Melec GDB-5K60 Instruction Manual page 28

〔Motor output Connector〕
〈Connection〉 〈Insertion〉〈Wiring〉
DRIVER
Housing
for J3
J3
VIO
BLK 1 1
BLU
RED
GRN 2 2
GRY
BLK
ORN 3 3
YLW
WHT
RED 4 4
ORN
GRN
BLU 5 5
BRN
〈Connection〉 〈Insertion〉〈Wiring〉
DRIVER
Housing
for J3
J3
VIO
BLK 1 1
BLU
RED
GRN 2 2
GRY
BLK
ORN 3 3
YLW
WHT
RED 4 4
ORN
GRN
BLU 5 5
BRN
●The color indications for the motor crimping J3 represent color of the leads of
the motor.
●Use a cable of 5m or less for the motor cable .
〈Crimping〉
Contact
(0.5mm 2 or more，5m Max)
〈Crimping〉
Contact
(0.5mm 2 or more，5m Max)
-28-
Instructions Manual
Leads of the motor
Violet/Blue
Red/Gray
Black/Yellow
White/Orange
Green/Brown
Leads of the motor
Black
Green
Orange
Red
Blue
GDB-5K60
MOTOR
MOTOR
