３－５．Operating Section
(O N⇔OFF)
Name of Operating Section
MOTOR SELECT switch
4
PULSE INPUT TYPE
3
SELECT switch
HOLD SWITCHING TIME
2
SELECT switch
STEP TABLE switch
1
STEP ANGLE SELECT switch
HOLD CURRENT SELECT switch
DRIVE CURRENT SELECT switch
Function
Use it with OFF.
Select a pulse input type.
DRIVE/HOLD CURRENT automatic
switching time is selected.
Select STEP TABLE.
Select a step angle.
Select HOLD CURRENT.
Select DRIVE CURRENT.
-13-
GDB-5K60
Instructions Manual
Factory Setting
4:〔OFF〕
3:〔OFF(2P)〕
2:〔OFF(DH1)〕
1:〔OFF(S.T1)〕
〔No.1〕
〔No.8〕
〔No.D〕
