维修手册
Service Manual
适用机型
（本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and
specific appearance and configuration are subject to the real product)
编制
审核
批准
Applicable Models
electronic
Prepared by
Reviewed by
Approved by
维修手册
Service Manual, 2018 v1.0
Model No.
机型编码
NY1507-14A
吴小虎
胡焱然
杨超
1 / 17
Advertisement
Related Manuals for Midea NY1507-14A
Summary of Contents for Midea NY1507-14A
- Page 1 维修手册 Service Manual, 2018 v1.0 维修手册 Service Manual Applicable Models Model No. 适用机型 机型编码 NY1507-14A electronic （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) Prepared by 编制 吴小虎 Reviewed by 审核...
-
Page 2: Important Safety Notice
Midea Environment Appliance Technical Maintenance Manual Copyright @2016 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Environment Appliance. 2 / 17... -
Page 3: Safety Warning Code
维修手册 Service Manual, 2018 v1.0 安全警示规范 Safety Warning Code WARNING 警告标语，此页不 Read these instructions. 需要修改 Keep these instructions. Follow all instructions. Do not use this appliance near water. This appliance is intended to be used in household and similar environments. Clean only with a damp cloth. - Page 4 维修手册 Service Manual, 2018 v1.0 整机拆卸 Dismantling of appliance 拆卸控制箱组件 Remove control box assembly 撕下面贴，露出沉头螺钉孔； 使用十字螺丝刀或者电批/风批将控制箱顶部 的 1 颗固定螺钉（M6*25）拆开； 使用十字螺丝刀或者电批/风批将控制箱尾部 的 2 颗固定螺钉（ST3.9*6）拆开； Tear down the face stick, reveal countersunk head screw hole; Remove 1 fixing screw (M6*25) from the top of the control box with a cross screwdriver or electric/air batch;...
- Page 5 维修手册 Service Manual, 2018 v1.0 拆卸控制箱内部所有接插端子 Remove all socket terminals inside the control box 使用尖嘴钳将控制箱内部所有接插端子拔除； (有焊锡的端子需要使用电烙铁辅助拆除) Remove all socket terminals inside the control box with needle-nose pliers;(solder terminals need to be removed with the help of an electric soldering iron) 拆卸瓷座上两螺母...
- Page 6 维修手册 Service Manual, 2018 v1.0 拆卸收线板、 感温头 Remove the wire take-up board and temperature sensing head 用钳子顶住收线板的卡扣，将收线板拆出； 将收线板从控制箱上拆除； 将感温头从收线板上拆下； Use pliers to hold the buckle of the take-up plate and remove the take-up plate. Remove the reel plate from the control box; Remove the temperature sensing head from the reel;...
- Page 7 维修手册 Service Manual, 2018 v1.0 2.10 拆卸提手 Remove the handle 使用十字螺丝刀或者电批/风批将固定提手的 螺钉（2 颗 ST3.9*9.5）拆下； 将提手向控制箱尾部方向推动，取下提手； Remove the screws (2 ST3.9*9.5) that hold the handle with a cross screwdriver or an electric/air batch; Push the handle toward the rear of the control box and remove the handle 2.11 拆卸控制面板...
- Page 8 维修手册 Service Manual, 2018 v1.0 2.12 拆卸电路板总成 Remove circuit board assembly 使用十字螺丝刀或者电批/风批将电路板总成 固定螺钉（1 颗 ST2.9*9.5）拆开； 将电路板取下； （注意静电防护） Disassemble the fixing screw (1 ST2.9*9.5) of circuit board assembly with a cross screwdriver or batch/batch; Remove the circuit board;(pay attention to electrostatic protection) 2.13 拆卸按键...
- Page 9 维修手册 Service Manual, 2018 v1.0 安装电路板总成 Install circuit board assembly 取电路板总成，控制面板； 将电路板总成扣在控制面板上； 使用十字螺丝刀或者电批/风批将电路板总 成固定螺钉（1 颗 ST2.9*9.5）紧固； Take circuit board assembly, control panel; Buckle the circuit board assembly on the control panel; Fix the circuit board assembly screw (1 ST2.9*9.5) with cross screwdriver batch/batch;...
- Page 10 维修手册 Service Manual, 2018 v1.0 安装倾倒开关 Install dump switch 取倾倒开关； 使用 2 颗 ST3.9*25 螺钉将其固定在控制箱 上； Dump switch; Fix 2 ST3.9*25 screws on the control box; 安装出线胶圈/电源线 Install outgoing apron/power cord 取出线胶圈，装到控制箱制定位置， （提示： 将胶圈加热后再装会更好装） ， 可借助尖嘴钳 安装； 取电源线， 将其从控制箱正面穿过出线胶圈； Take out the wire apron and install it at the designated position of the control box.
- Page 11 维修手册 Service Manual, 2018 v1.0 一起；用钳子紧固好螺母。 Place the porcelain holder in the designated position inside the control box, and use a cross screwdriver/batch to fix one ST3.9*15 screw on the porcelain holder; Internal wiring harness and power cable lines to zero to zero, wire to wire, use 2 pieces of Φ 4 ball pad and 2 M4 nut connected together;Fasten the nut with pliers.
- Page 12 维修手册 Service Manual, 2018 v1.0 3.10 插线/扎线 Plug/tie the wire 将内部线端子插接到位，需要焊锡的位置加 焊锡； 将内部导线理顺，使用扎带将内部导线按要 求扎好，避免内部导线凌乱或贴近控制箱散 热孔； Insert the terminal of the internal wire into the position, add solder where solder is needed; Straighten out the internal wire, tie up the internal wire as required with the band, avoid the internal wire messy or close to the heat dissipation hole of the control box;...
- Page 13 维修手册 Service Manual, 2018 v1.0 3.12 紧固控制箱 Tighten the control box 使用十字螺丝刀/电批锁紧控制箱对应的固 定螺钉 （1 颗 M6*25 螺钉， 2 颗 ST3.9*6 螺钉） ； Use cross screwdriver/batch lock control box corresponding to the fixed screw (1 M6*25 screw, 2 ST3.9*6 screw); 3.13 贴面贴...
- Page 14 维修手册 Service Manual, 2018 v1.0 A. Check whether it is used under abnormal conditions. If it is, disassemble the control box components and press down the manual temperature limiting device; B. If it is used under normal circumstances, please replace the manual temperature limiter. The value of the manual temperature limiter is not accurate;...
- Page 15 维修手册 Service Manual, 2018 v1.0 Appendix: 附录 Electrical Schematic Diagram 整机接线图 油汀维修常用工具、设备和材料 heater maintenance tooling and equipment and material 工具 Tooling 名称 图片 主要用途 Name Photo Main Usage 十字螺丝刀 拆卸螺钉 Phillips screw assemble and screwdriver disassemble 15 / 17...
- Page 16 维修手册 Service Manual, 2018 v1.0 平口螺丝刀/小铲刀 拆卸螺钉和铆钉 screw and slotted screwdriver/scraper rivet assemble and disassemble 尖嘴钳 辅助工具 Nipper pliers assistive tool 16 / 17...
- Page 17 美的环境电器 如需获得厂家详细技术咨询，请联系： liujianlin@midea.com 环境电器事业部 海外营销公司 地址：中国安徽省合肥市经济技术开发区锦绣大道 176 号 Midea Environment Appliance If you need to get detailed technical information from the manufacturer, please contact: liujianlin@midea.com Refrigeration Division Overseas Sales Company Address: No. 176, Jinxiu Avenue, Economic-Technological Development Area, Hefei, Anhui,...
