Cargo Bed Spacer Kit
Workman
Model No. 163-5055
Safety
Safety-Alert Symbol
The safety-alert symbol
manual and on the machine identifies important safety
messages that you must follow to prevent accidents.
Safety-alert symbol
The safety-alert symbol appears above information
that alerts you to unsafe actions or situations and
is followed by the word DANGER, WARNING, or
CAUTION.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious
injury.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
This manual uses two other words to highlight
information. Important calls attention to special
mechanical information and Note emphasizes general
information worthy of special attention.
© 2024—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
MDX Utility Vehicle
(Figure
1) shown in this
Figure 1
Register at www.Toro.com.
g000502
Original Instructions (EN)
Form No. 3472-598 Rev A
Installation Instructions
*3472-598*
Printed in the USA
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Toro 163-5055
Summary of Contents for Toro 163-5055
- Page 1 Form No. 3472-598 Rev A Cargo Bed Spacer Kit Workman ® MDX Utility Vehicle Model No. 163-5055 Installation Instructions Safety Safety-Alert Symbol The safety-alert symbol (Figure 1) shown in this manual and on the machine identifies important safety messages that you must follow to prevent accidents.
-
Page 2: Installation
Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty. – No parts required Prepare the machine. – No parts required Disconnect the battery. – No parts required Remove the cargo bed. Front tube frame Right bed spacer assembly Left bed spacer assembly... -
Page 3: Disconnecting The Battery
WARNING Battery terminals or metal tools could short against metal machine components, causing sparks. Sparks can cause the battery gasses Disconnecting the Battery to explode, resulting in personal injury. • When removing or installing the battery, No Parts Required do not allow the battery terminals to touch any metal parts of the machine. - Page 4 Removing the Cargo Bed No Parts Required For Machines with a Manual Cargo Bed Lift Cargo box weight: approximately 57 kg (126 lb) Lift the latch lever on either side of the machine g025013 (near the forward corner of the cargo bed) and Figure 5 fully raise the bed (Figure...
- Page 5 Lift the cargo bed up and off the machine (Figure g226635 Figure 7 g226666 Figure 8 For Machines with an Electric 1. Locknut (1/2 inch) 4. Lift actuator rod Cargo Bed Lift 2. Hex-head bolt (1/2 x 5-1/2 5. Clevis pin (3-1/2 inches) inches) Remove the hex-head bolt (1/2 x 5-1/2 inches) 3.
- Page 6 Place the front tube frame flush with the forward edge of the bed frame assembly. Connect the right bed spacer assembly to the front tube frame with a bolt and to the bed frame Installing the Bed Spacers assembly with a carriage bolt as shown in Figure Parts needed for this procedure: Front tube frame...
- Page 7 Installing the Cargo Bed No Parts Required For Machines with a Manual Cargo Bed Lift Rotate the cargo bed so that the hinge-bracket assembly and prop rod are facing downward (Figure 12). Using lifting equipment at the front and rear of the cargo bed, raise the cargo bed, and align it over the frame of the machine with the g227146...
- Page 8 For Machines with an Electric Cargo Bed Lift Rotate the cargo bed so that the hinge-bracket assembly and prop rod are facing downward (Figure 12). Using lifting equipment at the front and rear of the cargo bed, raise the cargo bed, and align it over the frame of the machine with the hinge-bracket assembly facing rearward (Figure...
-
Page 9: Connecting The Battery
Connecting the Battery No Parts Required Procedure Connect the positive battery cable to the positive battery terminal (Figure Connect the negative battery cable to the negative battery terminal (Figure Install the battery cover onto the top of the battery (Figure... - Page 10 Notes:...
- Page 11 Notes:...
