- Page 1 Installation Guide Power-D-Box redundant 2 x 232 A – 2 x 5 Load Circuits 19BGT-2-X8345-10R4-B0-S370...
- Page 2 CAUTIONS PDU must be located in restricted access locations only. • PDU is intended to be used in a redundant distribution system where power under normal operation is distributed at 50 % • through each side of the panel. In the event of a single source power loss, the unit is designed to be able to carry 100 % of the load through one side of the panel.
- Page 3 Power-D-Box Features 19” Power distribution unit for 10 pcs. hydraulic-magnetic circuit breakers type 8345-C01A-W0M1-DB1B2B-xA. • 2U chassis with anodized front plate. • Redundant setup with 2 x 5 load circuits in two groups A and B. • Supply feeds through rear screw terminals 35 to 95 mm² (AWG 2 to AWG 4/0). •...
-
Page 4: Wiring Diagram
Grounding Bridge enabled (Condition as delivered) Grounding Bridge disabled Fig. 3 Plus Pole Grounding Bridge Wiring Diagram Fig. 4 - Wiring Diagram 2 x 5 Load Circuits... -
Page 5: Specifications
Specifications Electrical Data Nominal Voltage Max. DC 80 V Max. Supply Current 232 A per group Protected Pole Negative Pole Protected Redundant System Dual Feed A and B or Single Feed A or B 0,1 100 A max. (channel 1 Load Current per Channel 32 A max. - Page 6 Notes...
- Page 7 Notes...
- Page 8 E-T-A Elektrotechnische Apparate GmbH Industriestrasse 2-8 — D-90518 ALTDORF GERMANY Phone: +49 9187 10-0 — Fax. +49 9187 10-397 E-Mail: info@e-t-a.de — www.e-t-a.com/e S370_Install Guide_short_120622_ia.doc...
