C R T T E L E V I S I O N
START
GUIDE
www.rca.com/television
Jacks
COMPONENT
(CVID) INPUT
P
P
Y
r
b
R-AUDIO-L
R-AUDIO-L
VIDEO
COMPOSITE (VID) INPUT
Remember: The Component (CVID) and the Composite jacks (VID) share the R/L Audio jacks shown above.
Note: If you're not getting a picture while using the component connection (above), check the connected device (for example,
a Progressive Scan DVD player). You need to change the setting on the device from progressive to interlaced (480i). Refer to
the User's Guide for more information.
OUT TO TV
Cable Box, Satellite
Receiver, or Wall Outlet
-OR-
ANTENNA/CABLE
INPUT
DIGITAL/ANALOG
TV
(Back Panel)
We help improve our environment by printing only this one page of instructions. The complete User's Guide is available at the support section on
www.rca.com/television.
Español- Ayudamos a mejorar nuestro ambiente imprimiendo sólo esta página de instrucciones. La Guía de Inicio Rápido en Español y la Guía del
Usuario completa se encuentran disponibles en la sección de soporte en www.rca.com/television.
Français- Nous aidons à améliorer l'environnement en imprimant cette seule page d'instructions. Le Guide de démarrage rapide et le Guide de
l'utilisateur sont disponibles en Français dans la section du soutien, sur le site Web www.rca.com/television.
Choose Your Connections
Make your connection decision easier by taking a few minutes to review the jacks on your
new TV. Compare the jacks on the device you want to connect and see if the same jacks
are available on your TV. Then refer to the chart below to determine the best connection to
make.
For more information about connecting your TV to other devices, refer to the User's Guide
that can be found in the support section on www.rca.com/television. Make sure you read the
safety information provided separately before you connect and operate your TV.
Quality
Connects to...
Devices with Y Pb Pr
(component) outputs, such as,
HD Receivers, Satellite
Receivers, Cable Boxes, DVRs,
and DVD Players
Devices with Video (composite)
outputs, such as DVD Players,
VCRs, Satellite Receivers,
Cable Boxes, Camcorders, and
Digital Cameras
Connect a Signal Source
or
Indoor Antenna
Outdoor Antenna
ANTENNA/CABLE
INPUT
DIGITAL/ANALOG
TV
(Back Panel)
Cables needed
Connect your TV to cable; a cable box or satellite
receiver; or an antenna in order to receive TV
channels. Connect the cables as shown in the first
or second connection.
If you're connecting a cable box or satellite
receiver and it has Component jacks (Y Pb Pr),
connect the cable box or satellite receiver to your
TV using the Component jacks (CVID) for a better
connection.
Continue to Step 2, Set Up Your TV, on the back
page.
(not included)
Component
Video
Audio
Video
Audio
