  • Page 1 Installation Guide G2H95A (19BGT-2-X8345-16R4SW-B0-S541)
  • Page 2 CAUTION!  The Equipment must be located in restricted access locations only.  A readily accessible disconnect device shall be incorporated in the building installation wiring. If more than one disconnect device is used, marking shall be provided to properly indicate total power disconnection. ...

  • Page 3: Product Specifications

    1. Product Specifications Electrical Data Nominal Operating Voltage Max. DC 80 V per group Protected Pole Negative pole protected Supply Current per Group Max. 232 A (UL60950-1 Max. 230 A per group) Load Current per Channel Max. 85 A for channels 1-3 and max. 30 A for channels 4-8 each group Number of Circuit Breakers 2 x 8 pcs.

  • Page 4: Product Description

    2. Product Description  19”, 2U Power Distribution System consisting of two aluminium 2U power distribution units.  Designed for power distribution cabinet installation.  Redundant setup with 2 x 8 load outputs in groups A and B.  Fits plug-in type hydraulic-magnetic circuit breakers type 8345-C01A-W0M1-DB1B2B-xxA rated 0,1 A ...80 A ...
  • Page 5 3. Principle Wiring Diagram Supply line minus Screw terminals 95 mm , max. 232 A (UL 230 A) Fig. 1- Principle wiring diagram 4. Illustrations Captive screws Circuit breaker removal tool (stored on the reverse side of the front panel) Additional type label on the reverse side of the front panel Labelling strip for custom labels Fig.
  • Page 6 As an alternative mounting option for system extensions and easy terminal access, the upper PDB’s mounting brackets may be reversed as shown in fig. 3. Upper PDB with reversed mounting brackets Lower PDB with level mounting brackets Fig. 3 - Upper PDB with mounting brackets reversed 5.
  • Page 7 6. Condition as Delivered A Grounding Bridge for each group provides positive supply to earth connection. Condition as delivered: Plus pole not grounded (open). Bridge connected, plus pole grounded Bridge not connected, plus pole not grounded Fig. 5 - Plus pole grounded (Group A) Fig.
  • Page 8 This installation manual reflects the current technical specifications at time of print. We reserve the right to change the technical or physical specifications. E-T-A Elektrotechnische Apparate GmbH Industriestraße 2-8 · D-90518...
