  • Page 1 S S p p e e c c i i f f i i c c a a t t i i o o n n s s All information in this Owner's Manual is current at the time of publi- cation. However, HYUNDAI Auto Canada Corp. reserves the right to make changes at any time so that our policy of continual product improvement may be carried out.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate condi- tions of the limited warranties covering the vehicle. Certain modifications may also be in vio- lation of regulations established by the Department of Transportation and other government agencies in your country.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER CAUTION DANGER indicates a hazardous situa- CAUTION indicates a hazardous situa- tion which, if not avoided, will result tion which, if not avoided, could result in death or serious injury.
  • Page 4 Your Owner's Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner's Manual carefully before driving your new vehicle. This manual contains important safety information and instructions intended to familiarize you with your vehicle's con- trols and safety features so you can safely operate your vehicle.
  • Page 5 GUIDE TO HYUNDAI GENUINE PARTS 1. What are HYUNDAI Genuine 2. Why should you use genuine 3. How can you tell if you are pur- Parts? parts? chasing HYUNDAI Genuine Parts? HYUNDAI Genuine Parts are the HYUNDAI Genuine Parts are...
  • Page 6 Introduction S S A A F F E E T T Y Y M M E E S S S S A A G G E E S S H H O O W W T T O O U U S S E E T T H H I I S S M M A A N N U U A A L L We want to help you get the greatest Your safety, and the safety of others, Throughout this manual DANGER,...
  • Page 7 Introduction V V E E H H I I C C L L E E M M O O D D I I F F I I C C A A T T I I O O N N S S •...
  • Page 8 Introduction V V E E H H I I C C L L E E D D A A T T A A C C O O L L L L E E C C T T I I O O N N A A N N D D E E V V E E N N T T D D A A T T A A R R E E C C O O R R D D E E R R S S This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR,...

  • Page 9: Table Of Contents

    Your vehicle at a glance Safety system of your vehicle Convenient features of your vehicle Infotainment system TABLE OF CONTENTS Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...
  • Page 10 E E l l e e c c t t r r i i c c V V e e h h i i c c l l e e S S y y s s t t e e m m O O v v e e r r v v i i e e w w Electric Vehicle ............H3 Charging Status .............H16 Characteristics of Electric Vehicles......H3...
  • Page 11 How to Disconnect Portable Charger Remaining Time ..............H53 (ICCB: In-Cable Control Box)..........H43 Charging Door Open ............H54 Unlock Charging Connector in Emergency ....H44 Charging Stopped. Check the AC/DC charger...H54 Precautions for Portable Charger Charging Stopped. Check the cable connection ..H55 (ICCB: In-Cable Control Box)..........H44 Check regenerative brakes/ Stop vehicle and check regenerative brakes..........H55 EV Charging Troubleshooting...

  • Page 12: Electric Vehicle

    E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E Electric Vehicle Characteristics of Electric Information Vehicles An electric vehicle is driven using a What does regenerative braking do? battery and an electric motor.

  • Page 13: Main Components

    ❈ LDC : Low Voltage DC-DC authorized HYUNDAI dealer. battery to the low voltage battery Converter (12V) in order to supply electrical power to the vehicle to operate the lights, wipers, multimedia, etc.

  • Page 14: High Voltage Battery (Lithium-Ion Polymer)

    • When the charge capacity and dis- CAUTION tance to empty keep falling, con- (lithium-ion polymer) tact an authorized HYUNDAI deal- • The charge amount of the high • Make sure to use a designated er for inspection and maintenance.

  • Page 15: High Voltage Battery Warmer System

    M M A A I I N N C C O O M M P P O O N N E E N N T T S S O O F F E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) High Voltage Battery Warmer CAUTION System...

  • Page 16: Nearby Stations

    E E V V M M O O D D E E Nearby Stations If you select the "EV" menu at the The EV mode has a total of 5 menus, home screen you can enter EV Nearby station, Energy information, mode.

  • Page 17: Energy Information

    E E V V M M O O D D E E ( ( C C O O N N T T . . ) ) Energy Information Battery information Energy consumption Select ‘EV → Energy Information’ on You can check the vehicle expected You can check the current energy range, total battery power remaining, consumption for each system of the...

  • Page 18: Charge Management

    ➃ ‘Battery care’ shows the momen- Charging and climate tary power and energy consump- tion which are used when: • Operating the winter mode to increase the battery temperature during winter to improve the driv- ing performance. • Cooling down the battery temper- ature during summer to prevent over temperature of the battery.

  • Page 19: Charging Location

    E E V V M M O O D D E E ( ( C C O O N N T T . . ) ) Charging location Scheduled climate settings Off-peak hours settings 1. Set target temperature. 1. If selected, the vehicle will begin If location-based charging is select- charging only during the designat- ed, scheduled charging and target...

  • Page 20: Charging Limit

    Charging limit • Note that if the battery charge level ECO Driving (SOC%) is above the designated maximum charging limit, the vehi- cle will not be charged. Charging current Select ‘EV → ECO Driving’ on the screen. You can check the CO2 reduction and ECO driving history.

  • Page 21: Co2 Reduction

    CO2 reduction Driving history EV Settings Select ‘EV → ECO Settings’ on the The CO2 reduction display allows The driving history displays informa- you to monitor the benefits of tion from the last several driving screen. You can set the Winter mode, reduced greenhouse gas emissions cycles including date, distance trav- Warning and EV route functions.

  • Page 22: Warning

    This is primarily due to reduced per- Warning EV route formance of the EV battery when exposed to cold temperatures. Some vehicles may come equipped with Winter mode selectable option. The Winter mode feature can be selected in the EV Settings menu. When selected, Winter...

  • Page 23: Charging Information

    C C H H A A R R G G E E T T Y Y P P E E S S F F O O R R E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E Charging Information Charging Time Information Information...

  • Page 24: Charging Types

    Charging Types Charging Inlet Category Charging Connector Charging Outlet How to Charge Charging Time (Vehicle) Use AC charger Approx. 6 hours 5 installed in homes minutes AC Charge or public charging (to fully charge, station 100%) OAEEQ016020N OLFP0Q5006K OLFP0Q4057N Use the DC 50 kw : approx.

  • Page 25: Charging Status

    C C H H A A R R G G E E I I N N D D I I C C A A T T O O R R L L A A M M P P F F O O R R E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E Charging Status Operation of Charging Indicator Lamp Details...

  • Page 26: Locking Charging Cable

    C C H H A A R R G G I I N N G G C C O O N N N N E E C C T T O O R R L L O O C C K K Locking Charging Cable When the Charging Connector •...

  • Page 27: Scheduled Charging

    S S C C H H E E D D U U L L E E D D C C H H A A R R G G I I N N G G Scheduled Charging (if equipped) • You can set-up a charging sched- ule for your vehicle using the info- tainment system or Blue Link appli- cation.

  • Page 28: Charging Precautions

    P P R R E E C C A A U U T T I I O O N N S S F F O O R R C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E Charging Precautions WARNING WARNING...
  • Page 29 P P R R E E C C A A U U T T I I O O N N S S F F O O R R C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) WARNING CAUTION •...

  • Page 30: Ac Charge

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( A A C C C C H H A A R R G G E E ) ) AC Charge How to Connect AC Charger 1.
  • Page 31 C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( A A C C C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) 4.
  • Page 32 ■ AC Charger Information • Even though charging is possible with the POWER button in the ON/START position, for your safe- ty, start charging when the POWER button is in the OFF position and the vehicle shifted to P (Park). After charging has started, you can use electrical components such as the radio by pressing the POWER but-...

  • Page 33: Unlock Charging Door In Emergency

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( A A C C C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) Unlock Charging Door in Information Emergency...

  • Page 34: Checking Charging Status

    Checking Charging Status Operation of Charging Indicator Lamp Details (OFF) (OFF) (OFF) Not Charged Blink (OFF) (OFF) 0~33% Blink (OFF) Charging 34~66% (ON) (ON) (ON) Blink 67~99% Fully charged (100%)(turns OFF in 5 seconds) (ON) (ON) (ON) Blink Blink Blink Error while charging Charging 12 V auxiliary battery or scheduled air condi- OAEEQ016025...

  • Page 35: How To Disconnect Ac Charger

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( A A C C C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) How to Disconnect AC Charger Information ■...

  • Page 36: Unlock Charging Connector In Emergency

    Unlock Charging Connector in Emergency OAEEQ016034N 3. Make sure to install the charging inlet cover. OAEEQ016057L 4. Make sure to completely close the If the charging connector does not charging door. disconnect due to battery discharge and failure of the electric wires, open the tailgate and slightly pull the emergency cable.

  • Page 37: Dc Charge

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( D D C C C C H H A A R R G G E E ) ) DC Charge (if equipped) How to Connect DC Charger Information...
  • Page 38 4. If you cannot open the charging door due to freezing weather : 1) Remove any ice near the charging door. 2) Pull the emergency cable to open the charging door. (When the charging door does not open, refer to "How to Unlock Charging Door...

  • Page 39: Unlock Charging Door In Emergency

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( D D C C C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) Unlock Charging Door in Information Emergency...

  • Page 40: Checking Charging Status

    Checking Charging Status Operation of Charging Indicator Lamp Details (OFF) (OFF) (OFF) Not Charged Blink (OFF) (OFF) 0~33% Blink (OFF) Charging 34~66% (ON) (ON) (ON) Blink 67~99% Fully charged (100%)(turns OFF in 5 seconds) (ON) (ON) (ON) Blink Blink Blink Error while charging Charging 12 V auxiliary battery or scheduled air condi- OAEEQ016025...

  • Page 41: How To Disconnect Dc Charger

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( D D C C C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) How to Disconnect DC Charger OAEEQ016034N 1.

  • Page 42: Trickle Charge

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( T T R R I I C C K K L L E E C C H H A A R R G G E E ) ) Trickle Charge How to set the charge level of the portable charger...

  • Page 43: How To Connect Portable Charger (Iccb: In-Cable Control Box)

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( T T R R I I C C K K L L E E C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) How to Connect Portable * Example for setting the ICCB charge level Charger (ICCB: In-Cable Control...
  • Page 44 3. Depress the brake pedal and apply the parking brake. 4. Turn OFF all switches, shift to P (Park), and turn OFF the vehicle. If charging is initiated without the gear in P (Park), the charging will start after the gear is automatical- ly shifted to P (Park).
  • Page 45 C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( T T R R I I C C K K L L E E C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) 6.
  • Page 46 Information • Even though charging is possible with the POWER button in the ON/START position, for your safe- ty, start charging when the POWER button is in the OFF position and the vehicle shifted to P (Park). After charging has started, you can use electrical components such as the radio by pressing the POWER button to ACC or ON position.

  • Page 47: Unlock Charging Door In Emergency

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( T T R R I I C C K K L L E E C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) Unlock Charging Door in Information Emergency...

  • Page 48: Checking Charging Status

    Checking Charging Status Operation of Charging Indicator Lamp Details (OFF) (OFF) (OFF) Not Charged Blink (OFF) (OFF) 0~33% Blink (OFF) Charging 34~66% (ON) (ON) (ON) Blink 67~99% Fully charged (100%)(turns OFF in 5 seconds) (ON) (ON) (ON) Blink Blink Blink Error while charging Charging 12 V auxiliary battery or scheduled air condi- OAEEQ016025...

  • Page 49: Charging Status Indicator Lamp For Portable Charger

    C C H H A A R R G G I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( T T R R I I C C K K L L E E C C H H A A R R G G E E ) ) ( ( C C O O N N T T . . ) ) Charging Status Indicator Lamp for Portable Charger Control Box Indicator...
  • Page 50 • Plug high temperature protection vehicle (Green ON) (Red blink) • Plug high temperature warning (Red ON) Contact an authorized HYUNDAI dealer. - Before plugging charging connector into vehicle (Red blink) - While charging • Abnormal temperature • Charge indicator (Green blink) •...
  • Page 51 (Red blink) • Diagnostic device failure • Communication failure • Current leakage • Abnormal temperature Contact an authorized HYUNDAI dealer. Contact an authorized HYUNDAI dealer. • Plug temperature sensor failure (Green blink) - Power saving mode • Plug high temperature protection •...

  • Page 52: How To Disconnect Portable Charger (Iccb: In-Cable Control Box)

    How to Disconnect Portable Charger (ICCB: In-Cable Control Box) Electric Outlet Plug OAEE046507N 4. Disconnect the plug from the OAEEQ016033N OAEEQ016034N household electric outlet. Do not 1.Hold the charging connector han- 2. Make sure to install the charging pull the cable when disconnecting dle and pull it while pressing the inlet cover.

  • Page 53: Unlock Charging Connector In Emergency

    • Keep the control box free of water. • Use the portable charger that is • Keep the AC charging connector or certified by HYUNDAI Motors. plug terminal free of foreign sub- stances. • Do not try to repair, disassemble, or adjust the portable charger.

  • Page 54: Ev Charging Troubleshooting - Steps To Consider

    4. If there is an error message on the charging station display screen, there may be a problem with the charging sta- tion. Try to charge the vehicle with a different charging station. 5. If the vehicle fails to charge with different charging station equipment, there may be a problem with the vehicle. Contact an authorized HYUNDAI dealer for inspection.

  • Page 55: How To Start The Vehicle

    D D R R I I V V I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E How to Start the Vehicle Information 1.

  • Page 56: How To Stop The Vehicle

    How to Stop the Vehicle Virtual Engine Sound System 1. Hold down the brake pedal while The Virtual Engine Sound System the vehicle is parked. generates engine sound for pedestri- ans to hear vehicle sound because 2. While depressing the brake pedal, there is no sound while the Electric shift to P (Park).

  • Page 57: Distance To Empty

    D D R R I I V V I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) Distance to Empty When destination is not set •...

  • Page 58: When Destination Is Set

    When destination is set Tips for Improving Distance to Power/Charge Gauge Empty When the destination is set, the dis- tance to empty may change. The dis- • If you operate the air conditioner tance to empty is recalculated using /heater too much, the driving battery the information of the destination.

  • Page 59: State Of Charge (Soc) Gauge For High Voltage Battery

    D D R R I I V V I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) •...

  • Page 60: Warning And Indicator Lights

    OFF system. In this case, have your vehi- after starting the vehicle, have your cle inspected by an authorized vehicle inspected by an authorized HYUNDAI dealer. HYUNDAI dealer.

  • Page 61: Power Down Warning Light

    D D R R I I V V I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) Power Down Warning Charging Indicator Light NOTICE...

  • Page 62: Regenerative Brake Warning Light

    In this case, drive safely and have OOSEV048133N/OOSEV048198N your vehicle inspected by an author- ized HYUNDAI dealer. OAEPHQ049833L This message is displayed to notify the remaining time to charge the bat- The operation of the brake pedal may...

  • Page 63: Charging Door Open

    If the same problem occurs when charging the vehicle with a normally operating AC charger or genuine HYUNDAI portable charger, have your vehicle inspected by an author- ized HYUNDAI dealer. OOSEV048130L OOSEV048131N/OOSEV048132N...

  • Page 64: Charging Stopped. Check The Cable Connection

    Charging Stopped. portable charger, we recommend Low Battery Check the cable connection that you have your vehicle inspected by an authorized HYUNDAI dealer. Check regenerative brakes/ Stop vehicle and check regener- ative brakes OOSEV048121L OOSEV048196N When the high voltage battery level...

  • Page 65: Charge Immediately. Power Limited

    EV battery tempera- played even after the ambient tem- ture. Power limited perature has increased, have the vehicle inspected by an author- ized HYUNDAI dealer. OOSEV048122L When the high voltage battery level OOSEV048199N/OOSEV048126N reaches below 6%, this warning [A] : Displays when turning off vehicle.

  • Page 66: Power Limited

    Battery Overheated! Power limited NOTICE Stop safety • When this warning message is displayed, do not accelerate or start the vehicle suddenly. • When the high voltage battery level is low, the power down warning illuminates and the power output from the vehicle is limited.

  • Page 67: Stop Vehicle And Check Power Supply

    In this case, have your vehicle inspect- ing message is displayed. safe location and recommend that ed by an authorized HYUNDAI dealer. In this case, have your vehicle inspect- you tow your vehicle to the nearest ed by an authorized HYUNDAI dealer.

  • Page 68: Energy Flow

    Energy Flow EV Propulsion Regeneration The electric vehicle system informs the drivers its energy flow in various operating modes. While driving, the current energy flow is specified in 3 modes. Vehicle Stop OAEPHQ049844L OAEPHQ049848L Only the motor power is used to drive The high-voltage battery is charged the vehicle.

  • Page 69: Aux. Battery Saver

    D D R R I I V V I I N N G G E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E Aux.

  • Page 70: System Setting

    S S A A F F E E T T Y Y P P R R E E C C A A U U T T I I O O N N S S F F O O R R E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E System Setting Utility Mode WARNING...

  • Page 71: System Deactivation

    S S A A F F E E T T Y Y P P R R E E C C A A U U T T I I O O N N S S F F O O R R E E L L E E C C T T R R I I C C V V E E H H I I C C L L E E ( ( C C O O N N T T . . ) ) System Activation If an Accident Occurs WARNING...
  • Page 72 Contact fire of water is needed to put out department or an authorized the fire. Using small amount HYUNDAI dealer. of water or fire extinguishers not meant for electrical fires Dolly OAEE069018 could cause serious injury or •...

  • Page 73: Other Precautions For Electric Vehicle

    If heat treatment is required, contact ing brake. OAEE069019 an authorized HYUNDAI dealer. • If you tow the vehicle while - While depressing the brake • When you clean the motor com- the front wheels are touching...

  • Page 74: Service Plug

    Service Plug OAEEQ016057 DANGER Never touch the service plug in the luggage compartment. The service plug is attached to high voltage battery system. Touching the service plug will result in death or serious injury. Service personnel should fol- low procedures in service man- ual.

  • Page 75: Your Vehicle At A Glance

    Your vehicle at a glance Exterior Overview ..........1-2 Interior Overview ...........1-4 Instrument Panel Overview ........1-5 Motor Compartment ..........1-6...
  • Page 76 Your vehicle at a glance E E X X T T E E R R I I O O R R O O V V E E R R V V I I E E W W ■ ■ Front view The actual shape may differ from the illustration.
  • Page 77 ■ ■ Rear view The actual shape may differ from the illustration. 10. Door lock ............ 14. High mounted stop lamp ......11. Charging door ..........15. Rear view camera ........12. Rear combination lamp ......16. Antenna ............13. Liftgate............OAEE019005N...
  • Page 78 Your vehicle at a glance I I N N T T E E R R I I O O R R O O V V E E R R V V I I E E W W 1. Door lock/unlock button ......3-10 2.
  • Page 79 I I N N S S T T R R U U M M E E N N T T P P A A N N E E L L O O V V E E R R V V I I E E W W 1.
  • Page 80 Your vehicle at a glance M M O O T T O O R R C C O O M M P P A A R R T T M M E E N N T T 1. Coolant reservoir ......7-12 2.

  • Page 81: Safety System Of Your Vehicle

    Safety system of your vehicle This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important safety precautions.......2-2 Child restraint system (CRS) ......2-36 Always Wear Your Seat Belt ..........2-2...

  • Page 82: Always Wear Your Seat Belt

    Safety system of your vehicle I I M M P P O O R R T T A A N N T T S S A A F F E E T T Y Y P P R R E E C C A A U U T T I I O O N N S S You will find many safety precautions Restrain All Children Driver Distraction...

  • Page 83: Control Your Speed

    • ALWAYS set up your mobile Control Your Speed Keep Your Vehicle in Safe devices (i.e., MP3 players, phones, Condition Excessive speed is a major factor in navigation units, etc.) when your crash injuries and deaths. Generally, Having a tire blowout or a mechanical vehicle is parked or safely stopped.

  • Page 84: Seats

    Safety system of your vehicle S S E E A A T T S S ■ Manual seat Front seats (1) Forward and backward (2) Seatback angle (3) Seat cushion height (4) Lumbar support (Driver’s seat)* ■ Power seat (5) Seat warmer* (6) Headrest Rear seats (7) Seat warmer*...

  • Page 85: Safety Precautions

    Safety Precautions Air bags WARNING You can take steps to reduce the risk Adjusting the seats so that you are sit- of being injured by an inflating air ting in a safe, comfortable position To reduce the risk of serious bag.

  • Page 86: Front Seats

    Safety system of your vehicle Seat belts Front Seats WARNING Always fasten your seat belt before WARNING starting any trip. Take the following precautions At all times, passengers should sit when adjusting your seat belt: Take the following precautions upright and be properly restrained. •...
  • Page 87 Manual adjustment (if equipped) (Continued) The front seat can be adjusted by • Use extreme caution when using the levers located on the out- picking small objects trapped side of the seat cushion. Before driv- under the seats or between ing, adjust the seat to the proper the seat and the center con- position so that you can easily con-...
  • Page 88 Safety system of your vehicle Reclining seatback Seat belts must be snug against your hips and chest to work properly. Sitting in a reclined position when When the seatback is reclined, the the vehicle is in motion can be dan- shoulder belt cannot do its job gerous.
  • Page 89 Power adjustment NOTICE (for driver's seat, if equipped) To prevent damage to the seats: The front seat can be adjusted by • Always stop adjusting the seats using the control switches located on when the seat has been adjust- the outside of the seat cushion. Before ed as far forward or rearward as driving, adjust the seat to the proper possible.
  • Page 90 Safety system of your vehicle Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dan- gerous. Even when buckled up, the protections of your restraint system (seat belts and air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seat- OAE036006...
  • Page 91 Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you.

  • Page 92: Rear Seats

    Safety system of your vehicle Seatback pocket Rear Seats CAUTION Folding the rear seat Do not put heavy or sharp The rear seatbacks can be folded to objects in the seatback pockets. facilitate carrying long items or to In an accident they could come increase the luggage capacity of the loose from the pocket and vehicle.
  • Page 93 To fold down the rear seatback: 1. Set the front seatback to the upright position and if necessary, slide the front seat forward. OAE036065L OAE036020 5. Pull on the seatback folding lever (1). OAE036018 2. Lower the rear head restraints to the lowest position by pushing and holding the release button (1) and OAE036019...
  • Page 94 Safety system of your vehicle WARNING When returning the rear seat- back from a folded to an upright position, hold the seatback and return it slowly. Ensure that the seatback is completely locked into its upright position by pushing on the top of the seat- back.
  • Page 95 Armrest (if equipped) WARNING CAUTION Make sure the vehicle is off, • careful when loading shifted to (Park), and the parking cargo through the rear pas- brake is securely applied when- senger seats to prevent dam- ever loading or unloading cargo. age to the vehicle interior.

  • Page 96: Head Restraints

    Safety system of your vehicle Head Restraints NOTICE (Continued) The vehicle's front and rear seats • To prevent damage, NEVER hit or have adjustable head restraints. The pull on the head restraints. head restraints provide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an...
  • Page 97 Front seat head restraints OAE036010 OLF034015 Adjusting the height up and down NOTICE OPDE036068 To raise the head restraint: The vehicle's front and passenger's If you recline the seatback towards 1. Pull it up to the desired position (1). seats are equipped with adjustable the front with the head restraint head restraints for the passengers and seat cushion raised, the head...
  • Page 98 Safety system of your vehicle ■ Type A ■ Type A 3. Press the head restraint release button (3) while pulling the head restraint up (4). OAE036012 OAE036014 ■ Type B ■ Type B OAE036011 OAE036013 Removal/Reinstallation To reinstall the head restraint: To remove the head restraint: 1.
  • Page 99 Rear seat head restraints OAE036017 OAE036072L Adjusting the height up and down Removal/Reinstallation OPDE036069 To raise the head restraint: To remove the head restraint: The rear seats are equipped with 1. Pull it up to the desired position (1). 1. Raise the head restraint as far as head restraints in all the seating it can go.

  • Page 100: Seat Warmers

    Safety system of your vehicle Seat Warmers WARNING WARNING Front seat warmers The seat warmers can cause a NEVER place anything on the Seat warmers are provided to warm SERIOUS BURN, even at low seat that insulates against heat the seats during cold weather. temperatures and especially if when the seat warmer is in oper- used for long periods of time.
  • Page 101 • Each time you push the switch, the NOTICE temperature setting of the seat is To prevent damage to the seat changed as follows : warmers and seats: → HIGH ( • Never use a solvent such as paint thinner, benzene, alcohol or gasoline to clean the seats.
  • Page 102 Safety system of your vehicle Rear seat warmers (if equipped) Each time you push the switch, the temperature setting of the seat is changed as follows : OFF → HIGH ( ) → LOW ( The seat warmer defaults to the OFF position whenever the POWER button is placed in the ON position.

  • Page 103: Seat Belts

    S S E E A A T T B B E E L L T T S S This section describes how to use the (Continued) (Continued) seat belts properly. It also describes • • NEVER allow children to ride Do not use a seat belt if the some of the things not to do when in the front passenger seat.

  • Page 104: Seat Belt Warning Light

    Safety system of your vehicle Seat Belt Warning Light If you continue not to fasten the seat WARNING belt and you drive over 9 km/h (6 Seat belt warning light mph), the warning light will stay illu- (for driver's seat) Damaged seat belts and seat minated.
  • Page 105 Seat belt warning light If you continue not to fasten the seat WARNING (for front passenger's seat) belt and you drive over 20 km/h (12 mph) the seat belt warning chime As a reminder to the front passenger, The front passenger's seat belt will sound for approximately 100 sec- the front passenger's seat belt warn- warning light may not properly...

  • Page 106: Seat Belt Restraint System

    Safety system of your vehicle Seat Belt Restraint System Seat Belt-Driver's 3-point sys- (Continued) tem with emergency locking • Position one arm under the retractor WARNING shoulder belt and the other over the belt, as shown in the illus- tration. •...
  • Page 107 NOTICE If you are not able to smoothly pull enough of the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, you will be able to pull the belt out smoothly. OHSS0380100 OAD035027 You should place the lap belt (1) por- Height adjustment...
  • Page 108 Safety system of your vehicle Release the button to lock the Rear Seat Belt – Passenger's To fasten your seat belt: anchor into position. Try sliding the 3-point system with convertible Pull the seat belt out of the retractor height adjuster to make sure that it locking retractor and insert the metal tab into the buck- has locked into position.
  • Page 109 Pre-tensioner seat belt NOTICE (Driver and front passenger) Although the seat belt retractor provides the same level of protec- tion for seated passengers in either emergency or automatic locking modes, the emergency locking mode allows seated pas- sengers to move freely in their seat while keeping some tension on the belt.
  • Page 110 This must be in tightly against the occupant's done authorized lower body in certain frontal or HYUNDAI dealer. side collision(s). • Do not hit the seat belt assem- If the system senses excessive ten- blies.
  • Page 111 1. SRS air bag warning light an authorized HYUNDAI dealer and should not be breathed for inspect the pre-tensioner seat 2. Retractor pre-tensioner prolonged periods. Wash all...
  • Page 112 Safety system of your vehicle Rear center seatbelt WARNING (3-point rear center seat belt) • Fasten your seat belt while sitting properly in an upright position to maximize the effectiveness of the pre-ten- sioner seat belt system. • A pre-tensioner seat belt sys- tem is designed to activate only once.

  • Page 113: Additional Seat Belt Safety Precautions

    Additional Seat Belt Safety (Continued) WARNING Precautions • To reduce the risk of serious Seat belt use during pregnancy ALWAYS properly restrain infants injury or death to an unborn and small children in a child child during an accident, The seat belt should always be used restraint appropriate for the pregnant women...
  • Page 114 LATCH system inspected by your • NEVER allow the shoulder Sitting in a reclined position when the authorized HYUNDAI dealer after an belt to contact the child’s vehicle is in motion can be dangerous. accident. An accident can damage neck or face.

  • Page 115: Care Of Seat Belts

    Any damaged parts should ous or fatal injuries in the event be replaced as soon as possible by of a collision or sudden stop. an authorized HYUNDAI dealer. • Drivers and passengers should always sit well back in their...

  • Page 116: Child Restraint System (Crs)

    Safety system of your vehicle C C H H I I L L D D R R E E S S T T R R A A I I N N T T S S Y Y S S T T E E M M ( ( C C R R S S ) ) Children Always in the Rear Most countries have child restraint Child restraint system (CRS)

  • Page 117: Selecting A Child Restraint System (Crs)

    • After an accident, have a HYUNDAI dealer check the child restraint system, seat belts, tether anchors and lower anchors. 2-37...
  • Page 118 Safety system of your vehicle Continue to use a rear-facing child seat for as long as your child will fit within the height and weight limits allowed by the child seat manufactur- er. It's the best way to keep them safe.

  • Page 119: Installing A Child Restraint System (Crs)

    Booster seats Installing a Child Restraint After selecting a proper child seat for your child, check to make sure it fits System (CRS) A booster seat is a restraint designed properly in your vehicle. Follow the to improve the fit of the vehicle’s seat instructions provided by the manu- belt system.
  • Page 120 Safety system of your vehicle Lower Anchors and Tether for CAUTION Children (LATCH System) The LATCH system holds a child A child restraint in a closed restraint during driving and in an acci- vehicle can become very hot. To dent. This system is designed to prevent burns, check the seat- make installation of the child restraint ing surface and buckles before...
  • Page 121 Securing a child restraint with WARNING the LATCH anchors system To install a LATCH-compatible child Do not attempt to install a child restraint in either of the rear outboard restraint system using LATCH Lower Anchor seating positions: anchors in the rear center seat- Position Indicator 1.
  • Page 122 • Always have the LATCH sys- Take the following precautions tem inspected by your author- when using the LATCH system: ized HYUNDAI dealer after an accident. An accident can • Read and follow all installation damage the LATCH system instructions provided with and may not properly secure your child restraint system.
  • Page 123 Securing a child restraint with WARNING lap/shoulder belt When not using the LATCH system, Take the following precautions all child restraints must be secured to when installing the tether strap: a vehicle rear seat with the lap part • Read and follow all installation of a lap/shoulder belt.
  • Page 124 Safety system of your vehicle To install a child restraint system on the rear seats, do the following: 1. Place the child restraint system on a rear seat and route the lap/ shoulder belt around or through the child restraint, following the restraint manufacturer's instruc- tions.
  • Page 125 5. Remove as much slack from the belt as possible by pushing down on the child restraint system while feeding the shoulder belt back into the retractor. 6. Push and pull on the child restraint system to confirm that the seat belt is holding it firmly in place.
  • Page 126 Safety system of your vehicle To remove the child restraint, press NOTICE the release button on the buckle and When the seat belt is allowed to then pull the lap/shoulder belt out of retract to its fully stowed position, the restraint and allow the seat belt the retractor will automatically to retract fully.
  • Page 127 A A I I R R B B A A G G - - A A D D V V A A N N C C E E D D S S U U P P P P L L E E M M E E N N T T A A L L R R E E S S T T R R A A I I N N T T S S Y Y S S T T E E M M 1.
  • Page 128 Safety system of your vehicle This vehicle is equipped with an WARNING Advanced Supplemental Air Bag System for the driver's seat and front AIR BAG SAFETY PRECAUTIONS passenger's seats. ALWAYS use seat belts and child restraints - every trip, every time, The front air bags are designed to everyone! Even with air bags, you can be seriously injured or killed in supplement the three-point seat...

  • Page 129: Air Bag

    Where Are the Air Bags? ■ The purpose of the SRS is to provide Driver's front air bag the vehicle's driver and front passen- Driver's and passenger's front gers with additional protection than air bags that offered by the seat belt system Your vehicle is equipped with a alone.
  • Page 130 Safety system of your vehicle Side air bags The side air bags are designed to (Continued) deploy only during certain side • Move your seat as far back as impact collisions, depending on the possible from front air bags, crash severity. while still maintaining control The side and curtain air bags on of the vehicle.
  • Page 131 Curtain air bags are located along front and rear pillar. authorized HYUNDAI dealer. both sides of the roof rails above the (Continued) front and rear doors. 2-51...
  • Page 132 Safety system of your vehicle They are designed to help protect the (Continued) WARNING heads of the front seat occupants • Do not allow passengers to and the rear outboard seat occupants To reduce the risk of serious lean their heads or bodies in certain side impact collisions.

  • Page 133: How Does The Air Bag System Operate

    How Does the Air Bag System 9. Side pressure sensors SRS warning light Operate? 10. Emergency Fastening Device System 11. Occupant classification system The SRSCM (Supplemental Restraint The SRS (Supplement Restraint System Control Module) continually System) air bag warning light on the monitors all SRS components while instrument panel displays the air bag the POWER button is in the ON posi-...
  • Page 134 • Generally, air bags are designed to and curtain air bags will remain inflate based upon the severity of a Have an authorized HYUNDAI inflated longer to help provide pro- collision, its direction, etc. These dealer inspect the SRS as soon...
  • Page 135 • To help provide protection, the air ■ Driver’s front air bag (1) WARNING bags must inflate rapidly. The speed of air bag inflation is a consequence To reduce the risk of serious of extremely short time in which to injury or death from an inflating inflate the air bag between the air bag, take the following pre-...
  • Page 136 Safety system of your vehicle ■ ■ Driver’s front air bag (2) Driver’s front air bag (3) WARNING To prevent objects from becom- ing dangerous projectiles when the passenger's air bag inflates: • Do not install or place any objects (drink holder, CD holder, stickers, etc.) on the front passenger's panel above the glove box where the pas-...

  • Page 137: What To Expect After An Air Bag Inflates

    Always have an authorized the vehicle. This is normal and is a from seeing out of the windshield or HYUNDAI dealer replace the result of the ignition of the air bag being able to steer. Curtain air bags air bag immediately after inflator.

  • Page 138: Occupant Classification System (Ocs)

    Safety system of your vehicle Occupant Classification Main components of the For example, if a child restraint of the Occupant Classification System type specified in the regulations is on System (OCS) the seat, the occupant classification • A detection device located within sensor can detect it and cause the the front passenger seat cushion.
  • Page 139 Always be sure that you and all vehi- Condition and operation in the front passenger Occupant Classification System cle occupants are seated properly and wearing the seat belt properly for Indicator/Warning light Devices the most effective protection by the Condition detected by the “PASSENGER Front passenger air bag and the seat belt.
  • Page 140 Safety system of your vehicle WARNING Riding in an improper position or placing weight on the front passenger’s seat when it is unoccupied by a passenger adversely affects the OCS. To reduce the risk of serious injury or death: • •...
  • Page 141 When changing or replacing the seat or seat cover, use original items only. The OCS has been devel- oped based on using original HYUNDAI car seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury when in collision. Any of the above could inter- fere with the proper operation of the OCS sensor thereby increasing the risk of an injury in an accident.
  • Page 142 Safety system of your vehicle Do Not Install a Child Restraint WARNING in the Front Passenger's Seat Never allow an adult passenger to ride in the front passenger seat when the "PASSENGER AIR BAG OFF" indicator is illuminat- ed. During a collision, the air bag will not inflate if the indicator is illuminated.

  • Page 143: Why Didn't My Air Bag Go Off In A Collision

    Have all air bag repairs conduct- • Do not hit or allow any objects could forcefully strike a child ed by an authorized HYUNDAI to impact the locations where air resulting in serious injury or dealer. bags or sensors are installed.
  • Page 144 Safety system of your vehicle 1. SRS control module/Rollover sensor 2. Front impact sensor 3. Side pressure sensor 4. Side impact sensor OAEE039005L/OAE036044/OAEE039006L/OAE036046/OAE036047 2-64...
  • Page 145 Air bag inflation conditions Although the driver’s and front pas- senger’s air bags are designed to inflate only in frontal collisions, they also may inflate in other types of col- lisions if the front impact sensors detect a sufficient impact. Side and curtain air bags are designed to inflate only in side impact collisions or rollover situations, but they may...
  • Page 146 Safety system of your vehicle Air bag non-inflation conditions OAEE039052 OAEE039008 Front air bags are not designed to Front air bags may not inflate in side OAEE039051 inflate in rear collisions, because impact collisions, because occupants In certain low-speed collisions the air occupants are moved backward by move in the direction of the collision, bags may not deploy.
  • Page 147 OAE036061 OAEE039054 OAE036055 In an angled collision, the force of Just before impact, drivers often Front air bags may not inflate in impact may direct the occupants in a brake heavily. Such heavy braking rollover accidents because air bag direction where the air bags would lowers the front portion of the vehicle deployment could not provide protec- not be able to provide any additional...

  • Page 148: Srs Care

    HYUNDAI dealer. ger’s panel above the glove sion energy is absorbed by the vehi- Improper handling of the SRS system box.

  • Page 149: Additional Safety Precautions

    If you require modification to your Consult authorized cle, against other occupants, or be vehicle to accommodate a disability, HYUNDAI dealer for the nec- ejected from the vehicle. contact the HYUNDAI Auto Canada essary information. Failure to at 1-888-216-2626. follow...

  • Page 150: Air Bag Warning Labels

    Safety system of your vehicle Air Bag Warning Labels OAD035053N Air bag warning labels, some required by the Canadian Motor Vehicle Safety Standards (CMVSS), are attached to alert the driver and passengers of potential risks of the air bag system. Be sure to read all of the information about the air bags that are installed on your vehicle in this Owners...

  • Page 151: Convenient Features Of Your Vehicle

    Convenient features of your vehicle Accessing your vehicle .........3-3 Sunroof ..............3-35 Smart Key ................3-3 Sunroof opening and closing........3-36 Immobilizer System ............3-8 Sliding the sunroof ............3-36 Tilting the sunroof............3-37 Door locks ...............3-9 Sunshade................3-37 Operating Door Locks from Outside the Vehicle ..3-9 Resetting the sunroof............3-38 Operating Door Locks from Inside the Vehicle ..3-10 Exterior features ..........3-39...
  • Page 152 Wipers and washers .........3-104 Interior features ..........3-128 Windshield Wipers ............3-104 Cup Holder ..............3-128 Windshield Washers ............3-105 Sunvisor................3-129 Power Outlet ..............3-129 Rear View Monitor (RVM) .......3-106 Wireless Cellular Phone Charging System ....3-130 Defroster.............3-108 Clock.................3-132 Rear Window Defroster ..........3-108 Clothes Hanger ..............3-133 Automatic climate control system....3-109 Floor Mat Anchor(s).............3-134 Automatic Heating and Air Conditioning....3-110...

  • Page 153: Smart Key

    OAE046029 OAE046001 • The POWER button is in ACC or To lock : Your HYUNDAI uses a Smart Key, ON position. which you can use to lock or unlock 1. Close all doors, hood and tailgate. • Any door except the tailgate is a door (and tailgate) and even start 2.
  • Page 154 Convenient features of your vehicle Unlocking 3. The driver's door will unlock. The Information hazard warning lights will blink two • The door handle button will only times. Also, the outer side view operate when the smart key is with- mirror will unfold, if the side view in 0.7~1 m (28~40 inches) from the mirror folding switch is in the...
  • Page 155 Tailgate unlocking Panic button NOTICE To open: Press and hold the Panic button (4) Always have the smart key with for more than one second. The horn 1. Carry the smart key. you when leaving the vehicle. If sounds and hazard warning lights 2.
  • Page 156 HYUNDAI dealer or tow and/or sending/receiving emails. the vehicle, if necessary. Avoid placing the smart key and your...
  • Page 157 This device complies with Industry you feel your smart key is not work- Canada RSS-210 standard. ing correctly, contact an authorized HYUNDAI dealer. Operation is subject to the following three conditions: 1. This device may not cause interfer- Information ence.

  • Page 158: Immobilizer System

    Immobilizer sys- tem malfunction could occur. If the system repeatedly does not recognize the coding of the key, it is recommended that you contact your HYUNDAI dealer.

  • Page 159: Operating Door Locks From Outside The Vehicle

    D D O O O O R R L L O O C C K K S S Operating Door Locks from If you lock the driver’s door with a Smart key mechanical key, all vehicle doors will Outside the Vehicle lock.

  • Page 160: Operating Door Locks From Inside The Vehicle

    Convenient features of your vehicle Once the doors are unlocked, they Operating Door Locks from • If the inner door handle of the dri- may be opened by pulling the door ver’s (or front passenger’s) door is Inside the Vehicle handle.
  • Page 161 With the central door lock WARNING WARNING switch ■ Driver’s door ■ Passenger’s door • Always secure your vehicle. The doors should always be fully closed and locked while Leaving your vehicle unlocked the vehicle is in motion. If the increases the potential risk to doors are unlocked, the risk of you or others from someone...

  • Page 162: Auto Door Lock/Unlock Features

    Convenient features of your vehicle Auto Door Lock/Unlock Features Child-Protector Rear Door locks CAUTION Impact sensing door unlock Opening a door when something All doors will be automatically is approaching may cause dam- unlocked when an impact causes the age or injury. Be careful when air bags to deploy.
  • Page 163 T T H H E E F F T T - - A A L L A A R R M M S S Y Y S S T T E E M M To lock the child safety lock, insert a This system helps to protect your Once the security system is set, key (or screw driver) (1) into the hole...

  • Page 164: Driver Position Memory System

    If the battery is disconnected, the position memory will be lost and the driving positions must be stored in the system again. If the Driver Position Memory System does not operate normally, have the system checked by an authorized HYUNDAI dealer. 3-14...

  • Page 165: Recalling Positions From Memory

    Recalling positions from mem- Easy Access Function NOTICE When exiting the vehicle the driver’s • While recalling the "1" memory seat will move rearward when the 1. Shift to P (Park) while the POWER position, pressing the SET or 1 vehicle is turned off, and the gear in button is in the ON position.

  • Page 166: Electric Power Steering (Eps)

    When the diagnostics is completed, vehicle operation, have the system the steering wheel will return to its checked by an authorized HYUNDAI normal condition. dealer. • A click noise may be heard from the...

  • Page 167: Tilt Steering / Telescope Steering

    Tilt Steering / Telescope Steering CAUTION Adjust the steering wheel so it points toward your chest, not toward your While adjusting the steering face. Make sure you can see the wheel height, please do not instrument cluster warning lights and push or pull it hard since the fix- gauges.

  • Page 168: Horn

    Convenient features of your vehicle Horn Heated Steering Wheel NOTICE (if equipped) Do not install any cover or acces- sory on the steering wheel. The cover or accessory could cause damage to the heated steering wheel system. OAE046009 OAEE049003 To sound the horn, press the area indicated by the horn symbol on your When the POWER button is in the steering wheel (see illustration).

  • Page 169: Inside Rearview Mirror

    M M I I R R R R O O R R S S Inside Rearview Mirror Day/night rearview mirror WARNING (if equipped) Before you start driving, adjust the rearview mirror to the center on the NEVER adjust the mirror while view through the rear window.
  • Page 170 Convenient features of your vehicle Electric chromic mirror (ECM) Automatic-Dimming Night Vision with compass and HomeLink ® Safety™ (NVS ® ) Mirror (if equipped) system The NVS ® Mirror automatically Your vehicle may be equipped with a reduces glare by monitoring light lev- Gentex Automatic-Dimming Mirror els in the front and the rear of the with a Z-Nav™...
  • Page 171 The auto-dimming function can be Z-Nav™ Compass Display Compass function controlled by pressing the ON/OFF The NVS™ Mirror in your vehicle is The Compass can be turned ON and button: also equipped with a Z-Nav™ OFF and will remember the last state Compass that shows the vehicle when the vehicle is cycled.
  • Page 172 Convenient features of your vehicle To adjust the Zone setting: 1. Determine desired Zone Number based upon your current location on the Zone Map. 2. Press and hold the button for more than 3 but less than 6 sec- onds, the current Zone Number will appear on the display.
  • Page 173 There are some conditions that can ® Integrated HomeLink Wireless WARNING cause changes to the vehicle mag- Control System nets, such as installing a ski rack or The HomeLink ® Wireless Control Before programming a CB antenna. Body repair work on System can replace up to three hand- HomeLink ®...
  • Page 174 Convenient features of your vehicle ® Rolling code programming To train rolling code devices, follow Programming HomeLink these instructions: Rolling code devices which are Please note the following: "code-protected" and manufactured 1. At the garage door opener receiv- • When programming a garage door after 1996 may be determined by the er (motor-head unit) in the garage, opener, it is advised to park the...
  • Page 175 4. Press and hold the just-trained Standard programming 4. While continuing to hold the but- HomeLink ® button and observe tons the red Indicator Status LED To train most devices, follow these the red Status Indicator LED. If the will flash slowly and then rapidly instructions: indicator light stays on constantly, after...
  • Page 176 Convenient features of your vehicle Gate operator & Canadian program- Reprogramming a single Erasing HomeLink ® buttons ® ming HomeLink button Individual buttons cannot be erased. During programming, your handheld To program a new device to a previ- However, to erase all three pro- transmitter may automatically stop ously trained HomeLink ®...

  • Page 177: Side View Mirrors

    Side View Mirrors Use your interior side view mirror or Information direct observation to determine the This device complies with Industry actual distance of following vehicles Canada RSS-210 standard. when changing lanes. Operation is subject to the following three conditions: WARNING 1.
  • Page 178 Convenient features of your vehicle Side view mirror control NOTICE NOTICE • Do not scrape ice off the mirror • The mirrors stop moving when face; this may damage the sur- they reach the maximum adjust- face of the glass. ing angles, but the motor contin- ues to operate while the switch •...
  • Page 179 Folding the side view mirrors NOTICE The electric type outside rearview mirror operates even though the POWER button is in the OFF posi- tion. However, to prevent unnec- essary battery discharge, do not adjust the mirrors longer than necessary while the vehicle is not in the ready ( ) mode.

  • Page 180: Reverse Parking Aid Function

    Convenient features of your vehicle Reverse Parking Aid Function The side view mirrors will automati- cally revert to their original positions if (if equipped) any of the following occur: • The POWER button is placed to either the OFF position or the ACC position.
  • Page 181 W W I I N N D D O O W W S S (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window...

  • Page 182: Power Windows

    Convenient features of your vehicle Power Windows Window opening and closing Information The POWER button must be in the • In cold and wet climates, power win- ON position to be able to raise or dows may not work properly due to lower the windows.
  • Page 183 If the power windows do not operate properly after resetting, have the system checked by an authorized HYUNDAI dealer. OLF044032 If a window senses any obstacle while it is closing automatically, it will WARNING...
  • Page 184 Convenient features of your vehicle Power window lock switch Information WARNING The automatic reverse feature is only Do not allow children to play active when the "Auto Up" feature is with the power windows. Keep used by fully pulling up the switch to the driver's door power window the second detent.
  • Page 185 S S U U N N R R O O O O F F ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Information (Continued) •...

  • Page 186: Sunroof Opening And Closing

    Convenient features of your vehicle Sunroof opening and closing Sliding the sunroof Automatic reverse (if equipped) Pressing the sunroof control lever backward or forward momentarily to the second detent position complete- ly opens or closes the sunroof even when the switch is released. To stop the sunroof at the desired position while the sunroof is in operation, press the sunroof control lever back-...

  • Page 187: Tilting The Sunroof

    Tilting the sunroof Sunshade WARNING Small objects that can get caught between the sunroof glass and the front glass chan- nel may not be detected by the automatic reverse system. In this case, the sunroof glass will not detect the object and will not reverse direction.

  • Page 188: Resetting The Sunroof

    • For more detailed information, con- the vehicle is in the ready ( step 2. tact an authorized HYUNDAI dealer. mode. 2. Push the control lever forward. 5. Within 3 seconds, push and hold...

  • Page 189: Hood

    E E X X T T E E R R I I O O R R F F E E A A T T U U R R E E S S Hood Opening the hood OAEE049005L OAD045039 3. Go to the front of the vehicle, raise 4.
  • Page 190 Convenient features of your vehicle Closing the hood WARNING WARNING 1. Before closing the hood, check the following: • • Grasp the support rod in the Before closing the hood, • All filler caps in motor compart- area wrapped in rubber. The ensure all obstructions are ment must be correctly installed.

  • Page 191: Tailgate

    Tailgate Closing the tailgate NOTICE Opening the tailgate In cold and wet climates, door lock 1. Make sure the vehicle is in P and door mechanisms may not (Park). work properly due to freezing con- ditions. WARNING The tailgate swings upward. Make sure no objects or people are near the rear of the vehicle when opening the tailgate.
  • Page 192 Convenient features of your vehicle Emergency tailgate safety WARNING WARNING release • For emergencies, be fully aware of the location of the emergency tailgate safety release lever in this vehicle and how to open the tailgate if you are accidentally locked in the luggage compartment.

  • Page 193: Charging Door

    Charging Door Closing the charging door Unlock Charging Door in Emergency 1. After recharging, install the charg- ing inlet cover. 2. Close the charging door until it is latched securely. For more details, refer to the Electric Vehicle Guide provided in the front of the owner’s manual.
  • Page 194 Convenient features of your vehicle I I N N S S T T R R U U M M E E N N T T C C L L U U S S T T E E R R 1. Power/Charge gauge 2.

  • Page 195: Instrument Cluster Control

    Instrument Cluster Control WARNING Adjusting instrument cluster illumination Never adjust the instrument cluster while driving. Doing so could lead to driver distraction which may cause an accident and lead to vehicle damage, serious injury, or death. OIK047144L • The brightness of the instrument panel illumination is displayed.

  • Page 196: Gauges And Meters

    Convenient features of your vehicle Gauges and Meters The speedometer is displayed differ- Power/Charge gauge ently according to the selected drive Speedometer/Eco guide mode in the Drive Mode Integrated ■ NORMAL/ECO mode selected Control System. For more information, refer to "Drive Mode Integrated Control System"...
  • Page 197 State of Charge (SOC) gauge for NOTICE high voltage battery When the high voltage battery level is low, the power down warn- ing illuminates and the power out- put from the vehicle is limited. Charge the battery immediately since your vehicle may not drive uphill or skid on a slope with the warning light ON.
  • Page 198 Convenient features of your vehicle Odometer Distance to Empty Outside temperature gauge OAEE049214 OAEE049215 OAEE049211 The odometer indicates the total dis- This gauge indicates the current out- • The distance to empty is the esti- tance that the vehicle has been driv- side air temperatures by 1°C (1°F).
  • Page 199 - Go to User Settings Mode ➝ Other Gear shift indicator Regenerative braking rate indi- Features ➝ Temperature Unit. cator - Press the AUTO button for 3 sec- onds while pressing the OFF button. Both the temperature unit on the cluster LCD display and climate con- trol screen will change.

  • Page 200: Warning And Indicator Lights

    - There is a problem with the cooling vehicle inspected by an authorized system, or a failure that may inter- - OFF : Normal driving is not possi- HYUNDAI dealer. rupt normal driving ble, or a problem has occurred. - Blinking : Emergency driving.
  • Page 201 SRS. Light slope with the warning light ON. In this case, have your vehicle inspected by an authorized HYUNDAI This warning light illuminates : dealer. When the high voltage battery level is low.
  • Page 202 HYUNDAI dealer. vehicle. Have the vehicle inspected reservoir is low. The operation of the brake pedal may by an authorized HYUNDAI dealer. - If the warning light illuminates be more difficult than normal and the with the parking brake released, it braking distance can increase.
  • Page 203 In this case, have your vehicle inspect- Driving the vehicle with a warn- ed by an authorized HYUNDAI dealer. ing light ON is dangerous. If the • When there is a malfunction with Parking Brake & Brake Fluid...
  • Page 204 In this case, have your vehicle inspect- location, turn off and turn on the the EPS. ed by an authorized HYUNDAI dealer. vehicle again, and check if the In this case, have your vehicle warning light turns off. If the warn-...
  • Page 205 • When the POWER button is in the In this case, have your vehicle inspect- ON position. ON position. ed by an authorized HYUNDAI dealer. - It illuminates for approximately 3 - It illuminates for approximately 3 seconds and then goes off.
  • Page 206 • [Yellow] When there is a malfunc- HYUNDAI dealer. If this occurs, have your vehicle tion with the auto hold system. inspected by an authorized HYUNDAI For more details, refer to "Forward dealer. In this case, have the vehicle Collision-Avoidance Assist (FCA)"...
  • Page 207 - It illuminates for approximately 3 In this case, have the vehicle inspect- and Outside Temperature Gauge seconds and then goes off. ed by an an authorized HYUNDAI blinks and then illuminates. Also, the • When there is a malfunction with dealer.
  • Page 208 ESC OFF but- Assist radar blocked (if equipped) ton. In this case, have your vehicle - Blind-Spot Collision Warning inspected by an authorized HYUNDAI For more information, refer to system malfunction (if equipped) dealer. "Electronic Stability Control (ESC)"...
  • Page 209 - The turn signal indicator light does seconds: not illuminate at all When the smart key is not in the If either of these conditions occur, vehicle. have your vehicle inspected by an authorized HYUNDAI dealer. - At this time, you cannot start the vehicle. 3-59...
  • Page 210 Convenient features of your vehicle High Beam Indicator High Beam Assist indi- Cruise Indicator Light Light cator light (if equipped) (if equipped) This indicator light illuminates: This indicator light illuminates : This indicator light illuminates: • When the headlights are on and in •...
  • Page 211 SPORT Mode Indicator ECO Mode Indicator ECO+ Mode Indicator Light Light (if equipped) This indicator light illuminates: This indicator light illuminates : This indicator light illuminates: • When you select "ECO" mode as When you select "ECO" mode as When you select "SPORT" mode as drive mode.

  • Page 212: Lcd Display Messages

    POWER ing the brake pedal. button, have your vehicle inspected button to the OFF position. by an authorized HYUNDAI dealer. Key not in vehicle Press POWER button while This warning message is displayed if turning wheel...
  • Page 213 Press POWER button with key Unplug vehicle to start Door / Hood / Tailgate open This warning message is displayed if This message is displayed when you you press the POWER button while start the vehicle without unplugging the warning message "Key not the charging cable.
  • Page 214 Convenient features of your vehicle Sunroof open Icy Road Warning (if equipped) CAUTION Before driving the vehicle, you should confirm that the door/ hood/tailgate is fully closed. Also, check there is no door/ hood/tailgate open warning light or message displayed on the instrument cluster.
  • Page 215 Turn on FUSE SWITCH Low Pressure Lights Mode OIK057165L OAEPH059643L OIK047145L This warning message is displayed if This warning message is displayed if This indicator displays which exterior the fuse switch under the steering the tire pressure is low. The corre- light is selected using the lighting wheel is OFF.
  • Page 216 We recommend that you have properly. A headlamp bulb may need the vehicle inspected by an authorized to be replaced. HYUNDAI dealer. Check turn signal (if equipped) Check brake light (if equipped) This warning message is displayed if This warning message is displayed if...
  • Page 217 Shift to P to charge Remaining Time Charging Door Open ■ AC charge ■ DC charge OAEPHQ049833L OOSEV048133N/OOSEV048198N OOSEV048130L This message is displayed if you This message is displayed to notify This message is displayed when the connect the charging cable without the remaining time to charge the bat- vehicle is driven with the charging the gear in the P (Park) position.
  • Page 218 If the same problem occurs when charging the vehicle with a normally operating AC charger or genuine HYUNDAI portable charger, have your vehicle inspected by an author- ized HYUNDAI dealer. OOSEV048131N/OOSEV048132N OOSEV048196N •...
  • Page 219 If the same problem occurs when Check regenerative brakes / Low Battery charging the vehicle with a replaced Stop vehicle and check regener- charging cable or genuine HYUNDAI ative brakes portable charger, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer.
  • Page 220 Power limited perature has increased, have the ■ DC charge ■ AC charge vehicle inspected by an author- ized HYUNDAI dealer. OOSEV048122L When the high voltage battery level OOSEV048199N/OOSEV048126N reaches below 6%, this warning [A] : Displays when turning off vehicle.
  • Page 221 Battery Overheated! Power limited NOTICE Stop vehicle • When this warning message is displayed, do not accelerate or start the vehicle suddenly. • When the high voltage battery level is low, the power down warning illuminates and the power output from the vehicle is limited.
  • Page 222 In this case, park the vehicle in a In this case, have your vehicle ing message is displayed. safe location and tow your vehicle to inspected by an authorized HYUNDAI In this case, have your vehicle the nearest authorized HYUNDAI dealer.

  • Page 223: Lcd Display Control

    L L C C D D D D I I S S P P L L A A Y Y LCD Display Control The LCD display modes can be changed by using the control buttons ■ ■ ■ ■ on the steering wheel. : MODE button for changing modes : MOVE...

  • Page 224: Lcd Display Modes

    Convenient features of your vehicle LCD display modes Menu Trip Computer Driving Assist User Settings Master warning Consumption Info Route Guidance Smart Cruise Control Driver Assistance Accumulated Info Lane Following Assist Drive Info Destination Info Door Highway Driving The Master Warning Assist Digital Speedometer Lights...
  • Page 225 Trip computer mode Turn By Turn (TBT) mode Driving Assist OAEE049679L OIK047147 OAEPH058615 The trip computer mode displays This mode displays the state of the SCC/LFA/HDA/LKA, DAW information related to vehicle driving navigation. This mode displays the state of parameters including energy effi- Smart Cruise Control,...
  • Page 226 Convenient features of your vehicle Master warning mode - Smart Cruise Control malfunction (if equipped) - Tire Pressure Monitoring System (TPMS) malfunction (if equipped) The Master Warning Light illumi- nates if one or more of the above warning situations occur. At this time, a Master Warning icon ( ) will appear beside the User Settings icon...
  • Page 227 User settings mode Quick guide (Help) This mode provides quick guides for the systems in the User Settings mode. Select an item, press and hold the OK button. For more details about each sys- tem, refer to this Owner's Manual OOSEV048172L Shift to P to edit settings OAD048572L...
  • Page 228 Convenient features of your vehicle 1. Driver Assistance Items Explanation • Fast/Normal/Slow To adjust the sensitivity of Smart Cruise Control system. SCC Response For more details, refer to ''Smart Cruise Control (SCC)'' in chapter 5. • Lane Following Assist To activate or deactivate Lane Following Assist system. For more details, refer to "Lane Following Assist (LFA)"...
  • Page 229 1. Driver Assistance Items Explanation • Leading Vehicle Departure Alert To activate or deactivate Leading Vehicle Departure Alert. For more details, refer to "Driver Attention Warning (DAW)" in chapter 5. Driver Attention Warning To adjust the sensitivity of DAW (Driver Attention Warning). For more details, refer to "Driver Attention Warning (DAW)"...
  • Page 230 Convenient features of your vehicle 2. Door Items Explanation • Disable : The auto door lock operation will be deactivated. • Enable on Speed: All doors will be automatically locked when the vehicle speed exceeds 15 km/h Auto Lock (9.3 mph). •...
  • Page 231 3. Lights Items Explanation • Off: The one touch turn signal function will be deactivated. • 3, 5, 7 Flashes: The turn signal indicator will blink 3, 5, or 7 times when the turn signal lever is moved One touch turn signal slightly.
  • Page 232 Convenient features of your vehicle 5. Convenience Items Explanation • Off: The seat easy access function is deactivated. • Normal/Extended: When you turn off the vehicle, the driver's seat will automatically move rearward Seat Easy Access short (Normal) or long (Extended) for you to enter or exit the vehicle more comfortably. For more details, refer to "Driver Position Memory System"...
  • Page 233 6. Service interval Items Explanation Service Interval To activate or deactivate the service interval function. Adjust Interval If the service interval menu is activated, you may adjust the time and distance. Reset To reset the service interval. If the service interval is activated and the time and distance is adjusted, messages are displayed in the following situations each time the vehicle is turned on.
  • Page 234 Convenient features of your vehicle 7. Other (features) Items Explanation To activate or deactivate the Aux. Battery Saver+ function. When activated, the high voltage battery is used to keep the 12V battery charged. AUX. BATTERY SAVER+ For more details, refer to the ''Electric Vehicle System Overview'' provided in the front of the owner’s manual.
  • Page 235 8. Language (if equipped) Items Explanation Language Choose the language. 9. Reset Items Explanation You can reset the menus in the User Settings Mode. All menus in the User Settings Mode are Reset reset to factory settings, except language and service interval. ❈...

  • Page 236: Trip Modes

    Convenient features of your vehicle T T R R I I P P C C O O M M P P U U T T E E R R The trip computer is a microcomput- Trip modes ■ ■ ■ ■ er-controlled driver information sys- tem that displays information related Consumption Info...
  • Page 237 Consumption info display Manual reset Instant Energy Consumption (2) To clear the average energy con- • The instantaneous energy con- sumption manually, press the OK but- sumption is displayed according to ton on the steering wheel for more the bar graph in the LCD display than 1 second when the average while driving.
  • Page 238 Convenient features of your vehicle Accumulated info display The accumulated driving information Drive Info display will continue to be counted while the vehicle is in the ready ( ) mode (for example, when the vehicle is in traffic or stopped at a stop light). Information The vehicle must be driven for a min- imum of 300 meters (0.19 miles) since...
  • Page 239 The driving information will continue Digital speedometer Driving style to be counted while the vehicle is in the ready ( ) mode (for example, when the vehicle is in traffic or stopped at a stop light.) Information The vehicle must be driven for a min- imum of 300 meters (0.19 miles) since the last ignition key cycle before the driving information is recalculated.
  • Page 240 Convenient features of your vehicle Energy flow OAEPHQ049851L The electric vehicle system informs the drivers its energy flow in various operating modes. While driving, the current energy flow is specified in 3 modes. For more details, refer to "Energy Flow" in the Electric Vehicle Guide provided in front of the owner's manual.

  • Page 241: Exterior Lights

    L L I I G G H H T T Exterior Lights Daytime running light (DRL) The Daytime Running Lights (DRL) Lighting control can make it easier for others to see To operate the lights, turn the knob at the front of your vehicle during the the end of the control lever to one of day, especially after dawn and before the following positions:...
  • Page 242 Convenient features of your vehicle NOTICE • Do not cover or spill anything on the sensor (1) located in front of the instrument panel. • Do not clean the sensor using a window cleaner, the cleanser may leave a light film which could interfere with sensor operation.
  • Page 243 High beam operation High Beam Assist (HBA) (if equipped) OLF044088C To flash the high beam headlamp, OLF044089C pull the lever towards you, then OOS047409N To turn on the high beam headlamp, release the lever. The high beams push the lever away from you. The High Beam Assist is a system that will remain ON as long as you hold lever will return to its original position.
  • Page 244 - When vehicle speed is below 24 Take your vehicle to an authorized Beam Assist will turn off. km/h (15 mph). HYUNDAI dealer and have the sys- • If the headlamp switch is placed tem checked. to the headlamp ON position,...
  • Page 245 (Continued) (Continued) WARNING • When external condition is When a vehicle suddenly The driver must be cautious in intervened appears from a curve. the below situations may not • When there is a similar shape • When the vehicle is tilted from work properly when recognition lamp with the front vehicle’s a flat tire or being towed.
  • Page 246 OAD045188C cle to an authorized HYUNDAI To signal a turn, push down on the dealer and have the system lever for a left turn or up for a right checked.
  • Page 247 Onetouch turn signal function Battery saver function Headlamp delay function (if equipped) To activate the One Touch Turn The purpose of this feature is to pre- Signal function, push the turn signal vent the battery from being dis- If the POWER button is placed in the lever up or down to position (B) and charged.
  • Page 248 ON). If the indicator continuously remains on, OAD045436C have the system be checked by an Adaptive front lighting system uses authorized HYUNDAI dealer. the steering angle and vehicle speed, to keep your field of vision wide by swiveling and leveling the headlamp.

  • Page 249: Interior Lights

    Interior Lights Interior lamp AUTO cut Front lamps The interior lamps will automatically WARNING go off approximately 20 minutes after the vehicle is turned off and the Do not use the interior lights doors closed. If a door is opened, the when driving in the dark.The inte- lamp will go off 40 minutes after the rior lights may obscure your view...
  • Page 250 Convenient features of your vehicle Front room lamp Rear lamp Front Door Lamp ( ■ Type A • The front or rear room lamps come Press the button to turn ON the on when the front or rear doors are room lamp for the front/rear seats.
  • Page 251 Luggage room lamp Vanity mirror lamp (if equipped) Puddle lamp (if equipped) OAE049418 OAD045410 OAE046419 The luggage room lamp comes on Push the switch to turn the light on or Welcome light when the tailgate is opened. off. When all doors (and tailgate) are •...

  • Page 252: Welcome System

    Convenient features of your vehicle Escort light Welcome System (if equipped) Door handle lamp (if equipped) When the POWER button is in the When all the doors (and tailgate) are Welcome light (if equipped) OFF position and the driver's door is closed and locked, the door handle opened, the puddle lamp will come lamp will come on for about 15 sec-...
  • Page 253 Headlamp and parking lamp Interior lamp When the headlamp (lamp switch in When the interior lamp switch is in the headlamp or AUTO position) is the DOOR position and all doors (and on and all doors (and tailgate) are tailgate) are closed and locked, the locked and closed, the parking lamp room lamp will come on for 30 sec- and headlamp will come on for 15...

  • Page 254: Windshield Wipers

    Convenient features of your vehicle W W I I P P E E R R S S A A N N D D W W A A S S H H E E R R S S Windshield Wipers Information Operates as follows when the If there is heavy accumulation of snow POWER button is in the ON position.

  • Page 255: Windshield Washers

    Windshield Washers NOTICE WARNING • To prevent possible damage to When the outside temperature is the washer pump, do not oper- below freezing, ALWAYS warm ate the washer when the fluid windshield using reservoir is empty. defroster to help prevent the •...
  • Page 256 Convenient features of your vehicle R R E E A A R R V V I I E E W W M M O O N N I I T T O O R R ( ( R R V V M M ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) •...
  • Page 257 (Continued) CAUTION • Always pay close attention • Rear View Monitor is not a when the vehicle is driven safety device. It only serves to close to objects, particularly assist the driver in identifying pedestrians, and especially objects directly behind the children.

  • Page 258: Rear Window Defroster

    Convenient features of your vehicle D D E E F F R R O O S S T T E E R R Rear Window Defroster NOTICE Information To prevent damage to the conduc- • If there is heavy accumulation of tors bonded to the inside surface snow on the rear window, brush it off of the rear window, never use...
  • Page 259 A A U U T T O O M M A A T T I I C C C C L L I I M M A A T T E E C C O O N N T T R R O O L L S S Y Y S S T T E E M M 1.

  • Page 260: Automatic Heating And Air Conditioning

    Convenient features of your vehicle Automatic Heating and Air To turn the automatic operation off, select any button of the following: Conditioning - Mode selection button - Front windshield defroster button (Press the button one more time to deselect the front windshield defroster function.

  • Page 261: Manual Heating And Air Conditioning

    Manual Heating and Air 3. Set the temperature control to the desired position. Conditioning 4. Set the air intake control to the The heating and cooling system can outside (fresh) air position. be controlled manually by pushing buttons other than the AUTO button. 5.
  • Page 262 Convenient features of your vehicle Mode selection OAEE049306 The mode selection button controls the direction of the air flow through the ventilation system. The air flow outlet direction is cycled as follows: OAEE049320 3-112...
  • Page 263 Floor & Defrost Face-Level (B, D, E, F) (A, C, E) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor and the windshield with a small outlet can be controlled to direct the amount directed to the side window air discharged from the outlet.
  • Page 264 Convenient features of your vehicle ■ Front Temperature control Temperature conversion If the battery has been discharged or disconnected, the temperature mode display will reset to Fahrenheit. To change the temperature unit from °C to °F or °F to °C: - On the instrument cluster, go to User Settings Mode ➝...
  • Page 265 Air intake control Recirculated air position WARNING With the recirculated air position selected, air • Continued use of the climate from passenger control system operation in compartment will the recirculated air position drawn through the heat- can cause drowsiness or ing system and heated sleepiness, that may cause or cooled according to...
  • Page 266 Convenient features of your vehicle Fan speed control Driver only NOTICE Operating the fan when the POWER button is in the ON posi- tion could cause the battery to discharge. Operate the blower when the vehicle is in the ready ) mode.
  • Page 267 Air conditioning HEAT button EV mode (if equipped) OAEE049310 OAEE049315 OAEE049311 Push the A/C button to manually turn Push the HEAT button to turn the Push the EV button to enter the EV the system on (indicator light will illu- heater on (indicator light will illumi- mode on the infotainment system minate) and off.

  • Page 268: System Operation

    Convenient features of your vehicle OFF mode System Operation Operation Tips • To keep dust or unpleasant fumes Ventilation from entering the car through the 1. Select the Face Level mode. ventilation system, temporarily set 2. Set the air intake control to the the air intake control to the recircu- outside (fresh) air position.
  • Page 269 Air conditioning Air conditioning system operation • If you operate air conditioner tips excessively, the difference between HYUNDAI Conditioning the temperature of the outside air • If the vehicle has been parked in Systems are filled with environmen- and that of the windshield could direct sunlight during hot weather, tally friendly R-134a refrigerant.

  • Page 270: System Maintenance

    Have the climate control air filter ing system in your vehicle should replaced by an authorized HYUNDAI only be serviced by trained and dealer according to the maintenance certified technicians.
  • Page 271 ■ Example OAEE086005N OHYK059003 Air Conditioning refrigerant label Each symbols and specification on the air conditioning refrigerant label You can find out which air condition- is represented as below: ing refrigerant is applied to your vehi- cle on the label located inside of the 1.

  • Page 272: To Defog Inside Windshield

    Convenient features of your vehicle W W I I N N D D S S H H I I E E L L D D D D E E F F R R O O S S T T I I N N G G A A N N D D D D E E F F O O G G G G I I N N G G •...

  • Page 273: To Defrost Outside Windshield

    To Defrost Outside Windshield Defogging Logic The air intake control button indicator will blink 3 times. It indicates that the defogging logic is canceled or returned to the programmed status. If the battery has been discharged or disconnected, it resets to the defog logic status.

  • Page 274: Auto Defogging System

    Convenient features of your vehicle Auto Defogging System When the Auto Defogging To cancel or reset the System operates, the indi- Auto Defogging System Auto defogging system reduces the cator will illuminate. Press the front windshield defroster possibility of fogging up the inside of button for 3 seconds when the the windshield by automatically POWER button is in the ON position.

  • Page 275: Automatic Ventilation

    C C L L I I M M A A T T E E C C O O N N T T R R O O L L A A D D D D I I T T I I O O N N A A L L F F E E A A T T U U R R E E S S ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Automatic Ventilation (if equipped) When the POWER button is in the...

  • Page 276: Center Console Storage

    Convenient features of your vehicle S S T T O O R R A A G G E E C C O O M M P P A A R R T T M M E E N N T T Center Console Storage Glove Box WARNING...

  • Page 277: Sunglass Holder

    Sunglass Holder Multi Box WARNING • Do not keep objects except sunglasses inside the sun- glass holder. Such objects can be thrown from the holder in the event of a sudden stop or an accident, possibly injuring the passengers in the vehicle. •...

  • Page 278: Cup Holder

    Convenient features of your vehicle I I N N T T E E R R I I O O R R F F E E A A T T U U R R E E S S Cup Holder Rear (if equipped) WARNING Pull the armrest down to use the cup ■...

  • Page 279: Sunvisor

    Sunvisor Power Outlet (if equipped) NOTICE Close the vanity mirror cover securely and return the sunvisor to its original position after use. WARNING For your safety, do not block your view when using the sunvi- sor. NOTICE OAEE046511N OAEE049405L To use a sunvisor, pull it downward. The power outlet is designed to pro- Do not put several tickets in the vide power for mobile telephones or...

  • Page 280: Wireless Cellular Phone Charging System

    Convenient features of your vehicle (Continued) Wireless Cellular Phone NOTICE Charging System (if equipped) • Push the plug in as far as it will To prevent damage to the Power go. If good contact is not made, Outlets : the plug may overheat and the •...
  • Page 281 To charge a cellular phone If your cellular phone is not charging: NOTICE - Slightly change the position of the The wireless cellular phone charging • The wireless cellular phone cellular phone on the charging system charges only the Qi-enabled charging system may not sup- pad.

  • Page 282: Clock

    Convenient features of your vehicle (Continued) (Continued) Clock • The wireless charging process • Some magnetic items like credit WARNING may temporarily stop, when tem- cards, phone cards or rail tickets perature abnormally increases may be damaged if left with the inside the wireless cellular cellular phone during the charg- Do not adjust the clock while...

  • Page 283: Clothes Hanger

    Vehicles with Navigation system Clothes Hanger (if equipped) WARNING Select the Settings menu on the ➟ Navigation system Select [Date/Time]. • GPS time: Displays time according to the received GNSS time. • 24-hour: Switches to 12 hour or 24 hour. ❈...

  • Page 284: Floor Mat Anchor(S)

    All Weather mats, remove tion, HYUNDAI recommends the carpeted floor mats before that the HYUNDAI floor mat installing them. Only use floor designed for use in your vehicle mats designed to connect to the be installed.
  • Page 285 To use the cargo security screen When the cargo security screen To remove the cargo security is not in use: screen 1. Pull the cargo security screen backward and up to release it from the guides. 2. The cargo security screen will automatically slide back in.
  • Page 286 Convenient features of your vehicle OAEE046424L 3. Open the luggage tray and keep the cargo security screen in the tray. 3-136...

  • Page 287: Infotainment System

    Infotainment system Infotainment system ..........4-2 USB and iPod ® port ............4-2 Antenna ................4-2 Steering Wheel Audio Controls........4-3 Bluetooth ® Wireless Technology Hands-Free...4-4 Audio (Display Audio) / Video / Navigation System.............4-4...

  • Page 288: Infotainment System

    Infotainment system I I N N F F O O T T A A I I N N M M E E N N T T S S Y Y S S T T E E M M USB and iPod® port Antenna NOTICE Shark fin antenna...

  • Page 289: Steering Wheel Audio Controls

    Steering Wheel Audio Control VOLUME (VOL + / - ) (1) MODE (3) • Press the VOLUME switch up to Press the MODE button to toggle increase volume. through Radio, SXM or AUX modes. • Press the VOLUME switch down to decrease volume.

  • Page 290: Bluetooth Wireless Technology Hands-Free

    Infotainment system Bluetooth Wireless (3) Microphone Audio (Display Audio) / Video / ® Technology Hands-Free Navigation System Detailed information (if equipped) Bluetooth ® Wireless Technology hands-free is described later in this Detailed information for the naviga- chapter or in the Car Multimedia tion system is described in a sepa- User's Manual.

  • Page 291: Driving Your Vehicle

    Driving your vehicle Before driving ............5-3 Braking system ...........5-25 Before Entering the Vehicle ...........5-3 Power Brakes ..............5-25 Before Starting ..............5-3 Disc Brake Wear Indicator ..........5-26 Electronic Parking Brake (EPB)........5-26 Power button ............5-5 Auto Hold ................5-31 POWER Button Positions..........5-6 Anti-lock Brake System (ABS) ........5-35 Starting the Vehicle ............5-8 Electronic Stability Control (ESC)........5-37 Turning Off the Vehicle ...........5-9...
  • Page 292 Blind-spot Collision Warning (BCW) ....5-70 Highway Driving Assist (HDA) system ...5-117 System description ............5-70 System Setting and Operation........5-117 System setting and operation........5-71 Warning Message ............5-120 Warning message and system control.......5-73 Rear Cross-Traffic Collision Declaration of conformity ..........5-81 Warning (RCCW) ..........5-124 Driver Attention Warning (DAW) ......5-83 System description ............5-124 System setting and operation........5-83...

  • Page 293: Before Entering The Vehicle

    B B E E F F O O R R E E D D R R I I V V I I N N G G Before Entering the Vehicle Before Starting WARNING • Be sure all windows, outside mir- •...
  • Page 294 Driving your vehicle (Continued) WARNING You are much more likely to have NEVER drink or take drugs and a serious accident if you drink or drive. take drugs and drive. If you are drinking or taking drugs, don't Drinking or taking drugs and drive.
  • Page 295 P P O O W W E E R R B B U U T T T T O O N N (Continued) WARNING If the vehicle is still moving, you To reduce the risk of SERIOUS can restart the vehicle without INJURY or DEATH, take the fol- depressing the brake pedal by lowing precautions:...

  • Page 296: Power Button Positions

    Driving your vehicle POWER Button Positions Button Position Action Notice To turn off the vehicle, press the POWER button with the gear in P (Park). Also, the vehicle will turn off when the POWER button is pressed with the gear in D (Drive) or R (Reverse) because the gear automatically shifts to the P (Park) position.
  • Page 297 Button Position Action Notice Press the POWER button while it is in the Do not leave the POWER button in the ON ACC position without depressing the brake position when the vehicle is not in the ready pedal. ) mode to prevent the battery from dis- charging.

  • Page 298: Starting The Vehicle

    Driving your vehicle Starting the Vehicle 1. Always carry the smart key with Information you. • The vehicle will start by pressing the WARNING 2. Make sure the gear is in P (Park). POWER button, only when the 3. Depress the brake pedal. smart key is in the vehicle.

  • Page 299: Turning Off The Vehicle

    Turning Off the Vehicle NOTICE 1. Depress the brake pedal fully. To prevent damage to the vehicle: 2. Shift to P (Park). If the " " indicator turns off 3. Apply the electronic parking brake while you are in motion, do not as needed for example on a attempt to shift to the P (Park) sloped driveway or hill...

  • Page 300: Reduction Gear Operation

    Driving your vehicle R R E E D D U U C C T T I I O O N N G G E E A A R R Gear position Reduction Gear Operation WARNING To reduce the risk of serious injury or death: •...
  • Page 301 P (Park) R (Reverse) When the driver’s door is opened within 3 minutes with the POWER Always come to a complete stop Use this position to drive the vehicle button in the ACC position and the before shifting into P (Park). backward.

  • Page 302: Parking

    Decrease the vehicle speed or slow You cannot shift the gear when the down before shifting the gear. battery is discharged. Jump start your vehicle (refer to “Jump Starting” in chapter 6) or con- tact an authorized HYUNDAI dealer. 5-12...
  • Page 303 Press brake pedal to change Shift to P after stopping PARK engaged gear OAEE059105L OAEE059111L OAEE059104L The message appears on the LCD The message appears on the LCD display when the gear is shifted to P display when the P (Park) position is The message appears on the LCD (Park) while the vehicle is moving.
  • Page 304 Immediately have the vehicle inspect- Make sure that there is no object ed by an authorized HYUNDAI dealer over the shift button. If the problem persists, immediately have the vehi- cle inspected by an authorized...

  • Page 305: Good Driving Practices

    • Alway apply the parking brake • ALWAYS wear your seat belt. • when parked on a sloped driveway HYUNDAI recommends you In a collision, an unbelted or hill when leaving the vehicle. Do follow all posted speed limits. occupant is significantly more...
  • Page 306 Driving your vehicle P P A A D D D D L L E E S S H H I I F F T T E E R R ( ( R R E E G G E E N N E E R R A A T T I I V V E E B B R R A A K K I I N N G G C C O O N N T T R R O O L L ) ) Information The paddle shifter does not operate when:...

  • Page 307: One Pedal Driving

    Initial setting of the regenerative One Pedal Driving Automatic engagement of braking level and adjustable range Electronic Parking Brake The driver can stop the vehicle by vary according to the selected Drive After the vehicle is stopped by the pulling and holding the left side pad- mode.

  • Page 308: System Setting

    Driving your vehicle S S M M A A R R T T R R E E G G E E N N E E R R A A T T I I O O N N S S Y Y S S T T E E M M W W I I T T H H S S M M A A R R T T C C R R U U I I S S E E C C O O N N T T R R O O L L S S Y Y S S T T E E M M ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) The Smart Regeneration System Activating the Smart controls the regenerative braking...

  • Page 309: Cancelling The Smart Regeneration System

    Cancelling the Smart WARNING Regeneration System: • Cancelled manually Smart Regeneration System which automatically Pulling and holding the right side controls the regenerative brak- paddle shifter for more than 1 sec- ing level when coasting is only ond. a supplemental system for the The Smart Regeneration System driver's convenience.

  • Page 310: Resuming The Smart Regeneration System

    HYUNDAI dealer. ance of the radar. • Use only genuine HYUNDAI Disabling the Smart • Always keep the radar sensor parts to repair or replace a Regeneration System and lens cover clean and free damaged sensor or sensor of dirt and debris.

  • Page 311: Warning Message

    If the system still does the vehicle is decelerating. not operate normally, take your vehi- cle to an authorized HYUNDAI deal- The driver must maintain a safe brak- er and have the system checked. ing distance, and if necessary,...
  • Page 312 Driving your vehicle On inclines Lane changing OAD058166L Your vehicle speed can be reduced OAEE059617 OAD058167L due to a vehicle in the adjacent lane. When coasting on an uphill or down- • A vehicle which moves into your Apply the accelerator pedal and hill, the system may not detect the lane from an adjacent lane cannot select the appropriate speed.
  • Page 313 Vehicle recognition A vehicle ahead cannot be recog- WARNING nized correctly by the sensor if any of following occurs: When using Smart - When the vehicle is pointing Regeneration System take the upwards due to overloading in the following precautions: luggage compartment •...
  • Page 314 Driving your vehicle Information Information • Vehicles moving in front of with frequent lane This device complies with Industry Radio frequency radiation exposure changes may cause a delay in Canada RSS-210 standard. information: the system's reaction or may Operation is subject to the following This equipment complies with RSS cause the system to react to a three conditions:...

  • Page 315: Power Brakes

    B B R R A A K K I I N N G G S S Y Y S S T T E E M M Power Brakes (Continued) WARNING Your vehicle has power-assisted • Wet brakes may impair the brakes that adjust automatically Take the following precautions: vehicle's ability to safely slow...

  • Page 316: Disc Brake Wear Indicator

    Driving your vehicle Disc Brake Wear Indicator Electronic Parking Brake NOTICE (EPB) When your brake pads are worn and • Do not continue depressing the new pads are required, you will hear Applying the parking brake brake pedal if the " "...
  • Page 317 However, if the EPB switch is Releasing the parking brake To release EPB (Electronic Parking pressed within 1 second after the Brake) automatically: vehicle is turned off, the EPB will not • Shifted to P (Park) be applied. With the vehicle in the ready ( mode depress the brake pedal and WARNING shift out of P (Park) to R (Reverse)
  • Page 318 • If you try to drive with the EPB tem checked an authorized applied, a warning will sound and a HYUNDAI dealer. message will appear. • Do not drive your vehicle with • If the driver's seat belt is not fas- the EPB applied.
  • Page 319 ■ Type A ■ Type B NOTICE WARNING • A click sound may be heard • To prevent unintentional move- while operating or releasing the ment when stopped and leav- EPB, but these conditions are ing the vehicle, do not use the normal and indicate that the P (Park) position in place of the EPB is functioning properly.
  • Page 320 POWER button is changed to the ON warning does not go off, have position, this indicates that the EPB the system checked by an may have malfunctioned. authorized HYUNDAI dealer. If this occurs, have the system checked by an authorized HYUNDAI dealer. 5-30...
  • Page 321 Brake) does not release If the EPB does not release normal- Do not operate the parking ly, contact an authorized HYUNDAI brake while the vehicle is mov- dealer by loading the vehicle on a ing except in an emergency sit- flatbed tow truck and have the sys- uation.
  • Page 322 Driving your vehicle Set up Leaving • If you press the accelerator pedal with the gear in D (Drive) or R(Reverse), the Auto Hold will be released automatically and the vehicle will start to move. The AUTO HOLD indicator changes from green to white.
  • Page 323 Contact an - The driver’s door is opened press the [AUTO HOLD] switch. The authorized HYUNDAI dealer. - The hood is opened while the gear AUTO HOLD indicator will turn off. • While operating Auto Hold, you may...
  • Page 324 When the conversion from Auto Hold not work properly. Contact an When the EPB is applied from Auto to EPB is not working properly a authorized HYUNDAI dealer. Hold, a warning will sound and a warning will sound and a message message will appear.

  • Page 325: Auto Hold

    Anti-lock Brake System (ABS) WARNING An Anti-Lock Braking System (ABS) or an Electronic Stability Control (ESC) system will not prevent accidents improper or dangerous driving maneuvers. Even though vehi- cle control is improved during emergency braking, always OIK057080L OOSEV058076N maintain safe distance Press brake pedal to deactivate...
  • Page 326 ABS. Contact an ABS will not prevent a skid that authorized HYUNDAI dealer as soon results from sudden changes in as possible. direction, such as trying to take a corner too fast or making a sudden lane change.

  • Page 327: Electronic Stability Control (Esc)

    ) may illuminate. Pull injury or death, contact your your car over to a safe place and turn the vehicle off. HYUNDAI dealer as soon as possible. Restart the vehicle. If the ABS warning light is off, then your ABS system is normal.
  • Page 328 Driving your vehicle ESC operation When operating WARNING When the ESC is in opera- ESC ON condition tion, the ESC indicator light When the POWER button is in the Never drive too fast for the road blinks: ON position, the ESC and the ESC conditions or too quickly when OFF indicator lights illuminate for •...
  • Page 329 If the POWER button is placed to the vehicle checked by an authorized abled, but the brake control function OFF position when ESC is off, ESC HYUNDAI dealer as soon as possi- of ESC still operates. remains off. Upon restarting the vehi- ble.
  • Page 330 Driving your vehicle ESC OFF usage NOTICE WARNING When Driving • Do not allow wheel(s) of one The ESC OFF mode should only be When the ESC is blinking, this axle to spin excessively while used briefly to help free the vehicle if indicates the ESC is active: the ESC, ABS, and parking brake stuck in snow or mud, by temporarily...

  • Page 331: Vehicle Stability Management (Vsm)

    Vehicle Stability Management VSM operation Information (VSM) VSM ON condition The VSM does not operate when: The Vehicle Stability Management The VSM operates when: • Driving on a banked road such as a (VSM) is a function of the Electronic •...

  • Page 332: Hill-Start Assist Control (Hac)

    HAC activates light illuminates, have the vehi- only for approximately 2 sec- cle checked by an authorized onds. HYUNDAI dealer as soon as possible. NOTICE Driving with wheels and tires with different sizes may cause the VSM system to malfunction.

  • Page 333: Good Braking Practices

    POWER button in the it is safe to do so and call an author- OFF position. ized HYUNDAI dealer for assistance. Vehicles parked with the park- DO NOT drive with your foot resting ing brake not applied or not on the brake pedal.

  • Page 334: Drive Mode

    Driving your vehicle D D R R I I V V E E M M O O D D E E I I N N T T E E G G R R A A T T E E D D C C O O N N T T R R O O L L S S Y Y S S T T E E M M ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Drive mode Initial setting for each Drive Mode Drive mode...

  • Page 335: Forward Collision-Avoidance Assist (Fca)

    F F O O R R W W A A R R D D C C O O L L L L I I S S I I O O N N - - A A V V O O I I D D A A N N C C E E A A S S S S I I S S T T ( ( F F C C A A ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Forward Collision-Avoidance Assist System setting and activation WARNING...
  • Page 336 If you change the warning timing, the checked authorized lowing: warning timing of other systems may HYUNDAI dealer. - Normal: change. Always be aware before changing the warning timing. When this option is selected, the initial Forward Collision Warning is activated sensitively.

  • Page 337: Fca Warning Message And Brake Control

    Prerequisite for activation FCA warning message and WARNING brake control FCA gets ready to be activated, when 'Active Assist' or 'Warning FCA produces warning messages, • To avoid driver distractions, Only' under Forward Safety is select- warning alarms, and emergency do not attempt to set or can- ed in the cluster LCD display, and braking based on the level of risk of...
  • Page 338 Driving your vehicle Collision Warning • If FCA detects a vehicle in front, Emergency braking (First warning) the system operates when your (Second warning) vehicle speed is between 8 km/h (5 mph) and 180 km/h (110 mph). Maximum vehicle speed may decrease depending on the condi- tion of the vehicle ahead and sur- roundings.
  • Page 339 • If FCA detects a vehicle in front, Brake operation CAUTION the system operates when your • In an urgent situation, the braking vehicle speed is above 8 km/h (5 system enters into the ready status • The driver should always use mph) and less than or equal to 180 for prompt reaction against the dri- extreme caution while operat-...

  • Page 340: Fca Sensor (Front View Camera+ Front Radar)

    Driving your vehicle FCA sensor (Front view Dirt, snow, or foreign substances on WARNING the sensor cover or sensor may camera+ Front radar) adversely affect the sensing perform- ■ Front view camera The braking control cannot ance of the sensor. completely stop the vehicle nor avoid all collisions.
  • Page 341 We recommend that reflection may prevent the sys- you have the vehicle inspected tem from functioning properly. by an authorized HYUNDAI deal- • Pay extreme caution to keep the camera dry. • If the front bumper becomes damaged in the area around the •...

  • Page 342: System Malfunction

    After the message disappears, the master warning light ( ) will illuminate. In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer. 5-52...
  • Page 343 (Continued) (Continued) WARNING • Even if there is any problem • If a vehicle in front abruptly • FCA is only a supplemental with the brake control func- stops, the brake control may system for the driver's con- tion of FCA system, the vehi- not work possibly causing a venience.

  • Page 344: Limitations Of The System

    Driving your vehicle Limitations of the system Detecting vehicles WARNING The sensor may be limited when: Forward Collision-Avoidance Assist system is designed to monitor the • The system may not operate for 15 • FCA system does not operate vehicle ahead or a pedestrian or seconds after the vehicle is started when the vehicle is in reverse.
  • Page 345 • The vehicle in front is an oversize • The vehicle in front is driving errati- • The rear part of the vehicle in front vehicle or trailer that is too big to cally is not normally visible. (the vehicle be detected by the front view cam- turns in other direction or the vehi- •...
  • Page 346 Driving your vehicle Always pay attention to road and driving conditions, and if neces- sary, depress the brake pedal to reduce your driving speed in order to maintain a safe distance. OAD058165L OAD058166L • Driving on a curve Forward Collision-Avoidance Assist system may recognize a vehicle or performance Forward...
  • Page 347 Always keep your eyes forward while driving upward or downward on a slope, and, if necessary, depress the brake pedal to reduce your driving speed in order to maintain distance. OAEE059617 OAD058167L • Driving on a slope • Changing lanes performance Forward When a vehicle changes lanes in...
  • Page 348 Driving your vehicle Detecting pedestrians or cyclists The sensor may be limited when: • The pedestrian or cyclist is not fully detected by the front view camera recognition system, for example, if the pedestrian is leaning over or is not fully walking upright •...
  • Page 349 • There is an item similar to a per- • The sensor recognition changes WARNING son's body structure suddenly when passing over a speed bump • The pedestrian or cyclist is small • Use extreme caution when the • You are on a roundabout •...
  • Page 350 20 cm (8 in.) between the radiator Operation is subject to the following inspected by an authorized (antenna) and your body. three conditions: HYUNDAI dealer. This transmitter must not be co-locat- 1. This device may not cause harmful ed or operating in conjunction with interference, and any other antenna or transmitter.
  • Page 351 L L A A N N E E K K E E E E P P I I N N G G A A S S S S I I S S T T ( ( L L K K A A ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) WARNING WARNING Lane Keeping Assist system is...
  • Page 352 Please refer to "Limitations of HYUNDAI dealer and have the stop controlling the steering the System". system checked for calibra- wheel. •...

  • Page 353: Lka Operation

    LKA operation If you press LKA button located on LKA system operation the instrument panel on the lower left hand side of the driver, LKA will be turned off and the indicator on the cluster display will go off. Note that the vehicle speed must be at least approximately 64 km/h (40 mph) to ENABLE the...
  • Page 354 Driving your vehicle ■ Line undetected ■ Line detected • If your vehicle speed exceeds 64 2. LKA system will help control the km/h (40 mph) and LKA system vehicle's steering to prevent the button is ON, the system is vehicle from crossing the lane enabled.
  • Page 355 WARNING The warning message may appear late according to road conditions. Therefore, always have your hands on the steering wheel while driving. OAEPH059625L OIK057120N Keep hands on steering wheel Driver's hands not detected. LKA system disabled temporarily If the driver takes their hands off the steering wheel for several seconds If the driver still does not have their while the LKA system is activated,...

  • Page 356: Warning Light And Message

    If the problem is not solved, we rec- Information ommend that the system be checked • Even though the steering is assisted by an authorized HYUNDAI dealer. by the system, the driver can still steer to control the steering wheel. • The steering wheel may feel heavier...

  • Page 357: Limitations Of The System

    LKA system will not be in the • There are more than two lane Limitations of the System ENABLED state and the steering markers on the road. (e.g. construc- LKA system may operate premature- wheel will not be assisted when: tion area) ly even if the vehicle does not depart •...
  • Page 358 Driving your vehicle • The lane marker is very thick or When external condition is inter- • Driving on a steep grade, over a thin. vened hill, or when driving on a curved road. • The lanes ahead are not visible •...

  • Page 359: Lka System Function Change

    LKA system function change Lane Keeping Assist This mode guides the driver to help The driver can change LKA to Lane keep the vehicle within the lanes. It Departure Warning (LDW) from the rarely controls the steering wheel, LCD display. Go to the 'User Settings →...

  • Page 360: Blind-Spot Collision Warning (Bcw)

    Driving your vehicle B B L L I I N N D D - - S S P P O O T T C C O O L L L L I I S S I I O O N N W W A A R R N N I I N N G G ( ( B B C C W W ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) System description 2) Closing at high speed WARNING...

  • Page 361: System Setting And Operation

    System setting and operation System setting OAEE059017L OAEE059648N • If you press the BCW button while • Selecting Warning Timing 'Warning Only' is selected, the indi- The driver can select the initial OTMA058088 cator on the button turns off and warning activation time from the the system deactivates.
  • Page 362 Driving your vehicle The options for the initial Blind-Spot Operating Conditions Collision Warning includes the fol- The system enters the ready status, lowing: when 'Warning Only' is selected in - Normal: the cluster LCD display and vehicle speed is above approximately 30 When this option is selected, the km/h (20 mph).

  • Page 363: Warning Message And System Control

    Warning message and system ■ Left side ■ Right side control ■ Left side ■ Right side OAE056036 OAE056037 [A] : Warning sound Second stage alert OAE056035 A warning chime to alert the driver will activate when: First stage alert 1.
  • Page 364 Driving your vehicle Detecting Sensor WARNING CAUTION ■ Rear radar • The warning light on the out- • Always pay attention to road side rearview mirror will illu- and traffic conditions while minate whenever a vehicle is driving, whether or not the detected at the rear side by warning light on the outside the system.
  • Page 365 In this case, a vehicle for an extended period of warning message may not be time. displayed. We recommend that the vehicle be inspected by an - When there is inclement weather authorized HYUNDAI dealer. such as heavy snow or rain. (Continued) 5-75...
  • Page 366 → Blind-Spot Safety' vehicle be inspected by an author- If there is a problem with BCW sys- ized HYUNDAI dealer. tem, a warning message will appear - Deactivate RCCW system by dese- and the light on the button will turn lecting off.
  • Page 367 Limitations of the system • The vehicle is driven on a curved • When the other vehicle approach- road. es very close. The driver must be cautious in the • The vehicle is driven through a toll- • When the other vehicle passes at a below situations because the system gate.
  • Page 368 Driving your vehicle • Temperature is extremely low around the vehicle. • The vehicle severely vibrates while driving over bumpy road, uneven/bumpy road, or concrete patch. • The vehicle drives on a slippery surface due to snow, water puddle, or ice. OAD058155N OAD058156N •...
  • Page 369 OAD058157N OAEE059592 OAD058150N • Driving where the road is merg- • Driving on a slope • Driving where the heights of the ing/dividing lanes are different BCW system may not operate BCW system may not operate properly when driving on a slope. BCW system may not operate properly when driving where the In certain instances the system...
  • Page 370 Driving your vehicle Information Information This device complies with Industry Radio frequency radiation exposure Canada RSS-210 standard. information: Operation is subject to the following This equipment complies with RSS three conditions: radiation exposure limits set forth for an uncontrolled environment. 1.

  • Page 371: Declaration Of Conformity

    Declaration of conformity • For Brazil • For Russia (if equipped) The radio frequency components (Rear Corner Radar) comply with OAEPH069061L requirements and other relevant pro- visions. • For South Africa (TA-2012/779) OAEPH069054L • For Taiwan • For UAE OAEPH069049L OAEPH069051L OAEPH069055L •...
  • Page 372 Driving your vehicle • For Serbia OAEPH069057L • For Ukraine OAEPH069058L • For Argentina OAEPH069059L • For Paraguay (2017-08-I-0000279 ) OAEPH069060L 5-82...

  • Page 373: Driver Attention Warning (Daw)

    D D R R I I V V E E R R A A T T T T E E N N T T I I O O N N W W A A R R N N I I N N G G ( ( D D A A W W ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Driver Attention Warning system dis- The options for the initial Driver plays the level of the driver’s fatigue...
  • Page 374 Driving your vehicle Display of the driver's attention ■ Inattentive driving level ■ System off OPDE056062 • The driver can monitor his/her driv- OTMA058094 ing conditions on the cluster LCD • Setting Warning Volume OAE048569L display. ■ Attentive driving The driver can select the warning The DAW screen will appear when volume from the User Settings in you select the Driving Assist mode...
  • Page 375 • The level decreases when the driv- Take a break CAUTION er does not take a break for a cer- tain period of time. If any other warning sound • The level increases when the driv- such as seat belt warning chime er attentively drives for a certain is already generated, Driver period of time.

  • Page 376: Resetting The System

    - The front view camera does not message appears, the system is not restarts driving. detect the lane. working properly. In this case, we recommend that you have the vehi- - Driving speed over 180 km/h (110 cle inspected by an authorized mph). HYUNDAI dealer. 5-86...
  • Page 377 To keep the front view your vehicle to an authorized venience function only. It is camera sensor in the best condi- HYUNDAI dealer and have the the responsibility of the driver tion, you should observe the fol- system checked for calibration.
  • Page 378 Driving your vehicle (Continued) CAUTION CAUTION • Forward drivability of the Driver Attention Warning sys- Playing the vehicle audio sys- vehicle is severely under- tem may not provide alerts in tem at high volume may prevent mined (possibly due to wide the following situations: occupants from hearing Driver variation in tire pressures,...

  • Page 379: Leading Vehicle Departure Alert

    Leading Vehicle Departure Function setting and operating conditions Alert (if equipped) System setting Leading Vehicle Departure Alert function provides whether the lead- • Selecting Driver Attention Warning ing vehicle an alert on while at a system stop. The Leading Vehicle Departure Alert can be activated from Users Settings mode in the cluster LCD display by following the procedure...
  • Page 380 Driving your vehicle WARNING CAUTION • Leading Vehicle Departure Alert Leading Vehicle Departure function is quite related with the Alert function is only a con- front camera in the vehicle for venient auxiliary for the driv- the better performance. For er.
  • Page 381 S S M M A A R R T T C C R R U U I I S S E E C C O O N N T T R R O O L L W W I I T T H H S S T T O O P P A A N N D D G G O O ( ( S S C C C C W W I I T T H H S S & & G G ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) To see the SCC screen on the LCD WARNING display in the cluster, select Driving...
  • Page 382 Driving your vehicle (Continued) (Continued) WARNING • Smart Cruise Control is not a - When driving on a sharp Take the following precautions : collision avoidance or warn- curve ing device. • Always set the vehicle speed - When driving with limited under the speed limit on the Smart Cruise...

  • Page 383: To Adjust The Sensitivity Of Smart Cruise Control

    Smart Cruise Control switch To adjust the sensitivity of You may select one of the three stages you prefer. Smart Cruise Control - Slow: Vehicle speed following the front vehicle to maintain the set distance is slower than normal speed. - Normal: Vehicle speed following the front vehicle to maintain the set distance...

  • Page 384: To Convert To Cruise Control Mode

    Driving your vehicle To convert to Cruise Control Smart Cruise Control speed WARNING mode To set Smart Cruise Control The driver may choose to only use speed When using the Cruise Control the conventional Cruise Control mode, must manually mode (speed control function) by adjust the distance to other doing as follows: vehicles by depressing the...
  • Page 385 To increase Smart Cruise Information Control set speed • Vehicle speed may decrease on an upward slope and increase on a downward slope. • When you are setting the cruise con- trol speed with a vehicle in front and your vehicle speed is between 0-30 km/h (0-20 mph), the speed will set to 30 km/h (20 mph).
  • Page 386 Driving your vehicle To decrease the Smart Cruise To temporarily accelerate with CAUTION Control set speed Smart Cruise Control on If you want to speed up temporarily Check the driving condition when Smart Cruise Control is on, before using the toggle switch. depress the accelerator pedal.
  • Page 387 Smart Cruise Control will be Cancelled automatically • The braking control is operated for temporarily cancelled when: FCA (Forward Collision-Avoidance • The driver's door is opened. Assist) • The shift lever is shifted to N • The driver starts driving by pushing (Neutral), R (Reverse) or P (Park).
  • Page 388 HYUNDAI (RES+) to resume speed. dealer. Always check the road conditions. Do not rely on the warning chime.

  • Page 389: Smart Cruise Control Vehicle-To-Vehicle

    To turn Cruise Control off Smart Cruise Control Vehicle- Each time the button is pressed, the vehicle to vehicle distance changes to-Vehicle Distance as follows: To set Vehicle-to-Vehicle Distance Distance 4 Distance 3 Distance 2 Distance 1 For example, if you drive at 90 km/h (56 mph), the distance is maintained as follows: Distance 4 - approximately 52.5 m...

  • Page 390: Distance 4

    Driving your vehicle When the lane ahead is clear: When there is a vehicle ahead WARNING of you in your lane: Distance 4 Distance 3 OAEPH059587L OAEPH058614 Distance 2 Distance 1 When using Smart Cruise The vehicle speed will maintain the Control system: OAEPH058615/OAEPH058614 set speed.
  • Page 391 In traffic situation (Continued) CAUTION • Even if the warning message does not appear and warning chime does not sound, always pay attention to the driving conditions to prevent danger- ous situations from occur- ring. • Playing the vehicle audio sys- tem at high volume may pre- vent occupants from hearing the system warning sounds.

  • Page 392: Sensor To Detect Distance To The Vehicle Ahead

    Driving your vehicle • If you push the Smart Cruise Sensor to detect distance to Warning message Control toggle switch (RES+ or the vehicle ahead SET-) while Auto Hold and smart cruise control is operating the Auto Hold will be released regardless of accelerator pedal operation and the vehicle will start to move.
  • Page 393 We recommend that you take your cle inspected by an author- vehicle to an authorized HYUNDAI • Always keep the radar sensor ized HYUNDAI dealer. dealer and have the system checked.

  • Page 394: Limitations Of The System

    Driving your vehicle Limitations of the system On curves Smart Cruise Control System may have limits to its ability to detect dis- tance to the vehicle ahead due to road and traffic conditions. OAD058166L Your vehicle speed can be reduced OAD058165L due to a vehicle in the adjacent lane.
  • Page 395 On inclines Lane changing Vehicle recognition OAEE059617 OAD058167L OAD058173N • During uphill or downhill driving, • A vehicle which moves into your Some vehicles in your lane cannot Smart Cruise Control system may lane from an adjacent lane cannot be recognized by the sensor: not detect a moving vehicle in your be recognized by the sensor until it - Vehicles offset to one side...
  • Page 396 Driving your vehicle A vehicle ahead cannot be recog- nized correctly by the sensor if any of following occurs: - When the vehicle is pointing upwards due to overloading in the luggage compartment - While the steering wheel is operat- - When driving to one side of the lane - When driving on narrow lanes or...
  • Page 397 WARNING When using Smart Cruise Control take the following pre- cautions: • If an emergency stop is nec- essary, you must apply the brakes. The vehicle cannot be stopped at every emergency situation by using Smart Cruise Control system. OAE056110 OAEE059620 •...
  • Page 398 Driving your vehicle NOTICE (Continued) (Continued) • Smart Cruise Control system • Smart Cruise Control system Smart Cruise Control system may cannot recognize a stopped may not recognize complex not operate temporarily due to: vehicle, pedestrians or an driving situations so always •...
  • Page 399 Information Information This device complies with Industry Radio frequency radiation exposure Canada RSS-210 standard. information: Operation is subject to the following This equipment complies with RSS three conditions: radiation exposure limits set forth for an uncontrolled environment. 1. This device may not cause harmful interference, and This equipment should be installed and operated with minimum distance...

  • Page 400: Lane Following Assist (Lfa)

    Driving your vehicle L L A A N N E E F F O O L L L L O O W W I I N N G G A A S S S S I I S S T T ( ( L L F F A A ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) WARNING WARNING Lane Following Assist system...
  • Page 401 • Do not place objects on the HYUNDAI dealer and have the • If you attach objects to the dashboard that reflects light system checked for calibra-...

  • Page 402: Lfa Operation

    Driving your vehicle LFA operation Operating conditions LFA system operation Select 'Lane Following Assist' from System setting the User settings mode in the cluster • With the ignition switch is in the ON LCD display and meet the following position, Lane Following Assist can conditions for the system to operate.

  • Page 403: Warning Message

    Warning message WARNING The warning message may appear late according to road conditions. Therefore, always have your hands on the steering wheel while driving. OAEPH059624L Driver's hands not detected. OAEPH059625L LFA system will be disabled tem- Keep hands on steering wheel porarily If the driver takes their hands off the If the driver still does not have their...
  • Page 404 Driving your vehicle LFA system will not be in the WARNING ENABLED state and/or the steering wheel will not be assisted when: • LFA system is a supplemental • The turn signal is turned on before system only. It is the responsi- changing a lane.

  • Page 405: Limitations Of The System

    • Radius of a curve is too small. Limitations of the system When the lane and road condi- tions are poor • The vehicle is driven on a steep LFA system may operate premature- incline. • It is difficult to distinguish the lane ly even if the vehicle does not depart marking from the road surface or from the intended lane, OR, LFA sys-...
  • Page 406 Driving your vehicle • The lane marker is very thick or When external condition is inter- • Driving on a steep grade, over a thin. vened hill, or when driving on a curved road. • The lane is very wide or narrow. •...
  • Page 407 H H I I G G H H W W A A Y Y D D R R I I V V I I N N G G A A S S S S I I S S T T ( ( H H D D A A ) ) S S Y Y S S T T E E M M ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Highway Driving Assist system helps System Setting and Operation Information...
  • Page 408 Driving your vehicle Operating conditions Steering wheel control Select 'Highway Driving Assist' from the Settings menu in the infotain- ment system screen and satisfy the following conditions for the system to operate. • Driving on the highway main line • Smart Cruise Control is operating - If Smart Cruise Control is in the READY state...
  • Page 409 Speed setting If the system changes to the auto- matic speed mode, the symbol will turn green and a chime will sound. When the highway speed limit changes, the set speed automatical- ly changes to the changed speed limit. OAEPH048607 Manual speed setting mode OAEPH048605 If the speed is set manually using the...
  • Page 410 Driving your vehicle Warning Message WARNING Hands-off warning The warning message may appear late according to road conditions. Therefore, always have your hands on the steering wheel while driving. OAEPH059681N Highway Driving Assist (HDA) system canceled OAEPH059625L If the driver still does not have their Keep hands on steering wheel hands on the steering wheel after the message "Keep hands on steering...
  • Page 411 If the problem continues, have • Vehicle speed is over 145 km/h (90 the vehicle inspected by an author- mph). ized HYUNDAI dealer. • The vehicle makes sharp lane changes. • The vehicle brakes suddenly. • Only one lane marker is detected.

  • Page 412: Highway Driving Assist (Hda) System

    Driving your vehicle (Continued) Information CAUTION • In the automatic speed setting • High Driving Assist is limited in mode, the vehicle automatically Highway Driving Assist system other countries. accelerates or decelerates when the may not function properly in the •...
  • Page 413 Information Information (Continued) • The speed limit of selected • For information's on vehicle to vehi- Radio frequency radiation exposure highway section is changed cle distance control and the front information: due to road conditions. radar, refer to "Smart Cruise This equipment complies with RSS Control (SCC)"...

  • Page 414: System Setting And Operation

    Driving your vehicle R R E E A A R R C C R R O O S S S S - - T T R R A A F F F F I I C C C C O O L L L L I I S S I I O O N N W W A A R R N N I I N N G G ( ( R R C C C C W W ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) System description System setting and operation WARNING...
  • Page 415 • When the system is initially turned The options for the initial Rear on and when the vehicle is turned Cross-Traffic Collision Warning off then on again, the warning light includes the following: will illuminate for 3 seconds on the - Normal: outside rearview mirror.

  • Page 416: Warning Message And System Control

    Driving your vehicle Operating conditions Warning message and system control To operate: 1. Go to the 'User Settings → Driver ■ Left ■ Right Assistance → Parking Safety → Rear Cross-Traffic Safety' on the LCD display. The system will turn on and standby to operate.
  • Page 417 The warning will stop when: WARNING CAUTION - The detected vehicle moves out of the sensing area or • When the operating condition • If any other warning sound - When the vehicle is right behind of Rear Cross-Traffic Collision such as seat belt warning your vehicle or Warning system is satisfied...

  • Page 418: Detecting Sensor

    In this case, a tions at all times. warning message may not be dis- played. We recommend that you have the vehicle inspected by an authorized HYUNDAI dealer. (Continued) 5-128...
  • Page 419 (Continued) If any of these conditions occur, the light on the BCW switch and the sys- • Do not apply foreign objects tem will turn off automatically. such as a bumper sticker or a bumper guard near the radar sensor or apply paint to the sen- Information sor area.
  • Page 420 If there is a problem with BCW sys- object such as a bumper sticker, a ized HYUNDAI dealer. tem, a warning message will appear bumper guard, a bike rack, etc. and the light on the button will turn •...
  • Page 421 • The vehicle is driven on a curved • While changing lanes. road. • If the vehicle has started at the • The road pavement (or the periph- same time as the vehicle next to eral ground) abnormally contains you and has accelerated. metallic components (i.e.
  • Page 422 Driving your vehicle OAD058160N OAD058162L OAD058152N • When the vehicle is in a complex [A] : Vehicle • When the vehicle is on/near a parking environment slope • When the vehicle is parked diago- nally The system may not operate prop- The system may not operate prop- erly when the vehicle is in a com- erly when the vehicle is on/near a...
  • Page 423 Information This device complies with Industry Canada RSS-210 standard. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any inter- ference received, including interfer- ence that may cause undesired OAD058161L OAD058163N operation.
  • Page 424 Driving your vehicle Information Radio frequency radiation exposure information: This equipment complies with RSS radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm (8 in.) between the radiator (antenna) and your body.

  • Page 425: Hazardous Driving Conditions

    S S P P E E C C I I A A L L D D R R I I V V I I N N G G C C O O N N D D I I T T I I O O N N S S Hazardous Driving Conditions Rocking the Vehicle WARNING...

  • Page 426: Smooth Cornering

    Driving your vehicle Smooth Cornering Driving in the Rain Information Avoid braking or gear changing in Rain and wet roads can make driving The ESC system (if equipped) must be corners, especially when roads are dangerous. Here are a few things to turned OFF before rocking the vehi- wet.

  • Page 427: Driving In Flooded Areas

    • If you believe your brakes may be Driving in Flooded Areas Highway Driving wet, apply them lightly while driv- Avoid driving through flooded areas Tires ing until normal braking operation unless you are sure the water is no Adjust the tire inflation, as specified. returns.

  • Page 428: Snow Or Icy Conditions

    Apply the brakes gently. Speeding, HYUNDAI dealer. rapid acceleration, sudden brake If you mount snow tires on your vehi- applications, and sharp turns are cle, make sure to use radial tires of potentially very hazardous practices.
  • Page 429 HYUNDAI dealer or a snow or ice around or near the rear may cause a failure. The manufactur- service station.
  • Page 430 Driving your vehicle V V E E H H I I C C L L E E L L O O A A D D L L I I M M I I T T Two labels on your driver's door sill Cargo Weight GVW (Gross Vehicle Weight) show how much weight your vehicle...

  • Page 431: Tire Loading Information Label

    Tire Loading Information Label Vehicle capacity weight Towing capacity 385 kg (849 lbs.) We do not recommend using this vehicle for trailer towing. Vehicle capacity weight is the maxi- mum combined weight of occupants and cargo. If your vehicle is equipped Cargo capacity with a trailer, the combined weight The cargo capacity of your vehicle...
  • Page 432 Driving your vehicle Steps for determining correct 5. Determine the combined weight of WARNING load limit luggage and cargo being loaded on the vehicle. That weight may 1. Locate the statement "The com- Do not overload the vehicle as not safely exceed the available bined weight of occupants and there is a limit to the total cargo and luggage load capacity...
  • Page 433 Example 1 ≥ ≥ Maximum Load Passenger Weight Cargo Weight (635 kg) (68 kg × 2 = 136 kg) (499 kg) (1400 lbs.) (150 lbs. × 2 = 300 lbs.) (1100 lbs.) Example 2 ≥ ≥ Cargo Weight Maximum Load Passenger Weight (635 kg) (68 kg ×...
  • Page 434 Driving your vehicle Certification label NOTICE WARNING The certification label is located on Overloading your vehicle may the driver’s door sill at the center pil- Overloading cause damage. Repairs would not lar and shows the maximum allow- be covered by your warranty. Do •...
  • Page 435 T T R R A A I I L L E E R R T T O O W W I I N N G G We do not recommend using this WARNING vehicle for trailer towing. If you carry items inside your vehicle (e.g., suitcases, tools, packages, or anything else), they are moving as fast as the...

  • Page 436: What To Do In An Emergency

    What to do in an emergency Hazard warning flasher ........6-2 Towing ..............6-21 Towing service ..............6-21 In case of an emergency while driving ....6-2 Removable Towing Hook ..........6-22 If the Vehicle Stalls While Driving.........6-2 Emergency Towing............6-23 If the Vehicle Stalls at a Crossroad or Crossing ..6-2 If you Have a Flat Tire While Driving ......6-3 If the vehicle will not start........6-3 Confirm the EV Battery Is Not Low on the...

  • Page 437: If The Vehicle Stalls While Driving

    • The turn signals do not work when • Try to start the vehicle again. If the hazard flasher is on. your vehicle will not start, contact an authorized HYUNDAI dealer or OAEE049016 seek other qualified assistance. The hazard warning flasher serves...

  • Page 438: If You Have A Flat Tire While Driving

    I I F F T T H H E E V V E E H H I I C C L L E E W W I I L L L L N N O O T T S S T T A A R R T T If you Have a Flat Tire While •...
  • Page 439 What to do in an emergency J J U U M M P P S S T T A A R R T T I I N N G G ( ( 1 1 2 2 V V B B A A T T T T E E R R Y Y ) ) Jump starting can be dangerous if (Continued) (Continued)
  • Page 440 Jump starting procedure Information 1. Position the vehicles close enough An inappropriately disposed that the jumper cables will reach, battery can be harmful to the but do not allow the vehicles to environment human touch. health. Dispose the battery 2. Avoid fans or any moving parts in according to your local law(s) the motor compartment at all or regulations.
  • Page 441 If your vehicle will not start after a few attempts, it probably requires servicing. In this event please seek qualified assistance. If the cause of your battery discharging is not apparent, have your vehicle checked by an authorized HYUNDAI dealer.
  • Page 442 Then, if coolant has been lost, cooling fan is operating. If the fan call an authorized HYUNDAI deal- is not running, turn the vehicle off er for assistance. NOTICE...
  • Page 443 What to do in an emergency T T I I R R E E P P R R E E S S S S U U R R E E M M O O N N I I T T O O R R I I N N G G S S Y Y S S T T E E M M ( ( T T P P M M S S ) ) ( ( I I F F E E Q Q U U I I P P P P E E D D ) ) Check Tire Pressure •...

  • Page 444: Tire Pressure Monitoring System (Tpms)

    Tire Pressure Monitoring As an added safety feature, your Your vehicle has also been equipped vehicle has been equipped with a tire with a TPMS malfunction indicator to System pressure monitoring system (TPMS) indicate when the system is not that illuminates a low tire pressure operating properly.

  • Page 445: Low Tire Pressure Telltale

    Low Tire Pressure LCD ized HYUNDAI dealer. stopping distances. You should stop Display with Position Indicator and check your tires as soon as pos- 1.
  • Page 446 Have the sys- is greatly higher or lower, you tem checked by an authorized should check the tire inflation HYUNDAI dealer as soon as possi- pressure and adjust the tires to ble. the recommended tire inflation pressure.

  • Page 447: Changing A Tire With Tpms

    Have the flat tire one minute if the vehicle is near the Low Tire Pressure LCD position repaired by an authorized HYUNDAI electric power supply cables or indicator and TPMS Malfunction dealer as soon as possible or...
  • Page 448 A cold tire means the vehicle has Information WARNING been sitting for 3 hours and driven for This device complies with Industry less than 1.6 km (1 mile) in that 3 Tampering with, modifying, or Canada RSS-210 standard. hour period. disabling the Tire Pressure Operation is subject to the following Allow the tire to cool before measur-...

  • Page 449: With Tire Mobility Kit (Tmk)

    Air pressure loss in the tire may tire should be inspected by an Temporary fix adversely affect tire performance. authorized HYUNDAI dealer as soon For this reason, you should avoid Have your tire repaired as soon as possible. abrupt steering or other driving as possible.
  • Page 450 • In case of eye contact with the Please contact nearest sealant,flush your eyes for at least HYUNDAI dealership if the tire 15 minutes.If the irritation persists, cannot be made roadworthy with seekmedical attention. the Tire Mobility Kit. 6-15...
  • Page 451 What to do in an emergency • In case swallowing Components of the Tire Mobility Kit sealant,rinse the mouth and drink plenty ofwater.However, never give anythingto an unconscious person and seekmedical attention immedi- ately. • Long time exposure to the sealant may cause damage to bodily tissue such as kidney, etc.
  • Page 452 Connectors, cable and connection Using the Tire Mobility Kit hose are stored in the compressor housing. Strictly follow the specified sequence, otherwise the sealant may escape under high pressure. WARNING Do not use the tire sealant after OIGH067042 the sealant has expired (i.e. 2.
  • Page 453 What to do in an emergency Information OAEE069005 OAEE069008 5. Unscrew the valve cap from the 6. Plug the compressor power cord OAEE069006 valve of the flat tire and screw the (4) into the vehicle power outlet. filling hose (3) of the sealant bottle Securely install the sealant filling hose 7.
  • Page 454 Distributing the sealant While driving, if you experience any CAUTION unusual vibration, ride disturbance or noise, reduce your speed and drive Do not attempt to drive your with caution until you can safely pull vehicle if the tire pressure is off of the side of the road.
  • Page 455 When you use the Tire Mobility tion to "I". To check the current including sealant inflation pressure setting, briefly approved by HYUNDAI, the tire switch off the compressor. pressure sensors may be dam- - To reduce the inflation pres- aged by sealant. The sealant on...

  • Page 456: Towing Service

    OAEE069018 OAEE069019 If emergency towing is necessary, CAUTION we recommend having it done by an authorized HYUNDAI dealer or a commercial tow-truck service. • Do not tow the vehicle with the front wheels on the Proper lifting and towing procedures...

  • Page 457: Removable Towing Hook

    What to do in an emergency Removable Towing Hook ■ Front WARNING If your vehicle is equipped with a rollover sensor, place the POWER button in the OFF or ACC position when the vehicle is being towed. The side impact and curtain air bag may deploy if the sensor detects the situa- tion as a rollover.

  • Page 458: Emergency Towing

    • While depressing the brake pedal mend you have it done by an author- shift to the N (Neutral) position and ized HYUNDAI dealer or a commer- turn the vehicle off. The POWER cial tow truck service. button will be in the ACC position.
  • Page 459 What to do in an emergency NOTICE NOTICE Accelerate or decelerate the vehi- To avoid damage to your vehicle cle in a slow and gradual manner and vehicle components when while maintaining tension on the towing: tow rope or chain to start or drive •...

  • Page 460: Maintenance

    Maintenance Motor compartment ..........7-3 Tires and wheels ..........7-23 Tire Care................7-23 Maintenance services ...........7-4 Recommended Cold Tire Inflation Pressures...7-24 Owner's Responsibility.............7-4 Check Tire Inflation Pressure ........7-25 Owner Maintenance Precautions........7-4 Tire Rotation ..............7-26 Owner maintenance..........7-5 Wheel Alignment and Tire Balance ......7-27 Owner Maintenance Schedule ........7-6 Tire Replacement ............7-27 Scheduled maintenance services......7-7 Wheel Replacement ............7-28...
  • Page 461 Light bulbs.............7-52 Headlamp, Parking Lamp, Turn Signal Lamp and Side Marker ..............7-53 Daytime Running Light (DRL)........7-57 Side Repeater Lamp Replacement ......7-57 Rear Combination Light Bulb Replacement .....7-58 High Mounted Stop Light Replacement ....7-60 License Plate Light Bulb Replacement .....7-61 Interior Light Bulb Replacement .........7-61 Appearance care ..........7-63 Exterior Care ..............7-63 Interior Care ..............7-69...
  • Page 462 M M O O T T O O R R C C O O M M P P A A R R T T M M E E N N T T 1. Coolant reservoir 2. Brake fluid reservoir 3. Fuse box 4.

  • Page 463: Owner's Responsibility

    HYUNDAI's high service quality ized HYUNDAI dealer. standards and receives technical Inadequate, incomplete or insuffi- support from HYUNDAI in order to cient servicing may result in opera- provide you with a high level of serv- tional problems with your vehicle that ice satisfaction.
  • Page 464 Block the tires (front and formed by the owner or an author- Performing maintenance work back) to prevent the vehicle ized HYUNDAI dealer at the frequen- on a vehicle can be dangerous. from moving. cies indicated to help ensure safe,...

  • Page 465: Owner Maintenance Schedule

    Maintenance Owner Maintenance Schedule While operating your vehicle: At least monthly: • Check for vibrations in the steering • Check coolant level in the coolant When you stop for fuel: wheel. Notice if there is any reservoir. • Check coolant level in the coolant increased steering effort or loose- •...
  • Page 466 • Driving for a prolonged period in cold temperatures and/or extreme- ly humid climates. • More than 50% driving in heavy city traffic during hot weather above 32°C (90°F). For additional information or assis- tance see your authorized HYUNDAI dealer.

  • Page 467: Coolant

    Air conditioning compressor, air conditioner refrigerant and performance : When replacing or adding coolant, we recommend that you visit an authorized HYUNDAI dealer. For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.
  • Page 468 Normal maintenance schedule R : Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary. KILOMETERS X 1000 96 108 120 132 144 156 168 180 192 DESCRIPTION MONTHS 12 Reduction gear oil 13 Brake pedal free play Inspect every 12,000 km 14 Brake fluid NOTICE...
  • Page 469 Maintenance Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE DRIVING MAINTENANCE ITEM...

  • Page 470: Brake Fluid

    E E X X P P L L A A N N A A T T I I O O N N O O F F S S C C H H E E D D U U L L E E D D M M A A I I N N T T E E N N A A N N C C E E I I T T E E M M S S Cooling System Brake Fluid Steering Gear Box, Linkage &...
  • Page 471 If the coolant level is low, have your vehicle inspected by an authorized HYUNDAI dealer. Use only designat- ed coolant water for electric vehicles, adding other types of water or antifreeze can damage the vehicle.

  • Page 472: Checking The Brake Fluid Level

    • Brake fluid, which has been the brake system checked by an exposed to open air for an authorized HYUNDAI dealer. extended time should NEVER be used as its quality cannot be WARNING guaranteed.

  • Page 473: Washer Fluid

    Maintenance W W A A S S H H E E R R F F L L U U I I D D Checking the Washer Fluid WARNING Level To prevent serious injury or death, take the following safety precautions when using washer fluid: •...

  • Page 474: Climate Control Air Filter

    C C L L I I M M A A T T E E C C O O N N T T R R O O L L A A I I R R F F I I L L T T E E R R Filter Inspection The climate control air filter should be replaced according to the Maintenance...
  • Page 475 Maintenance NOTICE Install a new climate control air fil- ter in the correct direction with the arrow symbol ( ↓ ↓ ) facing down- wards to prevent noise and reduced effectiveness. OAEE076029 OHG075041 3. Press and hold the lock (1) on 5.

  • Page 476: Wiper Blades

    W W I I P P E E R R B B L L A A D D E E S S Blade Inspection Blade Replacement NOTICE Contamination of either the wind- When the wipers no longer clean To prevent damage to the wiper shield or the wiper blades with for- adequately, the blades may be worn blades, arms or other compo-...
  • Page 477 Maintenance OLMB073021 OLMB073020 OLF074017 Type A Type B 1. Raise the wiper arm and slightly 1. Raise the wiper arm. rotate the wiper blade assembly to expose the plastic locking clip. CAUTION Do not allow the wiper arm to OLMB073022 fall against the windshield, 2.
  • Page 478 5. Install a new wiper blade assem- bly in the reverse order of removal. 6. Return the wiper arm on the wind- shield. CAUTION To prevent damage to the wiper arms or other components, have an authorized HYUNDAI dealer replace the wiper blade. 7-19...

  • Page 479: Battery

    Maintenance 1 1 2 2 V V B B A A T T T T E E R R Y Y (Continued) (Continued) WARNING • Batteries contain sulfu- NEVER attempt to recharge To prevent SERIOUS INJURY or ric acid which is highly the battery when the vehicle’s DEATH to you or bystanders, corrosive.

  • Page 480: For Best Battery Service

    • Always genuine • Rinse any spilled acid from the bat- • Wear eye protection when HYUNDAI approved battery tery immediately with a solution of checking the battery during when you replace the battery. water and baking soda. charging. •...

  • Page 481: Reset Features

    Maintenance By jump starting Reset Features After a jump start from a good bat- Some items need to be reset after tery, drive the vehicle for 20-30 min- the battery has been discharged or utes before it is shutoff. The vehicle the battery has been disconnected.

  • Page 482: Tire Care

    T T I I R R E E S S A A N N D D W W H H E E E E L L S S Tire Care (Continued) WARNING For proper maintenance, safety, and • Replace tires that are worn, maximum fuel economy, you must Tire failure may cause loss of show uneven wear, or are dam-...

  • Page 483: Recommended Cold Tire Inflation Pressures

    Maintenance Recommended Cold Tire WARNING Inflation Pressures All tire pressures (including the Recommended pressures must spare) should be checked when the be maintained for the best ride, tires are cold. "Cold tires" means the vehicle handling, and minimum vehicle has not been driven for at tire wear.

  • Page 484: Check Tire Inflation Pressure

    Radial tires may look properly inflat- ized HYUNDAI dealer. ed when they are under-inflated. • Over-inflation produces Remove the valve cap from the tire harsh ride, excessive wear at valve stem.

  • Page 485: Tire Rotation

    Maintenance ■ Without a spare tire Tire Rotation Information To equalize tread wear, HYUNDAI Tires that are asymmetrical or direc- recommends that the tires be rotated tional can only be installed on the every 6,000 km (3,600 miles) or wheel in one direction. The outside sooner if irregular wear develops.

  • Page 486: Tire Replacement

    Wheel Alignment and Tire Tire Replacement WARNING Balance The wheels on your vehicle were Tread wear indicator To reduce the risk of DEATH or aligned and balanced carefully at the SERIOUS INJURY: factory to give you the longest tire life •...

  • Page 487: Wheel Replacement

    If you find a tire is worn Regardless of the remaining factory units in diameter, rim width unevenly, have your dealer check the tread, HYUNDAI recommends and offset. wheel alignment. that tires be replaced after six (6) years of normal service.
  • Page 488 Example tire size designation: Wheel size designation (These numbers are provided as an Wheels are also marked with impor- example only; your tire size designa- tant information that you need if you tor could vary depending on your ever have to replace one. The follow- vehicle.) ing explains what the letters and numbers in the wheel size designa-...
  • Page 489 Maintenance Tire speed ratings 3. Checking tire life (TIN : Tire 4. Tire ply composition and Identification Number) material The chart below lists many of the dif- ferent speed ratings currently being Any tires that are over six years old, The number of layers or plies of rub- used for passenger car tires.
  • Page 490 6. Maximum load rating Tread wear Traction - AA, A, B & C The tread wear grade is a compara- The traction grades, from highest to This number indicates the maximum tive rating based on the wear rate of lowest, are AA, A, B and C. Those load in kilograms and pounds that the tire when tested under controlled grades represent the tire's ability to...
  • Page 491 Maintenance Temperature - A, B & C Tire Terminology and WARNING Definitions The temperature grades are A (the highest), B and C representing the Air Pressure The temperature grade for this tire’s resistance to the generation of tire is established for a tire that The amount of air inside the tire heat and its ability to dissipate heat is properly inflated and not...
  • Page 492 Bead DOT Markings Kilopascal (kPa) The tire bead contains steel wires The DOT code includes the Tire The metric unit for air pressure. wrapped by steel cords that hold the Identification Number (TIN), an tire onto the rim. alphanumeric designator which can Light truck(LT) tire also identify the tire manufacturer, A tire designated by its manufacturer...
  • Page 493 Maintenance Maximum Load Rating Outward Facing Sidewall Pneumatic options weight The load rating for a tire at the maxi- An asymmetrical tire has a particular The combined weight of installed mum permissible inflation pressure side that faces outward when mount- regular production options weighing for that tire.
  • Page 494 Sidewall UTQGS Vehicle Normal Load on the Tire The portion of a tire between the Uniform Tire Quality Grading Load on an individual tire that is tread and the bead. Standards is a tire information sys- determined by distributing to each tem that provides consumers with axle its share of the curb weight, ratings for a tire's traction, tempera-...

  • Page 495: All Season Tires

    Maintenance All Season Tires Snow Tires Radial-Ply Tires HYUNDAI specifies all season tires If you equip your car with snow tires, Radial-ply tires provide improved on some models to provide good they should be the same size and tread life, road hazard resistance and...

  • Page 496: Low Aspect Ratio Tires

    • If the tire is subjected to a severe impact, have the tire and wheel inspected by an authorized HYUNDAI dealer. • Inspect the tire condition and pressure every 3,000 (1,800 miles).
  • Page 497 Maintenance CAUTION • It is not easy to recognize tire damage with your own eyes. But if there is the slightest hint of tire damage, have the tire checked replaced because the tire damage may cause air leakage from the tire.
  • Page 498 Avoid using the system involved and imme- diately consult authorized NOTICE HYUNDAI dealer. Do not use a screwdriver or any Blown Normal other metal object to remove Information fuses because it may cause a...

  • Page 499: Instrument Panel Fuse Replacement

    7. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. 7-40...

  • Page 500: Motor Compartment Panel Fuse Replacement

    Fuse switch Motor Compartment Panel Information Fuse Replacement ■ Blade type fuse OAEE076033 OAEE079011 OIK057165L ■ Cartridge type fuse Always, place the fuse switch to the If the fuse switch is OFF, the above ON position. message will appear. If you move the switch to the OFF position, some items such as the NOTICE audio system and digital clock must...
  • Page 501 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized HYUNDAI dealer. CAUTION After checking the fuse box in the motor compartment secure-...

  • Page 502: Fuse/Relay Panel Description

    Fuse/Relay Panel Description Instrument panel fuse panel OAEE079014 Inside the fuse/relay box cover, you can find the fuse/relay label describ- ing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at OAEE076053N the time of printing.
  • Page 503 Maintenance Instrument panel fuse panel Fuse Name Fuse Rating Protected Component Electro Chromic Mirror, Audio, Driver IMS Module, Rear Seat Warmer Module, DBL Unit, VESS Unit, MODULE5 Front Seat Warmer Control Module, Head Lamp LH/RH, Front Air Ventilation Seat Control Module Lane Keeping Assist Unit, Crash Pad Switch, Electric Parking Brake Unit FCA Unit, MODULE4 Blind-spot Collision Warning (BCW) Radar LH/RH...
  • Page 504 Instrument panel fuse panel Fuse Name Fuse Rating Protected Component E/R Junction Block (Power Outlet Relay), Wireless Charger Unit, SBW Switch, BCM, USB Charging, MODULE2 Smart Key Control Module, Audio, A/V & Navigation Head Unit, Power Outside Mirror Switch, AMP PDM3 7.5A Smart Key Control Module...
  • Page 505 Maintenance Instrument panel fuse panel Fuse Name Fuse Rating Protected Component SUNROOF Sunroof Motor P/WDW RH Power Window (RH) Relay, Passenger Safety Power Window Switch P/WDW LH Driver Safety Power Window Module PDM2 7.5A Smart Key Control Module, Start/Stop Button Switch BRAKE 7.5A Stop Lamp Switch, Smart Key Control Module...
  • Page 506 Instrument panel fuse panel Fuse Name Fuse Rating Protected Component Data Link Connector, FCA Unit, Driver/Passenger Power Outside Mirror, MODULE1 Driver/Passenger Smart Key Outside Handle, Driver/Passenger Door Module DOOR LOCK Door Lock/Unlock Relay, ICM Relay Box (Two Turn Unlcok Relay) WIPER FRT2 Wiper Motor, PCB Block (Front Wiper (Low) Relay) BCM MODULE6...
  • Page 507 Maintenance Motor compartment fuse panel OAEE076016 Inside the fuse/relay box cover, you can find the fuse/relay label describ- ing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing.
  • Page 508 Motor compartment fuse panel Fuse Name Fuse Rating Protected Component EPCU (Low Voltage DC-DC Converter), E/R Junction Block (Fuse - H/LAMP HI, MAIN 180A POWER OUTLET1, AHB2, AHB1) MDPS MDPS Unit REAR E/R Junction Block (Rear Defogger Relay) HEATED1 BLOWER E/R Junction Block (Blower Relay) IGPM (Fuse - ARISU (4CH), IPS (1CH/2CH)) IGPM (Fuse - P/WINDOW LH/RH, TAILGATE OPEN, SUNROOF, AMP, CHARGER, OBC,...
  • Page 509 Maintenance Motor compartment fuse panel Fuse Name Fuse Rating Protected Component B/UP LAMP E/R Junction Block (B/UP Lamp Relay), Multipurpose Check Connector POWER E/R Junction Block (Power Outlet Relay) OUTLET1 H/LAMP HI E/R Junction Block (Head Lamp (HI) Relay) AHB1 IBAU, Multipurpose Check Connector AHB2 IBAU, Multipurpose Check Connector...
  • Page 510 Motor compartment fuse panel (Battery terminal cover) OAEE076018 Inside the fuse/relay box cover, you can find the fuse/relay label describ- ing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your OAEE076043 vehicle;...
  • Page 511 The removable level may dif- fer depending on lamp size, lamp posi- tion and environmental condition. However, if moisture is not removed, we recommend that your vehicle is inspect- ed by an authorized HYUNDAI dealer. 7-52...

  • Page 512: Headlamp, Parking Lamp, Turn Signal Lamp And Side Marker

    Headlamp, Parking Lamp, Turn • Always handle them carefully, and avoid scratches and abrasions. If Signal Lamp and Side Marker the bulbs are lit, avoid contact with Type A– Standard type liquids. • Never touch the glass with bare hands. Residual oil may cause the bulb to overheat and burst when lit.
  • Page 513 Information The headlamp aiming should be High beam adjusted after an accident or after the headlamp assembly is reinstalled at an authorized HYUNDAI dealer. OAE076030 OAE076031 Headlamp and parking lamp Turn signal 1. Open the hood.
  • Page 514 (3) Turn signal lamp (4) Parking lamp (5) Side marker lamp Headlamp, parking lamp and side marker lamp If the light bulb does not operate, we recommend that you have the vehi- cle checked by an authorized HYUNDAI dealer. 7-55...
  • Page 515 Cycling vehicle checked by an author- the headlamps on and off more than ized HYUNDAI Dealer. typical use will shorten HID lamps OAEPH078041 life. HID lamps do not fail in the same...

  • Page 516: Daytime Running Light (Drl)

    If the LED lamp lamps. LED lamps do not have does not operate, have the vehicle replaceable bulbs. If the LED lamp checked by an authorized HYUNDAI does not operate, have the vehicle dealer. checked by an authorized HYUNDAI dealer.

  • Page 517: Rear Combination Light Bulb Replacement

    Replacement Your vehicle is equipped with LED lamps. LED lamps do not have replaceable bulbs. If the LED lamp does not operate, have the vehicle checked by an authorized HYUNDAI dealer. OAE076037 OAE078053 1. Open the liftgate. 2. Open the lamp assembly retaining (1) Stop/Tail lamp screw covers.
  • Page 518 6. Remove the bulb from the socket by pressing it in and rotating it counterclockwise until the tabs on Turn signal lamp the bulb align with the slots in the socket. Pull the bulb out of the socket. 7. Insert a new bulb by inserting it into the socket and rotating it until it locks into place.

  • Page 519: High Mounted Stop Light Replacement

    Maintenance Backup lamp High Mounted Stop Light Replacement Backup lamp OAEPH078040 4. Remove the socket from the OAEE079025 assembly by turning the socket OAE079043 1. Turn off the vehicle. counterclockwise until the tabs on 1. Open the liftgate. 2. Open the tailgate. the socket align with the slots on the assembly.

  • Page 520: License Plate Light Bulb Replacement

    If the LED lamp does not operate, have the vehicle checked by an lamp housing. authorized HYUNDAI dealer. 2. Remove the bulb by pulling it straight out. 3. Install a new bulb.
  • Page 521 Maintenance 1. Using a flat-blade screwdriver, Map lamp, room lamp, vanity mirror lamp and gently pry the lens from the interi- luggage compartment lamp or lamp housing. ■ Map lamp (Bulb type) ■ Vanity mirror lamp 2. Remove the bulb by pulling it straight out.

  • Page 522: Exterior Care

    A A P P P P E E A A R R A A N N C C E E C C A A R R E E Exterior Care Protecting your vehicle’s finish After washing, rinse the vehicle thor- oughly with lukewarm or cold water.
  • Page 523 Maintenance High-pressure washing NOTICE • When using high-pressure wash- • Do not use strong soap, chemi- ers, make sure to maintain suffi- cal detergents or hot water, and cient distance from the vehicle. do not wash the vehicle in direct Insufficient clearance or excessive sunlight or when the body of the pressure can lead to component...
  • Page 524 Waxing NOTICE NOTICE A good coat of wax provides a barri- Matte paint finish vehicle • Wiping dust or dirt off the body er between your paint and environ- (if equipped) with a dry cloth will scratch the mental contamination. finish.
  • Page 525 HYUNDAI dealer. Take extreme care, as it is difficult to restore the quality after the repair. 7-66...
  • Page 526 Some of the and construction practices to combat NOTICE common causes of accelerated cor- corrosion, HYUNDAI produces cars • Do not use abrasive cleaner, pol- rosion are road salts, dust control of the highest quality. However, this is...
  • Page 527 Maintenance High temperatures can also acceler- • When cleaning underneath the Keep your garage dry ate corrosion of parts that are not vehicle, pay particular attention to Don’t park your car in a damp, poor- properly ventilated so the moisture the components under the fenders ly ventilated garage.

  • Page 528: Interior Care

    Interior Care Cleaning the upholstery and Leather (if equipped) interior trim • Feature of Seat Leather Interior general precautions Vinyl (if equipped) - Leather is made from the outer Prevent caustic solutions such as skin of an animal, which goes Remove dust and loose dirt from perfume and cosmetic oil, from con- through a special process to be...
  • Page 529 Maintenance • Caring for the leather seats • Cleaning the leather seats CAUTION - Vacuum the seat periodically to - Remove contaminations remove dust and sand on the instantly. Refer to instructions • Wrinkles or abrasions which seat. It will prevent abrasion or below for removal of each con- appear naturally from usage damage of the leather and main-...
  • Page 530 Cleaning the seat belt webbing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet. Follow the instructions provided with the soap. Do not bleach or re-dye the webbing because this may weaken the seat belt. Cleaning the interior window glass If the interior glass surfaces of the...

  • Page 531: Specifications & Consumer Information

    Specifications & Consumer information Dimensions ..............8-2 Electric vehicle specifications......8-2 Bulb wattage............8-3 Tires and wheels ............8-4 Volume and weight ..........8-5 Air conditioning system ........8-5 Recommended lubricants and capacities ...8-6 Vehicle identification number (VIN)....8-7 Vehicle certification label ........8-7 Tire specification and pressure label ....8-8 Motor number............8-8 8 8 8 8...
  • Page 532 Specifications & Consumer information D D I I M M E E N N S S I I O O N N S S Items mm (in) Overall length 4,470 (175.9) Overall width 1,820 (71.6) Overall height 1,475(58) Front tread 1,555 (61.2) Rear tread 1,564 (61.5)
  • Page 533 B B U U L L B B W W A A T T T T A A G G E E Light Bulb Bulb Type Wattage H7LL Headlamp High 9005HL+ Type A Parking lamp Turn signal lamp 28/8W 28/8 Side marker Front Headlamp...
  • Page 534 Specifications & Consumer information T T I I R R E E S S A A N N D D W W H H E E E E L L S S Inflation Pressure Wheel Lug Nut kPa (psi) Torque Items Tire Size Wheel Size...
  • Page 535 A A I I R R C C O O N N D D I I T T I I O O N N I I N N G G S S Y Y S S T T E E M M Items Weight of Volume Classification without heat pump 550±25 (19.40±0.88) Refrigerant R-134a g (oz.) with heat pump 1,100±25 (38.80±0.88) Compressor lubricant cc (oz.) 180±10 (6.34±0.35) Contact an authorized HYUNDAI dealer for more details.
  • Page 536 Specifications & Consumer information R R E E C C O O M M M M E E N N D D E E D D L L U U B B R R I I C C A A N N T T S S A A N N D D C C A A P P A A C C I I T T I I E E S S To help achieve proper vehicle performance and durability, use only lubricants of the proper quality.
  • Page 537 V V E E H H I I C C L L E E I I D D E E N N T T I I F F I I C C A A T T I I O O N N N N U U M M B B E E R R ( ( V V I I N N ) ) V V E E H H I I C C L L E E C C E E R R T T I I F F I I C C A A T T I I O O N N L L A A B B E E L L ■...
  • Page 538 Specifications & Consumer information T T I I R R E E S S P P E E C C I I F F I I C C A A T T I I O O N N A A N N D D M M O O T T O O R R N N U U M M B B E E R R P P R R E E S S S S U U R R E E L L A A B B E E L L OAEE086001...

  • Page 539: Index

    Index...
  • Page 540 Index Accessing your vehicle .............3-3 Battery(12V) ..............7-20 Immobilizer System .............3-8 Battery Recharging.............7-21 Smart Key ..............3-3 For Best Battery Service ...........7-21 Air bag - Advanced supplemental restraint system ..2-47 Reset Features ............7-22 Additional Safety Precautions........2-69 Before driving ..............5-3 Air Bag Warning Labels..........2-70 Before Entering the Vehicle .........5-3 How Does the Air Bag System Operate?....2-53 Before Starting .............5-3...
  • Page 541 System malfunction............5-86 System setting and operation ........5-83 System standby............5-86 Child restraint system (CRS) ..........2-36 Driver position memory system ........3-14 Children Always in the Rear ........2-36 Easy Access Function..........3-15 Installing a Child Restraint System (CRS) ....2-39 Recalling positions from memory......3-15 Selecting a Child Restraint System (CRS)....2-37 Storing Positions into Memory .........3-14 Climate control additional features ......3-125 Automatic Ventilation..........3-125...
  • Page 542 Index Bluetooth ® Wireless Technology Hands-Free....4-4 Steering Wheel Audio Controls........4-3 ® USB and iPod port .............4-2 Hazard warning flasher.............6-2 Instrument cluster ............3-44 Highway Driving Assist (HDA) system ......5-117 Gauges and Meters .............3-46 System Setting and Operation ........5-117 Instrument Cluster Control.........3-45 Warning Message .............5-120 LCD Display Messages ..........3-62 Warning and Indicator lights ........3-50...
  • Page 543 Lane Following Assist (LFA) ........5-110 Maintenance services ............7-4 LFA operation ............5-112 Owner Maintenance Precautions........7-4 Limitations of the system .........5-115 Owner's Responsibility..........7-4 Warning message............5-113 Mirrors ................3-19 Lane Keeping Assist (LKA) ...........5-61 Inside Rearview Mirror ..........3-19 Limitations of the System ..........5-67 Reverse Parking Aid Function ........3-30 LKA operation............5-63 Side View Mirrors ............3-27 LKA system function change ........5-69...
  • Page 544 Index Seat warmers ..............2-20 Smart Cruise Control with Stop and Go (SCC with S&G)............5-91 Rear Cross-Traffic Collision Warning (RCCW)...5-124 Limitations of the system .........5-104 Detecting Sensor ............5-128 Sensor to detect distance to the vehicle ahead..5-102 System description ...........5-124 Smart Cruise Control speed ........5-94 System setting and operation ........5-124 Smart Cruise Control Vehicle-to-Vehicle Distance..5-99 Warning message and system control ......5-126...
  • Page 545 Steering wheel..............3-16 Tire specification and pressure label ........8-8 Electric Power Steering (EPS) ........3-16 Tires and wheels ............7-23, 8-4 Heated Steering Wheel..........3-18 All Season Tires ............7-36 Horn................3-18 Check Tire Inflation Pressure........7-25 Tilt Steering / Telescope Steering ......3-17 Low Aspect Ratio Tires ..........7-37 Storage compartment ............3-126 Radial-Ply Tires............7-36 Center Console Storage..........3-126...
  • Page 546 Index Vehicle certification label ..........8-7 Vehicle identification number (VIN) ........8-7 Vehicle load limit ............5-140 Tire Loading Information Label.......5-141 Volume and weight ............8-5 Washer fluid ..............7-14 Checking the Washer Fluid Level ......7-14 Windows .................3-31 Power Windows............3-32 Windshield defrosting and defogging......3-122 Auto Defogging System ..........3-124 Defogging Logic ............3-123 To Defog Inside Windshield........3-122 To Defrost Outside Windshield........3-123...

This manual is also suitable for:

Ioniq electric 2020

Table of Contents

Save PDF
