Power On / Off Button
Press and hold for two seconds to turn on or off.
Lock Out Button
Press and hold for two seconds to activate or deactivate lockout of all functions.
Side Rail Down Indicator
Indicates when the left or right side rails are down.
Fowler Angle Indicator
Indicates when fowler angle is greater than 30°.
Alarm Indicator
Indicates when an alarm condition exists.
Alarm Silence / Clear Button
Press to clear an alarm indicator or to acknowledge an alarm.
Seat Deflate Button
Press to activate or deactivate seat deflate.
Head Deflate Button
Press to activate or deactivate head deflate
Firm Mattress Button
Press to activate or deactivate firm mattress function
Patient Transport Button
Press to activate or deactivate patient transport.
Patient Turn Right Button (nurse assist)
Press to rotate the patient 20° to their right.
Patient Center Button
Press to return from a turned position to a flat.
Patient Turn Left Button (nurse assist)
Press to rotate the patient 20° to their left.
Continuous Patient Turn
Hold Time Button (optional configuration)
Press to initiate continuous patient turn.
Height / Weight Presets
Press button to select the patient body type and weight.
Pressure Zone Indicators
Press the up arrows to increase pressure.
Press the down arrows to decrease pressure.
Pulsation / AP Therapy Button
Press to adjust intensity of pulsation therapy.
Pulsation / AP Cycle Time Button
Press to select the pulsation cycle time.
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com
