Supported VGA/DVI input signal timing

Resolution
720 x 400 31.467
640 x 480 31.469
640 x 480 37.861
640 x 480 37.5
800 x 600 37.9
800 x 600 48.077
800 x 600 46.875
1024 x 768 48.363
1024 x 768 56.476
1024 x 768 60.023
1360 x 768 47.7

Supported Component/HDMI input signal timing

Resolution
720 x 480i (not 15.73
available for DVI
input)
720 x 576i (not 15.62
available for DVI
input)
720 x 480p 31.47
720 x 576p 31.25
1280 x 720p@59 44.955
1280 x 720p@60 45
1280 x 720p@50 37.5
1920 x 1080i@50 28.13
1920 x 1080i@59 33.716
1920 x 1080i@60 33.75
• PC (VGA/DVI) and Video (Component/HDMI) timing modes outside of these tables are not
recognised and will may not be displayed properly.
• When viewing VGA input on the TV, you should select 1360 x 768 @60Hz as your PC VGA
source resolution to gain the best quality image.
• If the picture contains movement or character shimmering when the signal timing is changed,
activate the 'Auto' function in the Setup menu to recalibrate the image. See
installation" on page
Horizontal
Frequency (Khz)
Horizontal
Frequency (Khz)
27.
Vertical
Frequency (Hz)
70.082 28.32
59.94 25.175
72.819 31.5
75 31.5
60.317 40
72.188 50
75 49.5
60 65
70.069 75
75.029 78.75
60 85.5
Vertical
Frequency (Hz)
59.94 13.5
50 13.5
59.94 27
50 27
59.94 74.176
60 74.25
50 74.25
50 74.25
59.94 74.176
60 74.25
Dot Clock
Frequency (Mhz)
Dot Clock
Frequency (Mhz)
"Performing Auto
Reference
Note
VGA
VGA
VGA
VGA
SVGA
SVGA
SVGA
XGA
XGA
XGA
WXGA
Note
Interlaced
Interlaced
Progressive
Progressive
Progressive
Progressive
Progressive
Interlaced
Interlaced
Interlaced
33
