New Classic Furniture JAMESTOWN B2118-110 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with the
PARTS LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person: this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently
PARTS LIST
NO: COMPONENT
A
Headboard
B
Footboard
C
Side Rail
D
Headboard Crossbar
HB Left side facing
E
(LSF) Leg
HB Right side facing
F
(RSF) Leg
G Roll out slats
H
Support Legs
I
Side Rail Cap
Assembly Instructions
B2118-110
B2118-128
B2118-238
SKETCH Q'TY
1PC
1PC
2PCS
1PC
1PC
1PC
1SET
8PCS
2PCS
MADE IN VIETNAM
JAMESTOWN 6"6"/6"0" K HEADBOARD
JAMESTOWN 6"6"/6"0" K STORAGE FOOTBOARD & SLATS
JAMESTOWN 6/0 WK STG BED RAILS
HARDWARE LIST
NO: COMPONENT
1
Bolt 5/16" x 1-3/4"
2
Bolt 5/16" x 3-1/2"
3
Flat Washer 5/16"*3/4"
4
Lock Washer 5/16"
5
Half Moon Washear 5/16"
6
Nut (5/16")
7
Screw: #8*1-1/4"
8 Allen key
9
Open Wrench 5/16"
10
Bolt 1/4" x 2"
11
Lock Washer 1/4"
12
Flat Washer 1/4"*1/2"
SKETCH Q'TY
8pcs
8pcs
8pcs
16pcs
8pcs
8pcs
26pcs
2pcs
1pc
10pcs
10pcs
10pcs
PAGE: 1 of 4
