- Page 1 AIR CONDITIONING SYSTEMS INDOOR UNIT TPWFYP036BU140A TPWFYP036AU141A TPWFYP072AU141A INSTALLATION MANUAL For safe and correct use, please read this installation manual thoroughly before installing the indoor unit. MANUAL DE INSTALACIÓN Para la utilización segura y correcta, lea detenidamente este manual de instalación antes de instalar la unidad interior.
- Page 2 [Fig. 6.1.1] [Fig. 6.2.1] 525[20- Ⓐ 500[19- 450[17- Ⓐ Ⓑ Ⓒ Ⓑ Ⓐ Piping space (right side) Ⓐ 4-ø14 [9/16] (Anchoring hole) Ⓑ Top view Ⓑ (Top view) Ⓒ Service space (front side) [Fig. 7.1.1] [Fig. 7.1.2] TPWFYP072AU141A Ⓒ Ⓖ Ⓔ...
- Page 3 [Fig. 7.1.3] Single system sample Note: The figure above shows a sample water circuit. This circuit is provided only as a reference, and Mitsubishi Electric Corporation shall not be held responsible for any problems arising from the use of this circuit. [Fig. 7.1.4] Multiple system sample Note: The figure above shows a sample water circuit. This circuit is provided only as a reference, and Mitsubishi Electric Corporation shall not be held responsible for any problems arising from the use of this circuit. 1 TPWFYP036/072AU141A or TPWFYP036BU140A 0 Expansion tank (closed type) *1 *2...
- Page 4 [Fig. 7.1.5] TPWFYP036BU140A TPWFYP036/072AU141A 3000 2500 2000 1500 1000 Ⓐ Water volume limitation [L] Ⓑ Total hardness [mg/L] Ⓒ Available water volume area [Fig. 7.2.1] [Fig. 7.4.1] [Fig. 7.4.2] Ⓑ Board AC208 - 230V DC30V or less TB141A OUT1 Ⓓ Ⓑ...
- Page 5 [Fig. 8.1.1] Ⓓ Ⓐ Ⓐ Refrigerant piping (gas) Ⓑ Refrigerant piping (liquid) 134[5- Ⓒ Water inlet Ⓓ Water outlet Ⓑ Ⓔ Drain outlet *1: TPWFYP036/072AU141A Ⓒ Ⓔ 114[4- 184[7- ] (206*1[8- [Fig. 9.1.1] [Fig. 9.1.2] Ⓐ Ⓒ Ⓑ Ⓐ Cut here Ⓐ...
- Page 6 10.1 [Fig. 10.1.1] TPWFYP036BU140A Ⓐ Ⓑ Ⓒ TPWFYP036/072AU141A Ⓐ Breaker for current leakage Ⓔ Ⓔ Ⓑ Local switch or breakers for wiring Ⓐ Ⓑ Ⓒ TPWFYP036BU140A Ⓓ TPWFYP036/072AU141A Ⓔ Pull box Ⓓ Ⓓ Ⓓ 10.2 [Fig. 10.2.1] Ⓐ Ⓑ Ⓒ Ⓔ TB02 TB15 M1M2 M1M2 M1M2 1 2 S earth cable (shielded) Ⓓ...
-
Page 7: Table Of Contents
- If the air conditioner is installed improperly, water leakage, electric shock, - It may also be in violation of applicable laws. or fire may result. - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible for • After completing installation work, make sure that refrigerant gas is not malfunctions or accidents resulting from the use of the wrong type of refrigerant. -
Page 8: Precautions For Devices That Use R410A Refrigerant
Install the power cable so that tension is not applied to the cable. - It may also be in violation of applicable laws. - Tension may cause the cable to break and generate heat and cause a fire. - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible • Install a leak circuit breaker, as required. -
Page 9: About The Product
- It may also be in violation of applicable laws. riorate the refrigerant machine oil in the new equipment. The existing piping - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible for mal- must not be used as the design pressure in systems using R410A is higher functions or accidents resulting from the use of the wrong type of refrigerant. -
Page 10: Precautions During Installation
The figure above shows a sample water circuit. This circuit is provided only as a sure to install a strainer on the water intake pipe. (In order to maintain the reference, and Mitsubishi Electric Corporation shall not be held responsible for heat source unit, a strainer on the circulating water inlet is necessary.) any problems arising from the use of this circuit. -
Page 11: Pump Interlock
② Water quality standard Lower mid-range temperature water system Higher mid-range temperature water system Tendency Items Water Temp. 60 °C [140 °F] Water Temp. > 60 °C [140 °F] Recirculating water Make-up water Recirculating water Make-up water Corrosive Scale-forming pH (25 °C) 7.0 ~ 8.0 7.0 ~ 8.0 7.0 ~ 8.0 7.0 ~ 8.0 Electric conductivity (mS/m) (25 °C [77 °F]) 30 or less... -
Page 12: Refrigerant Pipe, Drain Pipe And Filling Port
② If the unit is used on the highest story of a building and under conditions of ③ If there are customer’s specifications, simply follow them. high temperature and humidity, it is necessary to use pipe size and insulating material’s thickness more than those given in the table above. 8.1. Refrigerant pipe, drain pipe and filling port [Fig. -
Page 13: Electrical Wiring
10. Electrical wiring Precautions on electrical wiring 6. Never connect the power cable to leads for the transmission cables. Other- wise the cables would be broken. Warning: 7. Be sure to connect control cables to the indoor unit, remote controller, and the outdoor unit. Electrical work should be done by qualified electrical engineers in accordance with “Engineering Standards For Electrical Installation”... -
Page 14: Connecting Remote Controller, Indoor And Outdoor Transmission Cables
10.2. Connecting remote controller, indoor Table10.3.2 OUT1 Operation ON/OFF and outdoor transmission cables OUT2 Defrost (Remote contoroller is optionally available.) OUT3*1 Compressor OUT4 Error signal • Connect unit TB5 and outdoor unit TB3. (Non-polarized 2-wire (shield)) *1 This function is available for TPWFYP036BU140A The “S” on unit TB5 is a shielding wire connection. For specifications about External input terminal the connecting cables, refer to the outdoor unit installation manual. The piping length must be within 100 m [328 ft]. -
Page 15: Medidas De Seguridad
• Una vez finalizada la instalación asegúrese de que no hay fugas de gas. - MITSUBISHI ELECTRIC CORPORATION no es responsable de cualquier ano- - Si hay fugas de gas refrigerante y se exponen a un calefactor de aire, es- malía o accidente derivantes del uso del tipo de refrigerante equivocado. -
Page 16: Precauciones Para Aparatos Que Utilizan Refrigerante R410A
- También podría suponer un quebrantamiento de la normativa aplicable. - Si no se instala, pueden producirse descargas eléctricas. - MITSUBISHI ELECTRIC CORPORATION no es responsable de cualquier • Utilice cables de alimentación de capacidad y gama de corriente adecuadas. -
Page 17: Sobre El Producto
- También podría suponer un quebrantamiento de la normativa aplicable. de diseño de los sistemas que usan el R410A es mayor que la de los sis- - MITSUBISHI ELECTRIC CORPORATION no es responsable de cualquier temas que usan otros tipos de refrigerante y las tuberías actuales podrían anomalía o accidente derivantes del uso del tipo de refrigerante equivocado. -
Page 18: Instalación De La Tubería De Agua
La imagen anterior muestra un ejemplo del circuito de agua. El circuito se ofrece utilice las juntas, válvulas, etc. apropiadas en los puertos de admisión y sali- solo como referencia y Mitsubishi Electric Corporation no será responsable de da de agua. Asimismo, asegúrese de instalar un filtro en el tubo de admisión ningún problema que derive del uso de este circuito. -
Page 19: Interbloqueo De Bomba
② Estándares de la calidad del agua Sistema de agua de temperatura de rango medio inferior Sistema de agua de temperatura de rango medio superior Tendencia Ítems Temperatura del agua 60 °C [140 °F] Temperatura del agua > 60 °C [140 °F] Agua recirculante Agua de compensación Agua recirculante Agua de compensación Corrosivo Forma oxidación pH (25 °C) -
Page 20: Tubo De Refrigerante, Tubo De Drenaje Y Abertura De Relleno
② Si la unidad se usa en la planta superior de un edificio y bajo condiciones de ③ Si el cliente le indica alguna especificación especial, siga siempre sus indi- humedad y temperatura elevadas, será necesario usar tubos y material de ais- caciones. lamiento de tamaño y espesor superiores a los indicados en la tabla anterior. 8.1. Tubo de refrigerante, tubo de drenaje y abertura de relleno [Fig. -
Page 21: Cableado Eléctrico
10. Cableado eléctrico Precauciones con el cableado eléctrico 6. Nunca conecte el cable de alimentación a las conexiones de los cables de transmisión. Si lo hace, los cables podrían romperse. 7. Asegúrese de conectar los cables de control en la unidad interior, el mando Advertencia: a distancia y la unidad exterior. -
Page 22: Conexión De Los Cables De Transmisión Del Mando A Distancia Y De Las Unidades Exterior E Interior
10.2. Conexión de los cables de transmisión Tabla 10.3.2 OUT1 Operación de ACTIVAR/DESACTIVAR del mando a distancia y de las unida- OUT2 Descongelar des exterior e interior OUT3*1 Compresor OUT4 Señal de error (El mando a distancia está disponible opcionalmente.) *1 Esta función está... - Page 24 This product is designed and intended for use in the residential, commercial and light-industrial environment. Please be sure to put the contact address/telephone number on this manual before handing it to the customer. HEAD OFFICE: 1340 SATELLITE BLVD, SUWANEE GA 30024 USA WT09286X01 Printed in Japan...
