Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown below.
Please read all instructions carefully. See the hardware and furniture part listing for guidance. Be sure you have
all parts listed before beginning assembly. Place all wooden parts on a clean, flat surface to protect the finish
from scratches. Follow the diagram to assemble.
CAUTION
1. Do not fully tighten the nuts or bolts until the table is fully assembled.
2. Please tighten by hand, not by a drill. Overtightening will damage threads. Do not overtighten.
3. Keep all hardware out of the reach of childen.
PARTS LIST
ITEM
DESCRIPTION
A
HEADBOARD
RIGHT SIDE FACING
B
(RSF) HEADBOARD LEG
LEFT SIDE FICING
C
(LSF)HEADBOARD LEG
FOOTBOARD
D
RIGHT SIDE FACING
E
(RSF)FOOTBOARD LEG
LEFT SIDE FACING
F
(LSF)FOOTBOARD LEG
G
SIDE RAIL
SLAT
H
SUPPORT LEG
I
WITH ADJUSTABLE FEET
J
PLUG
HEADBOARD
K
SUPPORT RAIL
HARDWARE DIMENSIONS
VERIFICATION TOOL
ASSEMBLY INSTRUCTION
EMPIRE COLLECTION
B2034-115 EMPIRE 6/6 EK HB,FB, & SLATS
B2034-335 EMPIRE 6/6-5/0 EK/Q SIDE RAILS
QTY
SKETCH
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
2 PCS
4 PCS
8 PCS
1 PC
1 PC
1
inches
HARDWARE LIST
ITEM
DESCRIPTION
BOLT M8 x
3
"
1
4
2
BOLT M6 x
5
"
8
3
3
BOLT M6 x 1
"
8
BOLT M6 x 2
"
4
5
SPRING WASHER M6 x
6
FLAT WASHER M6 x
7
CSK C/B SCREW M4 x 1
8
ALLEN KEY M4 x 4 "
1
9
ALLEN KEY M5 x 2
2
2
SKETCH
8 PCS
4 PCS
10 PCS
6 PCS
1
"
8 PCS
2
3
"
8 PCS
4
1
"
8 PCS
4
1 PC
"
1 PC
3
4
MADE IN MALAYSIA
PAGE 1 OF 4
QTY
Advertisement
Related Manuals for New Classic Furniture EMPIRE B2034-115
Summary of Contents for New Classic Furniture EMPIRE B2034-115
- Page 1 ASSEMBLY INSTRUCTION EMPIRE COLLECTION B2034-115 EMPIRE 6/6 EK HB,FB, & SLATS B2034-335 EMPIRE 6/6-5/0 EK/Q SIDE RAILS Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list shown below.
- Page 2 STEP 1: Place the Headboard (A) face down on a soft and clean area. Attach RSF Headboard leg (B) and LSF Headboard leg (C) to the Headboard (A) by using Allen Key (8) with hardware 4, 5, and 6. BACK VIEW STEP 2: Attach Headboard Support Rail (K) to the RSF Headboard leg (B) and RSF Headboard leg (C) by using Allen Key (8) with hardware 3, 5, and 6.
- Page 3 STEP 3: Place the Footboard (D) upside down. Attache the RSF Footboard leg (E) and LSF Footboard leg (F) to the Footboard (D) by using Allen key (8) with hardware 2. STEP 4: Attach the Side Rails (G) to the Headboard Legs (B & C) and to the Footboard (D) by using the Allen Key (9) with hardware 1.
- Page 4 STEP 5: Assemble the Slat Support Leg (I) to the Slat (H) by using Allen Key (8) with hardware 3. Repeat for each slat. STEP 6: Assemble the Slats (H) to the Side Rails (G) by using a screwdriver with hardware (7). Adjust leveling feet (I) to touch floor.
