....................130 5. Convenience Features ..............135 Smart Key ......................135 Hyundai Digital Key ..................141 Fingerprint Authentication System ..............152 Door Locks ......................157 Theft-Alarm System ..................165 Advanced Rear Occupant Alert (ROA) ............166 Integrated Memory System (IMS) ..............
  • Page 6 Hood ........................ 206 Front Trunk ...................... 209 Power Liftgate ....................212 Smart Liftgate ....................219 Head-Up Display (HUD) ...................221 Vehicle System Over-the-Air (OTA) update ........... 224 Exterior Lights ....................227 High Beam Assist (HBA) ..................233 Interior Lights ....................236 Wipers and Washers ..................241 Automatic Climate Control System ...............
  • Page 7 Driver Assistance System Information ............409 Forward Collision-Avoidance Assist (FCA) ............. 415 Lane Keeping Assist (LKA) ................432 Blind-Spot Collision-Avoidance Assist (BCA) ..........436 Safe Exit Warning (SEW) .................444 Safe Exit Assist (SEA) ..................447 Manual Speed Limit Assist (MSLA) ..............451 Intelligent Speed Limit Assist (ISLA) ..............
  • Page 8 Appearance Care .................... 638 California Perchlorate Notice ................. 645 10. Vehicle Information, Reporting Safety Defects, and Consumer Information ..................647 Vehicle Specifications ..................647 Vehicle Load Limit ...................652 Vehicle Identifications ..................659 Operation in Foreign Countries ..............920 Vehicle Data Collection and Event Data Recorders ........921 Reporting Safety Defects ................922 Consumer Information ...................

  • Page 9: Introduction

    Congratulations, and thank you for choosing HYUNDAI. We are pleased to welcome you to the growing number of discerning people who drive HYUNDAI. We are very proud of the advanced engineering and high quality construction of each HYUNDAI we build.

  • Page 10: Vehicle Modifications

    Some vehicle interior sounds (including welcome chime, navigation alerts, or warning chimes) may be generated from the interior speakers or amplifier. Do not replace these components with anything other than the original Hyundai factory parts. Any unauthorized product may cause a malfunction of the vehicle interior sounds that may affect the intended operation of the vehicle.

  • Page 11: Vehicle Handling Instructions

    introduction_vehicle_handling_instructions.xml Vehicle Handling Instructions Specific design characteristics (higher ground clearance, track, etc.) give this vehicle a higher center of gravity than other types of vehicles. In other words they are not designed for cornering at the same speeds as conventional 2-wheel drive vehicles. Avoid sharp turns or abrupt maneuvers.
  • Page 12 introduction_vehicle_handling_instructions.xml Introduction...

  • Page 13: Picture Index

    picture_Index.xml 2. Picture Index This chapter shows the names of the vehicle components and the locations of the control systems. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.

  • Page 14: Interior Overview

    picture_index_exterior_overview_front_view.xml Tires and wheels........................864 Windows..........................191 Picture Index...

  • Page 15: Exterior Overview (Rear View)

    picture_index_exterior_overview_rear_view.xml Exterior Overview (Rear View) 1C_OutsideVehicleRearOverview Power liftgate........................210 Wide-rear view camera/Digital center mirror camera..........176, 807 Rear window wiper blade....................858 High mounted stop light....................891 Hidden antenna (Glass antenna)..................288 Rear combination light...................... 891 Reverse light........................891 License plate light......................891 Power liftgate open/close switch..................

  • Page 16: Interior Overview

    picture_index_interior_overview.xml Interior Overview 1C_SideInsideVehicleOverview Electric charging door open button................. 329 Hood open button......................204 Power liftgate open/close button..................210 ESC (Electronic Stability Control) OFF button..............375 EPB (Electronic Parking Brake) switch................370 Instrument panel illumination control button..............102 Steering wheel........................170 Steering wheel tilt/telescopic lever..................

  • Page 17: Center Console Overview

    picture_index_center_console_overview.xml Center Console Overview 1C_CenterInsideVehicleOverview Instrument cluster......................101 Horn.............................174 Driver's front airbag......................75 Start/stop button.......................346 Infotainment system......................286 Hazard warning flasher button..................814 Automatic climate control system................... 244 Glove box........................... 268 Passenger's front airbag..................... 84 Fingerprint authentication system................... 150 Auto Hold button.......................
  • Page 18 picture_index_center_console_overview.xml Power outlet........................272 Rear automatic climate control system................246 Picture Index...

  • Page 19: Steering Wheel Control Overview

    picture_index_steering_wheel_control_overview.xml Steering Wheel Control Overview 1C_SteeringWheelControlOverview Lighting control lever......................225 Wiper and washer control lever..................239 Paddle shifter........................359 Driving Assist button......................725 Vehicle Distance button....................725 Cluster display control....................... 128 Lane Driving Assist button....................746 Gear Shifting (Rotary gear shift dial)................353 Steering wheel audio controls..................288 Voice recognition...

  • Page 20: Motor Compartment Overview

    picture_index_engine_compartment_overview.xml Motor Compartment Overview For more information, refer to the 'Motor Compartment' section in chapter 9. Picture Index...

  • Page 21: Seats & Safety System

    seats_amp_safety_system.xml 3. Seats & Safety System This chapter explains how to use the seats and safety systems installed in the vehicle. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.

  • Page 22: Control Your Speed

    seats_amp_safety_system_important_safety_precautions.xml • ONLY use your mobile device when allowed by laws and conditions permit safe use. NEVER text or email while driving. Most states have laws prohibiting drivers from texting while driving. Some states and cities also prohibit drivers from using handheld phones while driving.

  • Page 23: Seats Overview

    seats_amp_safety_system_seats_overview.xml Seats Overview Safety Precautions Adjusting the seats so that you are sitting in a safe and comfortable position plays an important role for the safety of the driver and passengers, as much as seat belts and airbags when in a collision. WARNING Do not use a cushion that reduces friction between the seat and the passenger.
  • Page 24 seats_amp_safety_system_seats_overview.xml WARNING To prevent serious injury or death: • Never use one seat belt for more than one occupant. • Always position the seatback upright with the lap portion of the seat belt snug and low across the hips. • Never allow children or small infants to ride on a passenger's lap.
  • Page 25 seats_amp_safety_system_seats_overview.xml Leg support or cushion support (if equipped) Forward or rearward/seat cushion height/seat cushion angle (if equipped) Seatback bolster (if equipped) Front seat warmers Front air ventilation seats (if equipped) Walk-in seat switch (if equipped) Head restraint Rear seats 7-Seater 1C_RearSeatOverview_1 Walk-in seat switch Seatback angle/seatback folding...
  • Page 26 seats_amp_safety_system_seats_overview.xml 3rd row seatback folding 2nd row head restraint 3rd row head restraint 6-Seater (Power adjustment) 1C_RearSeatOverview_2 2nd row seat warmers/2nd row air ventilation seats Walk-in switch Seatback angle/Seatback folding Forward or rearward/Seat cushion angle Leg support Emergency strap folding 3rd row seatback angle 2nd row seatback folding/unfolding 3rd row seatback folding/unfolding...
  • Page 27 seats_amp_safety_system_seats_overview.xml INFORMATION Select Setup > Vehicle > Seat from the Settings menu in the infotainment system, you may use various convenience functions. The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. Seats &...

  • Page 28: Adjusting Front Seats

    seats_amp_safety_system_adjusting_front_seats.xml Adjusting Front Seats Before driving, adjust the seat to the proper position so that you can easily control the steering wheel, foot pedals and controls on the instrument panel. WARNING To prevent serious injury or death: • Never attempt to adjust the seat while the vehicle is moving. The seat could respond with unexpected movement and may cause loss of vehicle control resulting in a collision.

  • Page 29: Forward And Rearward Adjustment

    seats_amp_safety_system_adjusting_front_seats.xml Manual Adjustment (Passenger's Seat) if equipped The front seat can be adjusted by using the levers located underneath the front part of the seat or on the outer side of the seat. Forward and rearward adjustment 2C_AdjustSeatForwardBackwardmanual Slide the seat while pulling up and holding the seat slide adjustment lever. Release the lever at the position you desire.

  • Page 30: Seat Cushion Height Adjustment

    seats_amp_safety_system_adjusting_front_seats.xml Seat cushion height adjustment if equipped 2C_AdjustSeatHeightmanual • Push down on the lever several times to lower the seat cushion. • Pull up on the lever several times to raise the seat cushion. Lumbar support if equipped For more information, refer to the 'Lumbar support' section in this chapter.
  • Page 31 seats_amp_safety_system_adjusting_front_seats.xml Forward and rearward adjustment 2C_AdjustSeatForwardBackwardAuto Push the control switch forward or rearward to adjust the seat to the desired position. Seatback angle adjustment 2C_AdjustSeatBackAuto Push the control switch forward or rearward to adjust the seatback angle. Leg support adjustment if equipped 2C_LegSupportCautionAdjust •...
  • Page 32 seats_amp_safety_system_adjusting_front_seats.xml WARNING • When lowering or raising the Leg support, be careful not to have your hands or legs caught under the front seats or other surrounding parts of the Leg support. Unexpected injuries may occur. • Do not allow children to adjust the switch. Unexpected injuries may occur. •...
  • Page 33 seats_amp_safety_system_adjusting_front_seats.xml Lumbar support if equipped Type A 2C_AdjustSeatBackCushionAuto Press the front or rear portion of the switch to increase or decrease lumbar support. Type B (if equipped) 2C_AdjustSeatBackCushionAuto_1 Press the front or rear portion of the switch to increase or decrease lumbar support. Press the top or bottom portion of the switch to move the support position up or down.
  • Page 34 seats_amp_safety_system_adjusting_front_seats.xml Seat bolster if equipped 2C_AdjustSeatBolster 1. Push the adjustment lever clockwise, the seatback bolster is adjusted inward. Push the lever counterclockwise, the seatback bolster is adjusted outward. 2. Release the lever once the bolster reaches the desired position. Seat cushion support if equipped 2C_SeatCushionAdjustment •...
  • Page 35 seats_amp_safety_system_adjusting_front_seats.xml CAUTION Take the following precautions when using the relaxation comfort seat: • Do not use the relaxation comfort seat while the vehicle is moving. Using the comfort seat could increase the risk of injuries in the event of a collision or sudden stop. •...
  • Page 36 When relaxation comfort seat cannot be operated, reset the Integrated Memory System. If relaxation comfort seat does not operate even after resetting the Integrated Memory System, contact an authorized HYUNDAI dealer. Resetting the Relaxation mode For more information, refer to the 'Integrated Memory System (IMS)' section in chapter 5.
  • Page 37 seats_amp_safety_system_adjusting_front_seats.xml 2C_ErgoMotionSeatAVN WARNING Before actually using each function, try the functions with the vehicle parked. Comfortable stretch Comfortable stretch is a function that helps relieve fatigue of the pelvis and lower back due to driving. 2C_ComfortStreching Every time you press the button, you may select a mode or turn off the function in the following order.
  • Page 38 seats_amp_safety_system_adjusting_front_seats.xml Smart posture assist After driving for an hour, Smart Posture Assist automatically adjusts the pelvis and back portion of the seat to assist the posture. You can activate or deactivate Smart Posture Assist function from the Settings menu in the infotainment system.

  • Page 39: Seatback Pocket

    seats_amp_safety_system_adjusting_front_seats.xml Seatback pocket 2C_SeatBackPocket The seatback pocket is provided on the back of the front seatbacks. WARNING Do not put heavy or sharp objects in the seatback pockets. In an accident they could come loose from the pocket and injure occupants. Seats &...

  • Page 40: Adjusting Rear Seats

    seats_amp_safety_system_adjusting_rear_seats.xml Adjusting Rear Seats Before driving, adjust the seat to the proper position for passengers or cargo. WARNING • When returning the rear seatback from a folded to an upright position, hold the seatback and return it slowly. Ensure that the seatback is completely locked into its upright position by pushing on the top of the seatback.
  • Page 41 seats_amp_safety_system_adjusting_rear_seats.xml Seatback angle adjustment 2C_Adjust2ndSeat3seatsTypeBack 1. Pull up the seatback recline lever. 2. Hold the lever and adjust the seatback of the seat to the position you desire. 3. Release the lever and make sure the seatback is locked in place. The lever MUST return to its original position for the seatback to lock.
  • Page 42 seats_amp_safety_system_adjusting_rear_seats.xml Description Leg support adjustment • • Push the control switch forward to raise the leg support. • • Push the control switch rearward to lower the leg support. Seat cushion angle adjustment Push the front portion of the control switch up or down to control the seat cushion angle.
  • Page 43 seats_amp_safety_system_adjusting_rear_seats.xml 3. Hold the seat to safely get in or out of the 3rd row seat. INFORMATION If a seat is located in the center of 7-seater, it moves together when using the seat adjustment of the 2nd row seat behind the driver seat. Walk-in switch may not operate properly when: •...
  • Page 44 seats_amp_safety_system_adjusting_rear_seats.xml 1. When the walk-in switch is pressed, both the seat cushion and seatback tilt forward. 2C_2ndSeatworkinSwitchBack_1 2. Hold your seat and safely get into or out of the 3rd row seat. After getting on or off, push the seat backward and raise the seatback to its original position.
  • Page 45 seats_amp_safety_system_adjusting_rear_seats.xml 7-Seater, Passenger's side seat 2C_2ndSeatWorkinStrapRearView_1 • 6-Seater (manual adjustment): Pull the seat folding strap to move forward the 2nd row seats. • 6-Seater (automatic adjustment), 7-Seater (manual adjustment): Pull the seat folding strap to fold 2nd row seats. Hold the seat and lower it safely. WARNING Never attempt to pull the strap while the 2nd row seat is occupied as the seat may suddenly move and cause the passenger on the seat to be injured.

  • Page 46: Manual Adjustment

    seats_amp_safety_system_adjusting_rear_seats.xml Power adjustment 2C_3rdRowBackrestElectricAdjust 1. Press the 3rd row seat back angle adjustment switch located on the left and right of the 3rd row side trim. 2. Carefully lean back on the seat and adjust it to the desired position. 3.
  • Page 47 seats_amp_safety_system_adjusting_rear_seats.xml • When using it as a seat, pull the seatback folding lever (2nd row seat) to fully raise the seatback. Adjust the seatback to the desired angle and release the lever to lock in place. 2C_RearSeatFoldingStep_2 3rd row seat •...
  • Page 48 seats_amp_safety_system_adjusting_rear_seats.xml CAUTION • Be careful when loading cargo through the rear passenger seats to prevent damage to the vehicle interior. • When cargo is loaded through the rear passenger seats, ensure the cargo is properly secured to prevent it from moving while driving. •...
  • Page 49 seats_amp_safety_system_adjusting_rear_seats.xml Seatback remote folding (Cargo area) if equipped 2C_2ndSeatBackFoldingSwitch This feature can make it easier for you to fold or unfold the 2nd row, 3rd row seatback when the liftgate is open. 1. Press the folding/unfolding switch located on the cargo area. •...
  • Page 50 seats_amp_safety_system_adjusting_rear_seats.xml Type Operation When the switch is pressed, the left (2nd L) or right (2nd R) seatback of the 2nd row seat is folded. and when pressed again, it is unfolded. When the switch is pressed, the left (3rd L) or right (3rd R) seatback of the 3rd row seats is folded, and when pressed again, it is unfolded.
  • Page 51 seats_amp_safety_system_adjusting_rear_seats.xml 7-Seater 2C_RearArmrestFlip_1 You can open or close the armrest by pulling the top of the armrest forward or pushing it toward the seatback. Seats & Safety System...

  • Page 52: Head Restraints

    seats_amp_safety_system_head_restraints.xml Head Restraints The vehicle's front and rear seats have adjustable head restraints. The head restraints are designed to help protect passengers from whiplash and other neck and spinal injuries during a collision, especially a rear impact collision. WARNING To help reduce, the risk of serious injury or death in a crash, take the following precautions when adjusting your head restraints: •...

  • Page 53: Front Seat Head Restraints

    seats_amp_safety_system_head_restraints.xml Front Seat Head Restraints 2C_HeadrestOverview The driver's and front passenger's seats are equipped with adjustable head restraint for the passenger's safety and comfort. Adjusting the height up and down 2C_AdjustHeadrestUpDown Press and hold the release button on the head restraint support to adjust the height. Removing the head restraint Manual seat 2C_RemoveHeadrestManual...
  • Page 54 seats_amp_safety_system_head_restraints.xml Power seat 2C_RemoveHeadrestAuto 1. Recline the seatback with the seatback angle lever or switch. 2. Raise the head restraint as far as it can go. 3. Press the head restraint release button while pulling the head restraint up. Reinstalling the head restraint Manual seat 2C_InstallHeadrestManual Power seat...

  • Page 55: Rear Seat Head Restraints

    seats_amp_safety_system_head_restraints.xml 3. Adjust the head restraint to the appropriate height. 4. Return the seatback with the seatback angle lever or switch. Rear Seat Head Restraints 6-seater 2C_RearHeadrestPosition 7-seater 2C_RearHeadrestPosition_1 The rear seats are equipped with head restraints in all the seating positions for the passenger's safety and comfort.
  • Page 56 seats_amp_safety_system_head_restraints.xml 2nd Row Head restraint Adjusting the height up and down 2C_AdjustRearHeadrestUpDown Press and hold the release button on the head restraint support to adjust the height. Removing the head restraint 2C_AdjustRearHeadrestUpDown_3 1. Raise the head restraint as far as it can go. 2.
  • Page 57 seats_amp_safety_system_head_restraints.xml 2. Adjust the head restraint to the appropriate height. 3rd row automatic head restraint folding The head restraints in the 3rd row seats automatically fold together when the seatback is folded. 2C_3-rowAuto-foldingHeadrest • The seatbacks and head restraints will automatically fold by pulling the 3rd row seat folding straps or pressing the button (if equipped) located on the seatback.

  • Page 58: Seat Warmers And Air Ventilation Seats

    • If the air vents do not operate, restart the vehicle. If there is no change, have your vehicle be inspected by an authorized HYUNDAI dealer. Seats Warmers Seat warmers are provided to warm the seats during cold weather. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the seat warmers off.
  • Page 59 seats_amp_safety_system_seat_warmer_and_air_venitlation_seat.xml Front seat warmers 2C_FrontSeatWarmerSwitch While the vehicle is running, touch the icon to warm the driver's seat or front passenger's seat. Touch the icon repeatedly to cycle through the seat warmer temperature from high, medium, low, and off. Rear seat warmers 2C_RearSeatWarmerSwitch While the vehicle is running, press the seat warmer button to warm the rear seat.

  • Page 60: Air Ventilation Seats

    seats_amp_safety_system_seat_warmer_and_air_venitlation_seat.xml INFORMATION • The seat warmer temperature is lowered automatically and then goes off after a certain time to prevent low temperature burns. If high temperature is selected again after the seat warmer turns off, the temperature is controlled automatically again. •...
  • Page 61 seats_amp_safety_system_seat_warmer_and_air_venitlation_seat.xml Press the button repeatedly to cycle through the air ventilation seat from high, medium, low, and off. Operating the rear ventilation seat from the front seat if equipped Select Seats > 2nd Row Seat air ventilation from the Settings menu in the infotainment system.

  • Page 62: Seat Belts

    • Do not use a seat belt if the webbing or hardware is damaged. Have the seat belt replaced by an authorized HYUNDAI dealer. Damaged seat belts and seat belt assemblies do not operate properly. Always replace: •...
  • Page 63 seats_amp_safety_system_seat_belts.xml Pregnant women should always wear a lap-shoulder seat belt. Place the shoulder belt across your chest, routed between your breasts and away from your neck. Place the lap belt below your belly and pull the shoulder portion so it fits SNUGLY across your hips and pelvic bone, under the rounded part of your belly.

  • Page 64: Periodic Inspection

    seats_amp_safety_system_seat_belts.xml If the shoulder belt portion slightly touches the child's neck or face, try placing the child closer to the center of the vehicle. If the shoulder belt still touches their face or neck, the child needs to return to an appropriate booster seat in the rear seat. WARNING •...
  • Page 65 The entire seat belt assembly or assemblies should be replaced if the vehicle has been involved in a crash. This should be done even if no damage is visible. Consult an authorized HYUNDAI dealer for assistance. Seat Belt Features Retractor pretensioner seat belt (front seat and second row outboard seat)
  • Page 66 When the pretensioner seat belt mechanism deploys during a collision, the pretensioner can become hot and can burn you. • Have the system serviced by an authorized HYUNDAI dealer. Body work on the front of the vehicle may damage the pretensioner seat belt system. CAUTION •...
  • Page 67 seats_amp_safety_system_seat_belts.xml Seat Belt Restraint System WARNING Improperly positioned seat belts may increase the risk of serious injury in a crash. Take the following precautions when adjusting the seat belt: • Position the lap portion of the seat belt as low as possible across your hips, not on your waist, so that it fits snugly.
  • Page 68 seats_amp_safety_system_seat_belts.xml • To raise the height, pull it up. To lower it, push it down while pressing the height adjuster button. Release the button to lock the anchor in place. Try pushing the height adjuster down to make sure that it is locked in place. Height adjustment Front seat 2C_AdjustSeatBeltHeight...
  • Page 69 seats_amp_safety_system_seat_belts.xml Rear center seat belt if equipped 2C_RearCenterSeatBeltWearStep Insert the tongue plate into the buckle until an audible "click" is heard, indicating the latch is locked. Pull the shoulder portion of the belt to snug the belt across your hips and remove slack.

  • Page 70: Seat Belt Warning Light

    seats_amp_safety_system_seat_belts.xml Releasing your seat belt 2C_SeatBeltRelease Press the release button in the locking buckle. The belt should automatically draw back into the retractor. If this does not happen, check the belt is not twisted, then try again. INFORMATION • The emergency locking mode allows seated passengers to move freely in their seats while keeping some tension on the belt.
  • Page 71 seats_amp_safety_system_seat_belts.xml WARNING Riding in an improper position may adversely affect the front passenger's seat belt warning system. Instruct the passenger to properly be seated when the vehicle is moving. NOTICE • If the front passenger seat is not occupied, the seat belt warning light blinks or illuminates for 6 seconds.
  • Page 72 seats_amp_safety_system_seat_belts.xml • After wearing the seat belt, if you unfasten it when you drive under 12 mph (20 km/h), the corresponding warning light will continue to illuminate for about 70 seconds. • After wearing the seat belt, if you unfasten it when you drive over 12 mph (20 km/h), the seat belt warning chime will sound for about 35 seconds and the corresponding warning light will blink.

  • Page 73: Child Restraint System

    seats_amp_safety_system_child_restraint_system.xml Child Restraint System Children Always in the Rear WARNING • Always properly restrain children in the rear seats of the vehicle. Children of all ages are safer when restrained in the rear seat. A child riding in the front passenger seat can be forcefully struck by an inflating airbag resulting in serious injury or death.

  • Page 74: Selecting A Child Restraint System

    Do not use an infant carrier or a child safety seat that 'hooks' over a seatback. It may not provide adequate protection in a crash. • After a crash, have an authorized HYUNDAI dealer check the Child Restraint System, seat belts, tether anchors, and lower anchors. Selecting a Child Restraint System When selecting a Child Restraint System for your child, always: •...

  • Page 75: Installing A Child Restraint System

    seats_amp_safety_system_child_restraint_system.xml WARNING NEVER install a child or infant restraint in the front passenger's seat. Placing a rearward-facing child restraint in the front seat can result in SERIOUS INJURY or DEATH if the child restraint is struck by an inflating air bag. Rearward-facing Child Restraint System A rearward-facing Child Restraint System provides restraint with the seating surface against the back of the child.
  • Page 76 seats_amp_safety_system_child_restraint_system.xml CAUTION Check the seating surface and buckles before placing your child in the Child Restraint System to prevent burns. A Child Restraint System in a closed vehicle can become very hot. After selecting a proper Child Restraint System for your child and checking that the Child Restraint System fits properly in a rear seating position, there are three general steps for proper installation: •...
  • Page 77 seats_amp_safety_system_child_restraint_system.xml LATCH anchors have been provided in the left and right outboard rear seating positions. Their locations are shown in the illustration. There are no LATCH anchors provided for the center rear seating position. Rear passenger seat 2C_ALRSeatBeltLowerAnchor Lower anchor position indicator Lower anchor The lower anchor position indicator symbols are located on the left and right rear seatbacks to identify the positions of the lower anchors in your vehicle.
  • Page 78 Never attach more than one Child Restraint System to a single anchorage. This could cause the anchor or attachment to come loose or break. Always have the LATCH system inspected by an authorized HYUNDAI dealer after a collision. A collision can damage the LATCH system and may not properly secure the Child Restraint System.
  • Page 79 seats_amp_safety_system_child_restraint_system.xml Securing a Child Restraint System seat with tether anchor system WARNING Take the following precautions when installing the top tether: • Read and follow all installation instructions provided with your Child Restraint System. • Never attach more than one Child Restraint System to a single tether anchor. This could cause the anchor or attachment to come loose or break.
  • Page 80 seats_amp_safety_system_child_restraint_system.xml 2. Connect the tether strap hook to the tether anchor, then tighten the top tether strap according to the instructions of your Child Restraint System's manufacturer to firmly secure the Child Restraint System. 2C_ALRSeatBeltTetherAnchorInstall 3. Check the Child Restraint System is secure by pushing and pulling the seat forward and back and side-to-side.
  • Page 81 seats_amp_safety_system_child_restraint_system.xml 1. Place the Child Restraint System on a rear seat and route the lap/shoulder belt around or through the Child Restraint System, following the Child Restraint System manufacturer's instructions. Make sure the seat belt webbing is not twisted. For more information, refer to the 'Passenger and rear seat belts - 3-point system with convertible locking retractor' section in this chapter.
  • Page 82 seats_amp_safety_system_child_restraint_system.xml 4. Slowly allow the shoulder portion of the seat belt to retract and listen for an audible "clicking" or "ratcheting" sound. If no distinct sound is heard, repeat Step 3 and 4. 2C_ALRSeatBeltInstall_4 5. Remove as much slack from the belt as possible by pushing down on the Child Restraint System while feeding the shoulder belt back into the retractor.

  • Page 83: Airbag - Supplemental Restraint System (Srs)

    seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Airbag - Supplemental Restraint System (SRS) Your vehicle is equipped with a Supplemental Airbag System for the driver's seat and front passenger's seats. The front airbags are designed to supplement the three-point seat belts. For these airbags to provide protection, seat belts must be properly worn at all times when driving. You can be severely injured or killed in a crash if you are not wearing a seat belt.

  • Page 84: Srs Components

    seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml SRS Components 1C_AirbagPartsOverview Front impact sensors Passenger's front airbag module Side impact sensors (pressure) SRS control module (SRSCM)/Rollover sensor Occupant classification system Side impact sensors (acceleration) Retractor pre-tensioner Airbag warning light Driver's knee airbag module Driver's front airbag module Driver's and front passenger's seatbelt buckle sensors Front center side airbag Side airbag module...
  • Page 85 Do not cause impact to the doors. Impact to the doors when the Start/Stop button is in the POWER ON or DRIVE READY position may cause the airbags to inflate. Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the HYUNDAI Customer Connect Center at 800-633-5151. WARNING AIRBAG SAFETY PRECAUTIONS •...
  • Page 86 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Airbags system operation The Supplemental Restraint System Control Module (SRSCM) continually monitors all SRS components while the Start/Stop button is DRIVE READY to determine if a crash impact is severe enough to require airbag deployment or pretensioner seat belt deployment. During a moderate to severe frontal collision, sensors detect the vehicle's rapid deceleration.
  • Page 87 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml 1. When the SRSCM detects a sufficiently severe impact to the front of the vehicle, it automatically deploys the front airbags. Driver's front airbag 1 2C_DriverAirbagProcedure 2. Upon deployment, tear seam in the pad cover separates from the expansion of the airbags.
  • Page 88 Always wash exposed skin areas thoroughly with cold water and mild soap. • Have an authorized HYUNDAI dealer inspect your vehicle and replace components as required before operating your vehicle again. Airbags are designed to be used only. Seats & Safety System...
  • Page 89 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Noise and smoke from inflating airbag When the airbags inflate, they make a loud noise and may release powder inside the vehicle. After the airbag inflates, you may feel discomfort while breathing. This may be due to the impact of the airbag or the seat belt with your chest and it may also be due to breathing residual powder in the air and around your vehicle.
  • Page 90 The light stays on after illuminating for about three to six seconds. • The light comes on while the vehicle is moving. • The light blinks when the vehicle is running. Have an authorized HYUNDAI dealer inspect the SRS as soon as possible. Seats & Safety System...
  • Page 91 DRIVE READY position because the side airbags can inflate. • If the seat or seat cover is damaged, have your vehicle serviced by an authorized HYUNDAI dealer. • Properly secure a Child Restraint System as far away from the door as possible •...
  • Page 92 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Driver's and passenger's front airbags Driver's front airbag 2C_DriverAirbag Driver's knee airbag 2C_KneeAirbag Passenger's front airbag 2C_PassengerAirbag The SRS consists of airbags located in the center of the steering wheel, in the driver's side lower crash pad below the steering wheel, and the passenger's side front panel pad above the glove box.

  • Page 93: Side Airbags

    seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml The SRS sensors provide the ability to control the SRS deployment based on whether or not the seat belts are fastened, and how severe the impact is. The SRS offers the ability to control the airbag inflation within two levels. A first stage level is provided for moderate-severity impacts.

  • Page 94: Curtain Airbags

    seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml The side airbags are designed to deploy during certain side impact collisions, depending on the crash severity. The side airbags on both sides of the vehicle are designed to deploy when a rollover is detected by a rollover sensor. The side airbags are not designed to deploy in all side impact or rollover situations.

  • Page 95: Occupant Classification System (Ocs)

    seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Occupant Classification System (OCS) 2C_OCSIndicator The OCS is designed to help detect the presence of a properly seated front passenger and determine if the passenger's front airbag should be enabled (ready to inflate if required) or not. The purpose is to help reduce the risk of injury or death from an inflating airbag to certain front passenger seat occupants, such as children, by requiring the airbag to be automatically turned off.
  • Page 96 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml Condition and operation in the front passenger OCS PASSENGER AIR SRS warning Front passenger Condition detected by the OCS BAG OFF light airbag indicator light Adult Activated Infant or child under 12 months old Deactivated *2*3 with a child restraint system Unoccupied Deactivated Problems with OCS...
  • Page 97 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml WARNING Riding in an improper position or placing weight on the front passenger's seat when it is unoccupied by a passenger, adversely affects the OCS. To reduce the risk of serious injury or death: • Never put a heavy load in the front seat or seatback pocket, or hang any items on the front passenger seat.
  • Page 98 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml • Make sure the seat has been completely dried before driving the vehicle. If a large quantity of liquid has been spilled on the front passenger seat, the airbag warning light may illuminate or malfunction. 2C_OCSWarning_10 • Do not place sharp objects on the front passenger seat. These may damage the occupant detection system, if they puncture the seat cushion.
  • Page 99 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml 2C_OCSWarning_5 • Never place your feet or legs on the dashboard. 2C_OCSWarning_3 • Never lean on the door or center console or sit on one side of the front passenger seat. 2C_OCSWarning_6 • Do not sit on the passenger seat wearing heavily padded clothes such as ski wear and hip protector.
  • Page 100 When changing or replacing the seat or seat cover, use original items only. The OCS has been developed based on using original HYUNDAI car seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury in a collision.

  • Page 101: Airbag Warning Labels

    Any work on the SRS system, such as removing, installing, repairing, or any work on the steering wheel, the front passenger's panel, front seats, and roof rails should be performed by an authorized HYUNDAI dealer. Improper handling of the SRS system may result in serious personal injury or death.
  • Page 102 seats_amp_safety_system_airbag_supplemental_restraint_system_srs.xml 2C_AirbagWarningLabel Airbag warning labels, required by the U.S. NHTSA, are attached to alert the driver and passengers of potential risks of the airbag system. Be sure to read all of the information about the airbags that are installed on your vehicle in this Owner's Manual. Seats &...

  • Page 103: Airbag Operation Conditions

    • Do not install bumper guards with non genuine HYUNDAI or non-equivalent parts. It may adversely affect the collision and airbag deployment performance. •...

  • Page 104: Airbag Inflation Conditions

    seats_amp_safety_system_airbag_operation_conditions.xml Airbag inflation conditions Front airbags 2C_AirbagOperatingConditionFrontAirbag Front airbags are designed to inflate in a frontal collision depending on the severity of impact. Side and curtain airbags 2C_AirbagOperatingConditionSideAirbag 2C_SideCurtainAirbagDeployment Side and curtain airbags are designed to inflate when an impact is detected by side collision sensors depending on the severity of impact resulting from a side impact collision.

  • Page 105: Airbag Non-Inflation Conditions

    seats_amp_safety_system_airbag_operation_conditions.xml If the vehicle chassis is impacted by bumps or objects on unimproved roads, the airbags may deploy. Drive carefully on unimproved roads or on surfaces not designed for vehicle traffic to prevent unintended airbag deployment. Airbag non-inflation conditions • In certain low-speed collisions, the airbags may not deploy.
  • Page 106 seats_amp_safety_system_airbag_operation_conditions.xml • In an angled collision, the force of impact may position the occupants in a direction where the airbags would not be able to provide any additional benefit, and thus the sensors may not deploy any airbags. 2C_AirbagNonOperatingConditionSidlingCrash • Just before impact, drivers often brake heavily.
  • Page 107 seats_amp_safety_system_airbag_operation_conditions.xml • Airbags may not inflate if the vehicle collides with objects such as utility poles or trees, where the point of impact is concentrated and the collision energy is absorbed by the vehicle structure. 2C_AirbagNonOperatingConditionPollCrash Seats & Safety System...
  • Page 108 seats_amp_safety_system_airbag_operation_conditions.xml Seats & Safety System...

  • Page 109: Instrument Cluster

    instrument_cluster.xml 4. Instrument Cluster This chapter explains the vehicle information, warning lights and status indicators that appear on the cluster. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.
  • Page 110 instrument_cluster_instrument_cluster_overview.xml Instrument panel illumination Control switch 2C_AdjustClusterLightingBrightness When the vehicle's parking lights or headlights are on, press the illumination control switch to adjust the brightness of the instrument panel illumination. When pressing the illumination control switch, the interior switch illumination intensity is also adjusted.

  • Page 111: Gauges And Meters

    instrument_cluster_gauges_and_meters.xml Gauges And Meters Speedometer 2C_Speedmeter The speedometer indicates the speed of the vehicle and is calibrated in miles per hour (MPH) and/or kilometers per hour (km/h). Charge/Power Gauge 2C_PowerChargeGauge The CHARGE/POWER gauge displays the charging and discharging status of the electric energy produced by the regenerative braking and the energy consumption of the electric motor.
  • Page 112 instrument_cluster_gauges_and_meters.xml State of Charge (SOC) Gauge for High Voltage Battery 2C_BatteryLevelGauge The SOC indicator is displayed at the bottom of the CHARGE/POWER gauge and shows the charge level of the high voltage battery as a percentage. The lower the number, the more the vehicle needs to be charged, and 100 % indicates a full charge.
  • Page 113 instrument_cluster_gauges_and_meters.xml The temperature indicated on the instrument cluster may not change as quickly as the outside temperature. Select Setup > General > Units > Temperature Unit > °C/°F. Both the temperature unit on the cluster display and climate control information screen is changed.
  • Page 114 instrument_cluster_gauges_and_meters.xml • Driving habits: The driving speed and tendency of accelerating and decelerating. High speed driving or frequent accelerating and decelerating reduces the distance to empty. • Power usage: Additional power use, such as the air conditioner, heater, lights, etc. As the power usage increases, the distance to empty reduces.

  • Page 115: Gear Shift Indicator

    instrument_cluster_gauges_and_meters.xml • Always maintain specified tire pressures and use tires for electric vehicles. • Do not use unnecessary electrical components while driving. • Do not load unnecessary items in the vehicle. • Do not mount parts that may increase air resistance. When the distance to empty is insufficient •...

  • Page 116: Warnings And Indicators

    Warnings And Indicators Warning and Indicator Lights CAUTION If the warning light illuminates while driving or does not go off, have your vehicle inspected by an authorized HYUNDAI dealer. ¢ « ¥ " ǹ (10) ǹ (11) (12) (13)

  • Page 117: Ready Indicator

    • Blinking: Emergency driving When the ready indicator goes OFF or blinks, there is a problem with the system. If this occurs, have your vehicle be inspected by an authorized HYUNDAI dealer. Service warning light « This warning light illuminates: •...
  • Page 118 This causes the Parking Brake warning light (red) and Regenerative Brake warning light (yellow) to illuminate simultaneously. If this occurs, drive safely and have your vehicle be inspected by an authorized HYUNDAI dealer. The operation of the brake pedal may be more difficult than normal and the braking distance may increase.
  • Page 119 WARNING If the parking brake warning light illuminates with the parking brake released, it indicates that the brake fluid level is low. Have your vehicle inspected by an authorized HYUNDAI dealer. INFORMATION If your vehicle is equipped with the dual-diagonal braking system, this means you still have braking on two wheels even if one of the dual systems should fails.
  • Page 120 This warning light remains ON after blinking for about 60 seconds, or repeatedly blinks ON and OFF at 3 second intervals: When there is a malfunction with the TPMS. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. For more information, refer to the...
  • Page 121 This indicator light illuminates: Whenever there is a malfunction with the AWD system. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. For more information, refer to 'All Wheel Drive (AWD)' section in chapter 6.
  • Page 122 If the yellow warning light is still on even after removing foreign material from the front of the sensors after Forward Safety select in settings, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. This warning light blinks: Red: When Forward/Side Safety of FCA is operating.

  • Page 123: Master Warning Light

    Yellow: When Driver Attention Warning (DAW) is disabled or a malfunction is detected. If the yellow indicator light remains on after the front view camera has been uncovered or unblocked, have your vehicle inspected by an authorized HYUNDAI dealer. This indicator light blinks: Yellow: When the inattentive driving warning is operating.
  • Page 124 HYUNDAI dealer. This warning light blinks: Whenever there is a malfunction with a LED headlight related part. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. NOTICE Driving with the LED headlight warning light on or blinking may reduce LED headlight life.

  • Page 125: Electronic Stability Control (Esc) Indicator Light

    When the Start/Stop button is in the POWER ON position. It illuminates for about 3 seconds and then goes off. • Whenever there is a malfunction with ESC system. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. This indicator light blinks: While ESC is operating.
  • Page 126 instrument_cluster_warnings_and_indicators.xml (31) High beam indicator light This indicator light illuminates: • When the headlights are on and the turn signal lever is moved to the high beam position. • When the turn signal lever is pulled into the Flash-to-Pass position. (32) High Beam Assist (HBA) indicator light This indicator light illuminates:...

  • Page 127: High Voltage Battery Level Warning Light

    If both Power down indicator light and Service warning light illuminate at the same time, have your vehicle inspected by an authorized HYUNDAI dealer. • When the indicator is illuminated, driving speed may be limited and power will be reduced.
  • Page 128 Do not connect any external electronic devices to the battery system or battery discharge may occur. If this message appears on the cluster and there are no other external electronic devices connected to the vehicle, have your vehicle inspected by an authorized HYUNDAI dealer. Door, Hood, Liftgate open indicator 2C_DoorOpenWarning...

  • Page 129: Low Tire Pressure

    instrument_cluster_warnings_and_indicators.xml This warning appears if any door or hood or liftgate is left open. The warning indicates which door is open on the cluster display. CAUTION Before driving the vehicle, confirm the door, hood, and liftgate are fully closed. Sunroof open indicator if equipped 2C_SunroofOpenWarning This warning appears if you turn off the vehicle when the sunroof is open.
  • Page 130 instrument_cluster_warnings_and_indicators.xml Lights 2C_LightMode This indicator displays which exterior light is selected using the lighting control. You can activate or deactivate wiper/lights display function from the Settings menu in the infotainment system. Select Setup > Cluster/Head-Up Display > Cluster > Content Selection >...
  • Page 131 Check turn signal This message appears if the turn signal lights are not operating properly. Have your vehicle inspected by an authorized HYUNDAI dealer. Check headlight LED This message appears if there is a problem with the LED headlight. Have your vehicle inspected by an authorized HYUNDAI dealer.
  • Page 132 instrument_cluster_warnings_and_indicators.xml Place digital key on the wireless charger to keep the vehicle running if equipped If the vehicle is remotely started and Start Vehicle is deselected from the Settings menu in the infotainment system for Driver 1 and Driver 2, this message will be displayed for up to 30 seconds when a door is opened after unlocking the doors with a digital key.

  • Page 133: Check Electric Vehicle System

    Check user authentication system if equipped This message is displayed if there is a problem with the digital key or fingerprint authentication system. Have the system inspected by an authorized retailer of HYUNDAI dealer. Electric Vehicle Cluster Display Messages Low EV charge This message appears when the high voltage battery level reaches below 20 %.

  • Page 134: Charging Door Open

    If the same problem occurs when charging the vehicle with an AC charger that has been approved for proper operation or a genuine HYUNDAI portable charger, have your vehicle inspected by an authorized HYUNDAI dealer. Charging Stopped. Check the cable connection This warning message appears when charging is stopped for the reasons below: •...
  • Page 135 If the same problem occurs when charging the vehicle with a charger that has been approved for proper operation or a genuine HYUNDAI portable charger, have your vehicle inspected by an authorized HYUNDAI dealer. Instrument Cluster...

  • Page 136: Cluster Settings

    instrument_cluster_cluster_settings.xml Cluster Settings INFORMATION The information provided may differ depending on which functions are applicable to your vehicle. Cluster Display Control 2C_ClusterMenuSwitch Switch Function Changing modes • • Driving Assist ô (MODE) • • Turn by Turn (TBT) • • Utility Changing items ñ...
  • Page 137 instrument_cluster_cluster_settings.xml Displays the state of Lane Keeping Assist, Smart Cruise Control, Lane Following Assist and Highway Driving Assist (if equipped). For more information, refer to each system information in chapter 7. INFORMATION Driver assistance 2C_ADASInfo The current operation condition of Manual Speed Limit Assist, Smart Cruise Control, Lane Following Assist, etc.
  • Page 138 instrument_cluster_cluster_settings.xml Utility view Current trip 2C_CurrentDrivingInfo The trip computer mode displays information related to vehicle driving parameters including average energy consumption, tripmeter information, and vehicle speed. After Charging 2C_InfoAfterCharging Trip distance, total driving time, average energy consumption, and instant energy consumption after the vehicle has been recharged are displayed.
  • Page 139 instrument_cluster_cluster_settings.xml Accumulated trip distance, total driving time, and average energy economy are displayed. The information is accumulated starting from the last reset. To reset manually, press the OK button on the steering wheel for more than 1 second when 'Since Last Reset' appears. Tire pressure 2C_TireLowPressureInfo The tire pressure of each tire appears.
  • Page 140 instrument_cluster_cluster_settings.xml Instrument Cluster...

  • Page 141: Convenience Features

    convenience_features.xml 5. Convenience Features This chapter explains how to use the user convenience features provided in the vehicle. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.
  • Page 142 convenience_features_smart_key.xml INFORMATION After unlocking the doors, the doors are locked automatically after 30 seconds unless a door is opened. Setting the Two Press Unlock feature You can activate or deactivate the Two Press Unlock feature from the Settings menu in the infotainment system.
  • Page 143 convenience_features_smart_key.xml Locking your vehicle Ď Close all doors, hood, and liftgate, and press the Door Lock button on the smart key. • The chime sounds and hazard warning lights blink. • The side view mirrors fold if On door unlock or On driver approach is selected from the Settings menu in the infotainment system.

  • Page 144: Smart Key Precautions

    A maximum of two smart keys can be registered to a single vehicle. If you happen to lose your smart key, immediately take the vehicle and remaining key to your authorized HYUNDAI dealer or tow the vehicle, if necessary. Smart key precautions The smart key may not work if any of the following occur: •...

  • Page 145: Replacing The Battery

    3. Reinstall the rear cover of the smart key. If you suspect your smart key might have sustained some damage or you feel your smart key is not working correctly, contact an authorized HYUNDAI dealer. WARNING This product contains a button battery. If swallowed, a lithium button battery can cause severe or fatal injuries within 2 hours.
  • Page 146 (for example, key chain) is near the key. The vehicle may not start because the metal may interrupt the transponder signal from transmitting normally. If the system repeatedly does not recognize the coding of the key, contact an authorized HYUNDAI dealer.

  • Page 147: Hyundai Digital Key

    Hyundai Digital Key If Equipped Hyundai digital key provides convenience to the driver, which the driver can use to lock or unlock the driver and passenger doors or the liftgate and turn on the vehicle. WARNING The vehicle can be started when the registered smartphone or card key is placed on the vehicle authentication pad (wireless charging pad).
  • Page 148 convenience_features_hyundai_digital_key.xml 2. Put the gear in P (Park), select Setup > Vehicle > Digital Keys > Smartphone Key > My Smartphone Key from the infotainment system. 2C_AVNRegisterSmartPhone 3. After selecting Digital Key > Set Up Digital Key from the Bluelink App in the smartphone, register the digital key according to the guidance in the smartphone screen.
  • Page 149 convenience_features_hyundai_digital_key.xml INFORMATION The NFC Antenna position on Samsung device can be found in the following path: Setup > Connections > NFC and contactless payments. The NFC Antenna position on Google Pixel phone can be found in the following path: Setup > Connected devices > Device Connections > NFC. The NFC Antenna position on Apple iPhone is located at the top of the rear and Apple WATCH is located at the center of the screen.
  • Page 150 convenience_features_hyundai_digital_key.xml Using the digital key (smartphone) INFORMATION • The Ultra Wide Band supported smartphone digital key can be used only when the smartphone and vehicle are connected with Bluetooth. The necessary distance between the smartphone and vehicle for Bluetooth connection may vary depending on the surroundings. Window tinting substances may cause poor Bluetooth connection.
  • Page 151 convenience_features_hyundai_digital_key.xml Locking/Unlocking the doors • Ultra Wide Band unsupported smartphone 2C_OutsideDoorHandleTouchBySmartPhone Door handle authentication pad NFC Antenna If the driver places the digital key (smartphone) NFC antenna to the driver's or passenger's door handle authentication pad for more than 2 seconds, the door locks or unlocks.
  • Page 152 convenience_features_hyundai_digital_key.xml • Ultra Wide Band supported smartphone With the smartphone inside the vehicle, depress the brake pedal and press the Start/ Stop button. To start the vehicle remotely, use the App provided by the smartphone manufacturer to lock the vehicle with the Door Lock button, and press the Remote Start button within 4 seconds.
  • Page 153 convenience_features_hyundai_digital_key.xml To delete only my registered digital key (smartphone), select Setup > Vehicle > Digital Keys > Smartphone key > My Smartphone Key > Delete from the infotainment system. 2C_AVNDeleteMySmartPhone • If a shared digital key (smartphone) is registered, it cannot be deleted. •...
  • Page 154 convenience_features_hyundai_digital_key.xml 3. Place your card key on the vehicle authentication pad (wireless charging pad) while the vehicle is on. 2C_WirelessChargingPad 4. Register your card key by selecting Vehicle > Digital Keys > NFC Card Key > Save from the Settings menu in the infotainment system. •...
  • Page 155 convenience_features_hyundai_digital_key.xml NOTICE • The digital key (card key) may not work under the following conditions: The digital key (card key) is not placed on the door handle authentication pad or vehicle authentication pad (wireless charging pad) correctly. The digital key (card key) is near NFC-enabled cards such as credit cards or smartphones.
  • Page 156 convenience_features_hyundai_digital_key.xml Linking user profile 1. Select Setup > User Profile > Link Digital Key (Smartphone) from Settings menu in the infotainment system. 2. Select Link to connect the registered smartphone's digital key and the user's profile. 3. Follow the instructions according to the message on the infotainment system. Unlinking user profile Select Setup >...
  • Page 157 Limitations of the System • HYUNDAI Digital Key may not operate if any of the following occurs: Smartphone battery or the vehicle battery is discharged. NFC or Bluetooth is turned off on the smartphone settings.

  • Page 158: Fingerprint Authentication System

    convenience_features_fingerprint_authentication_system.xml Fingerprint Authentication System If Equipped Fingerprint authentication system provides convenient features such as allowing the driver to start the vehicle without a smart key, making electronic payments without a password, etc., with a registered fingerprint. A fingerprint must be registered in the User Profile settings from the infotainment system to use the system.
  • Page 159 convenience_features_fingerprint_authentication_system.xml INFORMATION • Remove all substances including protection film on the fingerprint sensor, and then register your fingerprint. • Starting the vehicle with fingerprint is available when your vehicle is equipped with the Digital Key system. • Electronic payment with fingerprint is available when you are a member of Blue Link. •...

  • Page 160: Starting The Vehicle

    Hyundai Pay (Electronic payment) See additional information in supplied Infotainment Manual to link profile, to set valet mode, or to use Hyundai Pay. INFORMATION You cannot link a profile with the same fingerprint for Driver 1 and Driver 2. The personalization function works with the recently linked profile, and the previously linked profile automatically cancels.
  • Page 161 HYUNDAI dealer. • When you visit an authorized HYUNDAI dealer to repair parts due to fingerprint authentication system or related part failure, your registered fingerprint might be deleted. Have your smart key when you visit an authorized HYUNDAI dealer.
  • Page 162 To remotely start the vehicle with the Digital Key App, refer to the 'Hyundai Digital Key' section in this chapter. And for Blue Link App, see additional information in separately supplied manual.

  • Page 163: Door Locks

    convenience_features_door_locks.xml Door Locks Operating Door Locks from Outside the Vehicle Using the smart key To lock or unlock the doors from outside the vehicle with the smart key button, refer to 'Smart Key' section in this chapter. When 'On driver approach' is set 2C_OutsideDoorHandle_2 Approach within 1 m (40 in.) to the front outside door handle while carrying the smart key.

  • Page 164: Unlocking The Door

    convenience_features_door_locks.xml NOTICE • If you lock the door with the touch sensor, the doors cannot be unlocked with the touch sensor within 3 seconds. • If you lock the doors using the door touch sensor, the doors are not locked under the following circumstances: The Smart Key is in the vehicle.

  • Page 165: Operating Door Locks From Inside The Vehicle

    convenience_features_door_locks.xml Operating Door Locks from Inside the Vehicle WARNING • Always close and lock the doors while the vehicle is moving. If the doors are unlocked, the risk of being thrown from the vehicle in a collision increases. • Do not pull the inner door handle of the driver's or passenger's door while the vehicle is moving.
  • Page 166 convenience_features_door_locks.xml With the central door lock/unlock switch Driver's seat 2C_CentralDoorLockButton Passenger's seat 2C_CentralDoorLockButton_1 The central door lock/unlock switch is located on the driver's door, and front passenger's door. When pressing the Ď portion on the switch, all vehicle doors are locked. •...
  • Page 167 convenience_features_door_locks.xml Unlocking with the mechanical key 1. Pull the door handle while pressing the front part of the outside door handle (front side of the vehicle). Then remove the cover under the rear part of the door handle. 2C_UsingEmerengcyKey 2. Insert the mechanical key into the key cylinder, and turn the key clockwise to unlock the vehicle (direction 1) or counterclockwise to lock the vehicle (direction 2).

  • Page 168: Auto Door Lock/Unlock Features

    convenience_features_door_locks.xml In case of an emergency 2C_HowToLockDoorInEmergency In case of emergency such as when the battery is discharged, the only way to lock the door(s) is with the mechanical key from the outside key hole. Doors without an outside key hole can be locked as follows: 1.
  • Page 169 Child safety lock failure When electronic child safety lock does not work even though the button is pressed, the message 'Child safety lock failure' appears and an alarm sounds. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer. Convenience Features...
  • Page 170 convenience_features_door_locks.xml Safe Exit Assist (with electronic child safety lock) Safe Exit Assist prevents the rear occupant from opening the rear door. When an approaching vehicle from the rear area is detected after the vehicle stops, the rear doors will not unlock even when the driver tries to unlock the rear doors using the electronic child safety lock button.

  • Page 171: Theft-Alarm System

    convenience_features_theftalarm_system.xml Theft-Alarm System This system helps protect your vehicle and valuables. The horn sounds and the hazard warning lights blinks continuously if any of the following occur: • A door is opened without using the smart key. • The liftgate is opened without using the smart key. •...

  • Page 172: Advanced Rear Occupant Alert (Roa)

    convenience_features_advanced_rear_occupant_alert_roa.xml Advanced Rear Occupant Alert (ROA) Advanced ROA is provided to help prevent a driver from leaving a vehicle with a passenger left in the vehicle. The system is designed to help detect an infant and child's presence. Advanced Rear Occupant Alert Settings To use ROA, it can be enabled from the Settings menu in the infotainment system.
  • Page 173 convenience_features_advanced_rear_occupant_alert_roa.xml Steering wheel 2C_SteeringWheelOkButton INFORMATION • The second alert is available for vehicles equipped with the ROA sensor and is activated only after the first alert is activated. • If the vehicle is started remotely (if equipped with Remote Start), inside movement detection will stop.
  • Page 174 convenience_features_advanced_rear_occupant_alert_roa.xml WARNING Even if your vehicle is equipped with Advanced ROA, always make sure to check the rear seats before you leave the vehicle. Advanced ROA may not operate when: • Movement does not continue for a certain period of time. •...

  • Page 175: Integrated Memory System (Ims)

    • Steering wheel position (if equipped) • Head-Up Display (HUD) position (if equipped) If the IMS does not operate normally, contact an authorized HYUNDAI dealer. WARNING Never attempt to operate the IMS while the vehicle is moving. INFORMATION If the battery is disconnected, the memory settings are erased.
  • Page 176 convenience_features_integrated_memory_system_ims.xml INFORMATION • To recall the IMS settings of memory button 2 while the settings of memory button 1 is being recalled, press memory button 1 to stop the IMS adjustment, and then press memory button 2. • If you adjust the driver seat and the side view mirror while the IMS is adjusting the seat and the side view mirror, the system stops the adjustments.
  • Page 177 convenience_features_integrated_memory_system_ims.xml • You can set the Seat Easy Access feature from the Settings menu in the infotainment system. Select Setup > Vehicle > Seat > Seating Easy Access > Driver Seat Easy Access > Extended/Normal/Off. WARNING To prevent injury or property damage, be aware if there are objects or passengers in the driver's side rear seat or seat floor.

  • Page 178: Steering Wheel

    Instrument cluster warning lights may illuminate or the steering effort may be high. If these symptoms occur, drive the vehicle to a safe location as soon as possible. Have the system inspected by an authorized HYUNDAI dealer as soon as possible.
  • Page 179 convenience_features_steering_wheel.xml Manual adjustment if equipped 2C_AdjustSteeringWheelManual 1. Pull down the lock-release lever. 2. Adjust the steering wheel to the desired angle and distance forward/back. 3. Pull the lock-release lever up to lock the steering wheel in place. INFORMATION Sometimes the lock-release lever may not engage completely. Pull down on the lock- release lever, readjust the steering wheel again, and then pull back up on the lock-release lever to lock the steering wheel in place.

  • Page 180: Steering Wheel Heater

    2. Continue pushing the switch for at least 2 seconds after the steering wheel has stopped. Resetting will be complete after the operational range is recognized. If the adjustment is still not possible after resetting the steering wheel power adjustment, have the system inspected by authorized HYUNDAI dealer. Steering Wheel Heater if equipped...
  • Page 181 convenience_features_steering_wheel.xml • The heated steering wheel defaults to the OFF position whenever the Start/Stop button is pressed to the POWER ON position. However, if the Link to Climate Settings for Auto- Adjustment feature is ON, the heated steering wheel will turn on and off depending on the outside temperature.
  • Page 182 convenience_features_steering_wheel.xml Haptic Warning/Steering Wheel Vibration Warning If haptic steering wheel is available, the Driver Assistance system vibrates the steering wheel to warn the driver when the system indicates hazardous situations. Setting haptic warning While the vehicle is on, select Setup > Vehicle > Driver Assistance > Warning Methods > Haptic Warning in the infotainment system.

  • Page 183: Mirrors

    convenience_features_mirrors.xml Mirrors Inside Rearview Mirror Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING • Make sure your line of sight is not obstructed. Do not place objects on the rear seat or in the cargo area that may interfere with your vision through the rear window.

  • Page 184: Electrochromic Mirror

    convenience_features_mirrors.xml Electrochromic mirror if equipped 2C_InsideRearViewMirrorECM 1. 1. Sensor When the vehicle is running, the glare from vehicle headlights behind you is automatically controlled by the sensor mounted in the rearview mirror. When the gear is shifted to R (Reverse), the mirror automatically goes to the brightest setting to improve the driver's view behind the vehicle.
  • Page 185 If you do, it may result in crashes or fire. In case you notice smoke or smell coming from the Digital Center Mirror, stop using the system immediately. Have your vehicle inspected by an authorized HYUNDAI dealer for servicing. •...
  • Page 186 convenience_features_mirrors.xml Icon display area Menu/Adjustment button How to change the mode 2C_DCMModeChange DCM mode Conventional rearview mirror mode The mode can be switched when the switch is in the ON position. 1. Pull the mode select lever all the way to switch to the Digital Center Mirror mode (camera view mode).
  • Page 187 convenience_features_mirrors.xml Display settings (Digital mirror mode) if equipped 2C_DCMInsidemirrorSetting_2 1. Press the menu button Ĵ . The icons will be displayed. • Select Ń to adjust the brightness of the display. • Select ń to adjust the display up/down. 2. Press the menu button repeatedly and select the item you want to adjust. 3.
  • Page 188 If the symbol shown in the illustration is displayed when using the Digital Center Mirror in digital mirror mode, the system may be malfunctioning. The symbol will disappear in a few seconds. Operate the lever, change to optical mirror mode and have your vehicle inspected by an authorized HYUNDAI dealer. Convenience Features...
  • Page 189 • Do not subject the camera to a strong impact as this could cause a malfunction. If this happens, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. • Operating the system at the POWER ON position while the vehicle is not running would cause discharging of the battery.
  • Page 190 convenience_features_mirrors.xml Symptom Likely cause Solution ł Electrochromic mirror (ECM) with HomeLink® system if equipped 2C_ECMHomelink 2C_ECMDCMHomelink HomeLink Channel Garage Door Opener Status Indicator: Closing or Closed HomeLink Operation Indicator Garage Door Opener Status Indicator: Opening or Opened HomeLink User Interface Indicator Your vehicle may be equipped with a Gentex Automatic-Dimming Mirror with an Integrated HomeLink®...
  • Page 191 convenience_features_mirrors.xml Automatic-Dimming Night Vision Safety™ (NVS®) Mirror if equipped The NVS® Mirror automatically reduces glare by monitoring light levels in the front and the rear of the vehicle. Any object that obstructs either light sensor will degrade the automatic dimming control feature. Your mirror will automatically dim upon detecting glare from the vehicles traveling behind you.
  • Page 192 convenience_features_mirrors.xml Programming a New HomeLink® 2C_ECMHomelink_2 HomeLink button HomeLink indicator light 1. When programming a garage door opener, park the vehicle outside of the garage and press the Start/Stop button to the POWER ON position. INFORMATION It is recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal.
  • Page 193 convenience_features_mirrors.xml If the device does not operate: 1. At the garage door opener motor, (security gate motor, etc.) firmly press and release the 'Learn', 'Smart', 'Set' or 'Program' button. You now have up to 30 seconds to complete the next step. 2C_ECMHomelink_5 Learn, Smart, Set, or Program button INFORMATION...
  • Page 194 convenience_features_mirrors.xml INFORMATION A ladder and/or second person may simplify the following steps. 2. On your garage door opener in your garage, press and release the 'Learn' button (usually near where the hanging antenna wire is attached to the garage door opener). A light on your garage door opener may flash, and your Two-Way Communication indicators in your vehicle may flash, confirming completion of the process.
  • Page 195 convenience_features_mirrors.xml INFORMATION The HomeLink indicator light should light green, solid or flashing, and your programmed device should operate. If your device does not operate, the HomeLink programming was not successful, and you'll need to reprogram the button. Two-Way Communication Display Behavior 2C_ECMHomelink_7 HomeLink button Garage Door Opener Status Indicator: Closing or Closed...
  • Page 196 convenience_features_mirrors.xml Erasing HomeLink® Buttons Erasing and Reprogramming a Single HomeLink® Button: 1. Press and hold the desired HomeLink button you want to re-program. DO NOT release the button. 2. The HomeLink indicator light will illuminate solid green. Release the button as soon as the HomeLink indicator light begins to flash orange, usually about 20 seconds.
  • Page 197 convenience_features_mirrors.xml This equipment complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. End Users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must be at least 20cm from the user and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 198 convenience_features_mirrors.xml HomeLink 5 Programing Flow Chart 1C_ECMHomelinkFlowChart Convenience Features...

  • Page 199: Side View Mirrors

    convenience_features_mirrors.xml Side View Mirrors 2C_SideViewMirror The mirrors can be adjusted remotely with the mirror adjustment control switch. Adjust the side view mirrors to your desired position before driving. The side view mirrors can be folded manually to help prevent damage when going through an automatic car wash or when passing through a narrow street.
  • Page 200 convenience_features_mirrors.xml 1. Press the side view mirror control selection lever either to the L or R to select the side view mirror you want to adjust. 2. Use the side view mirror control switch to position the selected mirror up, down, left, or right.
  • Page 201 convenience_features_mirrors.xml Infotainment system if equipped • Enable on door unlock If Setup > Vehicle > Lights > Welcome Mirror/Light > On door unlock is selected from the Settings menu in the infotainment system, the mirror folds or unfolds when the door is locked or unlocked using the smart key or touching the touch sensor on the outside door handle.
  • Page 202 convenience_features_mirrors.xml Saving reverse parking aid user settings mode 1. Make sure to park your vehicle in a safe place, with your vehicle turned on. 2. Press the L or R switch to select the side view mirror you want to adjust. 3.

  • Page 203: Windows

    convenience_features_windows.xml Windows 2C_WindowOpenClose Driver's door open/close window switch Front passenger's door open/close window switch Rear door (left) open/close window switch Rear door (right) open/close window switch Power window lock button/Electronic child safety lock Power Windows The Start/Stop button must be in the POWER ON or DRIVE READY position to be able to raise or lower the windows.

  • Page 204: Auto Up/Down Window

    1. Press the Start/Stop button to the POWER ON or DRIVE READY position. 2. Close the window and continue pulling up on the power window switch for at least one second. If the power windows do not operate properly after resetting, contact an authorized HYUNDAI dealer. Automatic reversal if equipped 2C_WindowEmergencyStop If a window senses any obstacle while it is closing automatically, it stops and lowers about 12 in.

  • Page 205: Power Window Lock Button

    convenience_features_windows.xml WARNING Make sure body parts or other objects are safely out of the way before closing the windows to avoid injuries or vehicle damage. Objects less than 0.16 in. (4 mm) in diameter caught between the window glass and the upper window channel may not be detected by the automatic reverse window and the window does not stop and reverse direction.
  • Page 206 convenience_features_windows.xml Remote window opening feature 2C_RemoteWindowOpenButton Press and hold the Door Unlock ď button on the smart key for more than 3 seconds and the windows move down after the doors are unlocked. Window movement stops when you release the Door Unlock ď button. WARNING Always double check to make sure arms, hands, head and other obstructions are safely out of the way before using remote window closing feature.

  • Page 207: Panoramic Sunroof

    convenience_features_sunroof.xml Panoramic Sunroof If Equipped If your vehicle is equipped with a sunroof, you can slide or tilt your sunroof with the sunroof control switch located on the overhead console. 2C_PanoramaSunroofButtonOverview The sunroof can only be operated when the Start/Stop button is in the POWER ON or DRIVE READY position.

  • Page 208: Tilt Open/Close

    convenience_features_sunroof.xml • Push the sunroof switch rearward to the first detent position, the power sunshade automatically slides open. • Push the sunroof switch forward to the first detent position, the power sunshade automatically closes. If the sunroof glass is open, the sunroof glass closes and then the sunshade closes.
  • Page 209 convenience_features_sunroof.xml • Push the sunroof switch rearward to the first detent position. The sunroof glass slides open. If the power sunshade is closed, the power sunshade opens first and then the sunroof glass opens. Push the sunroof switch forward to the first detent position. The sunroof glass closes. If the sunroof glass is closed, the power sunshade closes.

  • Page 210: Resetting The Sunroof

    convenience_features_sunroof.xml NOTICE • Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor may occur or may cause the sunroof system to malfunction. • Using the sunroof for a long time may make noise caused by dust accumulated between the sunroof and vehicle body.
  • Page 211 convenience_features_sunroof.xml 5. Push and hold the sunroof switch forward again until the power sunshade and sunroof glass slide open and close. Do not release the switch until the operation is completed. If you release the switch, start the procedure again from step 2. NOTICE If the sunroof is not reset after the vehicle battery is disconnected or discharged, or the sunroof fuse is blown, the sunroof may not operate normally.

  • Page 212: Hood

    convenience_features_hood.xml Hood Opening the Hood Before opening the hood, shift the gear to P (Park) and make sure the vehicle has completely stopped. 1. Hood unlock button: Press the hood unlock button, which is located on the crash pad, twice. 2C_HoodUnlockButton •...

  • Page 213: Hood Open Warning

    convenience_features_hood.xml • Lift the hood halfway and it opens automatically. 2C_HoodOpen INFORMATION If the hood does not open, pull the hood release lever twice to open it. Hood Open Warning When the hood opens, a warning message will be displayed on the cluster. If you drive at speeds above 2 mph (3 km/h) while the hood is opened, a warning will sound.
  • Page 214 convenience_features_hood.xml • All glove, rags, or other combustible material have been removed. • All filler caps are tightly and correctly installed. 2. Lower the hood until it is about 12 in. (30 cm) above the closed position and then let it drop.

  • Page 215: Front Trunk

    convenience_features_front_trunk.xml Front Trunk Opening the Front Trunk 2C_FrontTrunk_1 2C_FrontTrunk 1. Hood unlock button: Press the hood unlock button, which is located on the crash pad, twice. • Smart key button: Press and hold the hood unlock button on the smart key for about 3 seconds to unlock the hood.
  • Page 216 convenience_features_front_trunk.xml WARNING • Never make an attempt to get inside the front trunk. It may cause serious or fatal injuries. • Before closing the hood, ensure all obstructions are removed from around the hood opening. The hood will rise up or move down automatically if the height is not firmly adjusted.
  • Page 217 convenience_features_front_trunk.xml • 2nd opening position: When the vehicle is below 3 mph (5 km/h), the hood opens completely and emergency escape is possible. Convenience Features...

  • Page 218: Power Liftgate

    convenience_features_power_liftgate.xml Power Liftgate If Equipped Power Liftgate Operating Conditions The power liftgate operates when the gear is in P (Park) with the vehicle running. However, the power liftgate will operate regardless of the gear position when the vehicle is off. When the liftgate is closed, press the power liftgate open/close button for 1 second.
  • Page 219 2C_GasLift • Do not modify or repair any part of the power liftgate by yourself. This must be done by an authorized HYUNDAI dealer. • Do not operate the power liftgate under the following conditions. The power liftgate may not operate properly.

  • Page 220: Power Liftgate Open/Close Button

    convenience_features_power_liftgate.xml the liftgate, the chime will sound 3 times, but the liftgate will remain closed. Allow the power liftgate system to cool for about 1 minute before operating the system again. Operating the Power Liftgate Power liftgate open/close button Smart key 2C_SmartKeyTailgateOpenButton Instrument panel 2C_CrashPadTailgateOpenButton...
  • Page 221 convenience_features_power_liftgate.xml While the liftgate is opening, press the button to stop liftgate operation. When the power liftgate is opened, press and hold the power liftgate open/close button to close the liftgate. If you release the button while the liftgate is closing, power liftgate operation will stop with a warning sound for 5 seconds.
  • Page 222 convenience_features_power_liftgate.xml Power liftgate lock button (Inside the power liftgate) 2C_TrunkTrimTailgateLockButton Press the power liftgate lock button while carrying the smart key. The liftgate closes and locks automatically. Additionally, all doors will lock. The liftgate can be closed and locked, and all doors locked only when the button is pressed while the vehicle is off.

  • Page 223: Resetting The Power Liftgate

    Wait until the liftgate fully opens to complete resetting. If the liftgate stops before it is fully open, resetting cannot be completed. INFORMATION If the power liftgate does not operate properly after the above procedure, have the system inspected by an authorized HYUNDAI dealer. Convenience Features...

  • Page 224: Emergency Liftgate Safety Release

    convenience_features_power_liftgate.xml Emergency Liftgate Safety Release 2C_EmergencyTailgateOpen To unlock and open the liftgate manually from inside the cargo area. Perform the following procedure: 1. Remove the cover at the bottom of the liftgate. 2. Slide the latch in the direction of the arrow to unlock the liftgate. 3.

  • Page 225: Smart Liftgate

    convenience_features_smart_liftgate.xml Smart Liftgate If Equipped 2C_SmartTailGate On a vehicle equipped with a smart key, the liftgate can be opened with hands-free activation using the smart liftgate system. Operating the Smart Liftgate The hands-free smart liftgate system can be used when: •...

  • Page 226: Detecting Area

    convenience_features_smart_liftgate.xml Detecting Area 2C_SmartTailgateSensingRange • The smart liftgate detecting area extends about 20-40 in. (50-100 cm) behind the vehicle. If you are positioned in the detecting area and are carrying the smart key, the hazard warning lights blinks and the chime sounds for about 3 seconds to alert you that the liftgate opens.

  • Page 227: Head-Up Display (Hud)

    convenience_features_headup_display_hud.xml Head-Up Display (HUD) If Equipped 2C_HUDOverview The HUD is an optional feature that allows the driver to view information projected onto a transparent screen while still keeping your eyes on the road ahead while driving. Precautions While Using the HUD •...
  • Page 228 convenience_features_headup_display_hud.xml HUD Information 2C_HUDIconInfo Turn by Turn (TBT) navigation Traffic signs or speed limit Surrounding vehicle (if equipped) Lane Safety Highway Driving Assist (if equipped) Highway Auto Speed Change (if equipped) Smart Cruise Control set speed Speedometer Smart Cruise Control vehicle distance Lane Following Assist Blind-Spot Safety WARNING...
  • Page 229 convenience_features_headup_display_hud.xml INFORMATION The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. Convenience Features...

  • Page 230: Vehicle System Over-The-Air (Ota) Update

    convenience_features_vehicle_system_ota_update.xml Vehicle System Over-The-Air (OTA) Update The OTA software update feature allows you to wirelessly update software to the latest version. Using this feature, you can keep your vehicle system up to date with the latest software. Downloading Software The latest software can be downloaded automatically while driving. After the latest software has been successfully downloaded, you will receive a notification on your phone or the vehicle screen that the software update is available.

  • Page 231: Updating Software

    Start/Stop button. • After the update starts, you can exit the vehicle. • The OTA software update feature is only available for HYUNDAI Connected Services users. Convenience Features...
  • Page 232 Center. • If the software update or recovery fails, please contact the HYUNDAI Call Center. If there is a safety issue, you may be notified by the HYUNDAI Call Center to provide services such as emergency dispatch. • After the update is complete, it may provide new functions or improvements. For more information, see the 'OTA Software Update' page on the HYUNDAI brand web or scan the QR code on the screen.

  • Page 233: Exterior Lights

    convenience_features_exterior_lights.xml Exterior Lights Lighting Control 2C_LightSwitchOverview AUTO headlight _ Parking light ^ Headlight To operate the lights, turn the knob at the end of the control lever to the desired position. AUTO headlight 2C_LightSwitchAutoPosition The headlights and parking lights are turned ON or OFF automatically depending on the amount of daylight as measured by the ambient light sensor in front of the instrument panel.

  • Page 234: Parking Light

    convenience_features_exterior_lights.xml Parking light 2C_TailLampOn The parking lights, license plate light, and instrument panel light turn ON when you turn the knob to the _ position. Headlight 2C_HeadLampOn The headlights, parking lights, license plate light, and instrument panel light turn ON when you turn the knob to the ^ position with the Start/Stop button in the DRIVE READY position.

  • Page 235: Battery Saver Function

    (position 2) for a right turn. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal light may require replacement. Contact an authorized HYUNDAI dealer. One Touch Turn Signal To use One Touch Turn Signal, slightly push the turn signal lever up or down (position 1) and then release it.

  • Page 236: Headlight Delay Function

    When moisture fogs up inside of the headlight with the headlight on for a certain period of time, the fan circulates air inside the headlight to remove moisture. If moisture is not removed, have your vehicle be inspected by an authorized authorized HYUNDAI dealer. INFORMATION The infotainment system may change after software updates.
  • Page 237 convenience_features_exterior_lights.xml Dynamic welcome light if equipped If The dynamic welcome light operates for about 4 seconds, and at the same time the position lamps come on for about 15 seconds. When the Door Lock button or Door Unlock button on the smart key is pressed while the dynamic welcome light is on, the dynamic welcome light turns off immediately.
  • Page 238 Go to the Bluelink Store homepage and purchase 'Lighting Patterns' to try out various lighting patterns. The Bluelink Store can be accessed through the lighting pattern screen of the infotainment system or QR in the 'Bluelink Store Guide' in this manual. https://commerce.hyundai.com/link/fod TL_VGSQRcode Convenience Features...

  • Page 239: High Beam Assist (Hba)

    convenience_features_high_beam_assist_hba.xml High Beam Assist (HBA) 2C_HBASwitch HBA automatically adjusts the headlights between high beam and low beam depending on the light detected from oncoming vehicles or vehicles in front using the front view camera. For more information on the location and the general precautions of front view camera, refer to the 'Sensor Information' section in chapter 7.
  • Page 240 When HBA is not working properly, the 'Check Driver Assistance system' warning message may appear, and the X warning light may illuminate on the instrument cluster. Contact an authorized HYUNDAI dealer. Limitations of HBA HBA may not work properly in the following situations if: •...
  • Page 241 convenience_features_high_beam_assist_hba.xml • The headlights from an oncoming or front vehicle is not detected because of exhaust fumes, smoke, fog, snow, blizzard, water spray on the road, or windshield condensation, etc. For more information on the limitations of the front view camera, refer to the 'Forward Collision-Avoidance Assist (FCA)' section in chapter 7.

  • Page 242: Interior Lights

    convenience_features_interior_lights.xml Interior Lights WARNING Do not use the interior lights when driving in the dark. The interior lights may obscure your view and result in a collision. NOTICE Do not use the interior lights for extended periods when the vehicle is turned off. Otherwise, the battery discharges.
  • Page 243 convenience_features_interior_lights.xml Rear Room Lamp 2C_RoomLamp Ċ : Press the button to turn on and off the rear lamp. Rear Personal Lamps 2C_PersonalLamp ĉ : Press the button to turn on and off the rear room lamp. Vanity Mirror Lamp 2C_SunvisorLamp Opening the lid of the vanity mirror.
  • Page 244 convenience_features_interior_lights.xml NOTICE Always have the switch in the off position when the vanity mirror lamp is not in use. If the sunvisor is closed without the lamp off, it may discharge the battery or damage the sunvisor. Glove Box Lamp if equipped 2C_GloveBoxLamp The glove box lamp turns on when the glove box is opened.
  • Page 245 convenience_features_interior_lights.xml Interior Button Lights The interior lighting including the button lighting are continuously on to make it easy to locate buttons and items during both day and night. Set Daytime Lighting You can enable or disable the exterior and interior button lighting. Select Vehicle > Lights >...
  • Page 246 convenience_features_interior_lights.xml INFORMATION • The mood lamps at both ends of the dashboard turn off to prevent reduced visibility of the side view mirror when the vehicle is not in P (Park). • The infotainment system may change after software updates. For more information, refer to the manual provided in the infotainment system and the quick reference guide.

  • Page 247: Wipers And Washers

    convenience_features_wipers_and_washers.xml Wipers And Washers Front Windshield Wipers 2C_WiperSwitchOverview Speed control knob • HI: The wiper runs at a higher speed. • LO: The wiper runs at a lower speed. • AUTO: The rain sensor located on the upper end of the windshield glass senses the amount of rainfall and controls the wiping cycle for the proper interval.

  • Page 248: Front Windshield Washers

    convenience_features_wipers_and_washers.xml AUTO (Automatic) control 2C_RainSensor The rain sensor located on the upper end of the windshield glass senses the amount of rainfall and controls the interval of the wiping cycle. To change the sensitivity setting, turn the sensitivity control knob. If the wiper switch is set in the AUTO mode when the Start/Stop button is in the DRIVE READY position, the wiper operates once to perform a self-check of the system.
  • Page 249 convenience_features_wipers_and_washers.xml In the OFF position, pull the lever gently toward you to spray washer fluid on the windshield and to run the wipers 1-3 cycles. The spray and wiper operation continues until you release the lever. If the washer does not work, you may need to add washer fluid to the washer fluid reservoir.
  • Page 250 convenience_features_wipers_and_washers.xml Auto rear wiper if equipped The rear wiper operates while the vehicle is in reverse with the front wiper on. You can select the function from the Settings menu in the infotainment system. Select Setup > Vehicle > Convenience > Auto Rear Wiper (in R). For more information, refer to the 'Recirculating Air When Washer Fluid is Used' section in this chapter.
  • Page 251 convenience_features_wipers_and_washers.xml • The rear window wiper operates and washer fluid is sprayed onto the rear window and camera. • If you push and hold the switch, the wipers will operate and washer fluid will be sprayed repeatedly on the rear window and camera. •...

  • Page 252: Automatic Climate Control System

    convenience_features_automatic_climate_control_system.xml Automatic Climate Control System If Equipped Front seat control 1C_AutoAircon AUTO (automatic control) Driver's temperature control DRIVER ONLY Fan speed control Scheduled climate Mode selection Front/Rear climate control information screen Passenger's temperature control SYNC A/C (air conditioning) Air intake control Front windshield defroster Rear window defroster Convenience Features...
  • Page 253 convenience_features_automatic_climate_control_system.xml Rear seat control from the front 1C_Aircon_1 Temperature control Fan speed control Mode selection Front/Rear climate control information screen AUTO (automatic control) A/C (air conditioning) Convenience Features...
  • Page 254 convenience_features_automatic_climate_control_system.xml Rear seat control if equipped 1C_2ndRowAircon Temperature display AUTO (automatic control) Temperature control A/C (air conditioning) Mode selection Fan speed control INFORMATION Temperature, Mode selection (air flow direction), and Fan speed can be controlled from the rear seat. However, if Setting > Vehicle > Climate > Climate Features > Lock Rear Climate Controls is selected, the rear climate control can be operated only from the front seat.

  • Page 255: Automatic Heating And Air Conditioning

    convenience_features_automatic_climate_control_system.xml INFORMATION Screen distortion that occurs when you press the screen strongly is a normal phenomenon that can occur due to the characteristics of LCD. Automatic Heating and Air Conditioning The Automatic Climate Control System is controlled by setting the desired temperature. 1.

  • Page 256: Manual Heating And Air Conditioning

    convenience_features_automatic_climate_control_system.xml CAUTION 2C_BatterySaverIndicator Never place anything near the sensor to ensure better control of the heating and cooling system. INFORMATION For your convenience and to improve the effectiveness of the climate control, use the AUTO button and set the temperature to 72 °F (22 °C). Manual Heating and Air Conditioning Set the various heating and air conditioning system such as fan speed, mode, temperature, air intake, etc., as desired.
  • Page 257 convenience_features_automatic_climate_control_system.xml Air flow direction 1C_AutoAirconModeSelectionOverview Symbol Operation Ř Select for effective cooling. Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air discharged from the outlet. B, C, F ś Air flow is directed toward the face and the floor.
  • Page 258 convenience_features_automatic_climate_control_system.xml Symbol Operation Ŝ Most of the air flow is directed to the floor, windshield and side window defrosters, with a small amount of the air being directed to the side vent. A, C, D, E, G Front windshield defroster (A, C) 2C_AirconFrontDefrostButton Press the front windshield defroster button (indicator light ON) to turn on the front windshield defroster.

  • Page 259: Temperature Control

    convenience_features_automatic_climate_control_system.xml 2C_RearVent The instrument panel vent air flow can be directed up/down or left/right using the vent adjustment lever. • Front vents: Move the lever all the way to the Á direction to close, and to the  direction to open the air vents. Temperature control Front seat control 2C_AirconTempButton...

  • Page 260: Air Intake Control

    convenience_features_automatic_climate_control_system.xml INFORMATION • Some of the airflow may be directed to other seating position to keep indoor air pleasant while using DRIVER ONLY. • When using the front windshield defroster, the air flow on the both sides of windshield continues to operate regardless of the activation of DRIVER ONLY. SYNC (Adjusting the driver and passenger side temperature equally) 2C_AirconSYNCButton_2 •...
  • Page 261 convenience_features_automatic_climate_control_system.xml WARNING To prevent serious injury or death: • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle that could fog the windshield and the side windows and obscure visibility. • Do not sleep in a vehicle with the air conditioning or heating system on.

  • Page 262: Air Conditioning

    convenience_features_automatic_climate_control_system.xml INFORMATION Operating the fan speed when the Start/Stop button is in the POWER ON position may cause the battery to discharge. Air conditioning 2C_AutoAirconButton_2 • Press the A/C button to manually turn on the system on (indicator light ON) and off. •...
  • Page 263 convenience_features_automatic_climate_control_system.xml INFORMATION • Water dripping on the ground of the vehicle is normal after the use of the air conditioning. • Avoid prolonged operation of the air conditioning in the circulated air position when operating in/outside mode. Carefully adjust to let outdoor air circulate regularly. •...

  • Page 264: System Maintenance

    Have the cabin air filter replaced by an authorized HYUNDAI dealer according to the maintenance schedule. If the vehicle is being driven in severe conditions such as dusty or rough roads and/or if transporting pets or occupants smoke inside the vehicle, then more frequent cabin air filter inspections and changes are required.
  • Page 265 Checking the amount of air conditioner refrigerant If the amount of refrigerant is too low or too high, the performance of the air conditioning is reduced. Have the system inspected by an authorized HYUNDAI dealer. WARNING Ęę • To prevent serious injury, have the air conditioning system be serviced by only trained and certified technicians.

  • Page 266: Windshield Defrosting And Defogging

    convenience_features_windshield_defrosting_and_defogging.xml Windshield Defrosting And Defogging • For maximum defrost performance, set the temperature control to the highest temperature setting and the fan speed control to the highest setting. • If warm air to the floor is desired while defrosting or defogging, select the floor-defrost position.
  • Page 267 convenience_features_windshield_defrosting_and_defogging.xml NOTICE Never use sharp instruments or window cleaners containing abrasives to clean the window to prevent damage to the rear window defroster. INFORMATION • If there is heavy accumulation of snow on the rear window, brush it off before operating the rear defroster.

  • Page 268: Climate Control Additional Features

    convenience_features_climate_control_additional_features.xml Climate Control Additional Features INFORMATION The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. Air Conditioning Auto drying The Air conditioning auto drying feature dries the moisture in the air conditioner and reduces air conditioner odor.
  • Page 269 convenience_features_climate_control_additional_features.xml Auto Defogging System if equipped 2C_RainSensor The Auto defogging reduces the possibility of fogging up the inside of the windshield by automatically sensing the moisture on inside the windshield. The Auto defogging system operates when the heater or air conditioning is on. When the Auto defogging system operates, the Ż...
  • Page 270 convenience_features_climate_control_additional_features.xml NOTICE • Do not remove the sensor cover located on the top of the windshield glass. Damage may not be covered by your vehicle warranty. • Do not select recirculated air while the Auto defogging system is operating. INFORMATION When Auto defogging system is operating, fan speed adjustment, temperature adjustment, and air intake control selection are all disabled.
  • Page 271 convenience_features_climate_control_additional_features.xml Recirculating Air When Entering a Tunnel if equipped To prevent the inflow of polluted air into the vehicle when passing through a tunnel, the windows and climate control system are operated using the navigation map information and vehicle speed as follows: To use this feature, it can be enabled from the infotainment system.
  • Page 272 convenience_features_climate_control_additional_features.xml Turning Scheduled ventilation control on or off The Scheduled ventilation control can be turned on and off by selecting Setup > Vehicle > Climate > Automatic Ventilation > Scheduled Ventilation from the infotainment system. Also, the starting time can be set within 24 hours. Scheduled ventilation control operates only once when the feature is set.
  • Page 273 convenience_features_climate_control_additional_features.xml Drive mode Air conditioning system control SNOW NORMAL Automatic Controls Linked to Climate Control Settings (for Driver's Seat) if equipped The temperature of the driver's seat warmer, air ventilated seat and heated steering wheel is automatically controlled depending on the inside and outside temperature of the vehicle when the vehicle is running.

  • Page 274: Storage Compartment

    convenience_features_storage_compartment.xml Storage Compartment WARNING • Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for an extended period of time. • Always keep the storage compartment covers closed securely while driving.
  • Page 275 convenience_features_storage_compartment.xml CAUTION • Make sure body parts are out of the way when closing the console cover after use. • Avoid storing food items in the two-way multi console for extended periods. Sliding Console if equipped 2C_MovingMultiConsole You can move the console box by pulling the lever and pushing or pulling it forward/ backward.
  • Page 276 convenience_features_storage_compartment.xml Pull the handle to open the storage compartment. Use it to store long items. The space can be separated by using a removable partition. CAUTION Avoid storing food items in the sliding tray for extended periods. Glove Box 2C_GloveBox To open, pull the lever.
  • Page 277 convenience_features_storage_compartment.xml 2C_OpenTray_1 You can use this space to store small items etc. WARNING Do not put sharp objects in the tray. In a collision, they can come loose from the tray and injure occupants. Storage 2C_StorageBox This storage is designed to store small items. Door tray Center console storage 2nd row console storage...
  • Page 278 convenience_features_storage_compartment.xml Cargo Tray 2C_CargoCompartmentStorageOrganizationBox Use the cargo tray to organize and store small items such as tools. To use the tray, lift the luggage floor by the handle. CAUTION • When storing small or easily movable items, they may cause noise while driving. •...

  • Page 279: Interior Features

    convenience_features_interior_features.xml Interior Features Cup Holder 2C_CupHolderCenterConsole Front seat Rear (2nd row seat) Rear seat (3rd row seat) Cups or small beverages cups may be placed in the cup holders. WARNING • Avoid abrupt starting and braking when the cup holder is used to prevent spilling your drink.
  • Page 280 convenience_features_interior_features.xml Vanity mirror Ticket holder Bracket To use the sunvisor, pull it downward. • To use the sunvisor to block the sun from the side window, release it from the bracket and swing it to the side toward the window. Adjust the sunvisor forward or backward as needed.
  • Page 281 convenience_features_interior_features.xml INFORMATION To prevent damage to the power outlets: • Use the power outlet only when the vehicle is running and remove the accessory plug after use. Using the accessory plug for an extended period of time with the vehicle off may cause the battery to discharge.
  • Page 282 Using the genuine charger specified for your vehicle can support up to 100 W. The color of the light indicates the charging status. The color of the light is designed for a driver's convenience. If a problem occurs repeatedly, contact an authorized HYUNDAI dealer. Color USB charging port state...
  • Page 283 Stop charging immediately. Turns on when there is a Have your vehicle be inspected malfunction with the charging by an authorized HYUNDAI device dealer. INFORMATION • The battery charging state may be monitored on the electronic device.
  • Page 284 100W Charging cable state Notes White Hyundai Motors authorized Support up to 100 W product (Default) Hyundai Motor Company has not Blue Support up to 60 W certified genuine products Indicator off USB-IF PD 3.0 Non-Specification Support up to 27 W CAUTION •...
  • Page 285 convenience_features_interior_features.xml Cluster Fascia Side Panel if equipped WARNING Do not attach the cellular phones and heavy or sharp items to the cluster fascia side panel for safety reason. This could result in loss of control, and an accident causing death, serious injury, or property damage.
  • Page 286 convenience_features_interior_features.xml Indicator light Charging pad 1. The wireless smartphone charger is available when all doors are closed, and when the Start/Stop button is in the POWER ON or DRIVE READY position. 2. Turn on the wireless charging function from the Settings menu in the infotainment system.
  • Page 287 convenience_features_interior_features.xml NOTICE • The wireless smartphone charging system may not support smartphones that do not meet the Qi specification ( þ ). • Wireless charging may stop temporarily when the smart key is used, or when starting the vehicle or locking/unlocking the doors. •...
  • Page 288 convenience_features_interior_features.xml WARNING 2C_CoatHookWarning Only hang soft clothing without heavy, sharp or breakable objects in the clothes pockets. In a collision or when the curtain airbag is inflated, the objects could move and cause serious injury. Plastic Bag Hook if equipped 2C_ShoppingBagHook Hooks are located on the left of the front trunk.
  • Page 289 Do not stack floor mats on top of one another (for example, all-weather rubber mat on top of a carpeted floor mat). Only a single floor mat must be installed in each position. To avoid any interference with pedal operation, install the HYUNDAI floor mat designed for use in your vehicle.
  • Page 290 convenience_features_interior_features.xml Cargo Net Holder if equipped 2C_CargoNet 2C_CargoNet_2 To keep items from shifting in the cargo area, use the 4 holders located in the cargo area side trim to attach the cargo net. Make sure the cargo net is securely attached to the holders in the cargo board. WARNING •...
  • Page 291 convenience_features_interior_features.xml Cargo Security Screen if equipped 2C_CargoShelf_3 Use the cargo security screen to cover items stored in the cargo area. Using the cargo security screen 2C_CargoShelf_4 Pull the cargo security screen towards the rear of the vehicle and insert the guide pin into the guide.
  • Page 292 convenience_features_interior_features.xml NOTICE Since the cargo security screen may be damaged or malformed, do not put luggage on it when it is used. Convenience Features...

  • Page 293: Exterior Features

    convenience_features_exterior_features.xml Exterior Features Roof Side Rails if equipped 2C_RoofRack If your vehicle is equipped with roof side rails, you can add roof rack crossbars as an accessory (not shown). WARNING • Loading cargo or luggage in excess of the specified weight limit on the roof side rails may damage your vehicle.

  • Page 294: Infotainment System

    convenience_features_infotainment_system.xml Infotainment System 2C_AVNOverview For more information, refer to the infotainment system manual. NOTICE • Do not install an aftermarket HID headlight. Your vehicle's audio and electronic devices may not function properly. • Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.
  • Page 295 Connecting an unspecified cable may damage the vehicle's USB port or the connected devices. Contact an authorized HYUNDAI dealer for more information on accessories for HYUNDAI vehicles.
  • Page 296 convenience_features_infotainment_system.xml INFORMATION • Some devices may not be charged through USB port. • When using a portable audio device connected to the power outlet, noise may occur during playback. If this happens, disconnect the USB cable and use the portable audio device's power source.
  • Page 297 convenience_features_infotainment_system.xml description Media mode Ĺ When you press briefly ñ ò • • RADIO mode • • MEDIA mode: TRACK UP/DOWN button When you press and hold (more than 0.8 seconds) • • RADIO mode: AUTO SEEK button to seek until you release the button •...
  • Page 298 convenience_features_infotainment_system.xml Voice Recognition 2C_SteeringWheelVoiceRecognitionButton For more information, refer to the infotainment system manual. Convenience Features...

  • Page 299: Vehicle To Load (V2L)

    convenience_features_vehicle_to_load_v2l.xml Vehicle To Load (V2L) If Equipped Using the V2L feature, you can turn on electronic devices by connecting them to the high voltage battery. Safety Precautions When Using the V2L Function Before using the V2L function, read and comply with all the safety information below. Failure to do so may cause electric shock or fire and result in serious injury, death, vehicle malfunction, or property damage.
  • Page 300 convenience_features_vehicle_to_load_v2l.xml Precautions for handling and using the V2L connector CAUTION • Do not modify or disassemble the V2L connector. It may cause fire, electric shock, or injury. Damage to your vehicle caused by modification and disassembling is not covered by warranty. •...
  • Page 301 convenience_features_vehicle_to_load_v2l.xml Precautions when using electric/electronic products CAUTION • Before using the product, check the precautions and how to use the product referring to the product manual. • Only use products that have obtained national safety certification. • Only use an electric device that does not exceed the maximum power capacity that the vehicle can supply.
  • Page 302 convenience_features_vehicle_to_load_v2l.xml 3. Open the connection terminal protection cap of the connector with the open switch pressed. 4. Open the charging door and connect the V2L connector to the charging inlet on the vehicle. • Connect the V2L connector to the charging inlet within 60 seconds after opening the charging door.
  • Page 303 convenience_features_vehicle_to_load_v2l.xml 2. Open the power outlet cover by sliding it to the left, and connect the power plug of the electric device to the power socket 2C_V2LPosition • Time remaining until the battery level reaches the set value, and the distance to empty at the set value appears on the instrument cluster or the infotainment system.
  • Page 304 convenience_features_vehicle_to_load_v2l.xml INFORMATION • V2L discharging mode shuts off if the vehicle is off using indoor V2L on the vehicle state of ON. • Opening the charging door or connecting the V2L connector to the charging inlet, the V2L discharging mode shuts off. •...

  • Page 305: Aux. Battery Saver

    convenience_features_aux_battery_saver.xml Aux. Battery Saver+ The Aux. Battery Saver+ is a function that specialized in battery protection, prevents the failure due to fully discharge of the 12 V battery. If the user drives or charges the vehicle, the Aux. Battery Saver+ is automatically activated to check the 12 V battery charging state.
  • Page 306 convenience_features_aux_battery_saver.xml Convenience Features...

  • Page 307: Driving Your Vehicle

    driving_your_vehicle.xml 6. Driving Your Vehicle This chapter provides information required to start and drive your vehicle, as well as information that helps you drive more safely and economically. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. •...

  • Page 308: Before Starting

    driving_your_vehicle_before_driving.xml Before Starting WARNING • To reduce the risk of serious injury or death: Always wear your seat belt. All passengers must be properly belted whenever the vehicle is moving. For more information, refer to the 'Seat Belts' section in chapter 3. Always drive defensively.

  • Page 309: Understanding Your Electric Vehicle

    driving_your_vehicle_understanding_your_electric_vehicle.xml Understanding Your Electric Vehicle Electric vehicles are driven using a battery and an electric motor. Characteristics of Your Electric Vehicle • Electric vehicles are eco-friendly because they do not use fossil fuels for driving. Additionally, unlike gasoline vehicles, noise and vibration are minimal, and the vehicle's lifespan is relatively long.
  • Page 310 • When the high voltage battery or its related components require inspection and maintenance, contact an authorized HYUNDAI dealer. Understanding Virtual Engine Sound System (VESS) Electric vehicles do not use an internal combustion engine, so there is no engine noise while driving.
  • Page 311 • If a collision occurs and the vehicle is impacted, have your vehicle inspected by an authorized HYUNDAI dealer to check the battery connection status. • Using the V2L function may reduce the driving distance due to the use of the high voltage battery energy, and repeated use of the V2L function may cause a decrease in the life of the high voltage battery.
  • Page 312 2C_HighVoltageCutoffSwitch High voltage cut-off switch is a device located inside the motor compartment to block the battery's high voltage when your vehicle is inspected at an authorized HYUNDAI dealer. Open the hood and remove the battery service cover on the front trunk to find the high voltage battery cut-off switch.

  • Page 313: Using Electric Vehicle Functions

    driving_your_vehicle_using_ev_mode_functions.xml Using Electric Vehicle Functions Electric Vehicle provides driving information and high voltage battery information. You can set various electric vehicle functions in Electric Vehicle. Checking the Electric Vehicle Screen Configuration 1C_ElectricVehicleMain On the Home screen from the infotainment system, select Electric Vehicle. Name Description ƺ...
  • Page 314 driving_your_vehicle_using_ev_mode_functions.xml Name Description 'Setting the target battery charge level' section in this chapter. You can set the battery discharging limit(%) for the high Electricity Use Settings voltage battery for driving. For more information, refer (V2L) to the 'Setting a battery discharging limit when using Vehicle to Load (V2L)' section in this chapter.
  • Page 315 driving_your_vehicle_using_ev_mode_functions.xml Name Description navigation), headlight, vehicle control unit, etc., and the percentage of the power vehicle system used in total power used since starting the vehicle. Shows the power and energy consumption used by the air conditioner Climate or heater and the percentage of the power climate system used in total power used since starting the vehicle.
  • Page 316 Battery usage statistics information is a feature that guides you on how to use the driving (high voltage) battery efficiently. If a performance problem occurs, have your vehicle be inspected by an authorized HYUNDAI dealer. • Performance deterioration may occur due to various reasons other than those displayed in the Battery Usage Statistics.
  • Page 317 driving_your_vehicle_using_ev_mode_functions.xml information is initialized and the screen will be re-displayed after collecting additional 1,900 mi. (3,000 km) driving (high voltage) battery usage information. 1C_BatteryUsageStatisticsInformation Battery usage with statistics Displays the average battery consumption while driving. INFORMATION If the usage is out of recommendation, it does not seriously affect the battery performance.
  • Page 318 driving_your_vehicle_using_ev_mode_functions.xml Message Description (in case if the lifespan of a battery is effectively managed, the message will also be presented though you are not under the recommended range.) Using AC charging rather than DC charging To maintain battery performance, try AC can benefit the lifespan of the high voltage charging.
  • Page 319 driving_your_vehicle_using_ev_mode_functions.xml Checking the electric energy economy history 1C_EVEconomyHistory On the infotainment screen select, Charge Efficiency History. • You can check the history of electric energy economy with the date and distance of previous driving. Setting the Next Departure Time You can set an anticipated departure time for scheduled charging and target temperature. INFORMATION •...
  • Page 320 driving_your_vehicle_using_ev_mode_functions.xml 3. Set anticipated time and temperature of the vehicle departure after charging. 4. At repeat option, select the day of the week to activate target temperature for the departure time. 1C_ScheduledClimate Setting the Options for the AC Charger You can set the options for the AC charger including scheduled charging and charging current.
  • Page 321 driving_your_vehicle_using_ev_mode_functions.xml 1C_ScheduledClharging_2 • Charge ONLY during Off-peak: Charging is activated only during the off-peak time. It may not be able to reach the target battery charge level. • Prioritize Off-peak Charging: Charging is activated during the off-peak time. It may keep on charging pass off-peak time to reach the target battery charge level.
  • Page 322 driving_your_vehicle_using_ev_mode_functions.xml INFORMATION • The distance to empty is estimated based on the energy economy and temperatures. It may vary according to your driving style. • The distance to empty may vary even with the same target level according to changes of your driving style.
  • Page 323 driving_your_vehicle_using_ev_mode_functions.xml 1C_ElectricityUseSettingsV2L Setting Electric Vehicle Specialized Functions You can set various EV specialized functions such as battery conditioning mode and utility mode. Using Battery Conditioning If the high voltage battery temperature is too high or too low, and there is a risk that the battery's charging performance may deteriorate.
  • Page 324 driving_your_vehicle_using_ev_mode_functions.xml INFORMATION • Battery Conditioning function operates only in a vehicle equipped with a battery heater. • Battery Conditioning function does not operate to ensure driving distance when the battery charge level is low. The function also does not operate if the temperature of the battery is ideal for charging.
  • Page 325 You can choose the charging station, the detailed information is provided. INFORMATION When you sign up for HYUNDAI Bluelink service, the available chargers at each charging station appears. 1. On the Home screen from the infotainment system, select Electric Vehicle > Đ >...
  • Page 326 driving_your_vehicle_using_ev_mode_functions.xml • You can choose among Route, Current Position, Destination, and Favorite. • The direction (arrow) and distance, charger type, address, and location on the map of the charging stations corresponding to the selected option are displayed on the right side of the screen. 1C_ChargingStationList 2.

  • Page 327: Charging Your Electric Vehicle

    driving_your_vehicle_charging_your_electric_vehicle.xml Charging Your Electric Vehicle Electric vehicles can be charged via an AC charger or DC charger installed at public charging stations or residences. • If the vehicle cannot be moved to an AC or DC charging station, you can charge the vehicle via the portable charger supplied with the vehicle (In-Cable Control Box (ICCB) with a 120 V Plug).
  • Page 328 driving_your_vehicle_charging_your_electric_vehicle.xml Basic safety precautions for charging WARNING • Before charging, apply the Electronic Parking Brake (EPB) with the brake pedal pressed, shift to P (Park) and turn off the vehicle. Movement of the vehicle while charging may result in death, serious injury, or property damage. •...
  • Page 329 driving_your_vehicle_charging_your_electric_vehicle.xml INFORMATION • While charging, the gear cannot be shifted from P (Park) to any other gear. • Ensure the vehicle door is unlocked before disconnecting the charging connector. The release button on the charging connector does not work when the vehicle door is locked, or has not been unlocked for an extended period.
  • Page 330 If there is any sign of damage, corrosion, or rust on the charging connector and plug, or if the connection of the charging connector and plug feels loose, do not use the cable. Have your vehicle inspected by an authorized HYUNDAI dealer. Driving Your Vehicle...
  • Page 331 driving_your_vehicle_charging_your_electric_vehicle.xml Precautions when handling and storing the charging cable CAUTION • Always keep the charging connector and plug dry and clean. • Ensure that the connectors, plugs, and control box (portable charger) of the charging cable are not submerged or in contact with water. •...
  • Page 332 driving_your_vehicle_charging_your_electric_vehicle.xml CAUTION • Risk of electric shock. Do not disconnect under load. • Suitable for use on a circuit capable of delivering not more than 5,000 rms symmetrical Amperes, 120 V AC Maximum. • Suitable for use on a circuit capable of delivering not more than 30,000 rms symmetrical Amperes, 1,000 V DC Maximum.

  • Page 333: Checking The Charging Status

    driving_your_vehicle_charging_your_electric_vehicle.xml INFORMATION • The DC charging time may be longer at cold temperature below 20 °F (-17 °C). • Depending on the condition and durability of the high voltage battery, charger specifications, and ambient temperature, the time required for charging the high voltage battery may vary.
  • Page 334 driving_your_vehicle_charging_your_electric_vehicle.xml On the instrument cluster 2C_ChargingLevelIndicator Check the charging state on the instrument cluster to monitor the battery capacity of the high voltage and estimated charging time. When charging starts, the charging state will be displayed on instrument cluster. INFORMATION •...
  • Page 335 driving_your_vehicle_charging_your_electric_vehicle.xml Charge indicator lamp SOC [%] 25-49 % 50-74 % 75-100 % Checking information on the charging label 2C_ChargingLabelLocation 1C_ChargingLabel Open the charging door and check the information on the charging label on the right side of the charging connector. The charging label shows safety symbols and the rated input specifications for charging.
  • Page 336 If the charging connector is not disconnected due to battery being fully discharged or a wiring failure, open the liftgate and pull the emergency cable on the liftgate's right wall. If the charging connector does not disconnect after pulling the emergency cable, have your vehicle inspected by an authorized HYUNDAI dealer. Driving Your Vehicle...
  • Page 337 driving_your_vehicle_charging_your_electric_vehicle.xml CAUTION Do not disconnect the charging connector forcibly. Doing so may damage the charging connector or the charging inlet on the vehicle. Electric Charging Door The driver can open and close the charging door with the following methods: • When the shift gear is in P (Park), push the charging door to open.
  • Page 338 driving_your_vehicle_charging_your_electric_vehicle.xml NOTICE Do not pry on the charging door or use unauthorized tools to open the charging door. NOTICE • If the charging door does not open or close because ice has formed around it, tap lightly or push on the door to break the ice and release the door. •...
  • Page 339 driving_your_vehicle_charging_your_electric_vehicle.xml • If there is any dirt or contaminants, remove it using the air gun. WARNING Do not touch the charging connector of the charging cable or the charging inlet on the vehicle. 5. Remove the charging connector protection cap of the AC charging cable, hold the charging connector handle, and connect it to the AC charging inlet on the vehicle.
  • Page 340 driving_your_vehicle_charging_your_electric_vehicle.xml Using a DC Charger If you need to charge the vehicle in a shorter time, you can charge at high speeds using a DC charger installed in public charging stations. • To find a nearby charging station, refer to the 'Using Electric Vehicle Functions' section in this chapter.

  • Page 341: Adapter Specifications

    driving_your_vehicle_charging_your_electric_vehicle.xml CAUTION Before disconnecting the charging connector, check if there is an unlock button on the connector handle. If the connector handle is equipped with an unlock button, forcibly disconnecting the connector without pressing the button may damage the charging connector or charging inlet on the vehicle.
  • Page 342 driving_your_vehicle_charging_your_electric_vehicle.xml CCS1 DC CCS1 AC Rated Voltage 1,000 VDC 250 VAC 350 ADC at 95 °F (35 °C) Rated Current 80 A Boost Current: 400 A for 10 min Maximum Current 400 ADC 80 A 100 Mohm or 100 Mohm or Insulation Resistance above above...
  • Page 343 driving_your_vehicle_charging_your_electric_vehicle.xml Connecting the adapter 1. Press the latch on the CCS1 DC charger and connect the adapter to the charging connector. 2C_DCAdapter_1 Adapter Latch 2. Connect the CCS1 DC Adapter to the vehicle charging inlet, and check if the charging connector is properly connected.
  • Page 344 driving_your_vehicle_charging_your_electric_vehicle.xml 2. Disconnect the adapter from the vehicle charging inlet. 2C_DCAdapter_3 3. Press the latch on the charging connector and pull the charging connector to remove the adapter. 2C_DCAdapter_4 Adapter Latch 4. Plug the charging connector into the station. 5. Store the CCS1 DC Adapter in the vehicle. Storing and maintaining the adapter •...
  • Page 345 WARNING Only use a Hyundai genuine adapter on Hyundai vehicles. The CCS1 DC Adapter was designed specifically for Hyundai vehicles. Using the adapter on vehicles other than Hyundai may cause overheating, decreased charging speed, or damage to the vehicle or adapter.
  • Page 346 driving_your_vehicle_charging_your_electric_vehicle.xml 2. Connect the CCS1 AC Adapter to the vehicle charging inlet, and check if the charging connector is properly connected. 2C_ACAdapter_2 3. Charge the vehicle by following the procedures in the 'Charging with an AC charger' section in this chapter. Disconnecting the adapter 1.
  • Page 347 driving_your_vehicle_charging_your_electric_vehicle.xml 4. Store the CCS1 AC Adapter in the vehicle. Storing and maintaining the adapter • Always store the charging adapter in its designated case or pouch to prevent loss and damage. • Wipe the charging adapter lightly with a soft cloth before or after using the adapter. Dirt or contaminants on the adapter may affect charging conditions.
  • Page 348 • The adapter may affect or damage nearby electric medical devices. For more information about the affects the adapter may cause to electric medical devices, contact an authorized HYUNDAI dealer. • Do not clean the adapter using detergent. •...
  • Page 349 To prevent property damage or injury due to fire or explosion, follow the instructions below. • Only use a genuine HYUNDAI portable charger (if equipped). • Do not let children operate or touch the portable charger. Doing so may lead to unexpected accidents.
  • Page 350 • If the same symptom repeats after resetting the portable charger, have your vehicle inspected by an authorized HYUNDAI dealer. • If there is no status change for more than one minute, the portable charger will be switched to power saving mode, and the display light will be turned off.
  • Page 351 driving_your_vehicle_charging_your_electric_vehicle.xml NOTICE An example of a portable charger charging current setting suitable for the rated current of the power supplied is as follows. However, the appropriate charging current may vary depending on the environment, such as the power usage inside the building. Outlet Current ICCB Charge level 14-16 A...
  • Page 352 'Using an AC Charger' and 'Using a Portable Charger (ICCB)' section in this chapter. • You can set up or cancel scheduled charging using the HYUNDAI Bluelink app on your smartphone. For more information, refer to the infotainment system manual. •...
  • Page 353 If the vehicle is charged normally using another charger, contact the charger manufacturer for a solution. If the vehicle is not charged even when using another charger, have your vehicle inspected by an authorized HYUNDAI dealer. Driving Your Vehicle...

  • Page 354: Start/Stop Button

    driving_your_vehicle_engine_startstop_button.xml Start/Stop Button 2C_StartButton Whenever the front door is opened, the Start/Stop button illuminates and goes off for a few minutes after the door is closed. WARNING • To turn the vehicle off in an emergency: Press and hold the Start/Stop button for more than 2 seconds or rapidly press and release the Start/Stop button 3 times (within 3 seconds).
  • Page 355 driving_your_vehicle_engine_startstop_button.xml Start/Stop button positions Button Action Notes Position To turn off the vehicle, press the Start/ Stop button with the vehicle shifted to P (Park). If the Start/Stop button is If the steering wheel is not locked pressed with the vehicle shifted to D properly when you open the driver's (Drive), R (Reverse), or N (Neutral), the door, the warning chime will sound.
  • Page 356 driving_your_vehicle_engine_startstop_button.xml WARNING • Always wear appropriate shoes when operating your vehicle. Unsuitable shoes such as high heels, ski boots, sandals, and flip-flops may interfere with your ability to use the brake and accelerator. Do not drive barefoot. • Do not start your vehicle with the accelerator pedal depressed. Place your foot firmly on the brake pedal while starting your vehicle.

  • Page 357: Stopping The Vehicle

    driving_your_vehicle_engine_startstop_button.xml INFORMATION • The vehicle starts by pressing the Start/Stop button, only when the smart key is in the vehicle. • The vehicle may not start even if the smart key is in the vehicle but it is not near you (for example, in the cargo area).

  • Page 358: Remote Start

    driving_your_vehicle_engine_startstop_button.xml Remote start 2C_SmartKeyRemoteStartButton 1. Press the Door Lock Ď button within 32 ft. (10 m) from the vehicle. 2. Press and hold the Remote Start Ĕ button for over 2 seconds within 4 seconds. To turn off the vehicle, press the Remote Start Ĕ button once. NOTICE •...

  • Page 359: Vehicle Auto-Shut Off

    driving_your_vehicle_vehicle_autoshut_off.xml Vehicle Auto-Shut Off If Equipped If you forget to turn off the vehicle that EV Drivable for a period of time, vehicle shuts off automatically to prevent waste of the electric power. Operating Conditions Vehicle Auto-Shut Off timer operates when all the following conditions are satisfied: •...
  • Page 360 driving_your_vehicle_vehicle_autoshut_off.xml WARNING Do not leave a passenger or a pet in the vehicle in hot weather since the air conditioning system turns off when the vehicle is off. Driving Your Vehicle...

  • Page 361: Gear Shifting

    driving_your_vehicle_reduction_gear.xml Gear Shifting 2C_ShiftButtonOverview Rotary gear shift dial P button Gear Shift Operation To change the gear, depress the brake pedal and rotate the rotary gear shift dial. WARNING To reduce the risk of serious injury or death: • Always check the surrounding areas near your vehicle for people, especially children, before shifting a vehicle into D (Drive) or R (Reverse).
  • Page 362 driving_your_vehicle_reduction_gear.xml WARNING • Shifting into P (Park) while the vehicle is moving may cause you to lose control of the vehicle. • When parking on an incline, shift the gear to P (Park), apply the parking brake, and turn the wheels toward the curb to prevent the vehicle from rolling downhill. •...
  • Page 363 driving_your_vehicle_reduction_gear.xml To shift the gear to R (Rear), rotate the rotary gear shift dial to R (Reverse) while depressing the brake pedal. The direction of the rotary gear shift dial is the same as that of the wheel. NOTICE Always come to a complete stop before shifting into or out of R (Reverse) to prevent damaging the reducer.

  • Page 364: Shift-Lock System

    When the battery (12 V) is discharged You cannot shift the gears when the battery is discharged. Jump start your vehicle. Refer to the 'In Case of Vehicle Malfunction' section in chapter 8 or contact an authorized HYUNDAI dealer. Driving Your Vehicle...

  • Page 365: Good Driving Practices

    Shifter system malfunction This message is displayed when there is a malfunction with the rotary gear shift dial. Have your vehicle inspected by an authorized HYUNDAI dealer. Check shifter dial This message is displayed when there is a malfunction with the rotary gear shift dial.
  • Page 366 • In the event your vehicle leaves the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. • HYUNDAI Vehicle recommends you to follow all posted speed limits. Driving Your Vehicle...

  • Page 367: Regenerative Braking System (Paddle Shifter)

    driving_your_vehicle_regenerative_braking_system.xml Regenerative Braking System (Paddle Shifter) Regenerative braking system operates the paddle shifter to control the regenerative braking intensity of the vehicle. It improves the energy efficiency of the vehicle and helps the driver to have a better driving experience. INFORMATION The regenerative braking system uses the electric motor to engage the brake.

  • Page 368: One Pedal Driving

    driving_your_vehicle_regenerative_braking_system.xml Checking the regenerative braking level 2C_RegenerationBrakeLevelInfo The selected regenerative braking level appears on the instrument cluster. When the vehicle is turned off and on again after the regenerative braking level is lowered to 0, the braking level changes to 1. Regenerative Braking System Limitations Regenerative braking intensity cannot be changed using the paddle shifter in the following situations:...
  • Page 369 driving_your_vehicle_regenerative_braking_system.xml INFORMATION Coasting is the process of driving a vehicle without the brake pedal and the accelerator depressed. Coasting uses the inertia of driving energy instead of the vehicle power. Using one pedal driving Pull and hold the left paddle shifter ° for over 0.5 seconds while coasting to enable the one pedal driving mode.
  • Page 370 driving_your_vehicle_regenerative_braking_system.xml • 5 minutes have passed after the vehicle has stopped. • One pedal driving is limited due to other reasons. Using i-PEDAL i-PEDAL assists the driver to accelerate, decelerate, and stop the vehicle with only the accelerator pedal. Turning on/off the i-PEDAL •...

  • Page 371: Smart Regeneration System

    driving_your_vehicle_smart_regeneration_system.xml Smart Regeneration System The smart regeneration system recognizes vehicle-to-vehicle distance, speed and road gradient, and controls the regenerative braking level while coasting. It reduces unnecessary depressing of pedals to improve energy efficiency and driver convenience. INFORMATION • Coasting is the process of driving a vehicle without the brake pedal and the accelerator pedal depressed.
  • Page 372 driving_your_vehicle_smart_regeneration_system.xml Smart Regeneration System Operating Condition When the regenerative braking level appears as AUTO and the vehicle speed is above 6 mph (10 km/h), the system automatically controls the regenerative braking level under the following conditions. • The road gradient changes. •...
  • Page 373 driving_your_vehicle_smart_regeneration_system.xml Setting smart regenerative braking distance level 2C_SmartRegenerationSettings Select Electric Vehicle > Ĵ > Smart Regeneration in the infotainment system and set the driver's distance level (Level 1/Level 2/Level 3) at the smart regenerative braking distance phase, and a distance from the leading vehicle is adjusted according to the setting. Pausing Smart Regeneration System The smart regeneration system is temporarily turned off in the following conditions.

  • Page 374: General Precautions

    Do not install a license plate frame or other objects such as bumper sticker, film, bumper guard, or bumper wrap near the radar. • Use only genuine HYUNDAI parts to repair the bumper where the radar is located. • Smart regeneration system may not work properly if the bumper has been replaced, or the surroundings of the radar has been damaged or painted.
  • Page 375 driving_your_vehicle_smart_regeneration_system.xml slowly, or when driving uphill, or when driving through a curve. The regenerative braking intensity may increase and decelerate your vehicle. • Some vehicles in your lane may not be detected by the sensor: Narrow vehicles, such as motorcycles or bicycles Vehicles offset to one side Slow-moving vehicles or sudden decelerating vehicles Vehicles with small rear profile, such as trailers with no loads...
  • Page 376 driving_your_vehicle_smart_regeneration_system.xml Driving on hills 2C_SmartRegenerationSystemDrivingOnIncline During uphill or downhill coasting, the smart regeneration system may not detect a moving vehicle in your lane, and cause your vehicle to accelerate. Also, your vehicle speed decelerates when a vehicle ahead is detected suddenly. Apply the brake pedal or accelerator pedal depending on the road and driving conditions.

  • Page 377: Braking System

    driving_your_vehicle_braking_system.xml Braking System Power-Assist Brakes WARNING Take the following precautions: • Do not drive with your foot resting on the brake pedal. This will create abnormal high brake temperatures, excessive brake lining and pad wear, and increased stopping distances. • When descending down a long or steep hill, use the paddle shifter to increase the regeneration braking level in order to decrease your speed without using the brake pedal excessively.

  • Page 378: Parking Brake Operation

    • If the Parking brake warning light is still on even though the EPB has been released, have the system inspected by an authorized HYUNDAI dealer. • Do not drive your vehicle with EPB applied. It may cause excessive brake pad and brake rotor wear.

  • Page 379: Emergency Braking

    It may damage the brake system and cause a collision. NOTICE If you notice a noise or burning smell when the EPB is used for emergency braking, have the system inspected by an authorized HYUNDAI dealer. Driving Your Vehicle...
  • Page 380 If the EPB warning light is still on or the Parking brake warning light blinks, press the switch, and then pull it up. Repeat this one more time. If the EPB warning does not go off, have your vehicle towed on a flatbed tow truck to an authorized HYUNDAI dealer. Parking brake warning light...
  • Page 381 driving_your_vehicle_braking_system.xml Auto Hold operation 2C_AutoHoldButtonOnOff Activating Auto Hold With the driver's door and hood closed, press the AUTO HOLD button. • The white AUTO HOLD N indicator light comes on and the system is in standby. • When you stop the vehicle completely by depressing the brake pedal, Auto Hold maintains the brake pressure to hold the vehicle stationary.
  • Page 382 If the AUTO HOLD N indicator light changes to yellow, or the driver's door, hood, or liftgate open detection system malfunctions, Auto Hold does not work properly. Contact an authorized HYUNDAI dealer. • When the conversion from Auto Hold to EPB is not working properly, a warning sounds and the 'Press brake pedal to deactivate AUTO HOLD' message appears.

  • Page 383: Abs Operation

    POWER ON position. During that time, ABS goes through self-diagnosis and the light goes off if everything is normal. If the light stays on, contact an authorized HYUNDAI dealer as soon as possible. WARNING If the ABS ǹ warning light is on and stays on, you may have a problem with the ABS. Your power brakes work normally.
  • Page 384 The ESC indicator light blinks whenever ESC is operating. • If the ESC indicator light stays on, have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. • The ESC OFF indicator light comes on when ESC is turned off.
  • Page 385 driving_your_vehicle_braking_system.xml WARNING When ESC is active: • Drive slowly and NEVER attempt to accelerate. • Never turn off ESC while the ESC indicator light is blinking. You may lose control of the vehicle and crash. NOTICE Driving with wheels and tires with different sizes may cause the ESC system to malfunction.
  • Page 386 If the ESC OFF b indicator light or MDPS E warning light stays illuminated or blinks, your vehicle may have a malfunction with the VSM system. Have your vehicle inspected by an authorized HYUNDAI dealer as soon as possible. Hill-Start Assist Control (HAC) HAC helps prevent the vehicle from rolling backwards when starting from a stop on a hill.
  • Page 387 driving_your_vehicle_braking_system.xml CAUTION • HAC does not activate when the gear is shifted to P (Park) or N (Neutral). • If ESC malfunctions, HAC does not activate. INFORMATION HAC activates even when the ESC is deactivated. Downhill Brake Control (DBC) 2C_DownhillBrakeControl DBC assists when descending down a steep hill without having to depress the brake pedal.
  • Page 388 Vehicle speed is between 25-37 mph (40-60 km/h). The yellow warning light illuminates when the system may have malfunctioned or may not work properly during activation. If this occurs, Downhill Brake Control is deactivated. Contact an authorized HYUNDAI dealer as soon as possible. System malfunction...
  • Page 389 When MDPS has problems, CSC may partially operate. • If the ESC a or MDPS E warning light stays illuminated or blinks, have your vehicle inspected by an authorized HYUNDAI dealer. WARNING CSC is only a supplementary system to assist the driver. The driver should be responsible for the control of the vehicle.
  • Page 390 Have your vehicle inspected by an authorized HYUNDAI dealer. DO NOT drive with your foot resting on the brake pedal. Even light, but constant pedal pressure can result in the brakes overheating, brake wear, and possibly even brake failure.

  • Page 391: All Wheel Drive (Awd)

    driving_your_vehicle_4wd.xml All Wheel Drive (AWD) If Equipped The AWD system delivers motor power to all front and rear wheels for maximum traction. AWD is useful when extra traction is required on roads such as slippery, muddy, wet, or snow-covered roads. AWD may also be used for occasional off-road use such as established unpaved roads and trails.
  • Page 392 driving_your_vehicle_4wd.xml Driving on snow-covered or icy roads • Start off slowly by applying the accelerator pedal gently. • Use snow tires or tire chains. • Keep a sufficient distance between your vehicle and the vehicle in front. • Use vehicle braking during deceleration. •...
  • Page 393 driving_your_vehicle_4wd.xml • Reduce vehicle speed when cornering. The center of gravity of AWD vehicles is higher than conventional 2WD vehicles. The vehicle is more likely to roll over if you turn the steering wheel too quickly. • Always hold the steering wheel firmly when you are driving off-road. WARNING Do not grab the inside of the steering wheel when you are driving off-road.
  • Page 394 When replacing the tires, be sure to equip all four tires with the same size, type, tread, brand, and load-carrying capacity. If you equip your vehicle with any tire/wheel combination not recommended by HYUNDAI for off- road driving, do not use these tires for highway driving.
  • Page 395 driving_your_vehicle_4wd.xml If a 2WD roll tester must be used: 2C_4WDTestCaution Roll tester (Speedometer) Temporary free roller 1. Check the tire pressures recommended for your vehicle. 2. Place the front wheels on the temporary free roller for a speedometer test as shown in the illustration.

  • Page 396: Drive Mode Integrated Control System

    driving_your_vehicle_drive_mode_integrated_control_system.xml Drive Mode Integrated Control System 2C_DriveModeButton The drive mode can be selected according to the driver's preference or road condition. The system resets to ECO mode, when the vehicle is restarted. Selecting Drive Mode INFORMATION • When ECO/SPORT mode is selected, the ECO/SPORT indicator illuminates on the instrument cluster.
  • Page 397 driving_your_vehicle_drive_mode_integrated_control_system.xml MY DRIVE MODE Motor ECO/NORMAL/SPORT Steering NORMAL/SPORT INFORMATION The infotainment system may change after software updates. For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. Terrain Mode (for AWD vehicle) 2C_TerrainModeButton The terrain mode helps achieve optimal driving performance by controlling vehicle and braking according to the road conditions.

  • Page 398: System Malfunction

    When Road Active Noise Control is not working properly, the 'Check Road Active Noise Control system' warning message may appear on the cluster display. If this occurs, have the system be inspected by an authorized HYUNDAI dealer. Driving Your Vehicle...

  • Page 399: Active Sound Design

    driving_your_vehicle_active_sound_design.xml Active Sound Design • Active sound design provides various virtual driving sounds based on the driving mode, vehicle speed, and accelerator pedal. You can adjust the volume and change the settings for acceleration pedal response and sound style. • You can activate or deactivate the Active Sound Design function from the Settings menu in the infotainment system.

  • Page 400: Active Air Flap (Aaf)

    When 'Check Active Air Flap System' is popped up on display, stop the vehicle in a safe place and check the status of the air flap. Start the vehicle after performing the necessary work like foreign matter removal and waiting 10 minutes. If the pop-up remains up, contact an authorized HYUNDAI dealer. CAUTION •...

  • Page 401: Special Driving Conditions

    driving_your_vehicle_special_driving_conditions.xml Special Driving Conditions Hazardous Driving Conditions When hazardous driving conditions are encountered such as water, snow, ice, mud, and sand: • Drive cautiously and allow for longer braking distances. • Avoid abrupt braking or steering. • If your vehicle is stuck in snow, mud, or sand, use the second gear. Accelerate slowly to avoid unnecessary wheel spin.
  • Page 402 driving_your_vehicle_special_driving_conditions.xml • Slow down and keep more distance between you and other vehicles, because it may be more difficult to see at night, especially in areas where there are no street lights. • Adjust your mirrors to reduce the glare from other drivers' headlights. •...
  • Page 403 Use approved window washer anti-freeze solution Add window washer anti-freeze solution, as specified on the window washer container. Window washer anti-freeze solution is available from an authorized HYUNDAI dealer, and most vehicle accessory outlets. NOTICE Do not use coolant or other types of anti-freeze solution, to prevent any damage to the vehicle paint.
  • Page 404 driving_your_vehicle_special_driving_conditions.xml flashlight, emergency flares, sand, shovel, jumper cables, window scraper, gloves, ground cloth, coveralls, blanket, etc. Do not place objects or materials in the motor compartment Putting objects or materials in the motor compartment may cause a motor failure. Such damage is not covered by the manufacturer's warranty.
  • Page 405 Therefore, the use of snow tires is recommended instead of tire chains. If tire chains must be used, use genuine HYUNDAI Parts and install the tire chains after reviewing the instructions provided with the tire chains.
  • Page 406 driving_your_vehicle_special_driving_conditions.xml Chain Installation When installing tire chains, follow the manufacturer's instructions and mount them as tightly possible. Drive slowly (less than 20 mph (30 km/h) or the chain manufacturer's recommended speed limit) with chains installed. If you hear the chains contacting the body or chassis, stop and tighten them.

  • Page 407: Trailer Towing

    driving_your_vehicle_trailer_towing.xml Trailer Towing Towing a trailer requires experience. The combination of the vehicle and trailer itself is not as responsive as the vehicle by itself. Towing a trailer also requires additional equipment and adequate planning before a trip. Plan your trip according to the speed limits for towing a trailer that may differ from country to country.
  • Page 408 Parking Collision-Avoidance Assist Remote Smart Parking Assist For more information on each function, refer to chapter 7. The tow hitch harness installed to your vehicle must be a genuine HYUNDAI parts. For more information, consult an authorized HYUNDAI dealer products. •...

  • Page 409: Trailer Weight

    driving_your_vehicle_trailer_towing.xml • Carefully observe the weight and load limits provided in the following pages. Towing load limits Your vehicle can tow a trailer if you carefully observe the towing load limits, use proper equipment, and follow the towing guidelines. Check the load limits before driving. Total trailer weight Do not exceed the maximum allowable weight of the trailer, cargo, and everything in or on it.
  • Page 410 driving_your_vehicle_trailer_towing.xml Tongue load 2C_TongueLoad Gross axle weight Gross vehicle weight The tongue load is extremely important when setting up your trailer for towing with your vehicle. Excessive tongue load reduces front tire traction and steering control. For example, too little tongue load can make the trailer unstable, causing the trailer to sway because the weight of the trailer is shifted to the rear.

  • Page 411: Trailer Towing Equipment

    • A HYUNDAI trailer hitch accessory is available at an authorized HYUNDAI dealer. NOTICE Make sure that all equipment is properly installed and maintained, and that it meets your country's regulations.

  • Page 412: Driving With A Trailer

    driving_your_vehicle_trailer_towing.xml Instructions about safety chains may be provided by the hitch manufacturer or trailer manufacturer. Follow the manufacturer's recommendation when attaching safety chains. Always leave just enough slack so you can turn with your trailer. And, never allow safety chains to drag on the ground. Trailer brakes Your country's regulations may require trailers to have their own braking system if the loaded weight of the trailer exceeds certain minimums that can vary from country to...
  • Page 413 Do not connect a trailer lighting system directly to your vehicle's lighting system. Use an approved trailer wiring harness. Failure to do so may result in damage to the vehicle electrical system and/or personal injury. Contact an authorized HYUNDAI dealer for assistance.

  • Page 414: Maintenance When Towing A Trailer

    driving_your_vehicle_trailer_towing.xml 2. Shift the gear to P (Park). 3. Apply the parking brake and shut off the vehicle. 4. Place wheel chocks under the trailer wheels on the down hill side of the wheels. 5. Start the vehicle, hold the brakes, shift to neutral, release the parking brake and slowly release the brakes until the trailer chocks absorb the load.

  • Page 415: Driver Assistance System Information

    driver_assistance_system.xml 7. Driver Assistance System This chapter explains how to use the driver assistance features. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.

  • Page 416: Status Indicators

    driver_assistance_system_driver_assistance_system_information.xml CAUTION • Driver assistance system may not operate properly when the detecting sensors are obscured or damaged. Before using the driver assistance system, refer to the safety precautions and location of the sensors. • The braking and steering function of the driver assistance system operates properly only when the vehicle braking and steering system is operating normally.

  • Page 417: System Warnings

    X warning light illuminates, and the malfunctioning system's warning light illuminates on the instrument cluster. Have your vehicle inspected by an authorized HYUNDAI dealer. • You can check the warning message in the Utility view mode on the cluster display.
  • Page 418 You can check the warning message in the Utility view mode on the cluster display. If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. Parking Distance Warning example 2C_PDWInfo_2 •...

  • Page 419: System Settings

    driver_assistance_system_driver_assistance_system_information.xml WARNING • Even though the warning message or warning light does not appear on the instrument cluster temporarily, driver assistance system may not properly operate. • Driver assistance system may not operate properly in open areas where no objects are detected (for example, open terrain, empty parking lot, etc.) or when the detecting sensors are obscured right after the vehicle is turned on.
  • Page 420 driver_assistance_system_driver_assistance_system_information.xml 2C_WarningTypeSetInfo • Warning Volume: The warning volume can be adjusted. • Haptic Warning: The steering wheel vibration can be set. • Lane Safety Warning Sound: Yon can turn on or off the Lane Safety Warning Sound when the Haptic Warning is on. •...

  • Page 421: Forward Collision-Avoidance Assist (Fca)

    driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Forward Collision-Avoidance Assist (FCA) FCA helps avoid possible collision by detecting and monitoring a vehicle, motorcyclist, pedestrian, or cyclist ahead or around your vehicle while driving. FCA warns the driver with a warning message, warning sound, etc., or assists with braking or steering your vehicle according to the surroundings.

  • Page 422: Basic Function

    driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Basic function 2C_FCABasicFunction While driving, FCA Basic function helps avoid a collision according to the speed of your vehicle and the vehicle, motorcyclist, pedestrian, or cyclist ahead by warning or applying emergency braking. • Vehicle or motorcyclist: The function operates with a strong braking power when there is a risk of collision, the vehicle ahead is moving, and your vehicle speed is between about 6-80 mph (10-130 km/h) or the vehicle ahead is not moving, and your vehicle speed is between about 6-53 mph (10-85 km/h).
  • Page 423 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Junction Turning function 2C_FCAJunctionTurningFunction When turning left at a crossroad with the turn signal on, Junction Turning function helps avoid a collision with an oncoming vehicle or motorcyclist in an adjacent lane by warning or applying emergency braking. The function operates when: •...
  • Page 424 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Braking control ends about 2 seconds after your vehicle is stopped following an emergency braking event. For your safety, the driver should depress the brake pedal immediately and check the surroundings. CAUTION If your vehicle or the oncoming vehicle or motorcyclist is not driving straight, Direct Oncoming function warning and control may be late or may not operate.
  • Page 425 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Lane-Change Oncoming function 2C_FCALaneOvertakingOncomingFunction When changing lanes, Lane-Change Oncoming function helps avoid a collision with an oncoming vehicle or motorcyclist by warning or assisting the driver's steering. The function operates when: • Your vehicle speed is between about 25-90 mph (40-145 km/h) •...
  • Page 426 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml 2C_FCALaneChangeSideFunction_2 When changing lanes, Lane-Change Side function helps avoid a collision with the vehicle or motorcyclist ahead in the next lane by warning or assisting the driver's steering. The function operates when: • Your vehicle speed is between about 25-90 mph (40-145 km/h). •...
  • Page 427 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Evasive Steering Assist function 2C_FCAEvasiveSteeringAssistFunction When there is a risk of collision with a subject ahead in the same lane, Evasive Steering Assist function helps avoid a collision by warning or assisting the driver's steering. Emergency steering (Driver steering assist) If there is a risk of collision with a vehicle, motorcyclist, pedestrian, or cyclist in front, the steering is assisted to help prevent collision when the driver steers the vehicle to avoid collision.
  • Page 428 FCA automatically turns off. In this case, you cannot get help from Forward/Side Safety function of FCA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used) Driver Assistance System...
  • Page 429 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Warning methods You can set the following Warning methods for FCA: • Warning volume • Haptic warning • Driving safety priority For more information, refer to the 'Driver Assistance System Settings' section in this chapter. WARNING Take the following precautions when using FCA: •...
  • Page 430 The system operates properly when foreign material is removed form the sensors. If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the...
  • Page 431 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml • The vehicle or motorcycle in front has no tail lights, tail lights are located unusually, etc. • In low light conditions, the tail lamps of the front vehicle or motorcycle are turned off or not bright. • The rear of the front vehicle is small or the vehicle does not look normal, such as when the vehicle is tilted, overturned, or the side of the vehicle is visible, etc.
  • Page 432 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml Driving through a tollbooth, construction area, unpaved road, partial paved road, uneven road, speed bumps, etc. Driving near areas containing metal substances, such as a construction zone, railroad, etc. Driving on an incline road, curved road, etc. Driving through a roadside with trees or streetlights Driving through a narrow road where trees or grass are overgrown Driving in an area where there is interference by electromagnetic waves, such as strong radio waves or electrical noise...
  • Page 433 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml A big vehicle such as a bus or truck A small moving obstacle such as a pedestrian, animal, shopping cart or a baby stroller A vehicle with low height such as a sports car • The lane is difficult to distinguish because: There is a curb or road edges without a lane The lane markings are complicated or a structure substitutes for the lines, such as a construction area...
  • Page 434 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml • The pedestrian or cyclist is moving laterally. 2C_EvasiveSteeringAssist_2 • The pedestrian or cyclist is positioned inside of the operating area, but there is not enough space available for evasive steering. 2C_EvasiveSteeringAssist_3 Driver Assistance System...
  • Page 435 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml WARNING • Driving on a curved road 2C_SCCDrivingOnCurve FCA may not detect a vehicle, motorcyclist, pedestrian, or cyclist in front of you when driving on curved roads, adversely affecting the performance of the sensors. This may not result in warning, braking assist or steering assist when necessary. FCA may detect a vehicle, motorcyclist, pedestrian or cyclist in the next lane or outside the lane when driving on a curved road.
  • Page 436 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml 2C_FCAChangingLane Your vehicle Lane changing vehicle (into your lane) Lane changing vehicle (out of your lane) Same lane vehicle When the vehicle or motorcyclist moves into your lane from an adjacent lane, it cannot be detected by the sensor until it is in the sensor's detection range. FCA may not immediately detect the vehicle or motorcyclist when the vehicle changes lanes abruptly.
  • Page 437 driver_assistance_system_forward_collisionavoidance_assist_fca_sensor_fusion.xml • FCA does not operate on bicycles, or smaller wheeled objects, such as luggage bags, shopping carts, or strollers. • FCA may be temporarily disabled if interfered by strong electromagnetic waves. • FCA may not operate for about 15 seconds after the vehicle is started or the front view camera is initialized.

  • Page 438: Lane Keeping Assist (Lka)

    • When LKA is not working properly, the S indicator turns yellow. If the indicator remains illuminated after vehicle inspection, have your vehicle inspected by an authorized HYUNDAI dealer. LKA Operation 2C_LaneDepartureWarning To warn the driver that the vehicle is departing from the projected lane in front without activating the turn signal, the green S indicator light blinks on the cluster, and the steering wheel makes adjustments to keep vehicle inside the lane.
  • Page 439 driver_assistance_system_lane_keeping_assist_lka.xml • Your vehicle speed is about 40-120 mph (60-200 km/h) • The lane markings (or road edges) are detected Precautions • You can steer your vehicle even when steering is assisted by LKA. • It may require more or less force to turn the steering wheel when LKA is providing steering assistance.

  • Page 440: Lka Malfunction

    When the trailer's connector is plugged into your vehicle, LKA automatically turns off. In this case, you cannot get help from LKA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 441 driver_assistance_system_lane_keeping_assist_lka.xml • There are more than two lane markings (or road edges) on the road • The lane markings (or road edges) are complicated or a structure substitutes for the lines, such as a construction area • There are road markings, such as zigzag lanes, crosswalk markings and road signs •...

  • Page 442: Blind-Spot Collision-Avoidance Assist (Bca)

    driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml Blind-Spot Collision-Avoidance Assist (BCA) BCA helps detect approaching vehicles in the driver's blind spot areas and warn you of a possible collision with a warning light, warning sound, and warning message. If there is a collision risk when exiting a parallel space, BCA may assist with braking your vehicle to help avoid a collision.
  • Page 443 driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml Collision warning (while driving) 2C_BCAOperation When a vehicle is detected in the rear blind spot area, the warning light illuminates on the side view mirror (or digital side mirror), a warning appears on the cluster, and HUD (if equipped) under following conditions: •...
  • Page 444 driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml Collision-avoidance assist (while exiting parallel parking) 2C_BCAOperation_3 When the driver turns the steering wheel about one turn to exit the vehicle forward, if there is a risk of collision, warning (with warning light, warning message, warning sound, and steering wheel vibration) and braking activates under the following conditions: •...
  • Page 445 When the trailer's connector is plugged into your vehicle, BCA automatically turns off. In this case, you cannot get help from BCA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 446 The system operates properly when foreign material is removed form the sensors. If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the...
  • Page 447 driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml • The road pavement (or the peripheral ground) abnormally contains metallic components (for example, possibly due to subway construction) • There is a fixed object near the vehicle, such as sound barriers, guardrails, central dividers, entry barriers, street lamps, signs, tunnels, walls, etc. (including double structures) •...
  • Page 448 driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml WARNING • Driving on a curved road 2C_BCADrivingOnCurvedRoad BCA may not operate properly when driving on a curved road. The function may not detect the vehicle in the next lane or the function may recognize a vehicle in the same lane.
  • Page 449 driver_assistance_system_blindspot_collisionavoidance_assist_bca.xml Always pay attention to road and driving conditions while driving. • Driving where the heights of the lanes are different 2C_BCAHeightDifference BCA may not operate properly when driving where the heights of the lanes are different. The function may not detect the vehicle on a road with different lane heights (underpass joining section, grade separated intersections, etc.).

  • Page 450: Safe Exit Warning (Sew)

    driver_assistance_system_safe_exit_warning_sew.xml Safe Exit Warning (SEW) If Equipped SEW helps detect a vehicle approaching in the rear corner of your vehicle, after the vehicle is stopped and a passenger opens a door. 2C_SEWOperation SEW Operation 2C_SideMirrorWaringLamp SEW warns the driver with a warning message and an audible warning. The warning light on the side view mirrors also blinks to warn you.
  • Page 451 When the trailer's connector is plugged into your vehicle, SEW automatically turns off. In this case, you cannot get help from SEW. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 452 If the system does not operate properly after it is removed, have your vehicle be inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter.

  • Page 453: Safe Exit Assist (Sea)

    driver_assistance_system_safe_exit_assist_sea.xml Safe Exit Assist (SEA) If Equipped SEA helps detect a vehicle approaching in the rear corner of your vehicle, after the vehicle is stopped and a passenger opens a door. SEA may warn you with an audible warning and a warning message to help avoid a collision.
  • Page 454 driver_assistance_system_safe_exit_assist_sea.xml After the vehicle is turned off, SEA operates for about 3 minutes. However, SEA turns off immediately if the doors are locked. • If a rear door is opened from the outside, it opens regardless of SEA operation. • For more information on electric child safety lock ( Ņ...
  • Page 455 When the trailer's connector is plugged into your vehicle, SEA automatically turns off. In this case, you cannot get help from SEA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 456 driver_assistance_system_safe_exit_assist_sea.xml WARNING • SEA may not operate properly if interfered by strong electromagnetic waves. • SEA may not operate for about 3 seconds after the vehicle is started or the rear corner radars are initialized. • If the vehicle is turned off and restarted while the radar is blocked or malfunctioned, the condition is maintained.

  • Page 457: Manual Speed Limit Assist (Msla)

    driver_assistance_system_manual_speed_limit_assist_msla.xml Manual Speed Limit Assist (MSLA) You can set the speed limit when you do not want to drive over a specific speed. MSLA Operation If you drive over the preset speed limit, MSLA operates (set speed limit blinks and chime sounds) until the vehicle speed returns within the speed limit.
  • Page 458 driver_assistance_system_manual_speed_limit_assist_msla.xml • If you would like to drive over the preset speed limit, depress the accelerator pedal beyond the pressure point to activate the kickdown function. Temporarily pausing or Resuming MSLA Press the ç switch to temporarily pause the set speed limit. •...

  • Page 459: Intelligent Speed Limit Assist (Isla)

    driver_assistance_system_intelligent_speed_limit_assist_isla.xml Intelligent Speed Limit Assist (ISLA) If Equipped ISLA uses information from the detected road sign and navigation system to inform you of the speed limit and additional information, and help maintain within the speed limit on the road. CAUTION •...
  • Page 460 driver_assistance_system_intelligent_speed_limit_assist_isla.xml Changing set speed 2C_ISLAChangeSetSpeedInfo If the speed limit of the road changes during the operation of Manual Speed Limit Assist (MSLA) or Smart Cruise Control (SCC), an arrow in the direction of up or down appears to inform the driver that the set speed needs to be changed. At this time, the driver can change the set speed according to the speed limit by using the î...
  • Page 461 driver_assistance_system_intelligent_speed_limit_assist_isla.xml ISLA Settings 2C_SpeedLimitSettings With the vehicle on, select or deselect Setup > Vehicle > Driver Assistance > Speed Limit from the infotainment system to set whether to use each function. • Speed Limit Offset: Speed Limit Offset can be adjusted. Speed Limit Warning and Speed Limit Assist warns the driver or adjusts the driving speed when the vehicle speed exceeds the speed at which the set Speed Limit Offset is added to speed limit.
  • Page 462 If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter.
  • Page 463 driver_assistance_system_intelligent_speed_limit_assist_isla.xml • The driver is driving on a new road that is not in the navigation system yet. • Driving on a road under construction. • The navigation software is being updated while driving • The navigation is restarted while driving WARNING •...

  • Page 464: Driver Attention Warning (Daw)

    driver_assistance_system_driver_attention_warning_daw.xml Driver Attention Warning (DAW) DAW monitors your driving pattern while driving. When the driver's attention level is below a certain level, DAW recommends a break to help with safe driving. DAW Operation Consider taking a break The 'Consider taking a break' message appears and the Inattentive Driving W warning light blinks on the cluster with a warning sound to suggest that the driver take a break, when the driver's attention level is below a certain level.

  • Page 465: Daw Settings

    The system operates properly when foreign material is removed form the sensors. If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the...
  • Page 466 driver_assistance_system_driver_attention_warning_daw.xml Detecting sensors DAW uses the following sensor: • Front view camera For more information, refer to the 'Driver Assistance System Settings' and 'FCA Malfunction and Limitations' section in this chapter. DAW limitations DAW may not work properly in the following situations: •...
  • Page 467 driver_assistance_system_driver_attention_warning_daw.xml • When the vehicle ahead sharply steers (such as to turn left or right or make a U- turn, etc.) 2C_DAWSharplySteer Your vehicle Front vehicle • When the vehicle ahead abruptly departures 2C_DAWAbruptlyDeparture • When a pedestrian or bicycle is between you and the vehicle ahead 2C_DAWBetweenVehicles Driver Assistance System...
  • Page 468 driver_assistance_system_driver_attention_warning_daw.xml • When the vehicle detects a parked vehicle in front drive away in a parking lot 2C_DAWInParkingLot • When your vehicle stops at a lane that divide or merge and it is difficult to identify the vehicle ahead 2C_DAWInTollbooth WARNING DAW may not operate for about 15 seconds after the vehicle is started or the front view camera is initialized.

  • Page 469: Forward Attention Warning (Faw)

    driver_assistance_system_forward_attention_warning_faw.xml Forward Attention Warning (FAW) If Equipped FAW uses the in-cabin camera to help prevent the driver from being distracted while driving with an audible warning and warning light. FAW Operation Operating conditions FAW will operate when the following conditions are satisfied: •...
  • Page 470 If FAW does not operate properly after the object is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter.
  • Page 471 driver_assistance_system_forward_attention_warning_faw.xml • The driver is wearing sunglasses, special glasses, infrared cutoff glasses, refracting glasses or thick glasses • The driver has heavy eye makeup (eyeliner, mascara, color makeup, false eyelash) or eye piercing • The driver's view is blocked by his/her hair, hat, etc. •...

  • Page 472: Blind-Spot View Monitor (Bvm)

    driver_assistance_system_blindspot_view_monitor_bvm.xml Blind-Spot View Monitor (BVM) If Equipped BVM uses the wide-side view cameras to show the rear blind spot areas of your vehicle on the instrument cluster when the turn signal is turned on to help with safe lane changes. BVM Operation Turn signal switch 2C_BVMTurnSignal...
  • Page 473 BVM in the infotainment system to turn on the BVM feature. BVM Malfunction When BVM is not working properly, or the cluster display flickers, or the camera image does not appear properly, have your vehicle inspected by an authorized HYUNDAI dealer. WARNING •...

  • Page 474: Smart Cruise Control (Scc)

    driver_assistance_system_smart_cruise_control_scc.xml Smart Cruise Control (SCC) SCC helps maintain the set speed and distance with the detected vehicle ahead. INFORMATION Emergency Stop may operate while the SCC is in operation. For more information, refer to 'Emergency Stop (ES)' section in this chapter. SCC Operation Operating conditions 2C_SCCOperatingIndicatorInfo_2...
  • Page 475 driver_assistance_system_smart_cruise_control_scc.xml Turning SCC on/off 2C_SCCButton Press the Driving Assist ĩ button to turn on or off SCC. • When SCC is on, the current speed on the cluster is set as the set speed. • If there is no vehicle in front of you, the set speed is maintained, but if there is a vehicle in front of you, the speed may change to maintain the distance to the vehicle ahead.
  • Page 476 driver_assistance_system_smart_cruise_control_scc.xml • SCC may not temporarily operate while the vehicle is turning on or detecting sensors are initializing (such as rebooting, etc.). • You may hear sounds when SCC is braking your vehicle. This is normal and does not indicate a malfunction. •...
  • Page 477 driver_assistance_system_smart_cruise_control_scc.xml Temporarily canceling and resuming SCC 2C_SCCTemporaryPausing Press the ç switch or depress the brake pedal to temporarily cancel SCC. To resume SCC after the function was canceled, operate the +, - or ç switch. • If you push the + switch up or - switch down, vehicle speed is be set to the current speed on the cluster.
  • Page 478 driver_assistance_system_smart_cruise_control_scc.xml WARNING Be careful when accelerating temporarily, because the speed and distance is not controlled automatically even if there is a vehicle in front of you. Overtaking Acceleration Assist Overtaking Acceleration Assist operates when the turn signal indicator is turned on to the left while SCC is operating, and the following conditions are satisfied: •...
  • Page 479 driver_assistance_system_smart_cruise_control_scc.xml Restarting after stopping In traffic, your vehicle stops if the vehicle ahead of you stops. Also, if the vehicle ahead of you starts moving within a certain period, your vehicle starts as well. • If your vehicle is equipped with Emergency Stop and an in-cabin camera for Forward Attention Warning, the vehicle's dwell time may be extended depending on whether the driver is keeping eyes forward.
  • Page 480 driver_assistance_system_smart_cruise_control_scc.xml With the vehicle on, select Setup > Vehicle > Driver Assistance > Driving Convenience > Smart Cruise Control from the Settings menu in the infotainment system, you can change the vehicle distance, the acceleration, and the reaction speed manually. •...
  • Page 481 driver_assistance_system_smart_cruise_control_scc.xml WARNING • SCC does not substitute for proper and safe driving. It is the responsibility of the driver to always check the speed and distance to the vehicle ahead. • SCC may not recognize unexpected and sudden situations or complex driving situations, so always pay attention to driving conditions and control your vehicle speed.
  • Page 482 If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter.
  • Page 483 driver_assistance_system_smart_cruise_control_scc.xml Driving in a parking lot Driving through a construction area, unpaved road, partial paved road, uneven road, speed bumps, etc. Driving near areas containing metal substances, such as a construction zone, railroad, etc. Driving on an incline road, curved road, etc. Driving through a roadside with trees or streetlights Driving through a narrow road where trees or grass are overgrown There is interference by electromagnetic waves, such as driving in an area with...
  • Page 484 driver_assistance_system_smart_cruise_control_scc.xml speed on inclines and apply the brake pedal or accelerator pedal according to the road and driving conditions ahead. • Changing lanes 2C_SCCChangingLane Your vehicle Lane changing vehicle When a vehicle moves into your lane from an adjacent lane, it cannot be detected by the sensor until it is in the sensor's detection range.
  • Page 485 driver_assistance_system_smart_cruise_control_scc.xml In the following cases, some vehicle, pedestrian, or animal in your lane cannot be detected by the sensor. Always check the traffic conditions around the vehicle. If necessary, control your speed. Vehicle that is offset to one side Slow-moving vehicle or sudden decelerating vehicle Vehicle with higher ground clearance or vehicle carrying loads that stick out of the back of the vehicle Vehicle that has the front lifted due to heavy loads...
  • Page 486 driver_assistance_system_smart_cruise_control_scc.xml • When a vehicle in front of you merges out of the lane, SCC may not immediately detect the new vehicle that is now in front of you. Always pay attention to road and driving conditions while driving. 2C_SCCVehicleAheadDisappears •...

  • Page 487: Emergency Stop (Es)

    driver_assistance_system_emergency_stop_es.xml Emergency Stop (ES) If ES judges the driver is unresponsive, the function helps stop your vehicle within the driving lane by centering the vehicle in the lane and assisting in braking. ES Operation Operating conditions ES is ready to operate when both Smart Cruise Control and Lane Following Assist operate.

  • Page 488: After Stopping

    driver_assistance_system_emergency_stop_es.xml 2C_ESBasicInfo_2 The forewarning and ES are deactivated if one of the following conditions is met: • The driver's gaze is detected to be focused on the road ahead by in-cabin camera (if equipped) and the driver controls the steering wheel. •...
  • Page 489 When ES is not working properly, the 'Check Emergency Stopping function.' warning message appears, and the Master X warning light illuminates on the instrument cluster. If this occurs, have your vehicle inspected by an authorized HYUNDAI dealer. Detecting sensors ES uses the following sensors: •...

  • Page 490: Navigation-Based Smart Cruise Control (Nscc)

    driver_assistance_system_navigationbased_smart_cruise_control_nscc.xml Navigation-Based Smart Cruise Control (NSCC) NSCC can help drive at a safe speed according to the road conditions when driving on highways by using road information from the navigation system while Smart Cruise Control (SCC) is operating. • NSCC is available only on controlled access roads. •...
  • Page 491 driver_assistance_system_navigationbased_smart_cruise_control_nscc.xml NSCC Settings Highway Set Speed Auto Change 2C_NSCCSetInfo With the vehicle on, select Setup > Vehicle > Driver Assistance > Driving Convenience > Highway Auto Speed Change from the Settings menu to turn on NSCC or deselect to turn off the function.
  • Page 492 driver_assistance_system_navigationbased_smart_cruise_control_nscc.xml • When the performance of sensors that detect objects around the vehicle is at limit • If the lane marking (or road edge) is unusual or damaged 2C_NSCCLimitation Set route Branch line Driving route Main road Curved road section •...
  • Page 493 driver_assistance_system_navigationbased_smart_cruise_control_nscc.xml • When it is judged that you are driving out of the route by entering the highway interchange or junction, Highway Curve Zone Auto Slowdown function does not operate. 2C_NSCCLimitation_3 Driving route Branch line Curved road section Main road •...
  • Page 494 driver_assistance_system_navigationbased_smart_cruise_control_nscc.xml WARNING • NSCC is not a substitute for safe driving practices, but a convenience function. Always have your eyes on the road, and it is the responsibility of the driver to avoid violating traffic laws. • The navigation's speed limit information may differ from the actual speed limit information on the road.

  • Page 495: Lane Following Assist (Lfa)

    driver_assistance_system_lane_following_assist_lfa.xml Lane Following Assist (LFA) LFA helps detect lane markings and/or a vehicle ahead on the road, and provide steering assist to help keep your vehicle in the center of the lane. Turning LFA On/Off 2C_LaneSafetyButton With the vehicle on, shortly press the Lane Driving Assist p button located on the steering wheel to turn on LFA.
  • Page 496 driver_assistance_system_lane_following_assist_lfa.xml • When both lane markings are detected, the lane lines on the instrument cluster changes from gray to white. Lane undetected/Lane detected 2C_LaneDetectionInfo Lane Following Assist If the vehicle ahead and/or both lane markings are detected and your vehicle speed is below 110 mph (180 km/h), the green º...

  • Page 497: Lfa Malfunction

    When the trailer's connector is plugged into your vehicle, LFA automatically turns off. In this case, you cannot get help from LFA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 498 driver_assistance_system_lane_following_assist_lfa.xml LFA limitations When the detecting sensors cannot detect the surroundings, LFA may not operate properly. For more information, refer to the 'Lane Keeping Assist (LKA)' section in this chapter. WARNING • For more information on LFA precautions, refer to the 'LKA Malfunction and Limitations' section in this chapter.

  • Page 499: Highway Driving Assist (Hda)

    driver_assistance_system_highway_driving_assist_hda.xml Highway Driving Assist (HDA) HDA helps maintain a set distance and speed from the vehicle ahead while driving on a highway main section and helps center the vehicle in the lane. HDA Operation 2C_HDAActiveIndicatorInfo HDA operates on main roads of highway, and does not operate on interchanges or junctions.
  • Page 500 driver_assistance_system_highway_driving_assist_hda.xml HDA operates when driving on the main road of highways, and turning on/off HDA by pressing the Driving Assist ĩ button. • HDA operates automatically when entering the main road of highways while Lane Following Assist (LFA) and Smart Cruise Control (SCC) are operating. HDA operating status 2C_HDAActiveIndicatorInfo_2 The indicators appear on the cluster display as below depending on the status of HDA.
  • Page 501 driver_assistance_system_highway_driving_assist_hda.xml Warning and control when hands-off detected Hands-off warning If the driver takes their hands off the steering wheel for several seconds, the 'Keep hands on steering wheel' warning message appears and an audible warning sounds. CAUTION If you keep taking your hands off the steering wheel, then the Emergency Stop will activate.
  • Page 502 driver_assistance_system_highway_driving_assist_hda.xml Controlled access roads are roads with limited entrances and exits that allow uninterrupted high speed traffic flow. Available highway (Controlled access road) Select Interstate Highway and U.S. (Federal) and State Highways Canada Select Provincial and Territorial Highways Additional highways may be available in future navigation system updates. HDA does not operate on interchanges or junctions.
  • Page 503 driver_assistance_system_highway_driving_assist_hda.xml • Hazard warning flasher is off While Highway Lane Change Assist function is turned on (indicator on), LFA does not cancel even if the turn signal indicator or hazard warning flasher is operating. Highway Lane Change Assist operation 2C_HDALaneChangeSwitchOperation Highway Lane Change Assist operates and the Ħ...
  • Page 504 driver_assistance_system_highway_driving_assist_hda.xml • Highway Lane Change Assist operates when the turn signal lever is pushed slightly. The turn signal indicator blinks until the lane change is complete even when the turn signal lever is released to the center. Highway Lane Change Assist standby Highway Lane Change Assist function is in the standby state and the indicator appears in gray when one of the ready state condition is not satisfied, or when entering or driving on one of the following roads.
  • Page 505 When the trailer's connector is plugged into your vehicle, HDA automatically turns off. In this case, you cannot get help from HDA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 506 If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter.
  • Page 507 driver_assistance_system_highway_driving_assist_hda.xml WARNING • The driver is responsible for controlling the vehicle and safe driving. • Always have your hands on the steering wheel while driving. • HDA is a supplemental function that assists the driver in driving the vehicle and is not a complete autonomous driving system.
  • Page 508 driver_assistance_system_highway_driving_assist_hda.xml • The infotainment system is overloaded by simultaneously performing functions such as route search, video playback, voice recognition, etc. • GPS signals are blocked in areas such as a tunnel • The driver goes off course or the route to the destination is changed or canceled by resetting the navigation •...

  • Page 509: Rear View Monitor (Rvm)

    driver_assistance_system_rear_view_monitor_rvm.xml Rear View Monitor (RVM) If Equipped RVM shows the area behind the vehicle to assist you when parking. RVM Operation Turning RVM on/off 2C_RearTopViewFunction 2C_RearViewInfo Change View button Previous button Infotainment system screen button When the gear is shifted to R (Reverse), RVM turns on and the rear view appears on the screen.

  • Page 510: Camera Settings

    driver_assistance_system_rear_view_monitor_rvm.xml If Extended Rear View Monitor is selected, RVM screen stays on under the following circumstances: • The gear is in P (Park), N (Neutral) or D (Drive) • The Parking/View button is pressed while the vehicle is driving below 6 mph (10 km/h) or less in D (drive) or N (Neutral) •...
  • Page 511 When RVM malfunctions, the image on the screen may appear green, blue, or black. When RVM is not working properly, or the screen flickers, or the camera image does not appear properly, have your vehicle inspected by an authorized HYUNDAI dealer. RVM limitations •...

  • Page 512: Surround View Monitor (Svm)

    driver_assistance_system_surround_view_monitor_svm.xml Surround View Monitor (SVM) If Equipped SVM uses the wide view cameras and images appear around your vehicle through the infotainment system to help with safe parking. SVM Operation Turning SVM on/off 2C_RearTopViewFunction 2C_SVMRearViewInfo Change View button Previous button Infotainment system screen button SVM turns on under the following circumstances: •...
  • Page 513 driver_assistance_system_surround_view_monitor_svm.xml • The Parking/View button is pressed • The Previous ŷ button is selected on the surround view menu • The Infotainment system button is pressed Selecting Front view/Rear view Front view/Rear view can be changed by shifting the gear. You may select the view using the View Mode button.
  • Page 514 driver_assistance_system_surround_view_monitor_svm.xml When the 3D view is selected by pressing the View Mode button, the gear is in R (Reverse), P (Park), N (Neutral) or D (Drive) when vehicle speed is below 6 mph (10 km/h). Precautions • 3D view does not show guidelines. •...
  • Page 515 When SVM malfunctions, the image on the screen may appear green, blue, or black. When SVM is not working properly, or the screen flickers, or the camera image does not appear properly, have your vehicle inspected by an authorized HYUNDAI dealer. SVM limitations •...
  • Page 516 driver_assistance_system_surround_view_monitor_svm.xml WARNING • The image shown on the screen may differ from the actual distance of the object. Also, the parking guide lines may not be accurate if the vehicle is tilted due to cargo load or position. Make sure to directly check the vehicle's surroundings for safety. •...

  • Page 517: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml Rear Cross-Traffic Collision-Avoidance Assist (RCCA) RCCA helps detect vehicles approaching from the rear left or right while your vehicle is reversing and warns you of a possible collision with a warning message and a warning sound. Also, RCCA may assist with braking your vehicle to help avoid a collision. CAUTION Warning timing may differ depending on the speed of the approaching vehicle.
  • Page 518 driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml To warn the driver of an approaching vehicle from the rear left/right side of your vehicle, the warning light on the side view mirror will blink and a warning will appear on the instrument cluster. At the same time, an audible warning sounds. If Rear View Monitor (RVM) is operating, a warning also appears on the infotainment system.
  • Page 519 driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml WARNING • Brake control ends when: The approaching vehicle is out of the detecting range The approaching vehicle passes behind your vehicle The approaching vehicle does not drive toward your vehicle The approaching vehicle speed slows down The driver depresses the brake pedal with sufficient power •...
  • Page 520 When the trailer's connector is plugged into your vehicle, RCCA automatically turns off. In this case, you cannot get help from RCCA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 521 driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml RCCA limitations RCCA may not operate properly, or it may operate unexpectedly under the following circumstances: • Departing from where trees or grass are overgrown • Departing from where roads are wet • Speed of the approaching vehicle is fast or slow Braking control may not work, driver's attention is required in the following circumstances: •...
  • Page 522 driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml WARNING • In the following cases, the vehicle approaching from the rear left or right may not be detected. RCCA may be limited and may not warn or assist in braking. Always check your surroundings and drive carefully. When your vehicle is backing up and there is a driving vehicle or structure nearby 2C_RCCADrivingNearVehicle Structure When the vehicle is in a complex parking environment (for example, a vehicle leaving...
  • Page 523 driver_assistance_system_rear_crosstraffic_collisionavoidance_assist_rcca.xml 2C_RCCANearSlope Pulling into the parking space where there is a structure that can reflect electric waves 2C_RCCAThereIsStructure Structure Wall When the vehicle is parked rearward 2C_RCCAParkRearward • When you are towing a trailer or another vehicle, turn off RCCA for safety reasons. •...

  • Page 524: Parking Distance Warning (Pdw)

    driver_assistance_system_forwardreverse_parking_distance_warning_pdw.xml Parking Distance Warning (PDW) PDW uses the front, side (if equipped), and rear ultrasonic sensors to help detect and warn you if a person, animal, or object is within a certain distance when your vehicle is stopped or driving at low speed. PDW Operation Turning PDW on/off 2C_ParkingSafetyButton...
  • Page 525 driver_assistance_system_forwardreverse_parking_distance_warning_pdw.xml • When Rear View Monitor (RVM) or Surround View Monitor (SVM) is on (with PDW turned on), PDW appears on the infotainment system. • The shape of the indicator in the illustration may differ from the actual vehicle. Forward Parking Distance Warning activates under the following conditions. •...
  • Page 526 When the trailer's connector is plugged into your vehicle, Reverse PDW automatically turns off. In this case, you cannot get help from Reverse PDW. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 527 • If the PDW does not operate properly, have your vehicle inspected by an authorized HYUNDAI dealer. • Driving with the liftgate open is abnormal. For your safety, be aware and drive safely.

  • Page 528: Parking Collision-Avoidance Assist (Pca)

    driver_assistance_system_parking_collisionavoidance_assist_pca.xml Parking Collision-Avoidance Assist (PCA) If Equipped PCA can warn the driver and assist with braking to help reduce the possibility of collision with a pedestrian or an object while driving at low speed. PCA can detect a pedestrian or an object when: •...
  • Page 529 driver_assistance_system_parking_collisionavoidance_assist_pca.xml Warning example 2C_PCAOnInfo_3 Front/Side Safety if equipped Front/Side Safety of PCA activates when the following conditions are satisfied: • Rear Safety and Front/Side Safety is selected from the Parking Safety settings menu in the infotainment system • The liftgate and door are closed •...

  • Page 530: Parking Safety

    When the trailer's connector is plugged into your vehicle, PCA automatically turns off. In this case, you cannot get help from PCA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 531 If the system does not operate properly after it is removed, have your vehicle inspected by an authorized HYUNDAI dealer. For more information, refer to the 'Driver Assistance System Warnings and Indicators' section in this chapter. Detecting sensors PCA uses the following sensors: •...
  • Page 532 driver_assistance_system_parking_collisionavoidance_assist_pca.xml The wind is either strong (above 12 mph (20 km/h)) or blowing perpendicular to the rear bumper Objects generating ultrasonic noise, such as vehicle horns, loud motorcycle engines or truck air brakes, are near your vehicle An ultrasonic sensor with similar frequency is near your vehicle The road is slippery or inclined •...
  • Page 533 driver_assistance_system_parking_collisionavoidance_assist_pca.xml WARNING • Always exercise extreme caution while driving. The driver is responsible for braking and safe driving • Always look around your vehicle to make sure there are no pedestrians or objects before moving the vehicle. • The performance of PCA may vary under certain conditions. If vehicle speed is above 2 mph (4 km/h), PCA provides collision avoidance assist only when pedestrians are detected.

  • Page 534: Remote Smart Parking Assist 2 (Rspa 2)

    driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Remote Smart Parking Assist 2 (RSPA 2) If Equipped RSPA uses vehicle sensors to help the driver park and exit parking spaces remotely from outside the vehicle by controlling the steering wheel, vehicle speed, and gearshifts. RSPA helps the driver remotely move the vehicle forward or backward from the outside and also helps with perpendicular reverse parking or parallel reverse parking from outside or inside the vehicle.

  • Page 535: Remote Operation

    driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Remote Operation The function can be operated from outside the vehicle using the smart key. Following is an example of using Remote Operation. Using the function with vehicle off 2C_RemoteForwardRewardProcedure 1. Within a certain range from the vehicle press the door lock Ď button on the smart key and lock all doors.
  • Page 536 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Using the function with vehicle on 2C_RemoteForwardRewardProcedure_2 1. Park the vehicle in front of the space where you want to use Remote Operation function, and shift the gear to P (Park). 2. Press and hold the Parking/View ā button to turn on RSPA. A message 'Under Remote Control' appears on the infotainment system.
  • Page 537 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml WARNING • Before starting moving the vehicle with the Remote Operation function from the outside of the vehicle, make sure that all passengers have gotten out of the vehicle. • If the vehicle's battery is discharged or RSPA malfunctions when parked in a narrow parking space, Remote Operation function does not operate.
  • Page 538 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Available functions Parallel reverse parking 1. Turning RSPA on With the vehicle on, depress the brake pedal and shift the gear to D (Drive) or N (Neutral). Press and hold the Parking/View ā button to turn on RSPA. 2. Searching for parking space 2C_SearchParkingSpace Slowly drive forward maintaining the distance of about 40 in.
  • Page 539 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml With the vehicle stopped by depressing the brake pedal, touch the infotainment system to select the desired parking type. 4. Selecting operating mode 2C_SelectParkingType • Operating mode: Remote Parking, Smart Parking After selecting a parking type, the infotainment system guides you with Remote Parking function and Smart Parking function.
  • Page 540 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • Smart Parking 2C_SmartParking_1 2C_SmartParking_2 1. Press the Parking/View ā button when the vehicle is stopped by depressing the brake pedal. 2. Release the brake pedal while pressing the Parking/View ā button. RSPA automatically controls the steering wheel, vehicle speed and gearshift While Smart Parking function is operating, if you do not hold down the Parking/ View ā...
  • Page 541 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Selecting parking type Selecting operating mode • While Smart Parking function is operating, if the vehicle is stopped by depressing the brake pedal, and the gear is shifted, Parking function turns off. At this time, EPB is not engaged. •...
  • Page 542 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • If Parking function is canceled unintentionally by pressing the Parking/View ā button before the parking type is selected, you can return to the parking type selection stage by pressing and holding the button again while the vehicle is stopped. •...
  • Page 543 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml WARNING Before selecting the Parking type, the driver should check whether the parking space is suitable. If the searched parking space by RSPA is narrow or unsuitable for parking, do not select the Parking type and move the vehicle to search for another parking space. •...
  • Page 544 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml 3. Selecting exit direction 2C_SelectExitDirection With the vehicle stopped by depressing the brake pedal, touch the infotainment system to select the desired exit direction. 4. Smart Exit 2C_SmartExitInstructions 1. Press the Parking/View ā button when the vehicle is stopped by depressing the brake pedal.
  • Page 545 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Checking space Selecting exit direction • While Smart Exit function is operating, if the vehicle is stopped by depressing the brake pedal, and the gear is shifted, Exiting function turns off. At this time, EPB is not engaged. WARNING •...
  • Page 546 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml Hazard warning Operation status Smart key LED Turn signal light The turn signal of the parking Green LED continuously Under control direction blinks blinks until the first reverse is complete. Red LED continuously Pause Blinks blinks Red LED illuminates for 4 Blinks 3 times and seconds and then turns off turns off...
  • Page 547 When the trailer's connector is plugged into your vehicle, RSPA automatically turns off. In this case, you cannot get help from RSPA. Pay extra attention when you drive when the function is inactive. (If a Hyundai genuine Trailer Kit that can determine whether a trailer is connected is used)
  • Page 548 2C_CheckRSPAInfo When RSPA is not working properly, the 'Check Parking Assist' warning message appears on the infotainment system. If the message appears, stop using RSPA, and have your vehicle inspected by an authorized HYUNDAI dealer. RSPA canceled 2C_CheckRSPACancelledInfo When RSPA is operating, the function can be canceled, and the 'Parking Assist Canceled' warning message may appear regardless of the parking order.
  • Page 549 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml RSPA standby 2C_CheckRSPAStandbyInfo The 'Parking Assist Conditions Not Met' message appears in the following circumstances: • When Parking/View ā button has been pressed and held while RSPA is in standby. After a while, press and hold the Parking/View ā button again to see if RSPA works. •...
  • Page 550 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • Your vehicle is leaned severely to one side • Your vehicle is equipped with a trailer hitch • The license plate is installed differently from the original location • Your vehicle is overloaded or cargo is loaded to one side •...
  • Page 551 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • Parking on uneven road 2C_RSPAParkingUnevenRoadInfo RSPA may cancel when the vehicle slips, or the vehicle cannot move due to road conditions such as pebbles or fragmented stones. • Parking near a truck 2C_RSPAParkingBehindTruckInfo Do not use RSPA around vehicles with higher ground clearance, such as a bus, truck, etc.
  • Page 552 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • Parking next to a misaligned vehicle 2C_RSPAParkingWithSideVehicleInfo If RSPA is used when parking in a space next to misaligned vehicles, your vehicle may not be parked side by side. However, if there is a parking line and it is detected properly, your vehicle parks side by side with the parking line.
  • Page 553 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml RSPA performance may reduce or collision with an obstacle may occur when there is a narrow object, circular pillar, square pillar, or a pillar surrounded by objects such as a fire extinguisher, etc., near the parking space. The driver should park the vehicle manually.
  • Page 554 RSPA may not operate properly if the vehicle needs wheel alignment adjustment such as when the vehicle tilts to one side. Have your vehicle inspected by an authorized HYUNDAI dealer. • Noise may be heard when braking occurs by RSPA or when the brake pedal is depressed by the driver.
  • Page 555 driver_assistance_system_remote_smart_parking_assist_rspa_2.xml • If the vehicle is remotely started that has been parked in cold weather for a long time, the operation of Remote Parking function may be delayed or canceled depending on vehicle condition. Driver Assistance System...

  • Page 556: Sensor Information

    driver_assistance_system_sensors.xml Sensor Information Driver Assistance System Sensors The driver assistance systems on your vehicle uses cameras and sensors to help detect potential hazards in the vicinity of your vehicle. 2C_ADASSensor 2C_ADASSensor_1 2C_IndoorCamera Front view camera Wide-front/side view camera Front corner radar Front radar Front side ultrasonic sensors Front ultrasonic sensors...

  • Page 557: Sensor Limitations

    If there is impact on or near the sensors, driver assistance system may not operate properly even though a warning message does not appear on the instrument cluster. Have your vehicle inspected by an authorized HYUNDAI dealer. • If the sensors or the surroundings are contaminated or damaged, driver assistance system may not work properly.
  • Page 558 Even though a warning message does not appear on the instrument cluster, driver assistance system may not operate properly. Have your vehicle inspected by an authorized HYUNDAI dealer. • If the radar have been replaced or repaired, have your vehicle inspected by an authorized HYUNDAI dealer.

  • Page 559: Ultrasonic Sensors

    driver_assistance_system_sensors.xml • The bumper around the radar is covered with objects, such as a bumper sticker, bumper guard, bike rack, etc. • The radar is blocked by other vehicles, walls or pillars. • A trailer or carrier is installed around the radar. •...
  • Page 560 Do not impact the wide view cameras. If the camera is out of position due to impact, it may not operate properly. If the wide view camera is damaged, have your vehicle inspected by an authorized HYUNDAI dealer. In-cabin camera The in-cabin camera is mounted to the steering wheel.

  • Page 561: Declaration Of Conformity

    driver_assistance_system_declaration_of_conformity.xml Declaration Of Conformity Front Radar The radio frequency components (Front Radar) complies : 2C_FrontRadarCertification Front Corner Radar (if equipped)/Rear Corner Radar The radio frequency components (Rear Corner Radar) complies: 2C_FrontRearSideRadarCertification Driver Assistance System...
  • Page 562 driver_assistance_system_declaration_of_conformity.xml Driver Assistance System...

  • Page 563: Emergency Situations

    emergency_situations.xml 8. Emergency Situations This chapter explains how to safely deal with emergency situations while driving. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.

  • Page 564: In Case Of Vehicle Malfunction

    For more information, refer to the instructions in 'Jump Starting' provided in this chapter. If the vehicle still does not start, contact an authorized HYUNDAI dealer for assistance. NOTICE Do not push or pull the vehicle to start it. This could cause damage to your vehicle.
  • Page 565 emergency_situations_in_case_of_vehicle_malfunction.xml WARNING To prevent SERIOUS INJURY or DEATH to you or bystanders, always follow these precautions when working near or handling the battery: • Always read and follow instructions carefully when handling a battery. Ě • Wear eye protection designed to protect the eyes from acid splashes. ğ...

  • Page 566: Jump-Starting Procedure

    emergency_situations_in_case_of_vehicle_malfunction.xml • NEVER attempt to recharge the battery when the vehicle's battery cables are connected to the battery. • The electrical ignition system works with high voltage. NEVER touch these components with the vehicle running or when the Start/Stop button is in the ON position. •...
  • Page 567 • If your vehicle does not start after a few attempts, it probably requires service. Have your vehicle inspected by an authorized HYUNDAI dealer. 8. When the vehicle starts, first disconnect the jumper cable from the negative - battery terminal of your vehicle and the black, negative - battery/jumper terminal of the assisting vehicle.

  • Page 568: Tire Pressure Monitoring System (Tpms)

    emergency_situations_in_case_of_vehicle_malfunction.xml speed that it is safe to do so, brake carefully and pull off the road. Drive off the road as far as possible and park on a firm, level ground. If you are on a divided highway, do not park in the median area between the two traffic lanes.
  • Page 569 emergency_situations_in_case_of_vehicle_malfunction.xml For more information, refer to the 'Cluster display view modes' section in chapter 4 of the complete Owner's Manual. • Tire pressure appears after a few minutes of driving. If the tire pressure does not appear when the vehicle is stopped, the message, 'Drive to display' appears. •...
  • Page 570 TPMS Low Tire Pressure Telltale. NOTICE Have the system inspected by an authorized HYUNDAI dealer if: • The Low Tire Pressure Telltale/TPMS Malfunction Indicator does not illuminate for 3 seconds when the Start/Stop button is moved to the POWER ON or DRIVE READY position.
  • Page 571 emergency_situations_in_case_of_vehicle_malfunction.xml Low Tire Pressure Position and Tire Pressure Telltale 2C_TPMSWaringLampOverView_2 2C_TireLowPressureWarning TPMS is not a substitute for manually checking the tire pressure with a tire gauge. Changes in temperature affect tire pressure. For proper tire inflation and tire pressure measurement procedure, refer to the 'Check tire inflation pressure' section in the chapter When the tire pressure monitoring system warning indicators illuminate and a warning...
  • Page 572 Changing a tire with TPMS If you have a flat tire, the Low Tire Pressure and Position Telltales come on. Have the flat tire repaired by an authorized HYUNDAI dealer as soon as possible or replace the flat tire with the spare tire.
  • Page 573 Low Tire Pressure Telltale and TPMS Malfunction Indicator goes off within a few minutes of driving. If the indicators do not turn off after a few minutes, visit an authorized HYUNDAI dealer. •...
  • Page 574 For safe operation, carefully read and follow the instructions in this manual before use. The Tire Mobility Kit is a temporary fix to the tire, have the tire replaced by an authorized HYUNDAI dealer as soon as possible. WARNING •...
  • Page 575 Use of the Tire Mobility Kit may not be effective for tire damage larger than about 0.16 in (4 mm). • Contact an authorized HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. • Do not use the Tire Mobility Kit if a tire is severely damaged by driving run flat or with insufficient air pressure.
  • Page 576 emergency_situations_in_case_of_vehicle_malfunction.xml Components of the Tire Mobility Kit 1C_TMKPartsOverview Connectors and cable for terminal connection ON/OFF switch Compressor Pressure gauge for displaying the tire inflation pressure Button for reducing the tire inflation pressure Speed restriction label Sealant bottle Filling hose from sealant bottle to wheel Filling hose WARNING •...
  • Page 577 emergency_situations_in_case_of_vehicle_malfunction.xml Using the Tire Mobility Kit when a tire is flat CAUTION • Detach the speed restriction label from the sealant bottle, and place it in a highly visible place inside the vehicle such as on the steering wheel to remind the driver not to drive too fast.
  • Page 578 emergency_situations_in_case_of_vehicle_malfunction.xml 2. Connect the filling hose on the compressor to the sealant bottle. Keep the sealant bottle upright so the filling hose is heading upwards. 2C_TMKPrecedure 3. Unscrew the valve cap from the valve of the defective wheel and screw the filling hose of the sealant bottle onto the tire valve.
  • Page 579 emergency_situations_in_case_of_vehicle_malfunction.xml 7. Connect the cables to the RED + jumper terminal in the motor compartment fuse panel and the BLACK - jumper terminal in numerical order. 2C_TMKPrecedure_2 RED cable: î jumper terminal BLACK cable: ï jumper terminal CAUTION • Tire Mobility Kit cable connection can be dangerous if done incorrectly. Therefore, to avoid harm to yourself or damage to the Tire Mobility Kit or battery, follow the Tire Mobility Kit cable connection procedures.
  • Page 580 Use of the Tire Mobility Kit may not be effective for tire damage larger than about 0.16 in. (4 mm). • Contact an authorized HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. • The sealant on the tire pressure sensor and wheel should be removed when you replace the tire with a new one and inspect the tire pressure sensors.
  • Page 581 emergency_situations_in_case_of_vehicle_malfunction.xml How to adjust tire pressure 1. Park your vehicle in a safe location. 2. Connect the filling hose of the compressor directly to the tire valve. 2C_TMKProcedure_6 CAUTION Do not use the sealant when the tire pressure only needs to be adjusted. 3.
  • Page 582 emergency_situations_in_case_of_vehicle_malfunction.xml INFORMATION • The pressure gauge may show higher than actual reading when the compressor is running. To get an accurate tire reading, the compressor needs to be turned off. • When reinstalling the repaired or replaced tire and wheel on the vehicle, tighten the wheel nut to 116-130 lbf·ft (16-18 kgf·m).
  • Page 583 emergency_situations_in_case_of_vehicle_malfunction.xml 2C_TireRemovalTool_3 Valve stem Emergency Situations...

  • Page 584: Towing

    Wheel lift Towing 2C_TowingGood_2 2C_TowingTwoWheelDrive Dollies If towing is necessary, contact an authorized HYUNDAI dealer or a commercial tow-truck service. AWD vehicles must be towed with a wheel lift and dollies or flatbed with all the wheels off the ground.
  • Page 585 emergency_situations_towing.xml When towing your vehicle without wheel dollies: 1. Release the parking brake before turning off the vehicle. 2. Place the Start/Stop button to the OFF position. 3. Change the gear to N (Neutral) while depressing the brake pedal. 4. Press the Start/Stop button to the POWER ON position. Precautions when moving a short distance using towing hook and so on before towing a vehicle Move short distances within 33 ft.
  • Page 586 emergency_situations_towing.xml CAUTION When a vehicle fire occurs due to the battery, there is a risk of a second fire. Contact the fire department when towing the vehicle. Emergency Situations...

  • Page 587: Countermeasures For Accidents Or Fire

    If the electric vehicle is submerged while driving, immediately turn off the vehicle and evacuate to a safe place with your key. Contact the emergency rescue service such as a fire department, or an authorized HYUNDAI dealer. WARNING Never touch the submerged electric vehicle. This may lead to an accident such as an electric shock or fire.
  • Page 588 When you paint or apply heat treatment to the vehicle as a result of an accident, the performance of the high voltage battery can be reduced. If heat treatment is required, contact an authorized HYUNDAI dealer. • Use or install only genuine parts. Third-party parts or modified parts may damage the...

  • Page 589: Maintenance

    maintenance.xml 9. Maintenance This chapter explains how to inspect and maintain your vehicle, to ensure safe driving. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. • The information provided may differ depending on which functions are applicable to your vehicle.

  • Page 590: Important Safety Precautions

    Performing maintenance on the vehicle can be dangerous. If you lack sufficient knowledge, experience, or proper tools and equipment to do the work, have it done by an authorized HYUNDAI dealer. Before performing maintenance: • Park your vehicle on level ground. Shift the vehicle to P (Park), apply the parking brake, and move the Start/Stop button to the OFF position.

  • Page 591: Maintenance Services

    Have your vehicle maintained and repaired by an authorized HYUNDAI dealer. An authorized HYUNDAI dealer meets HYUNDAI's high service quality standards and receives technical support from HYUNDAI in order to provide you with a high level of service satisfaction. Guide to HYUNDAI Genuine Parts HYUNDAI Genuine Parts are the parts used by HYUNDAI Motor Company to manufacture vehicles.
  • Page 592 Purchasing HYUNDAI Genuine Parts Look for the HYUNDAI Genuine Parts Logo on the package (see below). HYUNDAI Genuine Parts exported to the U.S. are packaged with labels written only in English. HYUNDAI Genuine Parts are only sold through authorized HYUNDAI Dealerships.
  • Page 593 maintenance_maintenance_services.xml Your vehicle must not be modified in any way. Such modifications may adversely affect the performance, safety, or durability of your vehicle and may, in addition, violate conditions of the limited warranties covering the vehicle. NOTICE Improper owner maintenance during the warranty period may affect warranty coverage. For more information, read the separate Owner's Handbook &...

  • Page 594: Owner Maintenance

    Owner Maintenance The following lists are vehicle checks and inspections that should be performed by the owner or an authorized HYUNDAI dealer at the frequencies indicated to help ensure safe and dependable operation of your vehicle. Any adverse conditions should be brought to the attention of your authorized HYUNDAI dealer as soon as possible.
  • Page 595 maintenance_owner_maintenance.xml WARNING Be careful when checking your coolant level when the motor compartment is hot. This may result in coolant being blown out of the opening and cause serious burns and other injuries. At least twice a year: • Check the radiator, heater, and air conditioning hoses for leaks or damage. •...

  • Page 596: Scheduled Maintenance Services

    maintenance_scheduled_maintenance_services.xml Scheduled Maintenance Services Follow the normal maintenance schedule if the vehicle is not operated under severe usage conditions. If your vehicle is operated under severe usage conditions, you should inspect, replace or refill more frequently than the normal maintenance schedule. For more information on severe usage conditions, refer to the 'Maintenance Under Severe Usage and Low Mileage...
  • Page 597 120 months. After that, replace every 25,000 mi. (39,000 km) or 24 months Inspect every 8,000 mi. (13,000 km) or 12 Brake fluid months, Replace every 48,000 mi. (78,000 km) or 48 months Consult an authorized HYUNDAI dealer, when replacing or adding coolant. Maintenance...
  • Page 598 maintenance_scheduled_maintenance_services.xml EV Special Care I: Inspect and if necessary, adjust, correct, clean or replace. R: Replace or change. Number of months or driving distance, whichever comes first Months 24 36 48 60 84 96 MAINTENANCE INTERVALS Miles×1,000 8 16 24 32 56 64 40 48 80 88...
  • Page 599 maintenance_scheduled_maintenance_services.xml Maintenance Driving Maintenance item Maintenance intervals operation condition Replace every 80,000 mi. Gear fluid A, C, F, G (120,000 km) Steering gear rack, Inspect more frequently A, B, C, D, E linkage and boots depending on the condition Inspect more frequently Suspension ball joints A, B, C, D, E depending on the condition...

  • Page 600: Vehicle Inspection And Maintenance

    If the coolant level is low, add enough distilled (deionized) water mixed with antifreeze to bring the level to the MAX mark. If frequent additions are required, have your vehicle inspected by an authorized HYUNDAI dealer for a cooling system inspection. Maintenance...
  • Page 601 maintenance_vehicle_inspection_and_maintenance.xml WARNING • Never remove the battery system coolant cap or the drain plug while the radiator is hot. Hot coolant and steam may blow out under pressure, causing serious injury. • Turn the motor system off and wait until it cools down. Use extreme care when removing the coolant cap.

  • Page 602: Changing Coolant

    It is suitable to use for most temperature ranges of -31 °F (-35 °C) and higher. Changing coolant Have the coolant changed by an authorized HYUNDAI dealer according to the maintenance schedule at the beginning of this chapter.

  • Page 603: Washer Fluid

    If the level is low, add the specified brake fluid to the MAX level. If the fluid level is excessively low or frequent additions are required, have the brake system inspected by an authorized HYUNDAI dealer. WARNING If brake fluid comes in contact with your eyes, flush your eyes with clean water for at least 15 minutes and get immediate medical attention.
  • Page 604 maintenance_vehicle_inspection_and_maintenance.xml WARNING To prevent serious injury or death: • Do not use coolant or antifreeze in the washer fluid reservoir. Coolant can severely limit your visibility when sprayed on the windshield and may cause loss of vehicle control resulting in a collision. •...

  • Page 605: Wiper Blades

    maintenance_vehicle_inspection_and_maintenance.xml 2. Press and hold the lock on the left side of the cover. 2C_AirFilterReplacementProcedure_3 3. Replace the cabin air filter. NOTICE 2C_AirFilterReplacementCaution Install a new cabin air filter with the arrow symbol (↓) facing down, to improve effectiveness. 4. Reassemble in the reverse order of disassembly. Wiper Blades Contamination of the windshield or wiper blades with foreign substances may reduce the effectiveness of the windshield wipers.
  • Page 606 maintenance_vehicle_inspection_and_maintenance.xml NOTICE • To prevent damage to the wiper blades, arms, or other components, do not: Use gasoline, kerosene, paint thinner, or other solvents on or near them. Attempt to move the wipers manually. • To prevent damage: Never use non-specified wiper blades. Lift the wiper arms when in the top wiping position.

  • Page 607: Rear Window Wiper Blade Replacement

    maintenance_vehicle_inspection_and_maintenance.xml 3. While pushing the clip, pull down the wiper blade. Remove the wiper blade from the wiper arm. 2C_FontWiperReplacementProcedure_6 4. Install a new wiper blade assembly in the reverse order of removal. 5. Gently put the wipers back down onto the windshield. 6.
  • Page 608 maintenance_vehicle_inspection_and_maintenance.xml 4. Insert a new wiper blade into the wiper arm until an audible "click" sounds. 2C_RearWiperReplacementProcedure_2 5. If the replacement is complete, put down the wiper arm onto the rear windshield, and turn the Start/Stop button to POWER ON and operate the wipers to check the blade is installed correctly.
  • Page 609 maintenance_vehicle_inspection_and_maintenance.xml Battery WARNING To prevent serious injury or death to you or bystanders when working near or handling the battery: • Always read and follow instructions carefully when handling a battery. Ě • Wear eye protection designed to protect the eyes from acid splashes. ğ...
  • Page 610 maintenance_vehicle_inspection_and_maintenance.xml • Do not attempt to jump start your vehicle if your battery is frozen. • Never attempt to recharge the battery when the vehicle's battery cables are connected to the battery. • The electrical Start/Stop button works with high voltage. NEVER touch these components with the ¢...

  • Page 611: Battery Capacity Label

    maintenance_vehicle_inspection_and_maintenance.xml • Rinse any spilled electrolyte from the battery immediately with a solution of water and baking soda. • If the vehicle is not going to be used for an extended period of time, disconnect the battery cables. Battery capacity label 2C_BatteryCapacityLabel_2 Battery recharging By battery charger...
  • Page 612 maintenance_vehicle_inspection_and_maintenance.xml WARNING To prevent the risk of serious injury or death from explosions or acid burns: • Before performing maintenance or recharging the battery, turn off all accessories and stop the vehicle. • Keep all flames, sparks, or smoking materials away from the battery. •...

  • Page 613: Tires And Wheels

    maintenance_vehicle_inspection_and_maintenance.xml • Clock (refer to chapter 5 of the complete Owner's Manual) • Infotainment System (refer to the infotainment system manual) Tires and wheels WARNING Tire failure may cause loss of vehicle control and result in a collision. To reduce risk of serious injury or death: •...

  • Page 614: Recommended Cold Tire Inflation Pressures

    • Under-inflation may cause excessive wear, poor handling, and reduced energy efficiency. Wheel deformation is also possible. Keep your tire pressures at the proper levels. If a tire frequently needs refilling, have it inspected by an authorized HYUNDAI dealer. •...
  • Page 615 maintenance_vehicle_inspection_and_maintenance.xml 2C_TireSideWallLabelling Manufacturer or brand name Tire size designation Checking tire life (TIN) Tire ply composition and material Maximum permissible inflation pressure Maximum load rating Uniform tire quality grading Manufacturer or brand name Manufacturer or brand name is shown. Tire size designation A tire's sidewall is marked with a tire size designation.
  • Page 616 maintenance_vehicle_inspection_and_maintenance.xml Speed Rating Symbol Maximum Speed 130 mph (210 km/h) 149 mph (240 km/h) 168 mph (270 km/h) 186 mph (300 km/h) Checking tire life (TIN) Any tires that are over six years old, based on the manufacturing date, (including the spare tire) must be replaced by new ones.
  • Page 617 maintenance_vehicle_inspection_and_maintenance.xml TEMPERATURE A Tread wear The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one-and-a-half times (1½) as well on the government course as a tire graded 100.

  • Page 618: Tire Maintenance

    maintenance_vehicle_inspection_and_maintenance.xml • If the cold tire inflation pressure matches the recommended pressure on the tire and loading information label, no further adjustment is necessary. • If the pressure is low, add air until it reaches the recommended pressure. • If you overfill the tire, release air by pushing on the metal stem in the center of the tire valve.

  • Page 619: Wheel Replacement

    Tire rotation 2C_TireRotation To equalize tread wear, HYUNDAI recommends that the tires be rotated according to the maintenance schedule or sooner if irregular wear develops. When rotating tires, check for correct balance, uneven wear, and damage.
  • Page 620 M+S (Mud and Snow) on the tire side wall. Snow tires If you plan to operate your vehicle in snowy or icy conditions, HYUNDAI recommends the use of snow tires on all four wheels.
  • Page 621 Inspect the tire condition and pressure every 1,800 mi. (3,000 km). • It is difficult to visually inspect for tire damage with your eyes. If any damage is found, contact your authorized HYUNDAI dealer to replace the tire. Tire terminology and definitions •...
  • Page 622 maintenance_vehicle_inspection_and_maintenance.xml • GAWR RR: Gross Axle Weight Rating for the Rear axle. • Intended outboard sidewall: The side of an asymmetrical tire, that must always face outward when mounted on a vehicle. • Kilopascal (kPa): The metric unit for air pressure. •...

  • Page 623: Other Maintenance Items

    maintenance_vehicle_inspection_and_maintenance.xml • Treadwear indicators: Narrow bands, sometimes called 'wear bars', that show across the tread of a tire when only 1/16 in. of tread remains. • UTQGS: Uniform Tire Quality Grading Standards is a tire information system that provides consumers with ratings for a tire's traction, temperature and treadwear. Ratings are determined by tire manufacturers using government testing procedures.

  • Page 624: Fuses

    maintenance_fuses.xml Fuses A vehicle's electrical system is protected from electrical overload damage by fuses. This vehicle has 2 (or 3) fuse panels, one located in the driver's side panel bolster, the other in the motor compartment. If any of your vehicle's lights, accessories, or controls do not work, check the appropriate circuit fuse.
  • Page 625 maintenance_fuses.xml 1C_InstrumentPanelFuseLabel_2 Fuse Fuse Name Circuit Protected Rating A/C2 7.5 A Front/Rear A/C Controller, A/C Control Module BRAKE 7.5 A Stop Lamp Switch, BDC SWITCH Driver/Passenger Door Mood Lamp, Rear Door Mood Lamp LH/RH, Rear Corner Radar LH/RH, Front/Rear A/C Controller, MEMORY1 10 A ADAS Unit (Parking), BDC, A/C Control Module, Cluster Unit,...
  • Page 626 maintenance_fuses.xml Fuse Fuse Name Circuit Protected Rating Steering Tilt & Telescopic Unit, ICC Unit, Data Link Connector, Rain Sensor, Multifunction Switch, Hazard Lamp Switch, 2ND MODULE7 10 A Power Seat Module LH/RH, Power Liftgate Unit, Rear Blower Relay, Driver Power Window Switch 3RD Seat Folding Unit, Driver Power Seat Switch, Driver Power Seat Module E-SHIFTER1 10 A...
  • Page 627 maintenance_fuses.xml Fuse Fuse Name Circuit Protected Rating MDPS2 7.5 A MDPS Unit ADP Unit, AMP, Console Mood Lamp #1~#2, CCNC Keyboard, MODULE1 10 A CCNC Head Unit, DCU, ADAS Unit (Parking), BDC, CCU, Infotainment Jack Assembly P/SEAT (PASS)1 30 A Passenger Power Seat Switch P/SEAT (RR 25 A...
  • Page 628 maintenance_fuses.xml Fuse Fuse Name Circuit Protected Rating P/WINDOW Driver Safety Power Window Module, Rear Safety Power 30 A (LH) Window Module LH, Rear Power Window Switch LH AIR BAG2 10 A Airbag Control Module DOOR LOCK 20 A Door Lock/Unlock Relay, Two Turn Unlock Relay 2ND Seat Heater Module, 2ND Air Ventilation Seat Module, 2ND S/HEATER (RR) 25 A...
  • Page 629 maintenance_fuses.xml 1C_CargoFuseLabel_1 Fuse Rating Fuse name Circuit Protected REARR HEATED 40 A Rear Junction Block (Rear Heaterd Relay) BLOWER (RR) 40 A Rear Junction Block (Rear Blower Relay) USB CHARGER2 20 A Driver Seat USB Connector USB CHARGER3 20 A Passenger Seat USB Connector 3rd ROW SEAT FOLDING 30 A...
  • Page 630 maintenance_fuses.xml Fuse Rating Fuse name Circuit Protected 2ND Seat LH Folding Actuator, 2ND Power Seat P/SEAT (RR LH)2 30 A Module LH USB CHARGER5 20 A Luggage USB Charging Connector RH TRAILER2 20 A E-Brake (Trailer) TRAILER3 20 A Trailer Connector USB CHARGER1 20 A Infotainment Jack Assembly...
  • Page 631 maintenance_fuses.xml 1C_MotorRoomFuseBoxLabel_1 Motor compartment junction block Fuse Type Fuse Name Circuit Protected Rating MDPS1 100 A MDPS Unit COOLING 80 A Cooling Fan Motor MULTI PDC (Fuse - AIR BAG2, SUNROOF1, SUNROOF2, FUSE- 60 A MODULE9, CHARGER, AMP, P/SEAT(DRV)3) BLOWER 50 A Blower Relay VCU1...
  • Page 632 maintenance_fuses.xml Fuse Type Fuse Name Circuit Protected Rating SBCM(DRV), SBCM(PASS), P/SEAT(DRV)1, P/SEAT(DRV)2, P/SEAT(PASS)1, P/SEAT(PASS)2) IEB1 60 A IEB Unit IEB2 60 A IEB Unit PCB Block (IG3 Main Relay, Wiper Power Relay, Fuse - 60 A HORN, EPCU2, VCU2) COOLANT 40 A Coolant Driver HUB1...
  • Page 633 maintenance_fuses.xml Fuse Type Fuse Name Circuit Protected Rating A/C1 10 A Blower Relay, A/C Control Module Battery Fuse Panel 2C_BatteryFuseLabel 1C_BatteryFuseLabel_1 Maintenance...
  • Page 634 maintenance_fuses.xml Fuse Name Fuse Rating 225 A How to Check Fuses by Type Type O: Normal/X: Disconnection Blade Cartridge Multi Midi Replacing Fuses Instrument panel fuse replacement 1. Turn off the vehicle and all other switches. Maintenance...
  • Page 635 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it is not tight, contact an authorized HYUNDAI dealer. In an emergency, if you do not have a spare fuse, use a fuse of the same rating from a circuit you may not need for operating the vehicle.
  • Page 636 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it is not tight, contact an authorized HYUNDAI dealer. CAUTION Always securely install the fuse panel cover. Water may contact the fuse and cause an electrical failure.
  • Page 637 Multi fuse/Midi fuse Multi Type 2C_EngineRoomFuseReplacement_4 Midi Type 2C_MidfuseReplacement If the multi fuse or midi fuse is blown, contact an authorized HYUNDAI dealer. Maintenance...

  • Page 638: Light Bulbs

    Light Bulbs Contact an authorized HYUNDAI dealer to replace most vehicle light bulbs. It is difficult to replace vehicle light bulbs because other parts of the vehicle must be removed before you can get to the bulb. This is especially true for removing the headlight assembly to get to the bulb(s).
  • Page 639 Replacing the LED Light If the LED light does not operate, contact an authorized HYUNDAI dealer for replacement. The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.
  • Page 640 maintenance_light_bulbs.xml Rear combination light replacement 2C_RearLampOverview High mounted stop light Tail/Stop light/Side marker Turn signal light Reverse light License plate light replacement 2C_LicensePlateLampLED Interior light replacement Map lamp, Personal lamp, Room lamp, Multi console storage lamp, Vanity mirror lamp, Glove box lamp, Front trunk lamp, Mood lamp, and Cargo area lamp Map lamp 2C_MapLampLED Maintenance...
  • Page 641 maintenance_light_bulbs.xml Personal lamp 2C_PersonalLamp_2 Room lamp 2C_RoomLampLED Multi console storage lamp 2C_MultiConsole Maintenance...
  • Page 642 maintenance_light_bulbs.xml Vanity mirror lamp 2C_SunvisorLampLED Glove box lamp 2C_GloveBoxLampLED Front trunk lamp 2C_FrontTrunkLampLED Maintenance...
  • Page 643 maintenance_light_bulbs.xml Mood lamp (if equipped) 2C_MoodLamp Cargo area lamp 2C_LuggageRoomLamp Maintenance...

  • Page 644: Appearance Care

    maintenance_appearance_care.xml Appearance Care Exterior Care Exterior general caution It is very important to follow the label directions when using any chemical cleaner or polish. Read all warning and caution statements that appear on the label. Finish maintenance Washing To help protect your vehicle's finish from rust and deterioration, with a frequency of at least once a month with lukewarm or cold water.
  • Page 645 maintenance_appearance_care.xml NOTICE • High pressure water may damage front and rear cameras, sensors, vehicle trim, and boots (rubber or plastic covers) or connectors. • Do not use strong soap, chemical detergents, or hot water, and do not wash the vehicle in direct sunlight or when the body of the vehicle is warm.
  • Page 646 Do not use any cleaners containing acid or alkaline detergents. Corrosion protection Protecting your vehicle from corrosion By using the most advanced design and construction practices to combat corrosion, HYUNDAI produces vehicles of the highest quality. However, this is only part of the Maintenance...
  • Page 647 maintenance_appearance_care.xml job. To achieve the long-term corrosion resistance your vehicle can deliver, the owner's cooperation and assistance are also required. Common causes of corrosion • Road salt, dirt, and moisture that is allowed to accumulate underneath the vehicle • Removal of paint or protective coatings by stones, gravel, abrasion, minor scrapes, and dents that leave unprotected metal exposed to corrosion High-corrosion areas If you live in an area where your vehicle is regularly exposed to corrosive materials,...
  • Page 648 maintenance_appearance_care.xml • Keep paint and trim in good condition Scratches or chips in the finish must be covered with 'touch-up' paint as soon as possible to reduce the possibility of corrosion. If bare metal is showing through, the attention of a qualified body and paint shop is recommended. Bird droppings are highly corrosive and may damage painted surfaces in just a few hours.
  • Page 649 maintenance_appearance_care.xml Wrinkles may appear as a natural result of stretching and shrinking depending on the temperature and humidity. Wrinkles may appear naturally from usage. It is not a fault of the products. The seat is made of stretchable fabric to improve comfort. The parts contacting the body are curved and the side supporting area is high which provides driving comfort and stability.
  • Page 650 • If the interior wooden trim is damaged, you may get a splinter from the wood surface. Have the damaged interior wooden trim replaced by an authorized HYUNDAI dealer. Cleaning the seat belt webbing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet.

  • Page 651: California Perchlorate Notice

    Notice to California Vehicle Dismantlers: The airbag module, safety belt pretensioners, and remote batteries must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a). Special handling may be necessary. See: www.dtsc.ca.gov/hazardouswaste/perchlorate. Contact an authorized HYUNDAI dealer for handling and disposal. Maintenance...
  • Page 652 maintenance_california_perchlorate_notice.xml Maintenance...

  • Page 653: Vehicle Information, Reporting Safety Defects, And Consumer

    vehicle_information_reporting_safety_defects_and_consumer_information.xml 10. Vehicle Information, Reporting Safety Defects, and Consumer Information This chapter provides additional information on the vehicle, such as the vehicle dimensions and vehicle identification information. INFORMATION • The illustrations are shown as a guide. The actual shape may differ from the illustration. •...
  • Page 654 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_specifications.xml Long range Performance Item Front 255 Front 350 Max. torque (Nm) Rear 350 Rear 350 Rear 350 Capacity (kWh) 110.3 110.3 110.3 Battery (Lithium- Power output ion) (kW) Voltage (V) Charger (OBC: 7 (single-phase) / 7 (single- 7 (single-phase) / On-Board Max.
  • Page 655 39.68±0.9 oz. (1125±25 Without heat pump 9.70±0.35 oz. (275±10 Heat pump Compressor lubricant 8.64±0.35 oz. (245±10 Without heat pump Contact an authorized HYUNDAI dealer for more details. Light Source Light source Source type Specification High Headlight Turn signal light, Parking light, Daytime running...
  • Page 656 CAUTION Severe motor and reduction gear damage may result from the use of poor quality lubricants that do not meet HYUNDAI specifications. You must always use high quality lubricants that meet the specifications listed below. Vehicle Information, Reporting Safety Defects, and Consumer Information...
  • Page 657 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_specifications.xml Classification Specifications Capacity Reduction Rear 4.33-4.44 US qt. (4.1-4.2 ℓ) gear fluid Front HK ATF 6S SP4M-1 3.38-3.49 US qt. (3.2-3.3 ℓ) Rear 4.33-4.44 US qt. (4.1-4.2 ℓ) SAE J1704 DOT-4 LV, Brake fluid FMVSS 116 DOT-4, IS As required O4925 CLASS-6 without 21.08 US qt.

  • Page 658: Vehicle Load Limit

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml Vehicle Load Limit Two labels on your driver's door sill show how much weight your vehicle was designed to carry: the Tire and Loading Information Label and the Certification Label. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle's weight ratings, from the vehicle's specifications and the Certification Label: Base Curb Weight This is the weight of the vehicle including high voltage battery and all standard...
  • Page 659 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml Type B 2C_TireLabel_2 Type C 2C_TireLabel_3 Type D 2C_TireLabel_4 Vehicle Information, Reporting Safety Defects, and Consumer Information...

  • Page 660: Vehicle Capacity Weight

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml Type E 2C_TireLabel_5 Type F 2C_TireLabel_6 The label located on the driver's door jamb shows the original tire size, cold tire pressures recommended for your vehicle, the number of people that can be in your vehicle and vehicle capacity weight. Vehicle capacity weight •...

  • Page 661: Cargo Capacity

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml 2WD: 3,500 lbs. (1,588 kg) AWD: 5,000 lbs. (2,268 kg) • Without brake system: 1,653 lbs. (750 kg) Towing capacity is the maximum trailer weight including its cargo weight that your vehicle can tow. Cargo capacity The cargo capacity of your vehicle increases or decreases depending on the weight, the number of occupants, and the tongue load, if your vehicle is equipped with a trailer.

  • Page 662: Certification Label

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml ≥ Example 2 Maximum Load Passenger Weight (150 lbs. Cargo Weight (1400 lbs.) (635 × 5 = 750 lbs.) (68 kg × 5 = (650 lbs.) (295 kg) 340 kg) ≥ Example 3 Maximum Load Passenger Weight (172 lbs. Cargo Weight (1400 lbs.) (635 ×...
  • Page 663 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml WARNING • Never exceed the GVWR for your vehicle, the GAWR for the front or rear axle and the vehicle capacity weight. Exceeding these ratings may affect your vehicle's handling and braking ability, and cause a collision. • Do not overload your vehicle. Overloading your vehicle may cause heat buildup in your vehicle's tires, possible tire failure, increased stopping distances, and poor vehicle handling.
  • Page 664 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_load_limit.xml of the trailer, any cargo, and equipment or items attached to the trailer. The towing load in excess of these limits can seriously affect vehicle steering and performance, and may damage the motor and drivetrain. Long range Performance Item With brake system 3,500 (1,588) 5,000 (2,268)

  • Page 665: Vehicle Identifications

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_identifications.xml Vehicle Identifications Vehicle Identification Number (VIN) Frame number 2C_VINPosition The VIN is the number used in registering your vehicle and in all legal matters pertaining to its ownership, etc. The number is punched on the floor under the right front seat. To check the number, open the cover.

  • Page 666: Vehicle Certification Label

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_identifications.xml Vehicle Certification Label 2C_CertificationLabelPosition The vehicle certification label attached on the driver's side center pillar gives the VIN. Tire Specification and Pressure Label 2C_TireLabel The tires supplied on your new vehicle are chosen to provide the best performance for normal driving.

  • Page 667: Refrigerant Label

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_identifications.xml 2C_MotorNumber_1 The motor numbers can be checked at the bottom of the vehicle. Refrigerant Label 2C_RefrigerantTypeLabel Caution/Flammable refrigerant/To require registered technician to service air conditioning system Classification of refrigerant/Amount of refrigerant Classification of Compressor lubricant The refrigerant label provides information such as refrigerant type and amount. (R-1234yf) The air conditioning refrigerant label is located inside of the hood.
  • Page 668 vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_identifications.xml Refrigerant Lubricating oil A compressor label informs you the type of compressor your vehicle is equipped with such as model, supplier part number, production number, refrigerant and lubricating oil. Vehicle Information, Reporting Safety Defects, and Consumer Information...

  • Page 669: Operation In Foreign Countries

    vehicle_information_reporting_safety_defects_and_consumer_information_operation_in_foreign_countries.xml Operation In Foreign Countries If you are going to drive your vehicle in another country, be sure to: • Observe all regulations regarding registration and insurance. Vehicle Information, Reporting Safety Defects, and Consumer Information...

  • Page 670: Vehicle Data Collection And Event Data Recorders

    vehicle_information_reporting_safety_defects_and_consumer_information_vehicle_data_collection_and_event_dat a_recorders.xml Vehicle Data Collection And Event Data Recorders This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed.

  • Page 671: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying HYUNDAI MOTOR AMERICA. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153);...

  • Page 672: Consumer Information

    This consumer information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation. Your HYUNDAI dealer will help answer any questions you may have as you read this information.

  • Page 673: Open Source Software Notice

    HYUNDAI Motor Company will provide the open source code to you in storage medium such as CD-ROM for minimum charge covering the cost of performing source distribution upon email request to opensource@hyundai.com within a period of 3 years from the date of product purchase.

Table of Contents

Save PDF
