Power Tech Generators PTSG-12 Operator's Manual page 6

DESCRIPTION
1. END COVER
2. EXCITER ROTOR
3. EXCITER STATOR
4. REAR HOUSING BRACKET
5. ROTOR BEARING
6. MAIN STATOR ASSEMBLY**
7. MAIN ROTOR ASSEMBLY
GENERATOR ASSEMBLY
VOLTAGE REGULATOR
**NOTE: Item #6 MAIN STATOR ASSEMBLY is a one-piece unit. The Stator cannot be separated from the Generator's outer housing.
NS-GENCAN
02RTR1520EXC
02STA1520EXCG
02HB15TCGE
02BRG207
02STMN15
02RTRMN15
02GEN15TCGE
06REG634AVC
"M" SERIES EXCITER TYPE GENERATOR ASSEMBLY
PART NUMBER
15KW 17.5KW
NS-GENCAN
02RTR1520EXC
02STA1520EXCG
02HB175
02BRG207
02STMN175
02RTRMN175
02GEN175TCGE
06REG634AVC
20KW
NS-GENCAN
02RTR1520EXC
02STA1520EXCG
02HB15TCGE
02BRG207
02STMN20
02RTRMN20
02GEN20TCGE
06REG634AVC
