Specifications Description; Important Safety Instructions; Other Specifications - Sitecom APB-100 User Manual

EN - At a glance
Item Specifications
Power button
1
USB-C in / out Power in:
2
5 V 3 A (15 W max)
Power out:
5 V 3 A (15 W max)
USB-A out 1 Power out:
3
5 V 3 A (15 W max)
USB-A out 2 Power out:
4
5 V 3 A (15 W max)
Status lights LED lights
5

Other specifications

Internal battery type Rechargeable Li-ion Polymer
Capacity 10.000 mAh, 3.7 V, 37 Wh
Power input USB-C: 5 V 3 A (15 W max)
Power output USB-C: 5 V 3 A (15 W max)
USB-A 1: 5 V 3 A (15 W max)
USB-A 2: 5 V 3 A (15 W max)
USB-C + USB A 1 + USB-A 2 combined: 5 V 3 A (15 W max)
Charge time Charge the power bank to 100% in 4 hours at 15 W
Safety Overcharge, discharge, overload, short circuit, overcurrent and
overheat protection
Airplane safe Yes, UN38.3
Supported devices Charge USB-C and USB-A devices with an operating voltage of 5 V
direct current, like phones and tablets. To charge the powerbank
please use a 5 V / 3 A (max 15 W) charger.
Dimensions 135.5 x 69 x 16.9 mm
Weight 233 gram
Description
Press 1x to turn on. Press 2x to turn off.
To charge your powerbank, connect a wall
charger with a USB-C cable to the USB-C
port. (A)
To charge your device, connect the device with
a USB-C cable to the USB-C port. (B)
To charge your device, connect the device with
a USB-A cable to the USB-A port. (B)
To charge your device, connect the device with
a USB-A cable to the USB-A port. (B)
Status lights indicate the powerbank battery
level (0% to 100%). Below 5% the first LED
is flashing.
During charging 1 LED will flash depending on
the battery level.
When the battery is fully charged all LEDs are on.
They will turn off after 30 seconds.

Important safety instructions

• Do not throw, drop, shake and avoid strong blows and collisions
• Do not disassemble or modify
• Do not burn or incinerate
• Do not use near inflammable materials or explosive gases
• Do not expose to excessive heat or excessive cold
• Avoid abrupt changes in temperature
• Do not expose to liquids
• Do not use or store in damp, humid or wet environments
• Do not cover with objects which may affect heat dissipation
• Avoid contact with battery chemicals
• Disconnect when not in use, do not charge or discharge unattended
• Keep out of reach of children
Warranty 24 months warranty. Please note that your rights under national law
remain unaffected by this warranty.
Support Lifetime technical support
Website www.sitecom.com
Contact support@sitecom.com
