KATO – KATO SYNCRO³
MANUALE ISTRUZIONI
ATTUATORE A CATENA
IT
Forza 300N – Corsa massima 400 mm
Alimentazione elettrica 110-230V~ 50/60Hz e 24V
INSTRUCTION MANUAL
CHAIN ACTUATOR
EN
Force 300N – Maximum stroke 400 mm
Electrical feeding 110-230V~ 50/60Hz and 24V
BETRIEBSANLEITUNG
KETTENANTRIEB
DE
Kraft 300N – Maximalhub 400 mm
Spannungsversorgung 110-230V ~ 50/60Hz und 24V
NEKOS S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa – VI – ITALY
+39 0424 411011 –  +39 0424 411013 - www.nekos.it - info@nekos.it
4420001.1 - Rev 2012
USER INSTRUCTIONS
CAUTION.
Carefully
observe
instructions to ensure personal safety.
The device is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lacking
experience and knowledge. Do not allow children to play with the
fixed controls and keep any remote-control units out of their reach.
Have installation checks performed periodically by qualified
personnel from a service centre authorised by the manufacturer.
Do not use if repair or adjustment is required.
CAUTION: if the power cable is damaged, it must be replaced by
qualified personnel from a service centre authorised by the
manufacturer.
CAUTION. Disconnect the power supply during cleaning or
maintenance operations. Do not use solvents or jets of water to
wash the appliance; the appliance should not be submerged in
water.
In the event of fault or malfunction, switch off the device at the
main switch. All repairs and adjustments (e.g. setting the stroke)
must only be performed by qualified personnel from a service
centre authorised by the manufacturer.
Always request exclusive use of original spare parts. Failure to
respect this condition could compromise safety and invalidate the
benefits contained in the warranty for the appliance. In the event of
any problems or queries, consult your agent or contact the
manufacturer directly.
The A-weighted sound pressure level is less than 70dB(A).
Carefully preserve these instructions after installation.
all
the
following
installation
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KATO and is the answer not in the manual?

Questions and answers

Related Manuals for nekos KATO

Summary of Contents for nekos KATO

  • Page 1 The A-weighted sound pressure level is less than 70dB(A). Carefully preserve these instructions after installation. NEKOS S.r.l. - Via Capitoni, 7/5 - 36064 Colceresa – VI – ITALY +39 0424 411011 –  +39 0424 411013 - www.nekos.it - info@nekos.it...

  • Page 2: Table Of Contents

    MANDATORY RISK ANALYSIS AND PROTECTION MEASURES conforms to the stipulations of current standards in force. The Nekos electrical actuators comply with the Machinery Directive (2006/42/EC), Standard IEC When correctly assembled, installed and used according to the present instructions, they 60335-2-103 (Particular requirements for drives for gates, doors and windows) and other will not generate any danger for persons, animals or items.

  • Page 3: Technical Information About Function

    Windows can be programmed to open and the device Top hung windows opening outwards with horizontal assembly allows chain opening at 110, 200, 300 and 400 mm for Kato, 100, 200 and 400 mm for Kato Bottom hung windows (motor on frame)

  • Page 4: Technical Data

    The KATO and KATO SYNCRO³ actuators are commercially available in four versions: IMPORTANT. The Syncro³ version of the actuator is packed in a cardboard box with 1. KATO 230V: runs on grid tension of 230V~ 50/60Hz, with a three wire cable (L IGHT two units and all accessories needed and is shipped already tested.

  • Page 5: Instructions For Assembly

    A. Pencil in an “X” over the centre line of the window frame (Fig. 2) or fairly divide it in case Check that the electrical supply used corresponds to the indications on the of use of more Kato Syncro “TECHNICAL DATA” label attached to the machine and that the given temperature B.

  • Page 6: Electrical Connections

    N. On re-entry the actuator limit switch functions automatically. The device exerts a traction 10. ELECTRICAL CONNECTIONS force to guarantee perfect sealing up of the weather strips. 10.1. Connections of Kato (+ optional BK-Lock electro lock) 9.4. Vertical assembly of the actuator on outward opening window The actuator comes with a 2 m long circa (±5%) lead which has been calculated in...

  • Page 7: Programming The Limit Switches

    Check that attachments and support brackets are firmly fixed to the window frame and that all screws have been correctly tightened. 11.2. Luminous indications on led (only for Kato 230V) Before activating the actuator, familiarise yourself with messages indicated by the red led opposite the lead.
  • Page 8 No. 3 No. 4 With electromechanical lock 11.6. Light signals of the LED (for Kato Syncro³) Without electromechanical lock In case of a problem during installation or operation of the machines, consult the possible  Power the machine in any direction: the machine automatically moves the chain in the...

  • Page 9: Checking For Correct Assembly

    12. CHECKING FOR CORRECT ASSEMBLY 15. ENVIRONMENTAL PROTECTION  Check that the window has closed completely, even at the corners, and check there are All materials used in the manufacture of this appliance are recyclable. We recommend that the device itself, and any accessories, packaging, etc. be sent to a no obstacles caused by assembly in the wrong position.

  • Page 10: Declaration Of Incorporation (For A Partly Completed Machine) And Ec Declaration Of Conformity

    KATO SYNCRO - KATO 305 SYNCRO INKA 356 - INKA 356 SYNCRO Type : 24 V : KATO 253 - KATO - KIMO - KATO 305 KATO SYNCRO - KATO 305 SYNCRO INKA 356 - INKA 356 SYNCRO Year of manufacturing from: 2017 Fulfil the essential requirements of the Machinery Directive 2006/42/EC, Annex I, Art.
