E-T-A Power-D-Box 19BGT-2-X8345-12R4SW-B0-S189 Installation Manual

Redundant 2 x 190 a - 2 x 6 load circuits
Hide thumbs

Advertisement

Table of Contents

Installation Guide
Power-D-Box redundant 2 x 190 A – 2 x 6 Load Circuits
19BGT-2-X8345-12R4SW-B0-S189

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power-D-Box 19BGT-2-X8345-12R4SW-B0-S189 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for E-T-A Power-D-Box 19BGT-2-X8345-12R4SW-B0-S189

Summary of Contents for E-T-A Power-D-Box 19BGT-2-X8345-12R4SW-B0-S189

  • Page 1 Installation Guide Power-D-Box redundant 2 x 190 A – 2 x 6 Load Circuits 19BGT-2-X8345-12R4SW-B0-S189...
  • Page 2 CAUTION! • PDU must be located in restricted access locations only. • PDU is intended to be used in a redundant distribution system where power under normal operation is distributed at 50 % through each side of the panel. In the event of a single source power loss, the unit is designed to be able to carry 100 % of the load through one side of the panel.

  • Page 3: Product Specifications

    230 A Max. Load Current per Channel 40 A Number of Circuit Breakers 2 x 6 Redundant System Circuit Breakers E-T-A Type 8345-C01A-W0xx-D…B-xA Operating Ambient Temperature 0 °C…+60 °C Storage Temperature -20 °C...+70 °C Mechanical Data Height: 88,9 mm Dimensions Width: 482,6 mm (19“) 531,4 mm (ETSI)

  • Page 4: Product Description

    1. Product Description The Power Distribution System Power-D-Box 19BGT-2-X8345-12R4SW-B0-S189 is a 2U 19” rack-mount panel, • equipped with two internal Power Distribution Units type X8345-D01. • The internal Power Distribution Units type X8345-D01 are set up in a 2 x 6 load channel redundant configuration and positioned to the left and right within the Power-D-Box housing.
  • Page 5 2. Principle Wiring Diagram Terminals for supply Integrated PDU X8345-D01L6… Integrated PDU X8345- Terminals for supply cables 95 mm², 1,5 m cables 95 mm², 1,5 m (factory dressed and (factory dressed and Plug type circuit breakers preinstalled) preinstalled) 8345-C01A-W0xx-D…B-xA 6² BK Load connections via lead through terminals 10 mm²...
  • Page 6 3. Illustrations Group B (+) load return, rear row terminals Group A (+) load return, rear row terminals Group A (-) loads protected pole, front row terminals Group B (-) loads protected pole, front row terminals Fig. 2 - Top view Plastic snap-in blanking covers Front plate quick release fastener Reversible mounting bracket...

  • Page 7: Rack Installation

    4. Rack Installation • Reversible mounting brackets are supplied with the unit and may be used interchangeably for 19” and ETSI rack installation (condition as delivered = 19” setup). • Slide the unit into the designated rack slot and use the four supplied M6 cross-head screws to attach the unit. •...
  • Page 8 531,4 mm (ETSI) 482,6 mm (19”) Front plate quick release fastener (Lift to open) Fig. 6 - Front plate (Front view)
  • Page 9 5. Connections NOTE: Any wiring-, connection- or installation-work shall be conducted only while the unit is disconnected from the power supply. 5.1 Supply Feed Connections • Supply connection through four sets of factory dressed and preinstalled 95 mm² / 150 cm cables. •...

  • Page 10: Load Connections

    5.2 Load Connections • This Power-D-Box is designed with 12 load terminals, where the load cables are fed into the top of the unit. Each terminal serves as an output from a breaker. • The terminals that connect to the loads are marked as A1 through A6 for group A and as B1 through B6 for group B. The alpha digit indicates the group/side and the numeric digit indicates the channel number from which breaker output the line originates.
  • Page 11 6. Circuit Breaker Removal and Insertion 6.1 Circuit Breaker Removal CAUTION! The circuit breakers are of a plug-type design with hot-swap capability. Do not remove a breaker in reset (‘ON’) position. Doing so may damage breaker or the entire unit. To switch off a circuit breaker, use the toggle switch and toggle down the actuator to its ‘OFF’...

  • Page 12: Important Note

    6.2 Circuit Breaker Insertion CAUTION! The circuit breakers are of a plug-type design with hot-swap capability. Do not insert a breaker in reset (‘ON’) position. Doing so may damage breaker or the entire unit. To switch off a circuit breaker, use the toggle switch and toggle down the actuator to its ‘OFF’...
  • Page 13 E-T-A Elektrotechnische Apparate GmbH Industriestrasse 2-8 · D-90518 ALTDORF GERMANY Phone: +49 9187 10-0 · Fax. +49 9187 10-397 E-Mail: info@e-t-a.de · www.e-t-a.com/e S189_Install Guide_120712_ie.doc -13-...
